LEGENDARY MAYTAG DEPENDABILITY

Maximizing your equipment investment for over a half-century.

FOR YOUR CUSTOMERS:

• Extra-Large 7.4-cu.-ft. Capacity

• Simple Controls Are Easy for Multiple Users

• Powerful, High Airflow Dries Load Quickly, Saving Time

• Extra-Large Door and Drum Openings Allow Quick, Easy Loading

and Unloading

• Time Remaining Display

FOR YOUR OPERATION:

• TurboVent™ Technology Provides Faster Drying and Better

Performance on Long Vents

• 4-Way Venting—Right or Left Side, Back or Front

• Advanced Computer Trac® Controls Allow for Easy Programming

• Maytag Connect 360°™ Wireless Audit System—Option

• Large-Capacity Metal Mesh Lint Filter

• Front Access for Easier Self-Service

• Reversible Side-Swing Door

BUILT-TO-LAST™FEATURES:

• Premium Porcelain-Enamel Top

• Four-Roller Suspension With Permanently Lubricated Bearings

• Blower Guard Reduces Service Calls

• 5-Year Limited Warranty—All Parts Covered

MDE/MDG18PR

MAYTAG®COMMERCIAL

SUPER-CAPACITY DRYER

MY130068

FASTER DRYING WITH

TURBOVENT™TECHNOLOGY

visit maytagcommerciallaundry.com

or call 800-662-3587

THE BEST WARRANTY IN THE BUSINESS—

5 YEARS ON ALL PARTS

For a period from the date of original purchase through the time listed above,

the designated parts that fail in normal commercial use will be repaired or

replaced free of charge for the part itself, with the owner paying all other

costs, including labor, transportation and customs duty. Chemical damage is

excluded from all warranty coverage. See complete warranty for details.

DRYER SPECIFICATIONS

MODEL MDE/MDG18PR

MOTOR

Single-phase, thermoprotected against overload,

auto-reset



HP (kw) .33 (.25)

TUMBLE SPEED—RPM 50 + 1

CAPACITY

Cu. ft. (liters) 7.4 (210)

AIRFLOW

Gas models—cfm (cmm) 230 (6.5)

Electric models—cfm (cmm) 215 (6.1)

ELECTRICAL REQUIREMENTS

MDE model—voltage/Hz 240/60*

MDG model—voltage/Hz 120/60

BREAKER/FUSE MINIMUM REQUIREMENTS

MDE model—amps 30

MDG model—amps 15

ELECTRIC HEATING ELEMENT—WATTS

Domestic models 5,600

Canadian models 5,250

GAS RATING

MDG model—BTU/hr. (kcal/hr.) 24,000 (6,048)

GAS INLET

MDG model—in. 3/8 N.P.T.

EXHAUST DUCT DIAMETER

In. (mm) 4 (101.6)**

ELECTRONIC BURNER IGNITION

MDG models



AUTOMATIC PRESSURE REGULATOR

MDG models



ADJUSTABLE LEVELING LEGS



APPROXIMATE WEIGHT

Crated—lbs. (kg) 140 (63.5)

Uncrated—lbs. (kg) 126 (57.2)

DIMENSIONS

Height—in. (mm) 41 (1,040)***

Width—in. (mm) 27 (686)

Depth—in. (mm) 29.25 (743)

WARRANTY 5-YEAR

*208-Volt electric element kit available.

**Use 4" (106 mm) diameter rigid aluminum or galvanized steel duct. Never use plastic, non-metal or combustible duct.

***Height at top of metercase.

Dimensions are for planning purposes only. See specific instructions for proper installation. Because of continuous

product improvement, Maytag reserves the right to change specifications without notice.

At Maytag, we believe durable goods should remain just that.

That’s why every Maytag® product is constructed of the

highest-quality materials and with the utmost in precision

craftsmanship. It’s also why we stand behind our equipment

with solid service and support from our professional Maytag

laundry suppliers. Simply put, when you choose Maytag®

products, you ensure your peace of mind.

OUR COMMITMENT

TO DEPENDABLE QUALITY

6/13

MDE/MDG18PR

MAYTAG®COMMERCIAL

SUPER-CAPACITY

DRYER

Maytag®Commercial Super-Capacity Dryer

MICROPROCESSOR CARD READER

MAXIMUM EXHAUST DUCT LENGTH

PER NUMBER OF TURNS

Number Of

90° Turns

Rigid Metal Vent

Box Hood and Angled Hood

Louvered Style Style

0 135 ft. (41.2 m ) 129 ft. (39.3 m )

1 125 ft. (38.1 m ) 119 ft. (36.3 m )

2 115 ft. (35.1 m ) 109 ft. (33.2 m )

3 106 ft. (32.3 m ) 100 ft. (30.5 m )

4 98 ft. (29.9 m ) 92 ft. (28.0 m )

Flexible Metal Vent

Box Hood and Angled Hood

Louvered Style Style

0 76 ft. (23.2 m ) 62 ft. (18.9 m )

1 71 ft. (21.6 m ) 57 ft. (17.4 m )

2 67 ft. (20.4 m ) 53 ft. (16.2 m )

3 65 ft. (19.8 m ) 51 ft. (15.6 m )

4 63 ft. (19.2 m ) 49 ft. (14.9 m)
