Use & Care Guide

Dishwasher

MAYTAG

MSE 760 FARS

Quick Guide

1. Loading baskets

Remove large food particles and debris. There is no need to rinse thanks to the Super

Cleaning System™.

2. Dispensing dishwasher detergent

The detergent compartment has a small compartment for pre-wash and one for main

wash.

3. Ensure that the spray arms can rotate freely

4. Turn on the main switch

5. Select program and press start

For washing normally soiled mixed loads use the Normal wash program with

normal temperature and normal drying .

To save more water and energy use economy temperature and economy drying.

6. Close the door

Mini Program Guide

75°C

70°C

65°C

70°C

50°C

60°C

30°C

Heavy

wash

Normal

wash

Delicate

wash

Quick

wash

Intensive

wash

Rinse &

Hold

Program

Press

Program

Options

How the

machine

works

Temperature

Main wash

Final rinse

Contents

Page

Contents 3-4

Before doing your first wash 5

Read through the directions for use

Take care with certain materials

Check the door

Check water hardness level

Machines with water softener

Safety 6

General

Winter storage/Transport

Overfill protection

Cleaning

Packaging materials

Scrapping

Child safety 7

Child-safe button lock

Child-safe dishwashing

Protect your children! Dishwasher detergent

is corrosive

Parts of the dishwasher 8

Technical information 8

Baskets 9

Control panel 10

Dispenser 10

Basic Course 11-13

Load the baskets correctly

Dispensing dishwasher detergent

Selecting programs

Options 13

Temperature

Delayed start

Drying

Press start

Changing options

Do you want to load more dishes?

If the machine is switched off at

the main switch

After dishwashing

Eco-dishwashing 14

Only perform washes with a full machine

Wash at a lower temperature

Select program without Extra dry

Do not rinse before dishwashing

Choose environmentally-friendly

dishwasher detergent

Connect to cold water supply

Fragile dishes 15

Fragile decoration

Crystal/ glass

Silver

Cutlery with glued handles

Wood

Aluminium

Plastic

Protect plastic goods

Standard program 16-17

Cleaning 18-19

Coarse filter

Fine filter

Drain pump

Spray arms

Door

Rinse aid 20

Pour in rinse aid

Select dosage

Salt 21

Pour in salt

Settings 22-24

Reprogramming

Child-safe button lock

Setting water hardness

Setting a signal

Fault indications 25

Troubleshooting 26-28

The dishes are not clean

Stains or a film on the china

The china has a whitish-blue sticky film

Stains on stainless steel or silver

Stains which remain after dishwashing.

Rattling sounds during dishwashing

The machine will not start

Water remains in the machine

Bad odour in the machine

Performance information 29

Installation 30-34

Suggestions on positioning the

dishwasher

A. Built-in

B. Freestanding

C. Semi-freestanding

Connection to water supply

Connection to electricity

Connection to drainage

Positioning the machine

A. Adjusting machines with six feet

(freestanding dishwasher)

B. Adjusting machines with

three or four feet

C. Adjusting machines with adjustable foot

Adjusting the plinth

(Only if you have a kick-plate

as an accessory)

Screw the dishwasher into place

Fitting strip seal

(on floor plinth covering plate)

NB! Not all models

Setting water hardness

Service & guarantee 35

Own comments 36-38

Search words 39

Before doing your first wash

Read through the directions for use

Read through the directions for use before

starting to use your machine, especially the

Safety, Child Safety and Basic Course

sections.

Take care with certain materials

Read the section ‘Fragile Dishes’ before

washing china with unglazed decoration or

other household goods made of plastic,

wood or crystal requiring careful treatment.

Check the door

Check that the door of the dishwasher fits

properly: open the door a little and let it go.

Does it stay exactly where you released it?

If not, you should check the installation

instructions or consult the installer.

Check the water hardness level

Phone your local Water Board to check the

water hardness in your area. This is important

when dispensing dishwasher detergent and

rinse aid.

If you have a machine with a water

softener

Once you know the water hardness, you

can set the water softener, see Settings.

Before you start dishwashing, you must

also fill with salt, see Salt.

Safety

General

Winter storage/Transport

• Read and keep the directions for use!

• Installation of water, drainage and elec-

tricity must be carried out by a qualified

professional.

• Do not use the dishwasher for any pur-

poses other than those stated in these

directions for use.

• Do not load the dishwasher door or the

dishwasher baskets with anything other

than dishes.

• Only use dishwasher detergent!

• Place knives and other sharp objects so

that they cannot cause injury to people or

damage the dishwasher.

Never put dishes containing solvent residue

in the machine due to risk of explosion.

Neither may dishes containing ashes, wax

or lubricating grease be washed in the

dishwasher.

Winter storage/Transport

Store the machine away from frost.

Avoid long journeys in extreme cold. Trans-

port the machine in an upright position or

lying on its back.

Overfill protection

The overfill protector starts pumping out

water and closes off the water intake if the

machine’s water level exceeds the normal

level. If the overfill protector starts up, shut

off the water supply and phone for service.

See ‘Troubleshooting’ on pages 26-28.

Cleaning

Only use a slightly damp cloth for cleaning

around the edge of the door. Do not use a

spray bottle! Water can penetrate into the

lock and come into contact with the elec-

trical components.

Packaging materials

Sort at source in accordance with the re-

commendations of your local authority.

Scrapping

When the time comes for the machine to be

scrapped, it should immediately be ren-

dered unusable. Remove the plug and cut

off the lead as short as possible.

Contact your refuse collection department

or your local authority for information on the

correct way to dispose of the machine!

The machine is manufactured and labelled

for recycling.

Child Safety!

Child-safe button lock

To prevent children starting the machine,

you can activate a button lock.

Proceed as follows:

1. Switch off the dishwasher with the main

switch.

2. Hold in the Temperature and Drying

buttons, and at the same time switch on the

main switch.

The temperature, drying and start symbols

will then flash. Release the Temperature

and Drying buttons.

4. Press the Program selection button. Once

the symbol for Intensive wash lights up, the

button lock has been activated.

5. Press the Start/Stop button to store the

setting.

Once the button lock has been activated,

the Temperature and Drying symbols will

flash when any of the buttons are pressed.

To deactivate the button lock temporarily

when you want to start the machine, press

the Temperature and Drying buttons

simultaneously. The button lock will then

automatically switch on again after 3 min-

utes.

To deactivate the button lock altogether, use

the same procedure as for activation. When

the symbol for Intensive wash goes out, the

button lock has been deactivated.

Advice!

You can read more about this in the Settings

chapter.

Child-safe dishwashing

• Use the knife basket, or knife holder, for

all long/sharp items.

• Always close the door and start the pro-

gram immediately once dishwasher deter-

gent has been added.

• Keep children away from the dishwasher

when it is open. There might be remains of

dishwasher detergent present!

• Do not allow children to use or play with

the dishwasher. Always take particular care

when the door is open.

Protect your children!

- Dishwasher detergent is

corrosive!

Store dishwasher detergent and rinse aid

out of the reach of children! Should dish-

washer detergent be swallowed, immedi-

ately drink one or two glasses of milk or

water. Do not attempt to induce vomiting.

Contact a doctor! Should dishwasher deter-

gent come into contact with the eyes, rinse

(for at least 15 minutes) with copious

amounts of water.

Parts of the dishwasher*

1. Knife basket

2. Upper basket

3. Lamp

4. Spray arms

5. Lower basket

6. Cutlery basket

7. Rinse Aid Filling

8. Dishwasher detergent compartment

9. Main switch

10. Program panel

11. Filter

12. Type plate

* Details may differ

depending on model and market!

Technical information

Height

Width

Depth

Weight

Capacity**

Water pressure

Connection

Max output

Accessories

* Details may differ depending on model and

market!

**In accordance with standard, EN 50242.

***See type plate.

****Without fitted wooden door.

820-870 mm

596 mm

550 mm****

48 kg/51 kg with water softener*

12 place settings

0.03-1.0 MPa (0.3–10 kp/cm2)

1-phase, 230 V, 50Hz 10/10A***

1 900 W***

Work surface, Side panels, Anti-tilt

Baskets*

Upper basket

Lower basket

Cutlery basket

1. Wine glass shelf

2. Cup rack

3. Folding plate stand

4. Cutlery basket with door and folding

handle

*Details may differ depending on the model and

market!

Knife basket

1. Program selector

2. Intensive wash

3. Strong wash

4. Normal wash

5. Light wash

6. Quick wash

7. Rinse & Hold

Control panel

8.Temperature

9. Delayed start 5 hours

10. Drying

11. Rinse aid indicator

12. Salt indicator

13. Start/stop

Dispenser

1 3

1. Compartment for main wash dish-

washer detergent

2. Compartment for pre-wash detergent

3. Inspection window for rinse aid (not all

models)

4. Rinse aid cover

5. Detergent compartment cover

8910 131234567

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Lavavajillas de Maytag

Maytag

Maytag DW-3 Manual de usuario

Maytag

Maytag MDB4651AWS - 24 Inch Full Console Dishwasher Manual de usuario

Maytag

Maytag MDB7759AWW4 Manual de usuario

Maytag

Maytag MDB4629AWS - Jetclean Plus 24 in. Dishwasher Manual de usuario

Maytag

Maytag MDB7709AWB0 Manual de usuario

Maytag

Maytag MDB4621AWB - Full Console Dishwasher Instrucciones de uso

Maytag

Maytag MDB8859AWB0 Manual de usuario

Maytag

Maytag MDB7851AWB - 24 Inch Full Console Dishwasher Manual de usuario

Maytag

Maytag 6 915928 A Manual de usuario

Maytag

Maytag BUILT-IN DISHWASHER Manual de usuario

Maytag

Maytag DWU9921AAE Manual del propietario

Maytag

Maytag MDB4709AWQ Manual de usuario

Maytag

Maytag MDB9150AWW Manual de usuario

Maytag

Maytag MDBTT75AWS Manual de usuario

Maytag

Maytag MDB6769AWS4 Manual de usuario

Maytag

Maytag W10255025A Manual de usuario

Maytag

Maytag MDB6709AWQ1 Manual de usuario

Maytag

Maytag MDB/C-2 Manual de usuario

Maytag

Maytag MDB6759AWW - 24 Inch Fully Integrated... Manual de usuario

Maytag

Maytag Dishwasher Manual de usuario

Maytag

Maytag Dishwasher Manual de usuario

Maytag

Maytag Jetclean 9502 Manual de usuario

Maytag

Maytag MDB8859AWB - Jetclean Plus 24 in. Dishwasher Manual de usuario

Maytag

Maytag MDB9750BWW - 24 Inch Full Console Dishwasher Manual de usuario

Manuales populares de Lavavajillas de otras marcas

Electrolux

Electrolux ESI5211LOX Manual de usuario

KitchenAid

KitchenAid KUDB230B Manual de usuario

Brandt

Brandt BDJ424DB Manual de usuario

Asko

Asko DSD767UXXL.AU Manual de usuario

Beko

Beko DFN26210W Manual de usuario

NEFF

NEFF S153ITX00E Hoja de especificaciones

Midea

Midea SV 4.45 wi Manual de usuario

LG LDF7932 Manual de usuario

Gorenje

Gorenje GV63214 Manual de usuario

Hotpoint

Hotpoint HDA1100ZWH Manual de servicio

Blomberg

Blomberg LDFN2240W Manual de usuario

AEG

AEG FFB83836PM Manual de usuario

Cylinda

Cylinda DM3220RFD Manual de usuario

Atag

Atag DW8214MB Manual de usuario

GE GLD8000 Series Manual de usuario

Siemens

Siemens SN23HI02KE Hoja de especificaciones

Omega

Omega ODW717X Manual de usuario

BORETTI

BORETTI BVW-683 Manual de usuario
