Maytag MDG30PCC Manual de usuario

Part No. 113201-7

MDG30PCC Installation Manual

(30 lb Single Pocket, Phase 7 Coin)

RETAIN THESE

INSTRUCTIONS IN A

SAFE PLACE FOR

FUTURE REFERENCE

AVERTISSEMENT:Assurez-vous de bien

suivre les instructions données dans cette

notice pour réduire au minimum le risque

d’incendie ou d’explosion ou pour éviter

tout dommage matériel, toute blessure ou

la mort.

—Ne pas entreposer ni utiliser d’essence

ni d’autres vapeurs ou liquides

inflammables à proximité de cet

appareil ou de tout autre appareil.

—QUE FAIRE SI VOUS SENTEZ UNE

ODEUR DE GAZ:

●Ne pas tenter d’allumer d’appareils.

●Ne touchez à aucun interrupteur. Ne

pas vous servir des téléphones se

trouvant dans le bâtiment.

●Évacuez la pièce, le bâtiment ou la

zone.

●Appelez immédiatement votre

fournisseur de gaz depuis un voisin.

Suivez les instructions du fournisseur.

●Si vous ne pouvez rejoindre le

fournisseur de gaz, appelez le service

des incendies.

—L’installation et l’entretien doivent être

assurés par un installateur ou un

service d’entretien qualifié ou par le

fournisseur de gaz.

WARNING: For your safety the information

in this manual must be followed to

minimize the risk of fire or explosion and

to prevent property damage, personal

injury or death.

— Do not store or use gasoline or other

flammable vapors and liquids in the

vicinity of this or any other appliance.

— WHAT TO DO IF YOU SMELL GAS:

●Do not try to light any appliance.

●Do not touch any electrical switch;

do not use any phone in your

building.

●Clear the room, building or area of

all occupants.

●Immediately call your gas supplier

from a neighbor’s phone. Follow

the gas supplier’s instructions.

●If you cannot reach your gas

supplier, call the fire department.

— Installation and service must be

performed by a qualified installer, service

agency or the gas supplier.

FOR YOUR SAFETY

Do not store or use gasoline

or other flammable vapors

and liquids in the vicinity of

this or any other appliance.

POUR VOTRE SÉCURITÉ

Ne pas entreposer ni utiliser d’essence

ni d’autres vapeurs ou liquides

inflammables à proximité de cet

appareil ou de tout autre appareil.

Retain This Manual In ASafe Place For Future Reference

Our products embody advanced concepts in engineering, design, and safety. If this product is properly maintained, it

will provide many years of efficient, trouble free, and most importantly, safe operation.

ONLY qualified technicians should service this equipment.

OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual

included with the dryer.

The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.

We have tried to make this manual as complete as possible and hope you will find it useful. The manufacturer reserves

the right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material,

and to change or discontinue models. The illustrations included in this manual may not depict your particular dryer

exactly.

Important

For your convenience, log the following information:

DATE OF PURCHASE ________________________________________________ MODEL NO. ________________________________

DEALER’S NAME ________________________________________________________________________________________________

Serial Number(s) _________________________________________________________________________________________________

________________________________________________________________________________________________________________

For replacement parts, contact the dealer from which the dryer was purchased or contact:

MAYTAG CO.

Benton Harbor, MI

1-800-662-3587

MDG30PCC PH7

“IMPORTANT NOTE TO PURCHASER”

Information must be obtained from your local gas supplier on the instructions

to be followed if the user smells gas. These instructions must be posted in a

prominent location near the dryer.

IMPORTANT

YOU MUST DISCONNECTAND LOCK OUT THE ELECTRIC SUPPLYAND THE GAS

SUPPLY OR THE STEAM SUPPLY BEFORE ANY COVERS OR GUARDS ARE

REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING,

ADJUSTING, INSTALLATION, OR TESTING OF ANY EQUIPMENT PER OSHA

(Occupational Safety and HealthAdministration) STANDARDS.

WARNING

CHILDREN SHOULD NOT BEALLOWED TO PLAY ON OR NEAR THE DRYER(S).

CHILDREN SHOULD BE SUPERVISED IF NEAR DRYERS IN OPERATION.

CAUTION

DRYERS SHOULD NEVER BE LEFT UNATTENDEDWHILE IN OPERATION.

FOR YOUR SAFETY

DO NOT DRY MOPHEADS INTHE DRYER.

DO NOT USE DRYER IN THE PRESENCE OF DRYCLEANING FUMES.

“Caution: Label all wires prior to

disconnection when servicing

controls. Wiring errors can

cause improper operation.”

«Attention: Au moment de l’entretien des

commandes, étiquetez tous les fils avant de les

débrancher. Des erreurs de câblage peuvent entraîner

un fonctionnement inadéquat et dangereux.»

State of California Proposition 65 Warnings:

WARNING: This product contains a chemical known to the State of California to cause

cancer.

WARNING: This product contains a chemical known to the State of California to cause

birth defects or other reproductive harm.

WARNING

The dryer must never be operated with any of the back guards, outer tops, or service

panels removed. PERSONAL INJURY OR FIRE COULD RESULT.

IMPORTANT

PLEASE OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment and/or

specified in the installation manual included with the dryer.

WARNING

DRYER MUST NEVER BE OPERATED WITHOUT THE LINT FILTER/SCREEN IN

PLACE, EVEN IFAN EXTERNAL LINT COLLECTION SYSTEM IS USED.

Dryer must not be installed or stored in an area where it will be exposed to water or weather.

The wiring diagram for the dryer is located in the front electrical control box area.

IMPORTANT

Dryer must be installed in a location/environment, which the ambient temperature

remains between 40° F (4.44° C) and 130° F (54.44° C).

WARNING

UNDER NO CIRCUMSTANCES should the door switch or the heat circuit devices

ever be disabled.

SECTION I

SAFETY PRECAUTIONS ................................................................................................ 2

SECTION II

SPECIFICATIONS ............................................................................................................ 4

SECTION III

INSTALLATION PROCEDURES .................................................................................. 6

A. Unpacking and Setting Up ............................................................................................................................... 6

B. Location Requirements .................................................................................................................................... 7

C. Dryer Enclosure Requirements ....................................................................................................................... 8

D. FreshAir Supply Requirements ....................................................................................................................... 9

E. Exhaust Requirements ................................................................................................................................... 10

F. Electrical Information .................................................................................................................................... 14

G. Gas Information ............................................................................................................................................. 16

H. Preparation for Operation and Start-Up ....................................................................................................... 19

I. Preoperational Tests ...................................................................................................................................... 20

J. Preoperational Instructions ............................................................................................................................ 21

K. Shutdown Instructions ................................................................................................................................... 22

SECTION IV

SERVICE/PARTS INFORMATION ............................................................................. 23

A. Service ........................................................................................................................................................... 23

B. Parts............................................................................................................................................................... 23

SECTION V

WARRANTY INFORMATION...................................................................................... 24

A. Returning Warranty Cards ............................................................................................................................ 24

B. Warranty ........................................................................................................................................................ 24

SECTION VI

ROUTINE MAINTENANCE ......................................................................................... 25

A. Cleaning ......................................................................................................................................................... 25

B. Adjustments ................................................................................................................................................... 26

C. Lubrication ..................................................................................................................................................... 26

SECTION VII

DATA LABEL INFORMATION .................................................................................... 27

SECTION VIII

PROCEDURE FOR FUNCTIONAL CHECK

OF REPLACEMENT COMPONENTS ....................................................................... 28

SECTION IX

MANUAL RESET BURNER HI-LIMIT INSTRUCTIONS ...................................... 30

A. Phase 7 .......................................................................................................................................................... 30

B. Dual Timer ..................................................................................................................................................... 30

Table of Contents

2 Maytag Co. 113201- 7

SECTION I

SAFETY PRECAUTIONS

WARNING: For your safety, the information in this manual must be followed to minimize the risk of

fire or explosion or to prevent property damage, personal injury, or loss of life.

WARNING: The dryer must never be operated with any of the back guards, outer tops, or

service panels removed.PERSONAL INJURY OR FIRE COULD RESULT.

1. DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other

appliance.

2. Purchaser or user should consult the local gas supplier for proper instructions to be followed in the event the

user smells gas. The instructions should be posted in a prominent location.

3. WHAT TO DO IF YOU SMELL GAS:

a. DO NOT try to light any appliance.

b. DO NOT touch any electrical switch.

c. DO NOT use any phone in your building.

d. Clear the room, building, or area of ALL occupants.

e. Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

f. If you cannot reach your gas supplier, call the fire department.

4. Installation and service must be performed by a qualified installer, service agency, or gas supplier.

5. Dryers must be exhausted to the outdoors.

6. Although Maytag produces a very versatile dryer, there are some articles that, due to fabric composition or

cleaning method, should not be dried in it.

WARNING: Dry only water washed fabrics. DO NOT dry articles spotted or washed in dry

cleaning solvents, a combustible detergent, or “all purpose” cleaner. EXPLOSION

COULD RESULT.

WARNING: DO NOT dry rags or articles coated or contaminated with gasoline, kerosene, oil, paint,

or wax. EXPLOSION COULD RESULT.

WARNING: DO NOT dry mop heads. Contamination by wax or flammable solvents will create a

fire hazard.

113201- 7 Maytag Co. 3

WARNING: DO NOT use heat for drying articles that contain plastic, foam, sponge rubber, or

similarly textured rubber materials. Drying in a heated basket (tumbler) may damage

plastics or rubber and may be a fire hazard.

7. A program should be established for the inspection and cleaning of lint in the burner area, exhaust ductwork,

and area around the back of the dryer. The frequency of inspection and cleaning can best be determined

from experience at each location.

WARNING: The collection of lint in the burner area and exhaust ductwork can create a potential fire

hazard.

8. For personal safety, the dryer must be electrically grounded in accordance with local codes and/or the

National Electrical Code ANSI/NFPA NO. 70-LATEST EDITION or in Canada, the Canadian Electrical

Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION.

NOTE: Failure to electrically ground the dryer properly will VOID THE WARRANTY.

9. UNDER NO CIRCUMSTANCES should the door switch or the heat circuit devices ever be disabled.

WARNING: PERSONAL INJURY OR FIRE COULD RESULT.

10. This dryer is not to be used in the presence of dry cleaning solvents or fumes.

11. Remove articles from the dryer as soon as the drying cycle has been completed.

WARNING: Articles left in the dryer after the drying and cooling cycles have been completed can

create a fire hazard.

12. READ AND FOLLOW ALL CAUTION AND DIRECTION LABELS ATTACHED TO THE

DRYER.

13. For safety, proper operation, and optimum performance, the dryer must not be operated with a load less

than sixty-six percent (66%) 20 lb (9.07 kg) of its rated capacity.

WARNING: YOU MUST DISCONNECT AND LOCKOUT THE ELECTRIC SUPPLYAND

THE GAS SUPPLY OR THE STEAM SUPPLY BEFORE ANY COVERS OR

GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS

FOR CLEANING, ADJUSTING, INSTALLATION, OR TESTING OFANY

EQUIPMENT PER OCCUPATIONAL SAFETYAND HEALTH

ADMINISTRATION (OSHA) STANDARDS.

IMPORTANT: Dryer must be installed in a location/environment, which the ambient

temperature remains between 40º F (4.44º C) and 130º F (54.44º C).

4 Maytag Co. 113201- 7

SECTION II

SPECIFICATIONS

Shaded areas are stated in metric equivalents 3/10/04

NOTE: The manufacturer reserves the right to make changes in specifications at any time without

notice or obligation.

MAXIMUM CAPACITY (DRY WEIGHT) 30 lbs 13.6 kg

TUMBLER DIAMETER 30” 76.2 cm

TUMBLER DEPTH 30” 76.2 cm

TUMBLER VOLUME 12.27 cu ft 0.347 cu m

TUMBLER MOTOR 1/2 hp 0.373 kW

DOOR OPENING (DIAMETER) 21-1/2” 54.61 cm

EXHAUST CONNECTION (DIAMETER) 8” 20.32 cm

DRYERS PER 20’/40’ CONTAINER 12 / 28

DRYERS PER 48’/53’ TRUCK 32 / 36

VOLTAGE AVAILABLE 120-240v 1ø 2w 50/60 Hz

APPROX. NET WEIGHT 535 lbs 242.7 kg

APPROX. SHIPPING WEIGHT 585 lbs 265.4 kg

HEAT INPUT 90,000 Btu/hr 22,680 kcal/hr

AIRFLOW 600 cfm 17 cmm

INLET PIPE CONNECTION 1/2” M.N.P.T.

GAS

113201- 7 Maytag Co. 5

Specifications

NOTE: The manufacturer reserves the right to make changes in specifications at any time without

notice or obligation.

6 Maytag Co. 113201- 7

SECTION III

INSTALLATION PROCEDURES

Installation should be performed by competent technicians in accordance with local and state codes. In the

absence of these codes, the installation must conform to applicable American National Standards: ANSI Z223.1-

LATEST EDITION (National Fuel Gas Code) or ANSI/NFPA NO. 70-LATEST EDITION (National Electrical

Code) or in Canada, the installation must conform to applicable Canadian Standards: CAN/CGA-B149.1-M91

(Natural Gas) or CAN/CGA-B149.2-M91 (Liquid Propane [L.P.] Gas) or LATEST EDITION (for General

Installation and Gas Plumbing) or Canadian Electrical Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION

(for Electrical Connections).

A. UNPACKING AND SETTING UP

Remove protective shipping material (i.e., plastic wrap and optional shipping box) from dryer.

IMPORTANT: Dryer must be transported and handled in an upright position at ALL times.

NOTE: The key for the top control door and bottom lint door is located in the information packaged

and shipped in the dryer’s basket (tumbler). This key should be made accessible because it

will be needed throughout various phases in the installation of the dryer.

The dryer can be moved to its final location while still attached to the skid or with the skid removed. To remove

the skid from the dryer, locate and remove the four (4) bolts securing the base of the dryer to the wooden skid.

Two (2) are at the rear base (remove the back panel for access), and two (2) are located in the bottom of the lint

chamber. To remove the two (2) bolts located in the lint chamber area, remove the lint door.

With the skid removed, to make it easier to slide the dryer into its final position, slightly lower ALL four (4)

leveling legs, so that the dryer will slide on the legs instead of the base frame.

The lint coops of ALL model dryers are supported during shipping by a bracket. REMOVE THIS BRACKET

BEFORE STARTING THE DRYER.

Leveling Dryer

The dryer is equipped with four (4) leveling legs, one (1) at each corner of the base. Two (2) are located at the

rear of the dryer base, and two (2) are located in the lint chamber (coop). To increase bearing life and improve

efficiency, the dryer should be tilted slightly to the rear.

Otros manuales para MDG30PCC

Tabla de contenidos

Otros manuales de Secadora de Maytag

Maytag

Maytag MGDE500WJ1 Manual de usuario

Maytag

Maytag MGDC500VW Manual de usuario

Maytag

Maytag W10312952A Manual de usuario

Maytag

Maytag MED5900TW - R CentennialR Electric Dryer Instrucciones de funcionamiento e instalación

Maytag

Maytag 3405344 Manual de usuario

Maytag

Maytag MD491 Manual de usuario

Maytag

Maytag MDG-75 Manual de usuario

Maytag

Maytag W10099070 Manual de usuario

Maytag

Maytag MDE20MN Manual de usuario

Maytag

Maytag MDG28PD Manual de usuario

Maytag

Maytag YMED9000YW3 Manual de usuario

Maytag

Maytag MDG75PNH Manual de usuario

Maytag

Maytag MDE9700A Manual de usuario

Maytag

Maytag MLG24PDAXW1 Manual de usuario

Maytag

Maytag Electric and gas dryer Manual de usuario

Maytag

Maytag MDE2706AYW Manual de usuario

Maytag

Maytag MDG76PC Manual de usuario

Maytag

Maytag MGDE500VW - Performance Series Front Load Steam Gas... Manual de usuario

Maytag

Maytag W10096990A Manual de usuario

Maytag

Maytag MLG27PN Manual de usuario

Maytag

Maytag MGD8200FC Manual de usuario

Maytag

Maytag Bravos MEDB750YW Manual de usuario

Maytag

Maytag Bravos W10201175A Manual de usuario

Maytag

Maytag EPIC z MEDZ600T Manual de usuario

Manuales populares de Secadora de otras marcas

Bosch

Bosch WTA79200GB Manual de usuario

Amana

Amana W10233410A Manual de usuario

Miele

Miele TWH 780 WP Manual de usuario

Asko

Asko T760 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manual de usuario

Bosch

Bosch Logixx 10 WTB76556GB Hoja de especificaciones

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Manual de instrucciones

Electrolux

Electrolux EW2H328R2 Manual de usuario

Beko

Beko DS8433RX1M Manual de usuario

Dawlance

Dawlance Spinner DS 6000 C Manual de usuario

Electrolux

Electrolux TP5080TW Manual de usuario

AEG

AEG TR838P4OB Manual de usuario

Indesit

Indesit IDV 75 Manual de usuario

Infiniton

Infiniton SD-DG85C Manual de usuario

BOMANN

BOMANN WT 5019 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manual de usuario

Asko

Asko T793C Manual de usuario

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manual de usuario
