DOOR TRIM

REMOVAL/INSTALLATION

< Previous Next >

2016 – MX-5 – Body and Accessories

DOOR TRIM REMOVAL/INSTALLATION

1. Disconnect the negative battery cable. (See NEGATIVE

BATTERY CABLE DISCONNECTION/CONNECTION.)

2. Remove the inner handle cover while detach tabs, pin.

3. Remove the recess cover.

4. Remove the screw.

Search here..

2/25/2020 DOOR TRIM REMOVAL/INSTALLATION | 2016 ND Shop Manual

https://www.hexorcism.com/16ND/sm356212/ 2/4

5. Move the door trim in the order of arrows (1), (2), (3), (4),(5)

and (6) shown in the gure and detach the clips.

6. Remove the door trim in the direction of the arrow shown in

the gure.

2/25/2020 DOOR TRIM REMOVAL/INSTALLATION | 2016 ND Shop Manual

https://www.hexorcism.com/16ND/sm356212/ 3/4

7. Remove tab A in the direction of the arrow (1) shown in the

gure.

8. Remove the inner handle in the direction of the arrow (2)

shown in the gure while detaching tab B.

9. Disconnect the connector.

10. Install in the reverse order of removal.
