Masterflex I/P Series Manual de usuario

MASTERFLEX®I/P®SERIES

PRECISION MODULAR DRIVES

Quick Start Guide

Product Accessories

Bench Top Model 07591-20 Only

77595-35 Footswitch DB-9

07595-45 Connector, DB-9 Remote Control

07595-47 Cable, Remote Control DB-9, 25 FT.

07557-51 Cable, Motor Extension, 9 FT.

NEMA Wall-Mount Model 07591-30 Only

07595-43 Footswitch, Washdown

77300-32 Cable, Remote Control Washdown, 25 FT.

07557-51 Cable, Motor Extension, 9 FT

Replacement Cord/Plug Sets Ordering Information

Catalog

Number

Catalog

Number

Catalog

Number

Description Description Description

50001-60

50001-62

50001-64

50001-68

50001-69

50001-70

50001-72

50001-74

50001-76

50001-78

—

Australia

Denmark

India

U.S. STD. 115V

Israel

Europe

England

Switzerland

Italy

U.S. 230V

—

DANGER: Remove power from the pump before any cleaning operation is started.

High voltages exist and are accessible. Use extreme caution when servicing internal

components

WARNINGS: Remove power from the pump before attempting any maintenance.

A contactor or other device that routinely disconnects and reapplies the AC line to

the drive to start and stop the motor can cause drive hardware damage. The drive is

designed to use control input signals that will start and stop the motor.

WARNINGS: Tubing breakage may result in fluid being sprayed from pump. Use

appropriate measures to protect operator and equipment.

Turn Pump System off before removing or installing tubing. Fingers or loose clothing

could be caught in drive mechanism.

CAUTIONS: When changing flow direction, allow the pump to come to a complete stop

before starting again. Failure to do so could cause permanent damage to the motor.

Replace the fuse only with one of the same type and rating. The fuse rating and type are

stated on the rear panel.

CAUTIONS: To avoid electrical shock, the power cord protective grounding conductor

must be connected to ground. Not for operation in wet locations as defined by EN61010-1.

If the product is not used in a manner specified in the instructions, the protection

provided by the equipment may be impaired.

CAUTION: Risk of Danger. Consult Operator’s manual for nature of hazard and corrective

actions.

CAUTION: Risk of crushing. Keep fingers away from rotor while pump is in operation. Stop

pump before loading or unloading tubing.

CAUTION: Hot Surface. Do not touch.

CAUTION: Risk of electric shock. Consult Operator’s manual for nature of hazard and

corrective actions.

This product is not designed for, nor intended for use in patient connected applications;

including, but not limited to, medical and dental use, and accordingly has not been

submitted for FDA approval.

This product is not designed for, nor intended for use in hazardous duty areas as

defined by ATEX or the NEC (National Electrical Code); including, but not limited to

use with flammable liquids. Consult the factory for products suitable for these types of

applications.

SAFETY

PRECAUTIONS

Explanation of

Symbols !

WARNING:

Product Use

Limitation

year

warranty

70 dba @ 1M

-25C, -13F +65C, +149F

+0C, +32F +40C, +104F

EN809 MACH. DIR.

EN61010-1 L.V. DIR.

EN61326-1 EMC DIR.

EN60529 / IEC 60034-5

07591-20

21.8 lbs. (9.88 kg)

07591-20

39.7 lbs. (18.0 kg)

IP 07591-20 IP33

07591-30 IP66 (NEMA 4X)

6-650 rpm

US & Canada only

Toll Free 1-800-MASTERFLEX | 1-800-637-3739

Outside US & Canada

1-847-549-7600 | 1-847-381-7050

*EN809 manufactured by:

Cole-Parmer Instrument Company

28W092 Commercial Avenue, Barrington, IL 60010

[email protected] | www.masterflex.com

A-1299-1086B Edition 03

I/P Precision Pump

System with

I/P Easy Load Head

77962-20

I/P Nema Precision Pump

System with

I/P Easy Load Head

77962-30
