Mattel 32854-0920G1 Manual de usuario

32854-0920G1

OWNER’S MANUAL

Please read thoroughly before o erating your vehicle. Kee these instructions for future reference: they contain im ortant information.

❷

❹

❸

I. CONTENTS

•6.0V JET TURBO®

HARLEY-DAVIDSON®Vehicle

•Transmitter

•Display Stand (store vehicle on stand

when not in use)

FEATURES

•Full-function Transmitter

•27 MHz or 49MHz

•Range up to 65’/20m

VEHICLE

❶Powerful Mabuchi Motor

❷ON/OFF Switch

❸ Battery Compartment

❹Battery Release Button

❺Functional Suspension (front)

❻Functional Suspension (rear)

❼Breakaway Rider Figure

❽Side Stabilizers (one each side)

TRANSMITTER

❶Left stick

(controls forward, “turbo”mode

and braking)

❷Right stick

(controls steering)

❸ Antenna

❹Power-On Indicator Light

❶

❺

❹❸

❼

❽

❷

❻

❶

®®

CAUTION:

Surfaces

may become hot and cause burns if

electronics get wet. Do not operate

vehicle through water or snow.

❺

❶

❸❹

❷

❻❼

❶

II. QUICK START

Please read this Owner’s

Manual thoroughly.

1. Start with a full charge.

2. Turn vehicle switch ON. Activate

transmitter to run and control your

vehicle.

3. When you’re done driving, turn vehi-

cle switch OFF. Remove all batteries

for storage.

❶FORWARD

❷FORWARD “TURBO”

❸BRAKING

❹WIDE LEFT TURN

❺SHARP LEFT TURN

❻WIDE RIGHT TURN

❼SHARP RIGHT TURN

IV. SPECIAL DRIVING

CONTROLS & FEATURES

❶STANDING START

Set your vehicle on the ground, leaning

on one of its side stabilizers. Push the

left stick forward to drive straight

ahead.

❷LAUNCH-START

Hold your vehicle steady on the ground

(keeping your fingers clear of the wheel

hubs). Gently guide your vehicle forward

while pushing the left stick forward.

❸“SCREECHING” STOP

While driving forward, quickly jam the

left stick back. Your vehicle will brake

to a quick stop with one of its side sta-

bilizers on the ground.

❹ GLIDE-STOP

While driving forward, release the sticks.

Your vehicle will glide to a stop with one

of its side stabilizers on the ground.

❺TURNING CIRCLE

Your vehicle’s “normal”turning circle is

about 30’/9m. For tighter circles, try

steering in the direction of the turn

while “pulsing”the left stick forward.

(This may take a little practice!)

❻BREAKAWAY RIDER FIGURE

Don’t operate your vehicle without the

breakaway rider figure attached: the

vehicle won’t balance properly without

it. The figure is designed to break away

on impact. To reattach the figure, snap

the figure into the seat, then rotate into

upright position as shown.

III. OPERATING YOUR VEHICLE

❹

❷

❸

❺

❻

STOP

30'/9m

NOTE: vehicle antenna extends

up through rider figure.

VI. POWER SYSTEM

(Batteries and Charger Not Included)

FOR DETAILED INFORMATION

REGARDING VEHICLE BATTERY

CHARGING AND SAFETY, PLEASE FOL-

LOW THE SPECIFIC INSTRUCTIONS

THAT CAME WITH YOUR BATTERY

PACK AND CHARGER.

Your vehicle will not operate without a

6.0V rechargeable NiCd battery pack

and charger. For best results, use only

a TYCO®R/C battery pack and charger.

To install the battery pack in this vehi-

cle, please refer to Section VII, “Bat-

tery Installation.”

Your vehicle is compatible with both

the TYCO®R/C Flash Charge™battery

pack and charger AND the TYCO®R/C

6.0V Jet Turbo®battery pack and

charger. The Flash Charge™power

system charges 8 TIMES FASTER than

conventional chargers…and less

charge time means MORE driving time!

PICK UP AN EXTRA BATTERY!

Charge additional battery packs ahead

of time for longer non-stop action!

V. QUICK TIPS

❶When your vehicle starts to lose

power, it may lose functions or per-

formance. It’s time for a recharge.

Your vehicle’s running time may

change depending on your driving

style.

❷Radio interference can make your

vehicle run badly. Interference can

be caused by other R/C vehicles

running on the same frequency;

electrical wires; large buildings; or

CB radios. Try to stay away from

these!

❸Point your transmitter antenna up -

not down toward your vehicle. If

your vehicle gets too far away, it

won’t work properly.

❹Don’t drive your vehicle in sand or

through water or snow. After dri-

ving, remove any water from your

vehicle, wipe with a towel and

allow to dry completely.

❺Don’t store your vehicle near heat

or in direct sunlight. Always turn

switches OFF and remove all batter-

ies for storage.

❺❹❶❷❸

™

ALSO AVAILABLE

VII. BATTERY INSTALLATION

VEHICLE

❶Hold the battery pack upright with

contacts as shown. Push the bat-

tery pack straight up into the vehi-

cle’s battery compartment from

below, making sure the battery

pack clicks securely into place.

❷To remove the battery pack, hold

the vehicle upright on a table or

other surface. Press the battery

release button to release the bat-

tery pack.

Estimated run time for this vehicle:

approximately 30 minutes

TRANSMITTER

❶Install one 9-volt battery with

polarity (+/-) as shown inside bat-

tery compartment.

❷The 9-volt transmitter battery will

last much longer than the run time

of the rechargeable NiCd battery

pack.

VIII. SAFETY INFORMATION

Adults, this toy is recommended for

children 5 years of age and older. To

ensure that the child’s play is both safe

and fun, please review the operating

instructions and these general safety

rules with the child.

SAFETY TIPS

•DO NOT pick up vehicle while in

motion.

•Keep fingers, hair and loose clothing

away from the tires, wheel hubs and

socket while the vehicle is switched

ON or the transmitter is in operation.

•If this toy is being operated in the

presence of young children, adult

supervision is recommended.

•To avoid accidental operation, remove

all batteries when not in use.

•DO NOT operate your vehicle on

streets! They are for real cars.

THIS PRODUCT USES A NICKEL-CADMIUM RECHARGEABLE BATTERY PACK. BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY.

FOR FURTHER INFORMATION REGARDING BATTERIES OR THEIR DISPOSAL PLEASE CALL 1-888-557-TYCO.

IMPORTANT DISPOSABLE BATTERY

INFORMATION

Insure that battery polarity is cor-

rect.

Use only batteries of the type rec-

ommended (or equivalent).

Do not mix old and new batteries.

Do not mix alkaline, standard (car-

bon-zinc), or rechargeable (nickel-

cadmium) batteries.

Remove used-up batteries immedi-

ately. Remove batteries if vehicle

will not be used for a long period.

For best performance use alkaline

batteries (where disposable batter-

ies are called for). Battery life may

vary depending on battery brand.

Do not recharge non-rechargeable

batteries.

Do not short-circuit terminals.

Remove rechargeable batteries

before recharging. Recharge batter-

ies only under adult supervision.

Dispose of batteries safely.

SYMPTOM

Vehicle runs slowly or will not run.

Erratic operation or only short range possible.

Short battery life.

Vehicle doesn't work after going through water

or snow.

PROBABLE CAUSE

• Loose battery connection or vehicle switch

not ON.

• Weak or uncharged rechargeable battery.

• Weak transmitter battery.

• Radio interference likely.

• Battery not fully charged.

• Water in the electronics area.

CORRECTION

• Check battery connector and vehicle switch.

• Charge battery or re lace.

• Re lace with fresh alkaline battery.

• Change location (see oint 2 – Quick Ti s)

• Hold transmitter above waist level, with

antenna not touching other objects (see

oint 3 – Quick Ti s)

• Recharge NiCd battery ack. For maximum

running time, make sure you give your bat-

tery ack a full charge.

• Vehicle will take several hours to dry. Allow

to dry com letely overnight before trying

again.

• O erate your vehicle in a dry area. Avoid

driving in water and snow.

NJ 08054 U.S.A.

PRINTED IN CHINA. All Rights

Reserved. ® and ™ designate U.S.

trademarks of Mattel, Inc.

Retain this address for future refer-

ence: Mattel U.K., Ltd., Vanwall Busi-

ness Park, Maidenhead SL6 4UB. Mat-

tel Australia Pty., Ltd., Richmond, Victo-

ria 3121 - Consumer Advisory Service:

1800 800 812 (valid only in Australia).

Mattel East Asia Limited, 930 Ocean

Centre, Harbour City, HK, China.

Produced under license from Harley-

Davidson Motor Company.

Harley-Davidson, Softail, Harley, Fat

Boy, and the Bar & Shield are regis-

tered trademarks of H-D Michigan, Inc.

COMPLIANCE WITH FCC REGULA-

TIONS

THIS DEVICE COMPLIES WITH PART 15

OF FCC RULES. OPERATION OF THIS

DEVICE IS SUBJECT TO THE FOLLOW-

ING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE

HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY

HARMFUL INTERFERENCE THAT MAY

CAUSE UNDESIRED OPERATION.

This device generates and uses radio

frequency energy and if not used prop-

erly may cause interference to radio

and television reception. It has been

tested and found to comply with the

limits set by the FCC, which are

designed to provide reasonable protec-

tion against such interference.

CAUTION: Changes or modifica-

tions not expressly approved by the

manufacturer responsible for compli-

ance could void the user’s authority to

operate the equipment.

Tabla de contenidos

Otros manuales de Juguete de Mattel

Mattel

Mattel Fisher-Price GWL84 Manual de usuario

Mattel

Mattel DIVA STARZ 55200-0920 Manual de usuario

Mattel

Mattel DC Super Hero GIRLS Manual de usuario

Mattel

Mattel Barbie R4300 Manual de usuario

Mattel

Mattel HOTWHEELS DWL04 Manual de usuario

Mattel

Mattel Fisher-Price M7596 Manual de usuario

Mattel

Mattel HotWheels COLOR SHIFTERS CITY OCTO BATTLE... Manual de usuario

Mattel

Mattel Barbie Doggie Park Kittens Manual de usuario

Mattel

Mattel Barbie Let's Play R4205 Manual de usuario

Mattel

Mattel Disney PIXAR LIGHTYEAR HJJ29 Manual de usuario

Mattel

Mattel Barbie Dream House GRG93 Manual de usuario

Mattel

Mattel Cookstruction MEGA MIXER Manual de usuario

Mattel

Mattel Disney Princess Color Magic X9383 Manual de usuario

Mattel

Mattel Barbie Riding Club Barbie & Walking Beauty Gift... Manual de usuario

Mattel

Mattel Barbie J9500 Manual de usuario

Mattel

Mattel HOTWHEELS RACE CRATE Manual de usuario

Mattel

Mattel HotWheels ROBO-LIFT SPEED SHOP Manual de usuario

Mattel

Mattel Hot Wheels CAR CRUSH HIGHWAY Manual de usuario

Mattel

Mattel Barbie J8955 Manual de usuario

Mattel

Mattel Hot Wheels Star Wars FLIGHT CONTROLLER Manual de usuario

Mattel

Mattel Barbie M3971 Manual de usuario

Mattel

Mattel JURASSIC WORLD CAMP CRETACEOUS EPIC ROARIN TYRANNOSAURUS... Manual de usuario

Mattel

Mattel Disney/PIXAR TOY STORY SHERIFF WOODY Manual de usuario

Mattel

Mattel Polly Pocket SECRET UTILITY VEHICLE FWY26 Manual de usuario

Manuales populares de Juguete de otras marcas

marklin

marklin 37321 Manual de usuario

Canon

Canon PAPER CRAFT Manual de usuario

GREAT PLANES

GREAT PLANES Pitts M-12S Manual de usuario

NOCH

NOCH 14261 Manual de usuario

Hausler

Hausler 450 SE V2 Manual de usuario

Dynaflite

Dynaflite Daydream Manual de usuario

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Manual

Kenner

Kenner Batman 63651 Manual de usuario

LEGO

LEGO 8527 Manual de usuario

iKarus

iKarus ECO 8 Manual de usuario

Multiplex

Multiplex EasyStar II Manual de instrucciones

Walkera

Walkera 38 Manual de instrucciones

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE Manual de usuario

MD MXION SWD Manual de usuario

marklin

marklin 39671 Manual de usuario

Meccano

Meccano 15103 Manual de usuario

LEGO

LEGO TECHNIC 8735 Manual de usuario

REVELL

REVELL Bristol Beaufighter TF.X Manual de usuario
