M-2850/M-2950 Sensor Product Guide
Revision F
McAfee® Network Security Platform
COPYRIGHT
Copyright © 2017 McAfee, LLC
TRADEMARK ATTRIBUTIONS
McAfee and the McAfee logo, McAfee Active Protection, ePolicy Orchestrator, McAfee ePO, McAfee EMM, Foundstone, McAfee LiveSafe, McAfee QuickClean, Safe Eyes,
McAfee SECURE, SecureOS, McAfee Shredder, SiteAdvisor, McAfee Stinger, True Key, TrustedSource, VirusScan are trademarks or registered trademarks of McAfee,
LLC or its subsidiaries in the US and other countries. Other marks and brands may be claimed as the property of others.
LICENSE INFORMATION
License Agreement
NOTICE TO ALL USERS: CAREFULLY READ THE APPROPRIATE LEGAL AGREEMENT CORRESPONDING TO THE LICENSE YOU PURCHASED, WHICH SETS FORTH THE
GENERAL TERMS AND CONDITIONS FOR THE USE OF THE LICENSED SOFTWARE. IF YOU DO NOT KNOW WHICH TYPE OF LICENSE YOU HAVE ACQUIRED, PLEASE
CONSULT THE SALES AND OTHER RELATED LICENSE GRANT OR PURCHASE ORDER DOCUMENTS THAT ACCOMPANY YOUR SOFTWARE PACKAGING OR THAT YOU HAVE
RECEIVED SEPARATELY AS PART OF THE PURCHASE (AS A BOOKLET, A FILE ON THE PRODUCT CD, OR A FILE AVAILABLE ON THE WEBSITE FROM WHICH YOU
DOWNLOADED THE SOFTWARE PACKAGE). IF YOU DO NOT AGREE TO ALL OF THE TERMS SET FORTH IN THE AGREEMENT, DO NOT INSTALL THE SOFTWARE. IF
APPLICABLE, YOU MAY RETURN THE PRODUCT TO MCAFEE OR THE PLACE OF PURCHASE FOR A FULL REFUND.
2McAfee® Network Security Platform M-2850/M-2950 Sensor Product Guide
Contents
Preface 5
About this guide ................................... 5
Audience ...................................5
Conventions ..................................5
What's in this guide ...............................6
Find product documentation ...............................6
1Introducing Network Security Sensors 7
About the M-2850/M-2950 Sensor .............................7
M-2850/M-2950 key features .............................. 8
M-2850/M-2950 physical description ............................8
Ports on the Sensor ...............................8
Front and back panel LEDs ............................10
2Before you install 13
Usage restrictions .................................. 13
Safety measures ...................................13
Working with ber-optic ports ..............................14
Contents of the Sensor box ...............................14
Unpack the Sensor ..................................15
3Setting up the Sensor 17
Setup overview ................................... 17
Position the Sensor ..................................17
Install the rails and ears on the chassis and rack ....................17
Mount the Sensor on a rack ........................... 18
Remove a Sensor from the rack .......................... 18
Redundant power supply ............................... 19
Install the power supply .............................19
Remove the power supply ............................ 19
Cable the Sensor .................................. 20
Small form-factor pluggable modules ...........................20
SFP module ................................. 21
Power on the Sensor ................................. 22
Power o the Sensor .................................22
4Attaching cables to the Sensor 23
Cable the Console port ................................ 23
Cable the Auxiliary port ................................ 24
Cable the fail-open port ................................24
Cable the Management port .............................. 24
Cable the Monitoring ports ...............................24
How to use peer ports ............................. 25
Default Monitoring port speed settings ....................... 25
Cable types for routers, switches, hubs, and PCs ....................25
McAfee® Network Security Platform M-2850/M-2950 Sensor Product Guide 3
Cable for in-line ...................................26
Connect the cables for tap mode .............................26
Connect the cables for SPAN or hub mode ......................... 27
Cable the fail-over interconnection ............................27
About the fail-open hardware ..............................27
5Troubleshooting the Sensor 29
ATechnical specications 31
BRegulatory, compliance, and safety information 33
Index 35
Contents
4McAfee® Network Security Platform M-2850/M-2950 Sensor Product Guide
Preface
This guide provides the information you need to congure, use, and maintain your McAfee product.
Contents
About this guide
Find product documentation
About this guide
This information describes the guide's target audience, the typographical conventions and icons used in this
guide, and how the guide is organized.
Audience
McAfee documentation is carefully researched and written for the target audience.
The information in this guide is intended primarily for:
•Administrators — People who implement and enforce the company's security program.
•Users — People who use the computer where the software is running and can access some or all of its
features.
Conventions
This guide uses these typographical conventions and icons.
Italic Title of a book, chapter, or topic; a new term; emphasis
Bold Text that is emphasized
Monospace Commands and other text that the user types; a code sample; a displayed message
Narrow Bold Words from the product interface like options, menus, buttons, and dialog boxes
Hypertext blue A link to a topic or to an external website
Note: Extra information to emphasize a point, remind the reader of something, or provide an
alternative method
Tip: Best practice information
Caution: Important advice to protect your computer system, software installation, network,
business, or data
Warning: Critical advice to prevent bodily harm when using a hardware product
McAfee® Network Security Platform M-2850/M-2950 Sensor Product Guide 5
What's in this guide
This guide contains information necessary to setup your M-2850/M-2950 Sensor model. This information
includes guiding you through preconguring, cabling, and troubleshooting your Sensor.
Find product documentation
On the ServicePortal, you can nd information about a released product, including product documentation,
technical articles, and more.
Task
1Go to the ServicePortal at https://support.mcafee.com and click the Knowledge Center tab.
2In the Knowledge Base pane under Content Source, click Product Documentation.
3Select a product and version, then click Search to display a list of documents.
Preface
Find product documentation
6McAfee® Network Security Platform M-2850/M-2950 Sensor Product Guide
1Introducing Network Security Sensors
This section describes the McAfee® Network Security Sensors at a high-level and also describes the McAfee®
M-2850/M-2950 Network Security Sensor (Sensor) in detail.
Sensors are high-performance, scalable, and exible content processing appliances built for the accurate
detection and prevention of intrusions, misuse, distributed denial of service (DDoS) attacks, and network access
control(NAC) of hosts. When deployed at key access points, a Sensor provides real-time trac monitoring to
detect malicious activity, and respond to the malicious activity as congured by the administrator.
After the Sensor is deployed and communication established, Sensors are congured and managed using the
McAfee Network Security Manager (Manager) server.
The process of conguring a Sensor and establishing communication with the Manager is described in the later
chapters of this guide. The Manager server is described in detail in the McAfee Network Security Platform Manager
Administration Guide.
Contents
About the M-2850/M-2950 Sensor
M-2850/M-2950 key features
M-2850/M-2950 physical description
About the M-2850/M-2950 Sensor
The M-2850/M-2950 Sensor provides eective network access control (NAC) of hosts.
The M-2850/M-2950 Sensor provides eective network IPS functionality as well as network access control (NAC)
of hosts.
The IPS functionality involves providing real-time detection and prevention of threats and known, zero-day, or
encrypted attacks. The Sensor can perform many types of attack responses, including generating alerts and
packet logs, resetting TCP connections, "scrubbing" malicious packets, and blocking attack packets entirely
before they reach the intended target.
NAC hosts involves regulating access to network resources based on host Operational Status level (Standard/
DHCP NAC), identity of the user logged into the host (IBAC) or both, and OOB NAC (L2, L3 ). The Sensor also
provides the Hybrid NAC functionality where a host is rst subjected to DHCP-NAC and then Standard NAC at
dierent ports of the same Sensor. For more information on the NAC functionality and congurations of the
Manager, see McAfee® Network Security Platform NAC Administration Guide.
Throughout this guide, the terms 'Sensor' and 'M-2850/M-2950' refer to the M-2850 or the M-2950 Sensor in
general.
1
McAfee® Network Security Platform M-2850/M-2950 Sensor Product Guide 7
M-2850/M-2950 key features
M-2850 M-2950
600 Mbps 1 Gbps
1 RJ-45 10/100/1000 Management port 1 RJ-45 10/100/1000 Management port
12 SFP one gigabit Ethernet monitoring ports 12 SFP one gigabit Ethernet monitoring ports
6 RJ-11 fail-open Control ports 6 RJ-11 fail-open Control ports
1 Response port 1 Response port
Dual power supply Dual power supply
External Compact Flash port External Compact Flash port
M-2850/M-2950 physical description
A high-port density M-2850/M-2950 Sensor, is designed for high bandwidth links, and is equipped with twenty
Fast Ethernet ports (or interfaces). This Sensor can monitor ten 1 Gbps Ethernet segments in full-duplex mode
(tap or in-line), and twenty segments in half-duplex mode (monitoring SPAN ports or hubs). M-2850/M-2950 can
monitor upto 600 Mbps of aggregate trac.
M-2850/M-2950 Sensor supports both built-in fail-open as well as conguring of external fail-open hardware.
Both passive and active fail-open kits (sold separately) are supported.
Ports on the Sensor
The M-2850/M-2950 Sensor is a 2RU (2 rack unit) and is equipped with the following components.
Figure 1-1 The front panel
Item Description
1 RJ-45 10/100/1000 Management port (1)
2 RS-232C Console port (1)
3 RS-232C Auxiliary port (1)
4 RJ-11 fail-open Control ports (6)
5 SFP one Gigabit Ethernet Monitoring ports (12)
6 External Compact Flash port (1)
7 Front panel LEDs (4)
1Introducing Network Security Sensors
M-2850/M-2950 key features
8McAfee® Network Security Platform M-2850/M-2950 Sensor Product Guide
Item Description
8 RJ 45 10/100/1000 Ethernet Monitoring ports (8)
9 Bypass LEDs (4)
Figure 1-2 The back panel
Item Description
10 Power supply A (included)
11 Power supply B (optional and sold separately)
12 Back panel LEDs (5)
1One RJ-45 10/100/1000 Management port, which is used for communication with the Manager server. You
can assign an IP address to this port during installation.
2One RS-232C Console port, which is used to set up and congure the Sensor using the CLI.
3One RS-232C Auxiliary port, which may be used to dial in remotely to set up and congure the Sensor.
4Six RJ-11 fail-open Control ports, designed for use the Optical fail-open bypass kit. Both optical and copper
kits can use these ports if congured in passive fail-open mode. The ports are marked X1, X2, X3, X4, X5, X6,
are used in conjunction with ports 1A/1B, 2A/2B, 3A/3B, 4A/4B, 5A/5B, 6A/6B, respectively.
5Twelve small form-factor pluggable (SFP) 1 Gigabit Monitoring ports, which enable you to monitor ten
Ethernet segments in-line.
If you choose to run in fail-over mode, port 6A is used to interconnect with a standby M-2850/M-2950
Sensor.
The gigabit ports of the M-2850/M-2950 running in In-line mode fail closed, meaning that if the Sensor fails, it
will interrupt/block data ow. Refer to the Gigabit Fail-Open Bypass Kit Guide for more information.
6One External Compact Flash port. This port is used only for ash recovery purposes. That is, this port is
used in troubleshooting situations where the Sensor's internal ash is corrupted and you need to reboot the
Sensor through the external compact ash. For more information, see the on-line KnowledgeBase at http://
mysupport.mcafee.com/Eservice/, where you need to click Search the KnowledgeBase.
7Four front panel LEDs, The LEDs which indicate the Sensor's general operational status.
8Four RJ-45 10/100/1000 Ethernet Monitoring port, which enable you to monitor four Ethernet segments
in-line. Also, built-in fail-open is available on ports 7-10.
9Four Bypass LEDs, which indicate the bypass status of the Sensor.
10 Primary Power Supplies—PWR A (included). Power supply A is included with each Sensor. The supply uses
a standard IEC port (IEC320-C13). McAfee provides a standard; 2m NEMA 5-15P (US) power cable (3 wire).
International customers must procure a country-appropriate power cable.
Introducing Network Security Sensors
M-2850/M-2950 physical description 1
McAfee® Network Security Platform M-2850/M-2950 Sensor Product Guide 9
11 Power Supplies—PWR B (optional, and can be purchased separately). Power supply B is a hot-swappable,
redundant power supply. This power supply also uses a standard IEC320-C13 port, and you can use the
McAfee--provided cable or acquire one that meets your specic needs.
12 Five Back panel LEDs. The LEDs which indicate the Sensor's fan and power supply operational status.
Front and back panel LEDs
Figure 1-3 Front panel LEDs
Figure 1-4 Back panel LEDs
Region in the image LEDs represented here
1 Sys, Temp, Flash, Fan
2 Power A
3 Back panel fan LEDs
4 Management Port Speed, Management Port Link, Response Port Speed, Response Port
Link
5 Gigabit Ports (SFP) Act, Gigabit Ports (SFP) Link
6 Fail-Open Control Port FO, Fail-Open Control Port Err
7 Bypass LEDs
The front panel LEDs provide status information for the health of the Sensor and the activity on its ports. The
back panel LEDs provide information regarding the Sensor fans and the power supply.
The following tables describe the front and back panel LEDs of M-2850/M-2950:
LED Status Description
Sys Green
Amber
Sensor is operating.
Sensor is booting. (It could also indicate a system failure.)
Temp Green
Amber
Inlet air temperature measured inside chassis is normal. (Chassis temperature OK.)
Inlet air temperature measured inside chassis is too hot. (Chassis temperature too hot.)
1Introducing Network Security Sensors
M-2850/M-2950 physical description
10 McAfee® Network Security Platform M-2850/M-2950 Sensor Product Guide
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Accesorios de McAfee
McAfee
McAfee IIP-S03K-NA-100I - IntruShield 3000 Sensor... Manual de usuario
McAfee
McAfee M-8000XC Manual de usuario
McAfee
McAfee IIP-M15K-ISAA - Network Security Platform... Manual de usuario
McAfee
McAfee IIP-M80K-ISAA - Network Security Platform... Manual de usuario
McAfee
McAfee IIP-S14C-NA-100I - IntruShield 1400 Sensor... Manual de usuario
McAfee
McAfee IFO-M65K-ISAA - Network Security Platform M-6050... Manual de usuario
McAfee
McAfee IIP-M65K-ISAA - Network Security Platform... Manual de usuario
McAfee
McAfee IIP-S41K-NA-100I - IntruShield 4010 Sensor... Manual de usuario
