MaxFoot MF-30 Manual de usuario
First of all, we would like to thank you for choosing our MaxFoot electric bike. We believe this technology,
with the benefits of electric propulsion, provides you with the perfect vehicle to increase your personal
mobility.
Our gear, brushless, electric hub motor allows you to run errands or to commute to work while saving
money on gas and reducing your environmental impact on our world. It also gives you an opportunity
to pedal if you want to exercise along the way.
We are here to help!
Maxfoot Electric Bike Help Center: https://maxfoot.zendesk.com/hc/en-us
Email: [email protected]
Phone: 1-818-305-6122
Thanks for Riding Maxfoot!
01
B I K E
PLEASE REGISTER YOUR MAXFOOT ELECTRIC BIKES AT
https://maxfoot.bike/pages/register-your-maxfoot
Facebook Maxfoot Owners Group
https://www.facebook.com/groups/maxfoot
Register Your MaxFoot Electric Bikes to Join MaxFoot
02
This manual contains detailed information about the product, its equipment, and information about
operation, maintenance and other useful tips for the owner. Before installing and riding, you must read
this manual carefully and be familiar with this E-bike to ensure riding safety and prevent accidents. If
you have any questions, please contact Maxfoot.
This manual comes with a copy of the bike, please keep it in a safe place for reference when needed.
However, all contents in this manual are subject to change or withdrawal without notice.
Please visit https://maxfoot.zendesk.com/hc/en-us to view and download the latest version.
Maxfoot will make every effort to ensure the accuracy of its documentation, but Maxfoot will not be
held responsible for any errors or inaccuracies.
The assembly of the Maxfoot electric bicycle is very simple, but if difficulties are encountered during
the assembly or the bike needs to be debugged, it is recommended that a certified and reputable
bicycle mechanic complete it.
Since it is impossible to predict every situation or situation that may occur during riding, this manual
does not represent the safe use of bicycles under all conditions. The risks associated with the use of
any bicycle cannot be predicted or avoided and are borne by the cyclist.
Using This Manual
03
Warning
----------------------------------------------------02
----------------------------------------------------03
----------------------------------------------------05
----------------------------------------------------11
----------------------------------------------------17
----------------------------------------------------19
----------------------------------------------------25
----------------------------------------------------26
----------------------------------------------------29
----------------------------------------------------30
----------------------------------------------------34
----------------------------------------------------37
----------------------------------------------------38
----------------------------------------------------42
----------------------------------45
----------------------------------------------------46
Register Your MaxFoot
Warning
General Info
Assembly Instructions
Adjusting the Seat
Battery Instructions
Handlebar Features
Using LCD Display
Brak Light
Other Considerations
Troubleshooting
Tyre inflation and replacement
Warranty and Safety
Dispute
Links to Assembly Video and Online Resources
Writing in Last
04
Index
----------------------------------------------------02
----------------------------------------------------03
----------------------------------------------------05
----------------------------------------------------11
----------------------------------------------------17
----------------------------------------------------19
----------------------------------------------------25
----------------------------------------------------26
----------------------------------------------------29
----------------------------------------------------30
----------------------------------------------------34
----------------------------------------------------37
----------------------------------------------------38
----------------------------------------------------42
----------------------------------45
----------------------------------------------------46
05
General Info
Assembly and Fit
The correct assembly of the bicycle is the basis for the safety, performance and comfort of the bicycle.
Please make sure your bike is correctly assembled before riding. Any questions, please feel free to
contact Maxfoot or seek help from a nearby bike shop.
NOTICE: If you do not have the experience, skill, and tools to complete assembly and fit, we recom-
mend having a certified, reputable bike mechanic complete these procedures as well as any future
adjustments or tuning.
Mandatory Equipment and Use Locations
Before each ride, please make sure you have all the necessary safety equipment and comply with the
relevant laws in your area. Maxfoot does not promote any riding behavior that violates the law.
Changing Components or Attaching Accessories
The use of non-original components or spare parts can jeopardize the safety of your ebike, void your
warranty, and, in some cases, cause your ebike to not conform with laws pertaining to your bike.
M-70
General Info
Safety Check Before Each Ride
In addition to regular maintenance, you should also check the condition of your bicycle before each
ride. Any questions, please contact Maxfoot or seek help from a nearby bicycle shop. For more
information, please check the safety checklist before riding.
Electrical System
The electrical system on the electric bicycle is powered by the battery to provide various auxiliary functions
for the rider. Riders should be familiar with the electrical parts of electric bicycles and check them before
riding to ensure safe and comfortable riding.
The front and rear brake levers are equipped with a power cut-off system, which cuts off the motor’s
assistance when in use. Before riding, you should check the mechanical parts of the brake lever and
the power cut-off system to ensure that they are all operating normally.
The throttle is equipped with a switch, please make sure the switch function is normal before use.
When using the throttle, you should twist it slowly. It is not advisable to fully twist the throttle at one time,
otherwise it may cause current overload and trigger the battery overload protection.
If the throttle, brake lever cutoff switches, pedal assistance, or lighting are functioning abnormally,
intermittently, or not working, please discontinue using your ebike immediately and contact the Maxfoot
Support team for assistance.
06
07
General Info
Quick Release Levers
The seat of the electric trike adopts a quick-release structure, which is convenient for the rider to disassemble
or adjust it without tools. Since the quick release lever may become loose during transportation or
riding, regular inspections are necessary.
Tires and Wheels
The wheels should always keep straight when rotating. Once it is found to rotate left or right, swing up
or down, please stop riding immediately and repair or replace it.
Please regularly check whether the tire pressure is sufficiently. When inflating the inner tube, please
ensure that the air pressure inside the tire is the recommended air pressure value, otherwise it will
reduce the tire performance, cause damage to the parts, and affect riding safety.
Suspension, Handlebar, Grips, and Seat Adjustments
The suspension fork will affect the operation and experience of riding, so if you find that the suspension
fork is not working properly, please contact Maxfoot for replacement in time. Make sure that the handlebar
is aligned with the handlebar rod and installed correctly. The height and angle of the handlebars should
be adjusted to suit the rider before riding. If the handlebar cannot be fixed, please contact Maxfoot to
purchase replacement parts. Before riding, make sure that the saddle and seat post are properly
installed and fastened to the trike through the quick release device.
M-70
General Info
Battery Charged, Secured, and Unplugged
Before riding, make sure that the battery is fully charged and can work normally, and corresponds to
the data displayed on the LCD display.
Before riding, make sure that the input and output ends of the charger are disconnected from the
socket and battery, and then place them in a safe place.
Please check and make sure that the battery is correctly locked on the battery holder before using,
otherwise dangerous situations such as battery ignition may occur.
08
09 Maxfoot MF-30 Electric Trike
Fully Assembled MF-30
