MELICONI Speedy Instrucciones de funcionamiento

Thank you for choosing Meliconi.

This simplified universal remote control contains all the main

functions of most TV remote controls of the brands listed

on the back.

Keep your Instructions and Code Booklet for future

reference.

USING THE KEYS AND FUNCTIONS

GB Use

To select the next

programme or to turn

ON your TV.

Mute key.

Control the volume

using +/-.

ON/OFF to turn OFF

your TV and, in

some cases, to turn

ON your TV.

To select the

previous programme

or to turn ON

your TV.

Press them together to

turn ON your TV on

programme 1.

To select an

external terminal.

FITTING THE BATTERIES

Before programming and using the

remote control, insert batteries.

The remote control requires 2 new

AAA/LR03 alkaline batteries.

Insert the batteries as shown:

•

Batteries must be changed once a year.

•

Change the batteries if the light indicator starts to flash during use.

The batteries are low.

•

When removing batteries, insert the new ones within 5 minutes or

you may have to reprogram your remote control.

•

Make a note of the code for your TV on the adhesive label supplied

inside the battery compartment cover. This note will be handy if you

have to reprogram your remote control.

1.Find the code for your TV in

the code list (see middle of

this booklet) . Make a note

of the code found. It has 4

+and -signs, indicated to

the side (e.g. Thomson - +

- +).

2.Make sure that the TV is ON.

3.Hold down the and

keys simultaneously until

the light indicator at the top

starts to flash indicating

that the remote control is

in programming mode.

4.Release the keys. Within 12

seconds, enter the brand

code previously identified

(e.g. - + - +).

5.Point the remote control at

the TV. Press and release

the key slowly several

times. STOP when your TV

goes OFF.

6.When your TV is OFF, press

the and keys

simultaneously. When you

release the keys, three

flashes indicate that the

search operation has been

completed correctly.

SET-UP

Read these instructions carefully before programming

your remote control!

Once you have programmed Speedy, you can turn ON your

TV in three ways:

•Press or .

•Press and simultaneously: this sends the code

for programme 1.

•Press .

To program Meliconi Speedy remote control, follow the

indications in paragraph Aor B.

BRAND SEARCH PROGRAMMING

MODE

IF YOU DO NOT HAVE THE

PROGRAMME SELECTION

KEYS ON YOUR ORIGINAL

REMOTE CONTROL

If your remote control does

not have the programme

selection keys (e.g. / ,

+/-, CH+/-..etc) once you

have programmed Speedy,

you can still select the

programmes from 0 to 9, as

follows:

•Hold down the and

keys simultaneously until

the light indicator starts to

flash indicating that the

remote control is in

programming mode.

•Release the keys and

press 8 times within

12 seconds.

Three flashes indicate that

the operation has been

completed correctly.

•Make sure you can change

programmes from 0 to 9

using the and keys.

If not, repeat the search

operation, starting from

point 3.

NOTE:

When – is indicated, you must press or .

When +is indicated, you must press or .

To return to programme 1 directly, press and simultaneously.

1.Make sure that the TV is

ON.

2.Hold down the and

keys simultaneously until

the light indicator at the top

starts to flash indicating

that the remote control is

in programming mode.

3.Release the keys, point the

remote control at your TV

and press and release the

key, slowly several

times. STOP when your TV

goes OFF.

4.When your TV is OFF,

press the and keys

simultaneously. When you

release the keys, three

flashes indicate that the

search operation has been

completed correctly.

IF YOU DO NOT HAVE THE

PROGRAMME SELECTION

KEYS ON YOUR ORIGINAL

REMOTE CONTROL

If your original remote

control does not have the

programme selection keys

This operation may take a few minutes.

Identify and take note of the TV code which you have

searched for, following the code noting procedure

(see "PROGRAMMED CODE NOTING" section).

NOTE:

DURING THE SEARCH OPERATION, THE LIGHT INDICATOR

FLASHES MORE QUICKLY.

THE LIGHT INDICATOR STOPS FLASHING.

The remote control leaves the programming mode and the

light indicator stops flashing:

•

if no keys are pressed for 12 seconds

•

if an invalid brand code is entered

•

if you press keys other than those indicated

•

if the code search list is completed.

In this case, switch to programming mode B.

(e.g. / , +/-, CH+/-

..etc), once you have

programmed Speedy,

you can still select the

programmes from 0 to 9,

as follows:

•Hold down the and

keys simultaneously until

the light indicator at the top

starts to flash indicating

that the remote control is

in programming mode.

•Release the keys and

press 8 times within

12 seconds.

Three flashes indicate that

the operation has been

completed correctly.

•Make sure you can change

programmes from 0 to 9

using the and keys.

If not, repeat the search

operation, starting from

point 2.

GLOBAL SEARCH REMOTE CONTROL

PROGRAMMING

Additional check

Check that all 7 keys are operating correctly. If the

commands work incorrectly or erratically, you have probably

entered a code for a similar but different remote control.

In this case, repeat the search procedure from point 3 until

all keys respond correctly to the commands sent.

If you cannot find the right code after several attempts,

switch to programming mode B.

Additional check

Check that all 7 keys are operating correctly. If the

commands work incorrectly or erratically, you have probably

entered a code for a similar but different remote control.

In this case, repeat the search procedure from point 2 until all

the keys respond correctly to the commands sent.

NOTE:

DURING THE SEARCH OPERATION, THE LIGHT INDICATOR

FLASHES MORE QUICKLY.

THE LIGHT INDICATOR STOPS FLASHING

The remote control leaves the programming mode and the

light indicator stops flashing:

•if no keys are pressed for 12 seconds

•if you press keys other than those indicated

•if the code search list is completed. In this case, visit

www.meliconi.it or contact the call center.

Identify and take note of the TV code which you have

searched for, following the code noting procedure

(see "PROGRAMMED CODE NOTING" section).

RE-PROGRAMMING YOUR REMOTE CONTROL

BY ENTERING THE CODE NOTED DOWN

If the remote control is no longer programmed because it has

been left without batteries for a long time or has flat batteries,

you can re-program it quickly as follows:

1.Hold down the and keys simultaneously until the

light indicator at the top starts to flash indicating that the

remote control is programming.

2.Release the keys and, within 12 seconds, using the

and keys, enter the eight-sign code which you noted

down before. At the end, three flashes indicate that the code

has been saved correctly. If not, try the code entry procedure

again from point 1.

When you have programmed Speedy Meliconi, note down the

code on the label in the battery compartment cover.

To find the code for your remote control:

1. Hold down the and keys simultaneously until the light

indicator at the top starts to flash indicating that the remote

control is searching for the code.

2. Release the keys and, within 12 seconds, press and

simultaneously.

3. Release and and pay attention to the flashing of the

LEDs: a long flash corresponds to a +while a short flash

corresponds to a -. Note the sequence of the 8 flashes and

note them down on the label in the battery compartment

cover, from left to right.

PROGRAMMED CODE NOTING

WARRANTY: 2 years

The warranty ceases to be valid if the product is tampered with or

used incorrectly.

Remote control model Speedy

Purchase date

Agent's stamp

PROBLEM

The TV does not respond

and the light indicator does

not light up when you press

a key.

The TV or VCR does not

respond but the light

indicator does light up.

The TV does not respond

and the light indicator

flashes.

Not all remote control

commands are working

correcting.

The code for your TV brand

is not in the Code list.

The and keys do not

select the programmes.

TROUBLESHOOTING

SOLUTION

Check that the batteries are

fitted correctly. If necessary,

replace them with 2 new 1.5 V

AAA/LR03 alkaline batteries.

Check that the batteries are new

and that the remote control is

pointing at the appliance without

any obstacles in the way. If

required, reset the remote

control code, following the

programming procedure

A or B .

Batteries are low. Replace them.

You may have used the wrong

code. Reset the remote control

code, following the programming

procedure A or B .

Set the remote control code,

following the global search

programming procedure B .

The original remote control may

not have had this function. In

this case, set the code (press

8 times) as described in

paragraphs A or B .

If you have any queries about Speedy:

•read this booklet carefully – this will help you to solve

almost all problems

•consult our Internet site www.meliconi.it to answer all

your queries more easily and quickly.

INFO-LINE

Tabla de contenidos

Otros manuales de Mando a distancia de MELICONI

MELICONI

MELICONI TLC02 Manual de usuario

MELICONI

MELICONI GUMBODY UNIVERSAL 3-300 Manual de usuario

MELICONI

MELICONI GumBody DIGITAL 2 SMART Manual de usuario

MELICONI

MELICONI EASY 300 Manual de usuario

MELICONI

MELICONI Personal 1+ Manual de usuario

MELICONI

MELICONI GUMBODY FACILE 100 Manual de usuario

MELICONI

MELICONI SPEEDY 2 Manual de usuario

MELICONI

MELICONI Control TV.1 Manual de usuario

MELICONI

MELICONI GumBody Universal 5 web Manual de usuario

MELICONI

MELICONI personal 4 Manual de usuario

MELICONI

MELICONI EASY 200 Manual de usuario

MELICONI

MELICONI GUMBODY UNIVERSAL 5 SMART Manual de usuario

MELICONI

MELICONI personal 4 Manual de usuario

MELICONI

MELICONI Personal 6+ Manual de usuario

MELICONI

MELICONI TLC04 Manual de usuario

MELICONI

MELICONI pratico 6 Manual de usuario

MELICONI

MELICONI SPEEDY 110 Plus Manual de usuario

MELICONI

MELICONI TLC05 Manual de usuario

MELICONI

MELICONI Speedy 210 combo Guía de instalación

MELICONI

MELICONI GumBody Personal 1 Manual de usuario

MELICONI

MELICONI GUMBODY UNIVERSAL 6 LIGHT Manual de usuario

MELICONI

MELICONI Personal 3 plus Manual de instalación y operación

MELICONI

MELICONI GUMBODY UNIVERSAL 5-500 - WINDOWS Manual de usuario

MELICONI

MELICONI Speedy 100 plus Manual de usuario

Manuales populares de Mando a distancia de otras marcas

Panasonic

Panasonic EUR7622KB0 Manual de usuario

Bang & Olufsen

Bang & Olufsen Beo4 Manual de usuario

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manual de usuario

Multiplex

Multiplex PROFI TX 9 Manual de usuario

One Remote

One Remote RMB4 Manual de usuario

FUTABA

FUTABA 9ZAP - PART2 Manual de usuario

HR Matic

HR Matic HR MULTI 3 Manual de usuario

Yamaha

Yamaha ACC-GNRST-30-20 Manual de usuario

EisSound

EisSound KBSOUND Manual de usuario

Marantz

Marantz RC101 Manual de usuario

Conrad

Conrad FS20 TC6 Manual de usuario

Anritsu

Anritsu MP1777A Manual de usuario

Niles

Niles WVC100 Guía de solución de problemas

RCA

RCA RCU1300 Manual de usuario

Bang & Olufsen

Bang & Olufsen BEO6 Manual de usuario

GE 94901 Manual de usuario

Onbon

Onbon YQ1-75 Manual de usuario

FUTABA

FUTABA R7108SB Instrucciones de instalación
