MEK HERO GAMING PC POWERED BY ZOTAC 8
Rear View
USB 3.2 Gen 1 Ports x4 (Blue)
The USB 3.2 Gen 1 port supports the SuperSpeed USB
3.0 devices and is backward compatible with USB 2.0/1.1
devices. For maximum performance, use this port for USB
3.0 compatible devices.
PS2 Keyboard/Mouse Port
The PS/2 port is used to connect with a legacy keyboard
or mouse.
USB 2.0 Ports x2 (Black)
The USB (Universal Serial Bus) port is compatible with
USB devices such as keyboards, mice, cameras, and hard
disk drives.
LAN Port
The eight-pin RJ-45 LAN port support standard Ethernet
cables for connection to a local network.
USB 3.2 Gen 2 Type A + C Ports
The USB 3.2 Gen 2 port support SuperSpeed 10Gbps
devices and is backward compatible with USB 2.0/1.1
devices.
WiFi Antenna Connectors
The WiFi antenna connector supports the included WiFi
antenna.
Audio Ports
Use the three audio ports to connect audio devices. The
pink jack connects to the microphone. The green jack
connects to stereo speakers or a gaming headset. The
blue jack connects to other stereo audio input sources.
DisplayPorts
DisplayPort supports both external (box-to-box) and
internal (laptop LCD panel) display connections.
B
C
D
E
F
G
H
I
HDMI Port
The HDMI (High Denition Multimedia Interface) port
supports a UHD device such as an LCD TV or monitor to
allow viewing on a larger external display.
Power Input
Connected with power cable to a standard US Type B
grounded electrical outlet (receptacle).
Power Switch
The Power switch turns the power supply ON (I) and
OFF (0).
J
K
L
CC
DD
BB
EE
FF
GG
HH
I
J
K
L
CCDD
