1. Specifics
1.1. Outdoor units specifics
Models
BD2M53A3 BD3M98A3
Power supply V- Ph, Hz 230V 220 ~ 240V , 50Hz
kW 5,0(2,0~6,3) 7,0(2,0~10,0)
Capacity Btu/h 17,0(6,9~21,5) 24,2(6,8~34,1)
Power input kW 1,5(0,5~2,5) 2,15(0,6~4,5)
Absorbed current A 6,8 10,9
Cooling
S.E.E.R. W/W 5,60-A+ 5,10-A
kW 5,6(2,5~6,6) 8,5(3,2~11,0)
Capacity Btu/h 19,1(8,5~22,6) 29,0(10,9~37,5)
Power input kW 1,5(0,5~2,7) 2,28(0,8~3,9)
Absorbed current A 6,8 11,4
Heating
S.C.O.P. W/W 3,80-A 3,80-A
Compressor trademark ZHUHAI LANDA COMPRESSOR CO. LTD
Compressor model QXA-B141zF030A QXAS-D23zX090B
Compressor type DC inverter Rotary
Compressor oil RB68EP
Comp. oil charge L 0,39 0,95
L.R.A.
Compressor RLA A 7,2 11,5
Compressor input W 1440 2550
Compressor capacity 4320 7250
Comp. Overload protector 1NT11L-6233
Throttling method Electronic expansion valve
Starting method Transducer starting
Working temp range °C -15°C ≤T ≤48°C
Condenser material Aluminum fin-copper tube
Rows-Fin Gap mm 2-1.4
Coil length (l) x height (H) x coil width (L) mm 851 x 660 x 38,1 982,2 x 748 x 38,1
Fan motor apeed rpm 880/700/500 690/600/500
Output of fan motor W 60
Fan Motor RLA A 0,56 0,6
Fan motor capacitor μF 4 3,5
Outdoor air flow volume m3/h 2600/2300/1600 3300/2900/2400
Fan type-piece Axial fan –1
Fan diameter mm 520 552
Defrosting method Automatic defrost
Climate type T1
Isolation
I
Moisture protection IP24
Permissible excessive operating pressure for the discharge side Mpa 4,3
Permissible excessive operating pressure for the suction side MPa 2,5
Sound pressure level dB(A) 56/53/50 58/54/52
Sound power level dB(A) 66/63/60 68/64/62
Outline dimension mm 963 x 700 x 396 1001 x 790 x 427
Packing dimension mm 1029 x 458 x 750 1083 x 488 x 855
Net / Gross weight kg 50/55 96/74
Outdoor unit
Refrigerant charge kg R410A / 1,40 R410A / 2,2
Max. connection pipe length (for each indoor unit) m ≤20 ≤20
Difference in livel m 10 10
Gas additional charge g/m
Liquid Inch 1/4 1/4 1/4
Connection
pipe
Pipe out.
diameter Gas Inch 3/8 1/2
3/8
Operating temperature °C -15 ~ 48
