TECHNICAL MANUAL

for ELECTROMECHANICAL CC 875

ELECTRONIC CC 875 L and CC 875 E

CASSETTE SPLIT SYSTEMS

This manual provides technical and installation information for

ELECTROMECHANICAL CC 875,ELECTRONIC CC 875 L and CC 875 E systems:-

INDOOR UNIT: 555 series CC 875, CC875 L or CC875 E

MATCHED WITH: 550 series MCU+ Condensing Units (MCUP=MCU+ in Germany)

551 series MHPUE or MHPUL Heat Pump Units

542 series DCUE Ducted Condensing Units

INDEX PAGE

GENERAL Part numbers, dimensions and weights 2 - 3

Features/accessories, unit combinations 4

SELECTION Performance data, optional heating, airflows 5 - 6

Discharge velocities, fresh air supply 6

Branch duct, discharge blanking 7

ELECTRICAL Electrical Data 7 - 9

Recommended Fuse Sizes 10

SOUND LEVELS Sound Pressure/Sound Power Levels 11

UNIT CC 875 unpacking 12

INSTALLATION Dimensions, weights, chassis removal 13

Pipework, restrictors 14

Condensate drain 15

Air outlet blanking, fitting the fascia 16

MCU+/MHPUE/MHPUL installation 17

DCUE installation 18

Pipe sizing 19

Electrical supply and interconnecting options 21

CC875 fan speed selection 21

CC875 L PCBA configuration 22

Outdoor unit supply wiring, fire link 22

Remote controller CC 875 23

CC 875 L 23

CC 875 E 24

Evacuating and charging 25

Additional refrigerant and oil 26

Check list 27

WIRING CC 875 units 28 - 29

DIAGRAMS Condensing units and heat pumps 30 - 37

Interconnecting wiring 38 - 40

OPERATING CC 875 41

INSTRUCTIONS CC 875 L 42 - 43

CC 875 E 44 - 47

IMAGE 875 Electric heater kits 48

KITS 5m high condensate pump 52

BMS interface kit 55

Fresh air inlet 56

Adjacent room discharge spigot 57

Remote temperature sensor kit 58

EMC termination Kit (CC 875 E units only) 59

Vane Motor Kit 60 - 61

COMPONENT Exploded views showing components 62 - 65

IDENTIFICATION

FAULT FINDING All units 66 - 68

TEV Ltd.

Armytage Road, Brighouse,

West Yorkshire. HD6 1QF

Tel: +44 (0) 1484 405600

Fax: +44 (0) 1484 405620

E-mail: [email protected] 55508037-07

Heronhill - for all your Marstair requirements

Tel: 01823 665660

www.heronhill.co.uk

Fax: 01823 665807

CEILING CASSETTE 875 Split Systems

The CC 875 CASSETTE range of split systems consists of the 555 series CC875 cassette indoor units matched with 550

series condensing units, 551 series heat pump outdoor units, 542 series electronic ducted condensing units.

By choosing appropriate combinations, the installer can provide:

AIR CONDITIONERS with a cooling range of 7.1-13.9 kW,

or HEAT PUMPS with a cooling range of 7.8-13.5 kW, and a heating range of 8.4 -14.5 kW (7°C outdoors)

PART NUMBERS

CC875 COOL AND HEAT PUMP MODELS

Fitted with lift pump Fitted with condensate pump

Electronic L 80L 110L 140L 80L 110L 140L

part number 55522013 55522014 55522015 55522028 55522029 55522030

Electronic E 80E 110E 140E 80E 110E 140E

Part Number 55522016 55522017 55522018 55522031 55522032 55522033

CC875 COOL ONLY MODELS Fitted with lift pump Fitted with condensate pump

Electromechanical 80 110 140 80 110 140

Part Number 55522001 55522002 55522003 55522019 55522020 55522021

Electronic L 80L 110L 140L 80L 110L 140L

Part Number 55522004 55522005 55522006 55522022 55522023 55522024

Electronic E 80E 110E 140E 80E 110E 140E

Part Number 55522007 55522008 55522009 55522025 55522026 55522027

CC875 FASCIA

All models 55522000

550 Series CONDENSING UNITS (MCU/MCU+)

MCU+ 1Ph MCU+60 MCU+80 MCU+90

R407C 55022007 55022008 55022009

R22 55022029 55022030 55022031

MCU+ 3Ph MCU+60 MCU+80 MCU+90 MCU+100 MCU+130 MCU+150

R407C 55022014 55022015 55022016 55022017 55022018 55022019

R22 55022035 55022036 55022037 55022038 55022039 55022040

551 Series HEAT PUMP UNITS (MHPUL) 551 Series HEAT PUMP UNITS (MHPUE)

MHPUL 1Ph MHPUL 80 MHPUE 1Ph MHPUE 80

R407C 55122046 R407C 55122007

R22 55122064 R22 55122025

MHPUL 3Ph MHPUL 80 MHPUL 100 MHPUL 150 MHPUE 3Ph MHPUE 80 MHPUE 100 MHPUE 150

R407C 55122052 55122054 55122186 R407C 55122013 55122015 55122184

R22 55122070 55122072 55122187 R22 55122031 55122033 55122185

542 Series DUCTED CONDENSING UNITS (DCUE)

DCUE 1Ph DCUE 60 DCUE 80

R407C 54200032 54200033

R22 54200007 54200008

DCUE 3Ph DCUE 60 DCUE 80

R407C 54200038 54200039

R22 54200018 54200019

Heronhill - for all your Marstair requirements

Tel: 01823 665660

www.heronhill.co.uk

Fax: 01823 665807

UNPACKED DIMENSIONS and WEIGHTS

CEILING CASSETTE 875 (inc. fascia)

Model CC 875

80 110 140

HEIGHT mm 314 314 314

WIDTH mm 880 880 880

DEPTH mm 967 967 967

WEIGHT kg 36 40 44

CONDENSING UNITS

Model MCU + 60 MCU + 80 MCU + 90 MCU + 100 MCU + 130 MCU + 150

HEIGHT mm 720 720 820 820 1080 1080

WIDTH mm 1000 1000 1000 1000 1000 1000

DEPTH* mm 300 300 350 350 425 425

WEIGHT

kg 1 Ph 65 66 76 - - -

3 Ph 63 64 73 81 101 103

HEAT PUMP OUTDOOR UNITS DUCTED CONDENSING UNITS

Model MHPUL(E) 80 MHPUL(E) 100 MHPUL(E) 150 Model DCUE 60 DCUE 80

HEIGHT mm 820 1080 1080 HEIGHT mm 625 625

WIDTH mm 1000 1000 1000 WIDTH mm 1245 1245

DEPTH* mm 350 425 425 DEPTH mm 565 565

WEIGHT

kg 1 Ph 75 - - WEIGHT kg 81 84

3 Ph 72 101 106

* excluding 10mm grille

PACKED DIMENSIONS AND WEIGHTS

CEILING CASSETTE 875 Units

Model CC 875 chassis CC 875 fascia

80 110 140 80 / 110 / 140

HEIGHT mm 385 385 385 100

WIDTH mm 1120 1120 1120 1060

DEPTH mm 930 930 930 1060

WEIGHT kg 41 45 49 8

CONDENSING UNITS

Model MCU + 60 MCU + 80 MCU + 90 MCU + 100 MCU + 130 MCU + 150

HEIGHT mm 725 725 825 825 1085 1085

WIDTH mm 1080 1080 1090 1090 1090 1090

DEPTH mm 340 340 390 390 465 465

WEIGHT

kg 1 Ph 67 68 78 - - -

3 Ph 65 66 75 83 105 107

HEAT PUMP OUTDOOR UNITS DUCTED CONDENSING UNITS

Model MHPUL(E) 80 MHPUL(E) 100 MHPUL(E) 150 Model DCUE 60 DCUE 80

HEIGHT mm 825 1085 1085 HEIGHT mm 660 660

WIDTH mm 1090 1090 1090 WIDTH mm 1270 1270

DEPTH mm 390 465 465 DEPTH mm 610 610

WEIGHT

kg 1 Ph 77 - - WEIGHT kg 86 90

3 Ph 74 105 107

Heronhill - for all your Marstair requirements

Tel: 01823 665660

www.heronhill.co.uk

Fax: 01823 665807

UNIT COMBINATIONS

Combinations of indoor unit and (ducted) condensing/heat pump unit can be chosen to give either air conditioning or heat

pump systems.

Air Conditioning Systems Heat Pump Systems

CC 875 MCU + DCUE CC875L MHPUL

80 60 60 80 80

80 80 80 110 100

110 80 80 140 150

110 90 -

110 100 - CC875E MHPUE

140 100 - 80 80

140 130 - 110 100

140 150 - 140 150

FEATURES/ACCESSORIES

INDOOR UNITS

CC 875 CC 875 L CC875 E

Electric heating ** *

Automatic air deflection (vane motor) ** *

De-ice thermostat / sensor STD STD STD

2 fan speed combinations STD STD STD

Remote infrared control -STDSTD

Remote hard wired control STD - STD

0.5m lift pump FFO FFO FFO

5m high condensate pump FFO / * FFO /*FFO /*

Fresh air duct spigot ** *

Branch duct spigot ** *

Programmable timer *STD STD

Long life washable filter STD STD STD

BMS alarm interface -- *

EMC termination kit -- *

Remote temperature sensor STD **

STD = standard FFO = factory fitted option *= site option --- = not available

OUTDOOR / DUCTED UNITS MCU+ MHPUL MHPUE DCUE

Fan speed head pressure control STD STD STD STD

HP cutout auto (with manual backup) --STDSTD

HP cutout auto STD STD --

HP cutout manual **--

LP cutout auto STD STD STD STD

3 minute start time delay STD STD STD STD

Low ambient start STD STD STD STD

Random start STD STD STD STD

Volt free relay (for remote alarm) ***-

Contactor STD STD STD STD

Overload 1Ph (standard on 3Ph) ****

Isolator (for remote mounting) ****

Isolator mounted on unit ---*

Wall mounting brackets ****

MHPUL(E) condensate drain tray --**-

Ducting kits ---*

Compressor jacket ***-

*= site option STD = standard - = not available

Heronhill - for all your Marstair requirements

Tel: 01823 665660

www.heronhill.co.uk

Fax: 01823 665807

AIR CONDITIONER PERFORMANCE DATA (kW)

Note that there are two speed ranges, each giving a low, medium and high speed.

Range 2 = for higher duties

Range 1 = for lower noise levels

UK conditions

Room 21°C/15°C

Ambient 27°C/19°C

Eurovent (NEMA)

Room 27°C/19°C

Amb 35°C/24°C

RANGE 2 Low Medium High High

RANGE 1 Low Medium High

CC 875 MCU+

MCUP

DCUE TOT SHR SENS TOT SHR SENS TOT SHR SENS TOT SHR SENS TOT SHR SENS

80 60 5.9 0.80 4.7 6.1 0.84 5.1 6.3 0.86 5.5 6.6 0.89 5.9 7.1 0.86 6.1

80 80 6.3 0.79 4.9 6.4 0.82 5.3 6.9 0.85 5.9 7.1 0.84 6.0 7.8 0.81 6.3

110 80 7.1 0.74 5.2 7.1 0.79 5.6 7.4 0.81 6.0 7.6 0.86 6.5 8.7 0.81 7.0

110 90 7.5 0.74 5.5 7.6 0.75 5.7 7.7 0.78 6.1 8.0 0.79 6.3 9.9 0.77 7.6

110 100 8.9 0.70 6.2 9.0 0.72 6.5 9.1 0.74 6.7 9.9 0.77 7.6 11.0 0.73 8.0

140 100 9.0 0.73 6.5 9.4 0.73 6.9 10.0 0.74 7.4 10.3 0.76 7.9 11.7 0.75 8.8

140 130 10.1 0.67 6.7 10.2 0.69 7.0 10.4 0.72 7.5 10.5 0.75 7.9 12.8 0.71 9.1

140 150 10.2 0.67 6.8 10.3 0.69 7.1 10.9 0.71 7.7 11.3 0.72 8.1 13.9 0.69 9.6

HEAT PUMP PERFORMANCE DATA (kW)

a. Cooling (Max. speed outdoor unit fan)

UK conditions

Room 21°C/15°C

Ambient 27°C/19°C

Eurovent (NEMA)

Room 27°C/19°C

Ambient 35°C/24°C

Range 2 Low Medium High High

Range 1 Low Medium High

CC 875 TOT SHR SENS TOT SHR SENS TOT SHR SENS TOT SHR SENS TOTAL SHR SENS

80L (E) 6.4 0.76 4.9 6.7 0.78 5.2 6.9 0.84 5.8 7.4 0.86 6.3 7.8 0.80 6.2

110L (E) 8.4 0.70 5.9 8.7 0.72 6.3 9.1 0.78 7.1 9.4 0.80 7.6 11.0 0.71 7.8

140L (E) 9.85 0.66 6.5 10.2 0.69 7.0 10.7 0.70 7.5 11.0 0.72 7.9 13.5 0.72 9.7

b. Heating (Max. speed outdoor unit fan)

Room 20°C/12°C Ambient 7°C (Eurovent rating) Room 20°C/12°C Ambient -1°C

Range 2 Low Medium High Low Medium High

Range 1 Low Medium High Low Medium High

CC 875 kW COP kW COP kW COP kW COP kW COP kW COP kW COP kW COP

80L (E) 7.1 2.7 7.1 2.6 7.6 2.8 8.4 2.9 5.2 2.1 5.3 2.1 5.5 2.3 5.8 2.3

110L (E) 9.4 2.8 9.8 2.9 10.5 3.0 11.8 3.2 6.5 2.2 6.6 2.3 6.9 2.4 7.2 2.6

140L (E) 11.4 2.5 11.7 2.5 12.8 3.0 14.5 3.3 9.3 2.3 9.4 2.4 9.6 2.7 9.7 2.7

OPTIONAL ELECTRIC HEATING (kW)

CC 875 All Models

240V 50Hz 1234

230V 50Hz 0.9 1.8 2.75 3.7

AIRFLOWS

Range 2 Low (Speed 2) Medium (Speed 3) High (Speed 4)

Range 1 Low (Speed 1) Medium (Speed 2) High (Speed 3)

CC 875 m3/s m3/s m3/s m3/s

80 0.33 0.37 0.45 0.54

110 0.32 0.36 0.45 0.53

140 0.30 0.35 0.43 0.50

Heronhill - for all your Marstair requirements

Tel: 01823 665660

www.heronhill.co.uk

Fax: 01823 665807

CEILING CASSETTE 875 AIR THROWS

AIRFLOWS OUTDOOR / DUCTED UNITS

MIN Speed MAX Speed Min. Speed Max. Speed

Model CFM m3/s CFM m3/s Model CFM m3/s CFM m3/s

MCU+ 60 - 1250 0.59 1660 0.78 DCUE 60 885 0.42 1115 0.53

MCU+ 80 - 1250 0.59 1660 0.78 DCUE 80 740 0.34 1040 0.48

MCU+ 90 MHPUL(E) 80 1440 0.68 2420 1.14

MCU+ 100 - 1440 0.68 2420 1.14 Note: On MCU+ and MHPUL the minimum speed

can fall to zero under fan speed control if the

ambient temperature is low

(to maintain good operating conditions).

MCU+ 130 MHPUL(E)100 2840 1.34 3690 1.74

MCU+ 150 MHPUL(E) 150 2840 1.34 3690 1.74

FRESH AIR SUPPLY (see page 56 for kit details)

CC 875 units are fitted with an inlet to allow the installer to provide a fresh air supply

The 100mm dia. spigot is available as kit 55200305.

The installer must provide ductwork, a screened source of fresh air and an auxiliary

fan.

The auxiliary fan must be sized to overcome the resistance of the filter, the ductwork

and the cassette itself. (To prevent excessive noise, the maximum fresh air volume

should be less than 5% of the nominal air volume for any given unit and fan speed).

The auxiliary fan should be connected to a separate electrical circuit, appropriately

fused and isolated.

Heronhill - for all your Marstair requirements

Tel: 01823 665660

www.heronhill.co.uk

Fax: 01823 665807

BRANCH DUCT (see page 57 for kit details)

This kit provides an air discharge into an adjacent room

The branch duct MUST be taken from the access point on the chassis, (kit details shown on page 57).

Ductwork should be fully insulated and supported throughout its length.

The graphs below show the airflow passed by a single branch duct: it can be seen that 3-way discharge on the unit, by

blanking off the fascia side to which the branch duct has been connected, will enhance the branch airflow.

DISCHARGE BLANKING

On cool only air conditioners, and heat pump systems without boost heaters, it is possible to blank off the airflowof any one

of the four sides (on latest models with kit 55500316).

This will assist applications such as L shaped rooms etc..

IMPORTANT NOTE:

On units fitted with electric heating, DO NOT blank off any side as this will

restrict airflow over the heating elements. causing them to overheat.

1. Fit the six foam blanking pieces prior to refitting the fascia.

2. Select the side to be blocked.

3. Wedgethesixfoamblankingpiecesintotherelevantairdischargeslotsofthechassisensuringthattheuppersurface

is 50mm below the top of the outer side wall of the chassis.

--o--o--O--O--O--o--o--

ELECTRICAL LOADS: Amps (230V 50Hz 1Ph) or A/Ph (400V 50Hz 3PhN)

CC 875 80 110 140

Lift Pump (10watts) 9 mA 9 mA 9 mA

Fan Motor 0.9 0.9 0.9

Electric heater (A/C) H1 / H2 / H3 / H4 4.0 8.0 12.0 8.0+8.0 4.0 8.0 12.0 8.0+8.0 4.0 8.0 12.0 8.0+8.0

Electric heater (HP) H1 / H2 / H3 / H4 4.0 8.0 12.0 8.0+8.0 4.0 8.0 12.0 8.0+8.0 4.0 8.0 12.0 8.0+8.0

H1= 0.9 kW H2= 1.8 kW H3= 2.75 kW H4= 3.7 kW @ 230V

MCU+ / MCUP MHPUL / MHPUE DCUE

60 80 90 100 130 150 80 100 150 60 80

Fan motor 0.6 0.6 1.0 1.0 1.2 1.2 1.0 1.2 1.2 2.6 2.6

Compressor

nominal FLA

R407C 1Ph 9.2 10.9 14.0 - - - 10.9 - - 11.8 14.4

R407C 3Ph 3.6 4.3 4.6 6.9 6.7 8.9 4.3 6.7 8.9 3.0 4.0

R22 1Ph 9.3 10.4 13.3 - - - 10.4 - - 11.0 13.8

R22 3Ph 3.5 3.9 4.3 6.6 6.4 8.5 3.9 6.4 8.5 2.8 3.8

Crankcase heater ---------0.250.25

Heronhill - for all your Marstair requirements

Tel: 01823 665660

www.heronhill.co.uk

Fax: 01823 665807

ELECTRICAL DATA ~ R407C

a) R407C: CC875 +MCU+

COOLING

27°C/19°C, 35°/24°C 1Ph 230V 50Hz 3Ph 400V 50Hz

INPUT FULL LOAD

AMPS

SYSTEM

MAX.

STARTING

CURRENT

INPUT FULL LOAD

AMPS

SYSTEM MAX.

STARTING

CURRENT

CC 875 MCU+ kW AMPS AMPS kW A/PH A/PH

80 60 2.6 10.7 62 2.6 5.1 33

80 80 3.2 12.4 77 3.2 5.8 41

110 80 3.2 12.4 77 3.2 5.8 41

110 90 3.4 15.9 96 3.4 6.5 44

110 100 - - - 3.7 8.5 51

140 100 - - - 3.7 8.5 51

140 130 - - - 4.6 8.5 63

140 150 - - - 5.7 11.0 64

HEATING

20°C/12°C, 7°C/6°C kW AMPS A/PH*

CC 875 MCU+ MCUP H1 H2 H3 H4 H1 H2 H3 H4 H1 H2 H3 H4

80/110/140 ALL 1Ph 230V 50Hz 1.12.02.9-4.98.912.9-----

80/110/140 ALL 3Ph 400V 50Hz 1.12.02.93.8----4.98.912.98.9

H1= 0.9 kW H2= 1.8 kW H3= 2.75 kW H4= 3.7 kW @ 230V *Max phase

b) R407C: CC875 + DCUE

COOLING

27°C/19°C, 35°/24°C 1Ph 230V 50Hz 3Ph 400V 50Hz

INPUT FULL LOAD

AMPS

SYSTEM

MAX.

STARTING

CURRENT

INPUT FULL LOAD

AMPS

SYSTEM MAX.

STARTING

CURRENT

CC 875 DCUE kW AMPS AMPS kW A/PH A/PH

80 60 3.2 15.6 61 3.1 6.5 26

80 80 3.5 18.2 72 3.5 7.6 28

110 80 3.5 18.2 72 3.5 7.6 28

HEATING

20°C/12°C, 7°C/6°C kW AMPS A/PH*

CC 875 DCUE H1 H2 H3 H4 H1 H2 H3 H4 H1 H2 H3 H4

80 / 110 / 140 ALL 1Ph 230V 50Hz 1.12.02.9-4.98.912.9-----

80 / 110 / 140 ALL 3Ph 400V 50Hz 1.12.02.93.8----4.98.912.98.9

H1= 0.9 kW H2= 1.8 kW H3= 2.75 kW H4= 3.7 kW @ 230V *Max phase

c) R407C: CC875 + MHPUL / MHPUE

COOLING

27°C/19°C, 35°/24°C 1Ph 230V 50Hz 3Ph 400V 50Hz

INPUT FULL LOAD

AMPS

SYSTEM

MAX.

STARTING

CURRENT

INPUT FULL LOAD

AMPS

SYSTEM MAX.

STARTING

CURRENT

CC 875 MHPUL(E) kW AMPS AMPS kW A/PH A/PH

80 80 3.0 12.8 89 3.0 6.2 61

110 100 - - - 3.9 8.8 64

140 150 - - - 5.7 11.0 76

HEATING

20°C/12°C, 7°C/6°C kW AMPS A/PH*

CC875 MHPUL/MHPUEH1H2H3H4H1H2H3H4H1H2H3H4

80 / 110 / 140 ALL 1Ph 230V 50Hz 4.15.05.9-16.917.821.8-----

80 / 110 / 140 ALL 3Ph 400V 50Hz 4.15.05.96.8----16.917.821.817.8

H1= 0.9 kW H2= 1.8 kW H3= 2.75 kW H4= 3.7 kW @ 230V *Max phase

Heronhill - for all your Marstair requirements

Tel: 01823 665660

www.heronhill.co.uk

Fax: 01823 665807

ELECTRICAL DATA ~ R22

d) R22: CC875 + MCU+

COOLING

27°C/19°C, 35°/24°C 1Ph 230V 50Hz 3Ph 400V 50Hz

INPUT FULL LOAD

CURRENT

SYSTEM

MAX.

STARTING

CURRENT INPUT FULL LOAD

AMPS SYSTEM MAX.

STARTING

CURRENT

CC 875 MCU+ kW AMPS AMPS kW A/PH A/PH

80 60 2.5 10.8 62 2.5 5.0 34

80 80 3.0 11.9 77 3.0 5.4 42

110 80 3.0 11.9 77 3.0 5.4 42

110 90 3.4 15.2 96 3.2 6.2 44

110 100 - - - 3.7 8.0 51

140 100 - - - 3.7 8.0 51

140 130 - - - 4.5 8.5 64

140 150 - - - 5.5 10.6 64

HEATING

20°C/12°C, 7°C/6°C kW AMPS A/PH*

CC 875 MCU+ MCUP H1 H2 H3 H4 H1 H2 H3 H4 H1 H2 H3 H4

80/110/140 ALL 1Ph 230V 50Hz 1.12.02.9-4.98.912.9-----

80/110/140 ALL 3Ph 400V 50Hz 1.12.02.93.8----4.98.912.98.9

H1= 0.9 kW H2= 1.8 kW H3= 2.75 kW H4= 3.7 kW @ 230V *Max phase

e) R22: CC875 + DCUE

COOLING

27°C/19°C, 35°/24°C 1Ph 230V 50Hz 3Ph 400V 50Hz

INPUT FULL LOAD

CURRENT

SYSTEM

MAX.

STARTING

CURRENT

INPUT FULL LOAD

AMPS

SYSTEM MAX.

STARTING

CURRENT

CC 875 DCUE kW AMPS AMPS kW A/PH A/PH

80 60 3.2 15.6 61 3.3 6.5 26

80 80 3.4 17.6 72 3.4 7.6 28

110 80 3.6 17.6 72 3.6 7.6 28

HEATING

20°C/12°C, 7°C/6°C kW AMPS A/PH*

CC 875 DCUE H1 H2 H3 H4 H1 H2 H3 H4 H1 H2 H3 H4

80/110 ALL 1Ph 230V 50Hz 1.12.03.0-5.29.213.2-----

80/110 ALL 3Ph 400V 50Hz 1.12.03.03.8----5.99.213.29.2

H1= 0.9 kW H2= 1.8 kW H3= 2.75 kW H4= 3.7 kW @ 230V *Max phase

f) R22: CC875 + MHPUL / MHPUE

COOLING

27°C/19°C, 35°/24°C 1Ph 230V 50Hz 3Ph 400V 50Hz

INPUT FULL LOAD

AMPS

SYSTEM

MAX.

STARTING

CURRENT

INPUT FULL LOAD

AMPS

SYSTEM MAX.

STARTING

CURRENT

CC 875 MHPUL (E) kW AMPS AMPS kW A/PH A/PH

80 80 3.2 12.3 89 3.2 5.8 53

110 100 - - - 4.0 8.5 63

140 150 - - - 5.5 10.6 76

HEATING

20°C/12°C, 7°C/6°C kW AMPS A/PH*

CC875 MHPUL/MHPUEH1H2H3H4H1H2H3H4H1H2H3H4

80/110/140 ALL 1Ph 230V 50Hz 4.15.16.0-4.98.912.9-----

80/110/140 ALL 3Ph 400V 50Hz 4.15.16.06.9----4.98.912.98.9

H1= 0.9 kW H2= 1.8 kW H3= 2.75 kW H4= 3.7 kW @ 230V *Max phase

Heronhill - for all your Marstair requirements

Tel: 01823 665660

www.heronhill.co.uk

Fax: 01823 665807

FUSES / DISJONCTEURS / SICHERUNGEN -HRC Type(EN60269) - MCBs (EN60898)

FUSE RATING / TAILLE DES DISJONCTEURS / EMPFOHLENE SICHERUNG (A)

1Ph - 230 V (R407C, R22)

CC875

80 (L) (E) 110 (L) (E)

MCU+ S H1 H2 H3 H4 S H1 H2 H3 H4

60 20202020------

80 25 25 25 25 - 25 25 25 25 -

90 -----32323232-

MHPUL(E)

80 25 32 32 40 - 25 32 32 40 -

DCUE

60 25252525------

80 32 32 32 32 - 32 32 32 32 -

S = No Electric Heating / Sans Batterie Electrique / Ohne Elektroheizung

H = + Electric Heaters / + Batterie Electrique / Mit Elektroheizung

H1= 0.9 kW H2= 1.8 kW H3= 2.75 kW H4= 3.7 kW @ 230V.

FUSE RATING / TAILLE DES DISJONCTEURS / EMPFOHLENE SICHERUNG (A/Ph)

3Ph - 400 V (R407C, R22)

CC875

80 (L) (E) 110 (L) (E) 140 (L) (E)

MCU+ S H1H2H3H4 S H1H2H3H4 S H1H2H3H4

60 10 10 16 16 16 - - - - - - - - - -

80 10 10 16 16 16 10 10 16 16 16 - - - - -

90 -----1616161616-----

100 -----16161616161616161616

130 ----------1616161616

150 ----------2525252525

MHPUL(E)

80 10 16 20 25 20 - - - - - - - - - -

100 -----1620202520-----

150 ----------2525323232

DCUE

60 16 16 16 16 16 - - - - - - - - - -

80 16 16 16 16 16 16 16 16 16 16 - - - - -

S = No Electric Heating / Sans Batterie Electrique / Ohne Elektroheizung

H = + Electric Heaters / + Batterie Electrique / Mit Elektroheizung

H1= 0.9 kW H2= 1.8 kW H3= 2.75 kW H4= 3.7 kW @ 230V.

FUSE RATING / TAILLE DES DISJONCTEURS / EMPFOHLENE SICHERUNG (A)

CC875 E + MHPUE ONLY (with separate supplies to electronic indoor and outdoor units)

Provided that both indoor and outdoor units are electronic (‘E’) and control cables between them are data cables, the

units may be independently supplied and fused.

CC875 S H1 H2 H3 H4 UNIT SIZE 60 80 100 150

80E 5 10 16 16 16 DCUE 1Ph 25 32 - -

110E 5 10 16 16 16 MHPUE 1Ph - 20 - -

140E 5 10 16 16 16 DCUE 3Ph 16 16 - -

MHPUE 3Ph - 10 16 20

S = No Electric Heating / Sans Batterie Electrique / Ohne Elektroheizung

H = + Electric Heaters / + Batterie Electrique / Mit Elektroheizung

H1= 0.9 kW H2= 1.8 kW H3= 2.75 kW H4= 3.7 kW @ 230V.

Heronhill - for all your Marstair requirements

Tel: 01823 665660

www.heronhill.co.uk

Fax: 01823 665807

Tabla de contenidos

Otros manuales de Acondicionador de aire de Marstair

Marstair

Marstair CWM 55 Manual de usuario

Marstair

Marstair ECO+ Manual de usuario

Marstair

Marstair CKC 20 1/50 Manual de usuario

Marstair

Marstair CWW 15 Manual de usuario

Marstair

Marstair MB Series Manual de usuario

Marstair

Marstair CX Series Manual de usuario

Marstair

Marstair CX Series Manual de usuario

Marstair

Marstair CC 600 Manual de usuario

Marstair

Marstair DXD(H) 50 Manual de usuario

Marstair

Marstair IMPACT 20 Manual de usuario

Marstair

Marstair CWM L 55 Manual de usuario

Marstair

Marstair 929 Series Manual de usuario

Marstair

Marstair CKC 15 1/50 Manual de usuario

Marstair

Marstair 17 Series Manual de usuario

Marstair

Marstair 526 HL Series Manual de usuario

Marstair

Marstair ECO+ Instrucciones de funcionamiento

Marstair

Marstair A2LSYSTEMATCH SMC 15 Manual de usuario

Marstair

Marstair 537 series Manual de usuario

Marstair

Marstair A2LCABINETMATCH Manual de usuario

Marstair

Marstair CC 600 Manual de usuario

Marstair

Marstair WM 60 Manual de usuario

Marstair

Marstair WM Manual de usuario

Marstair

Marstair CX Series Manual de usuario

Marstair

Marstair CXE Series Manual de usuario

Manuales populares de Acondicionador de aire de otras marcas

Spheros

Spheros CC 355 Manual de usuario

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manual de usuario

Panasonic

Panasonic CS-E12HKEW Manual de usuario

nedis

nedis ACMB1WT7 Manual de usuario

Samsung

Samsung AR KV Series Guía

Daikin

Daikin FCFV50A Manual de usuario

Fujitsu

Fujitsu Inverter ASBA30JFC Manual de usuario

Toshiba

Toshiba RAS-M10SMUV-E Manual de usuario

Daikin

Daikin FXLQ20MAVE Manual de usuario

Hitachi

Hitachi RAS-E24CAK Manual de usuario

CIAT

CIAT Magister 2 Series Guía

Bestron

Bestron AAC6000 Manual de usuario

Hisense

Hisense 7K Manual técnico

Frigidaire

Frigidaire FFRE0533S1E0 Manual de usuario

Samsung

Samsung AS09HM3N Manual de usuario

Frigidaire

Frigidaire CRA073PU11 Manual del propietario

Soleus Air

Soleus Air GB-PAC-08E4 Manual de usuario

McQuay

McQuay MCK020A Manual de usuario
