TOP AND CABINET PARTS
1
For Models: MFW9800TQ0, MFW9800TK0
(White) (Pacific Blue)
10−07 Printed in U.S.A. (drd) Part No. W10157670 Rev. A
AUTOMATIC
WASHER
TOP AND CABINET PARTS
2
For Models: MFW9800TQ0, MFW9800TK0
(White) (Pacific Blue)
W10157670
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10137082
Use & Care Guide
8182658 Quick Start Guide
8182677 Tech Sheet
W10163495
Energy Guide
2 Top
8181641 White
W10163316
Pacific Blue
3 Cabinet
8182609 White
8182541 Pacific Blue
4 Panel, Front
8182605 White
W10163317
Pacific Blue
5 Toe Panel
8181643 White
8182550 Pacific Blue
6 8181636 Foot, Leveling
7 8181763 Bracket, Spring
8 8181695 Switch, Pressure
9 8181739 Hose, Pressure
Switch
10 8181635 Pan, Bottom
11 8182661 Brace, Transport
12 Bolt, Shipping
8182797 Upper
8182798 Lower
13 8182698 Panel, Rear
14 8183009 Cord, Power
15 8181690 Strain Relief
16
W10138248
Brace, Rear
17 8182701 Clip, Drain Hose
18 8181737 Hose, Drain
(Outer)
19 8181738 Connector,
Drain Hose
20 8181752 Clamp, Hose
21 8181632 Brace, Top
22 8183019 Filter,
Interference
23 Hose, Water Inlet
8182795 Blue Coupler
8182792 Red Coupler
24 8183030 Grid, Ventilation
25 8181691 Screw
26 8182700 Cover, Transport
27 8181768 Storage, Hose
28 8181828 Screw
29 8183086 Microswitch (2)
30 8182699 Grommet,
Cord Support (2)
31 8182201 Screw, 3 x 8 mm
32 8182702 Clip, Outer Hose
Holder
Following Parts Not Illustrated
8182109 Harness Channel
DOOR AND LATCH PARTS
3
For Models: MFW9800TQ0, MFW9800TK0
(White) (Pacific Blue)
W10157670
DOOR AND LATCH PARTS
4
For Models: MFW9800TQ0, MFW9800TK0
(White) (Pacific Blue)
W10157670
Illus. Part
No. No. DESCRIPTION
1 8182210 Clamp, Bellow
To Tub
2 8182119 Bellow
3 8182634 Lock, Door
4 8181760 Screw
5 8182211 Clamp, Bellow
To Front Panel
6 8181758 Screw
7 8181651 Hook, Door
8 8181661 Screw
9 8181660 Screw
10
W10163308
Frame, Door
Back Support
11
W10128586
Clamp,
Glass Support
12 8181650 Clamp, Glass (2)
13 8181655 Glass, Door
14 8181843 Hinge, Door
15
W10163299
Frame, Door
Front Assembly
16 8182779 Clip, Trim
17 Trim, Upper Left
8182592 White
W10163318
Pacific Blue
18 Cover, Hinge
(Outer)
8182595 White
W10163322
Pacific Blue
19 Cover, Hinge
(Inner)
8182596 White
W10163323
Pacific Blue
20 Trim, Lower
8182594 White
W10163321
Pacific Blue
21 Handle, Door
8182591 White
W10163324
Pacific Blue
22 Trim, Upper Right
8182593 White
W10163319
Pacific Blue
23 8182153 Foam, Door Handle
24 8181759 Screw
CONTROL PANEL PARTS
5
For Models: MFW9800TQ0, MFW9800TK0
(White) (Pacific Blue)
W10157670
CONTROL PANEL PARTS
6
For Models: MFW9800TQ0, MFW9800TK0
(White) (Pacific Blue)
W10157670
Illus. Part
No. No. DESCRIPTION
1 Panel, Control
W10163309
White
W10163310
Pacific Blue
2 8182150 User Interface
3
W10163302
Button, Power
4 8182183 Pal−nut
5
W10163305
Button Set,
Left
6
W10163304
Button Set,
Middle
7
W10163303
Button Set,
Right
8
W10163306
Button Set,
Start
9 8182224 Brace, Front Top
10 8181640 Channel, Water
11
W10137702
Microcomputer,
Machine Control
12 8181756 Screw
13 8182212 Harness, Wiring
(Main)
14 8182171 Bezel, Knob
15
W10163300
Overlay, Door
16 8183059 Medallion
17
W10163301
Knob, Control
18 Endcap, Left
8182599 White
W10163314
Pacific Blue
19 Endcap, Right
8182600 White
W10163315
Pacific Blue
20 Handle, Drawer
(Includes Item 18)
W10163312
White
W10163313
Pacific Blue
DISPENSER PARTS
7
For Models: MFW9800TQ0, MFW9800TK0
(White) (Pacific Blue)
W10157670
DISPENSER PARTS
8
For Models: MFW9800TQ0, MFW9800TK0
(White) (Pacific Blue)
W10157670
Illus. Part
No. No. DESCRIPTION
1 8182862 Valve, Inlet
2 8181710 Hose, Flowmeter
(L−Shaped)
3 8181751 Clamp, Hose
4 8181696 Flowmeter
5 8181708 Hose, Flowmeter
6 8183010 Nozzle, Inlet
7 8181714 O−Ring
8 8183022 Harness, Wiring
(Inlet Valve)
9 8181726 Cam, Actuator
10 8181725 Lever, Water
Distribution
11 8181723 Actuator
12 8181724 Connection, Lever
13 8181727 Spring, Lever
14 8183032 Dispenser
15 8181712 Nozzle,
Distribution
16 8181747 Seal
17 8181718 Tube, Dispenser
To Bellow
18 Handle, Drawer
W10163312
White
W10163313
Pacific Blue
19 Endcap
8182599 White
W10163314
Pacific Blue
20 8182173 Cushion, Handle
21 8181720 Drawer,
Detergent
22 8181722 Container,
Detergent
23 8182665 Siphon,
Bleach/Softener
24 8181730 Separator
25 8181721 Hook, Drawer
26 8182123 Cap
TUB AND BASKET PARTS
9
For Models: MFW9800TQ0, MFW9800TK0
(White) (Pacific Blue)
W10157670
TUB AND BASKET PARTS
10
For Models: MFW9800TQ0, MFW9800TK0
(White) (Pacific Blue)
W10157670
Illus. Part
No. No. DESCRIPTION
1 8182132 Nut, Pulley
2 8182650 Pulley
3 8183269 Belt
4 8181645 Counterweight,
Front (2)
5 8181744 Pipe, Ventilation
6 8181746 Clamp
7 8181743 Hose, Exhaust
8 8181666 Tub, Rear
(Includes Items
10, 22, 23 & 24)
9 8181644 Counterweight,
Rear
10 8181673 Gasket, Tub
11 8182247 Basket
12 8182233 Baffle, Basket
13 8181748 O−Ring
14 8181731 Airtrap
15 8181785 Screw
16 8182814 Spring,
Suspension
17 8181647 Bolt
18 8181742 Clamp, Hose
19 8181794 Hose, Tub to
Dispenser
20 8181667 Clamp, Tub
21 8181665 Tub, Front
(Includes Items
10 & 22)
22 8182512 Nut, Push−In
23 8182214 Screw
24 8181686 Clamp,
Heating Element
25 8182666 Element, Heating
26 8181705 NTC
27 8182812 Shock Absorber
Following Parts Not Illustrated
8182126 Screw, Baffle
Mounting
