User Manual
v10_9722
NetFeeler 2
CONTENTS
1. Introduction................................................................1
2. Features.....................................................................2
3. Specifications ............................................................3
4. Application .................................................................4
4.1. Connect to NetAgent II................................................. 4
5. Settings ......................................................................5
5.1. How to set RFID on NetFeeler 2 .................................. 6
5.2. How to set Wireless Smoke/Gas sensor...................... 8
5.3. How to set Wireless Door / Window sensor............... 11
5.4. How to set wireless glass-break sensor..................... 13
5.5. How to set InfraRed Beam Detector........................... 15
5.6. How to set PIR sensor................................................ 17
Introduction
NetFeeler 2
1
1. Introduction
NetFeeler 2 can detect variation in temperature, humidity and
presence of water. It can also be used with the following add-on
devices;
1. Wireless Smoke sensor
2. Wireless Gas sensor
3. Wireless Door/Window sensor
4. Wireless Glass-Break sensor
5. Wireless InfraRed Beam detector
6. Wireless PIR sensor
When an event occurs, NetFeeler 2 alarm will buzz. It can also
be configured to simultaneously send an email thru NetAgent II
(3-port model). When connected to NetAgent II, it can then
provide environment status feedback (temperature, humidity and
water presence) via the internet using a standard browser.
2. Features
2. Features
nAble to measure variations in temperature, humidity and
presence of water.
oBuilt-in radio frequency (“RF”) receiver.
pSupport up to 7 individually ID’d wireless Door / Window
sensor to detect unauthorized access.
qSupport Wireless Smoke or Gas sensor to trigger alarm
and send notification. Only one ID is available per type.
More then one unit can share the same ID.
rSupport Glass sensor.
sSupport InfraRed Beam detector.
tSupport Passive InfraRed (“PIR”) for motion detection.
Specifications
NetFeeler 2
3
3. Specifications
Humidity Specification
Detection Range 0 to 100% Relative Humidity non-condensing
Accuracy ±3.0% Relative Humidity
Response Time 10 Sec.
Temperature
Range -40℃to +75℃(-40℉to +75℉)
Temperature Specification
Detection Range -40℃to +70℃
Accuracy ±3℃
Response Time 10 Sec.
RF Specification
Detection Range 6~10 meter visible range
Frequency 315MHZ
Sensitivity -105dB
Applications
NetFeeler 2
4
4. Application
4.1.Connect to NetAgent II
nMonitor environment data via a standard web browser
oSend Email when an event occurs.
pPowered either directly from NetAgent II.
Fig.1 Conect to NetFeeler 2
Settings
NetFeeler 2
5
5. Settings
Description
Red LED Power
Yellow LED Alarm Indicator
Reset button To turn off alarm
Power supply from NetAgent II
RS232 port To connect to NetAgent II
(3-port models)
RFID Switch Used for pairing NetFeeler 2 with wireless
devices (see next page)
Settings
NetFeeler 2
6
5.1. How to set RFID on NetFeeler 2
nSet RFID switch 1 and 2: “on”
oSet RFID switch 3 to 8: “off“
Once set, the combinations will be used to pair other
wireless device to NetFeeler 2.
Fig.2: NetFeeler 2 RFID Switch
