Memphis ELITE VG0002 Manual de usuario

CONTENTS

Clearance to Combustibles

Wiring Diagram

3-4

MEMPHIS ELITE

MODEL NUMBER

VG0002/VG0002E/VG0002S4/VG00002S4-3

YOUR MEMPHIS GRILL MUST MAINTAIN THE

SPECIFIED CLEARANCE TO COMBUSTIBLE

MATERIALS WHILE OPERATING THE GRILL

OR WHILE THE GRILL IS HOT!

Below are some guidelines to ensure safe

operation of your Memphis Grill

The grill is to be supported by the casters provided.

Grill casters are to be locked while the grill is in

use or while the grill is hot.

It is recommended that the grill be placed on a

non-combustible surface.

Operating the grill under a combustible ceiling or

overhang is NOT recommended.

Maintain the minimum clearance to combustible

materials specified below.

A MAJOR CAUSE OF FIRES IS

FAILURE TO MAINTAIN REQUIRED

CLEARANCES (AIR SPACES) TO

COMBUSTIBLE MATERIALS. IT IS OF

THE UTMOST IMPORTANCE THAT

THIS PRODUCT BE INSTALLED ONLY

IN ACCORDANCE WITH THESE

INSTRUCTIONS

CLEARANCE TO

COMBUSTIBLE MATERIALS

Item #

NAME

DESCRIPTION

USB Port

Used to update your grill, see the “Updating Controller Software” section of the

main manual for information.

Meat Probe Wiring

This terminal is used to connect the meat probes to the controller.

120/240 Select Jumper

Used when changing the input voltage to the controller, see “120v to 240v

Conversion” section of the main manual for information.

AC Load Wire from Filter to

Controller

Carries AC voltage from the filter to the control board, load wire.

AC Neutral Wire from Filter to

Controller

Carries AC voltage from the filter to the control board, neutral wire.

Filter

Reduces electrical feedback. Line = Outlet Side, Load = Grill Side. L1 = Load L2=

Neutral

AC Neutral and Load from IEC to

Filter

A two wire component which has a ferrite choke to eliminate input electrical

disturbances from the grid. Load and Neutral wires.

IEC Plug

The same plug terminal used to attach your power cord to your grill. Top down view.

Ethernet Cable

Used to connect your grill controller to the Wi-Fi card in the back of the grill.

Grounding Wire

In the event your grill experiences a short, the grounding wire will send the voltage

to the 3rd prong of a standard AC outlet.

AC Component Wiring

This large plastic connector carries all voltage used for AC components in the grill.

See “Component Wiring Diagram” for a description of all wires in this connector.

RTD Wiring (DC)

This small plastic connector carries DC voltage to the RTD.

Controller Box Ethernet Cable

Gland

This gland is a weather tight pass-through for the Ethernet cable into the back of

the controller box.

Controller Box Plug

This plug is a weather tight quick disconnect for the main wiring harness which

carries all AC,DC, and Ground wires to the grill’s components.

MEMPHIS ELITE CONTROLLER

BOX WIRING DIAGRAM

LOAD

NEUTRAL

GROUND

Item #

NAME

Wire Identification

DESCRIPTION / INSTRUCTION

Auger Motor

Wiring

1x Black Wire, 1x White Wire

Attach both spade connectors to their respective terminals on the

top of the auger motor as indicated by the arrows shown above.

RTD Wiring

1x Orange Wire, 1x Brown Wire

Attach both spade connectors to the leads extending from the RTD

as shown above.

Grounding Wire

Green Wire

The connection point for the ground is located directly below the

auger motor on the vertical panel behind the auger motor.

Ethernet Cable

Black Cable with Ethernet End

Attach the Ethernet cable to the terminal on the Wi-Fi card as

shown. Ensure that the wiring does not interfere with the auger

motor’s moving components.

Igniter Wiring

1x Red Wire, 1x White Wire

Attach both spade connectors to the leads extending from the

igniter. These leads will extend from the airbox and can be located

in between the two fans.

Fan Wiring

1x Blue Wire w/ 2 spade ends,

1x White Wire w/ 2 spade ends

Attach BOTH blue spade connectors to 1 fan and then attach the red

spade connectors to the other fan.

MEMPHIS ELITE COMPONENT

WIRING DIAGRAM

NOTE: ALL TWO WIRE PAIRS FOR A SPECIFIC COMPONENT ARE REVERSABLE

Example: The auger motor wiring can have the either spade connector from

its two wire pair attached to either terminal and the motor will function

normally.

RTD

Auger Motor

Igniter

Wi-Fi Card

Fans
