Mectron OzoActive Manual de usuario

→ MECTRON OZOACTIVE

OzoActive produces ozone

and injects it directly into

mectron device irrigation

lines, providing ozonated

water which reduces the

risk of fungi, bacteria and

virus contamination through

aerosols. The OzoActive

device is compatible with

the COMBI touch and the

Multipiezo device line.

1OZOACTIVE

Connect foot-pedal via the jack terminal

2OZOACTIVE

Connect the power cord

→ASSEMBLY PROPHYLAXIS DEVICE / OZOACTIVE

(*)

3OZOACTIVE

Connect the thinner tube of the

Prophylaxis irrigation kit into the

designated coupler

4MECTRON DEVICE

Disconnect the foot-pedal cable

5MECTRON DEVICE

Connect foot-pedal via the

Ethernet plug port

6MECTRON DEVICE

Remove the cover of the peristaltic

pump motor

→ MECTRON OZOACTIVE

7MECTRON DEVICE

Looking at the rotating pump, disconnect

the tube on the left and connect it to the

tube-tube connection of the irrigation kit

8MECTRON DEVICE

Connect the hose to the coupler on

the mectron device

NOTE: Arrow indicates the direction of water ow (*)

9MECTRON DEVICE

Reattach the peristaltic pump cover

10 MECTRON DEVICE

Prime the irrigation line by running

a Pump/Flush cycle

11 OZOACTIVE

Choose the Prophylaxis function,

check that the irrigation line has been

properly primed then press OK

12 OZOACTIVE

Adjust the level of ozone according to

the irrigation level on the device

09:00 Prophylaxis 03 Apr

Ozone

14 MECTRON DEVICE / OZOACTIVE

Press foot-pedal to start

13 SETTINGS TABLE

Set the ozone level in accordance with

the irrigation level of the mectron device.

See indications table

IRRIGATION LEVEL OZONE LEVEL

1 1

2 2

3 (default) 3 (default)

4 4

5 5

6 (7 for COMBI touch device) 6

WARNING

• COMBI touch: OzoActive is usable only with bottle irrigation (ultrasound ablation only).

Select bottle irrigation function. Default level of irrigation is 3. Utilize + and - buttons to

adjust the level of irrigation.

• DO NOT USE during air-polishing powder treatments. Make sure to disconnect OzoActive

foot-pedal before utilizing water supply and powders.

09:00 Home 03 Apr

Oral Surgery

Prophylaxis

cod. 0074
