MIT300 Series

Insulation and Continuity Testers

USER MANUAL

MIT300_UG_en_V11.qxp 14/1/09 3:03 pm Page 1

www.netzerotools.com

GSAFETY WARNINGS

nSafety Warnings and Precautions must be read and understood before the instrument is used. They must be observed during use.

nThe circuit under test must be switched off, de-energised and isolated before test connections are made when carrying out insulation and continuity

tests.

nCircuit connections and exposed metalwork of an installation or equipment under test must not be touched.

nThe live circuit warning and automatic discharge are additional safety features which may fail and therefore safe working practices must be

observed.

nThe voltage function will only work if the instrument is functional and switched on.

nAfter insulation tests, capacitive circuits must be allowed to discharge before disconnecting test leads.

nThe instrument should not be used if any part of it is damaged.

nTest leads, probes and crocodile clips must be in good order, clean and with no broken or cracked insulation.

nEnsure that hands remain behind guards of probes/clips when testing.

nNational Safety Authorities may recommend the use of fused test leads when measuring voltage on high-energy systems.

nReplacement fuses must be of the correct type and rating. Failure to fit the correctly rated fuse may result in a safety hazard and may cause damage to

the instrument in the event of an overload.

nThe battery cover must be in place whilst conducting tests.

nThe MIT310A is designed for use only in a controlled electromagnetic environment.

Users of this equipment and/or their employers are reminded that National Health and Safety Legislation requires them to carry out valid risk assessments of

all electrical work so as to identify potential sources of electrical danger and risk of electrical injury such as inadvertent short circuits. Where the assessments

show that the risk is significant then the use of fused test leads may be appropriate.

NOTE

THE INSTRUMENT MUST ONLY BE USED BY SUITABLY TRAINED AND COMPETENT PERSONS.

MIT300_UG_en_V11.qxp 14/1/09 3:03 pm Page 2

www.netzerotools.com

Insulation testing 15

Test lock 15

SP4F Switched (optional accessory for MIT320) 16

Test result storage (MIT330 only) 16

Replacing batteries and fuses 18

Low battery warning symbol 18

To replace batteries 18

Fuse replacement (user replaceable) 19

Preventive maintenance 19

Technical specification 20

Accessories and equipment 23

Repair and Warranty 24

Symbols used on the instrument are:

FCaution: risk of electric shock

GCaution: refer to accompanying notes

tEquipment protected throughout by Double

Insulation (Class II)

cEquipment complies with current EU directives.

Equipment complies with ‘C tick’ requirements

CONTENTS

Safety warnings 4

Introduction 2

General description 4

Case contents 5

LCD display 6

Front panel (digital instruments) 6

Connection panel 7

Lid open/closure 7

Preparations for use (all instruments) 8

Batteries 8

Preliminary test lead check 8

General operating instructions 8

General functions 8

Test lead connection. 9

Continuity measurement (MIT300, 310, 320, 330) 10

Test lead null 10

Continuity test (MIT300, 310,320, 330) 10

Continuity Buzzer (MIT300, 310, 320, 300) 11

Continuity buzzer mode: 11

Setup mode (MIT320/330 only) 11

Insulation testing - General 12

Insulation test 12

Test lock 13

Insulation test (MΩalarm ON/OFF (MIT320 only) 13

MΩthreshold adjustment (MIT320/330 only) 13

Insulation test lock disable (MIT320/330 only) 13

AC / DC Voltage measurement 14

Analogue Instrument MIT310A 14

Test lead null 14

Continuity test 15

Continuity buzzer test 15

N13117

MIT300_UG_en_V11.qxp 14/1/09 3:03 pm Page 3

www.netzerotools.com

The MIT300 series variants have the following features:

MIT300 MIT310 MIT310A MIT320 MIT330

Insulation testing

1kV Insulation range nnnn

500 V Insulation range nnnnn

250 V Insulation range nnnnn

Insulation test full scale 999 MΩ999 MΩ999 MΩ999 MΩ999 MΩ

Insulation limit alarm

0.01 MΩto 1 GΩnn

Continuity

Voltmeter range

(600 V digit) nnnn

Continuity buzzer nnnnn

Adjustable buzzer

threshold 1 Ωto 20 Ωnn

Audible buzzer disable nn

Lead null to 9.0 Ω

(0.5 Ωfor MIT310A) n n 0.5Ωn n

Stored test lead null nnnnn

Resistance

10 Ωto 1M Ωresistance

range nn

INTRODUCTION GENERAL DESCRIPTION

Thank you for purchasing the Megger Insulation Tester.

For your own safety and to get the maximum benefit from your

instrument, please ensure that you read and understand the following

safety warnings and instructions before attempting to use the instruments.

This user guide describes the operation and functions of the following:

MIT300 Series of insulation and continuity testers:

MIT300

MIT310

MIT310A

MIT320

MIT330

MIT300_UG_en_V11.qxp 14/1/09 3:03 pm Page 4

www.netzerotools.com

Please complete the warranty card and return it to Megger Limited as soon

as possible to help us reduce any delays in supporting you, should the

need arise.

Case contents

1 x MIT300 series insulation tester

1x Red/Black test lead set with clips

8xAA (LR6) batteries fitted

1x Warranty card

1 x Certificate of test

1x Calibration certificate

1 x CD containing user manual

1x Printed quick start guide

1 x USB lead (MIT330 only)

1 x SP4F switched probe (MIT320 and MIT330 only)

CASE CONTENTS

MIT300 MIT310 MIT310A MIT320 MIT330

Features

Locking test button nnnnn

Backlight and rotary

switch illuminations nn

Voltage warning n

Default voltmeter nnnn

Auto-power-down with

defeat nn nn

Switched test probe

connector n n

Switched test probe n n

Results storage n

Downloading n

USB n

MIT300_UG_en_V11.qxp 14/1/09 3:03 pm Page 5

www.netzerotools.com

LCD DISPLAY FRONT PANEL (DIGITAL INSTRUMENTS)

MIT300, 310, 320 and 330

MIT310A

Voltage warning LED

Test Lock LED

Test lead null

Batterycheck

Battery condition

indication

Moving coil

Analogue

display

indication

MIT300_UG_en_V11.qxp 14/1/09 3:03 pm Page 6

www.netzerotools.com

Memory control keys:

STORE: Store initiates the storing of a test result.

LAST/NEXT: Selects the type of location; ie Job, distribution

board, circuit, phase etc.

ESC: Aborts a save at any time.

OK: Final operation to save the result.

sSelects the job, db, circuit number; ie 01,02,03 etc

Lid open/closure

1. Open lid by lifting up front panel tab (1).

2. Fold-away underneath instrument (2 & 3) and push into retaining slot

(4).

Connection Panel

MIT300 Series test lead connections

An interlock sliding panel prevents connection of unsafe test lead

configurations. (MIT320/MIT330 only)

MIT330 Additional Controls

MIT300_UG_en_V11.qxp 14/1/09 3:03 pm Page 7

www.netzerotools.com

GENERAL OPERATING INSTRUCTIONS

Safety note:

If a voltage greater than 25 V appears on the circuit under test the

instrument will default to a voltage measurement and display the

supply voltage.

On supply voltages over 50 V the instrument will prevent the test

button from performing an insulation test, protecting your

instrument from damage.

General functions

Voltage Testing on High Energy Systems

Use extreme care when using or measuring voltages above 30 V,

particularly in high energy systems. Fused test leads are available as

optional accessories for local situations where increased protection is

required. See accessories section.

Tests lock

The LOCK Lindicates when an INSULATION test range is locked ON.

It is activated by holding down the [TEST] button, and pressing the LOCK

Lbutton.

Note: See analogue section for MIT310A

Warning: Hazardous voltages can exist on the insulation test range all the

time the [TEST] button is locked down.

Voltage warning (MIT300 only)

If a voltage exists on the circuit under test, the instrument will emit a

warning beep.

If a voltage greater than 50 V exists, testing will be automatically inhibited.

Batteries

The Megger MIT300 series of instruments are supplied with batteries

fitted. When batteries become exhausted, refer to page 18, battery

replacement.

Warning: Do not switch the instrument on with the battery cover

removed.

Preliminary test lead check

Functional verification

1. Before each use of the instrument visually inspect the test leads, prods

and crocodile clips to confirm that their condition is good, with no

damaged or broken insulation.

2. Check continuity of the test leads by firmly shorting the leads together

and read the test lead resistance measurement directly from the display,

which should be less than 1.0 Ω.

Refer to page 10 for operation guide.

3. Supply voltage

Using an approved method, ensure the circuit to be tested has been

fully disconnected from the supply prior to using the instrument.

PREPARATIONS FOR USE (ALL INSTRUMENTS)

MIT300_UG_en_V11.qxp 14/1/09 3:03 pm Page 8

www.netzerotools.com

Voltage warning (MIT310A only)

If a voltage exists on the circuit under test the voltmeter will indicate this.

However voltages under 50 V will be displayed but may be difficult to read

from the analogue display.

Default voltmeter (MIT310, MIT320 and MIT330)

The default voltmeter automatically operates if a voltage is present across

the test probes of greater than 25 V.

In Volts range the meter operates at greater than 2 V.

If the voltage exceeds 50 V any further testing is inhibited for safety.

The voltage will be displayed.

Backlight operation (MIT320 and MIT330 only)

Both the display and test ranges are backlit. The backlight function can be

selected at any time while the instrument is switched on by pressing the

BACKLIGHT Jbutton.

The backlight function will switch off automatically 20 seconds after the

instrument has finished testing.

Display warning symbols

GRefer to user manual

Any time the warning triangle is displayed the operator should refer to

the user manual for further information.

LRange lock

Displayed at any time the [TEST] button is locked in the on position.

zLead nulled

Indicates that the test lead resistance has been removed from the test

result.

Battery condition indication. Refer to page 18.

fFuse blown indicator, appears when an instrument fuse has failed.

Refer to page 19.

Test lead connection

The Red/Black test lead set should be connected to the appropriate

sockets on the rear of the instrument marked + and – respectively.

Test probes and crocodile clips are supplied for connection to the circuit

under test.

Fused test leads are available as an optional accessory, please refer to

accessories list at the end of this document.

Application

This instrument may be connected live to earth or between live

conductors of systems that have a rated voltage of 600 V a.c. rms to earth

and an installation (overvoltage) Category III or lower, or CATIV

applications with a rated voltage of 300 V or less.

This means that the instrument may be connected to any fixed wiring of a

building installation, but not to primary supply circuits such as overhead

cables. To maintain user safety and ensure accurate measurements, only

use the test leads supplied by Megger Limited.

MIT300_UG_en_V11.qxp 14/1/09 3:03 pm Page 9

www.netzerotools.com

4. The display shows the resistance value. (Maximum 99,9 Ω)

5. Disconnect the test probes to terminate the test.

6. On completion of testing switch to the [OFF] position. Alternatively auto

shut off operates after a period of instrument inactivity.

All continuity measurements are AUTO ranging from 0.00 Ωto 100 Ωon

Digital/analogue scale).

The MIT310A has manual range selection to 2 kΩ.

From 0.00 Ωto 10 Ωtest current is greater than 200 mA. From 10 Ωto

100 Ωtest current is greater than 20 mA. (See page 15 for MIT310A)

Test lead Null

(See page 14 for MIT310A)

Before using the continuity range or buzzer range for the first time, the test

lead resistance should be ‘zeroed out’. This ensures any measurement does

not include the resistance of the test leads.

1. Connect the test leads to the instrument and firmly short both leads

together.

2. Wait for the reading to stabilise and press the [TEST] button.

3. Display of the zconfirms test leads zeroing. The display

should be 0.00 Ω.

Note: Lead zeroing is retained when the instrument is switched off, or auto

shut-off operates.

To remove the ‘lead zero’ press the [TEST] button again.

Continuity test (MIT300, 310,320 and 330)

(See page 15 for MIT310A)

Tomake a continuity measurement:

1. Turn the instrument ‘On’ by selecting the continuity Ωrange.

2. If required, zero test lead resistance, see test lead null (above).

3. Connect the test probes to the isolated circuit under test. The test will

start automatically.

CONTINUITY MEASUREMENT (MIT300, 310, 320, 330)

MIT300_UG_en_V11.qxp 14/1/09 3:03 pm Page 10

www.netzerotools.com

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Equipo de prueba de Megger

Megger

Megger DDA-1 Manual de usuario

Megger

Megger MWA3 Series Manual de usuario

Megger

Megger T22/13B Manual de usuario

Megger

Megger MIT200 Series Manual de usuario

Megger

Megger MFT1700 series Manual de usuario

Megger

Megger VLF Sinus 62 Manual de usuario

Megger

Megger Programma Sverker 750 Manual de usuario

Megger

Megger EZ-ThumpV3 Manual de usuario

Megger

Megger MIT417 Manual de usuario

Megger

Megger PFL22M1500 Series Manual de usuario

Megger

Megger DET4 Series Manual de usuario

Megger

Megger MET1000-DE Manual de usuario

Megger

Megger ODEN AT Manual de usuario

Megger

Megger AVTMTTR100 Manual de usuario

Megger

Megger TTR20 Manual de usuario

Megger

Megger Centrix Evolution Manual de usuario

Megger

Megger 128311841 Manual de usuario

Megger

Megger OTS100AF Manual de usuario

Megger

Megger SVERKER 750 Manual de usuario

Megger

Megger LRCD200 series Manual de usuario

Megger

Megger ME1000351 Manual de usuario

Megger

Megger MFT1711 Manual de usuario

Megger

Megger TRS1PLUS Manual de usuario

Megger

Megger SPG 40 Manual de usuario

Manuales populares de Equipo de prueba de otras marcas

SMART

SMART KANAAD SBT XTREME 3G Series Manual de usuario

Agilent Technologies

Agilent Technologies BERT Serial Manual de usuario

Agilent Technologies

Agilent Technologies N3280A Manual de usuario

Vernier

Vernier Go Direct Voltage Manual de usuario

Lifeloc

Lifeloc R.A.D.A.R. Manual de usuario

Fluke

Fluke T5-600 Instrucciones de funcionamiento e instalación

Mercury

Mercury TSL01 Manual de usuario

MAHA

MAHA MBT Series Manual de usuario

Fuji Electric

Fuji Electric P-61 Manual de usuario

ETC

ETC SealerAtor Manual de usuario

Skyfine

Skyfine ETHYWAY V2 Manual de usuario

Appion

Appion G5 Twin Manual de usuario

PCB Piezotronics

PCB Piezotronics 8159-0112A Manual de usuario

BW Technologies

BW Technologies MicroDock II Manual de usuario

Sun Nuclear

Sun Nuclear 1027 Manual de usuario

Biomark

Biomark HPR LITE READER Manual de usuario

Hioki

Hioki 3169-20 Manual de usuario

Ashcroft

Ashcroft ATE-100 Manual de usuario
