MARELUX Pro X Manual de usuario
Allen Wrench
扳手*1
Package Contents
SOFT Pro Main Body
Dock for Retra Flash Pro X
Str
Mounting Ball * 1
Lanyard Lock
Lock for mounting ball of strobe
Product Features
Use with strobe to narrow down the beam coverage
Length: 155mm
Weight: 790g (Battery Weight 25g), Underwater 210g (With buoyancy cover 125g)
Depth Rating：-100m
Focal Length (Underwater)：130mm
Beam Spot Adjustment Range: 3~50mm
Beam light switchable between white and red colors with adjustable luminance
and adjustable delay shutoff time of beam light
Use one 18350 Lithium battery which can support 3 hours of continuous use
Part Names and Functions
（1）
（2）
(1) Power Switch
(2) Beam Spot Adjustment Knob
Battery Installation
This product requires one 18350 Lithium battery
Remove the battery end cap by
rotating it counter clockwise
then insert the battery in the
direction shown in the figure.
Attach the battery
end cap by rotating
it clockwise.
Dock Installation
Use screws to attach the
mounting ball lock to the
dock and tighten them.
Attach the mounting ball to
the strobe.
Attach the dock to the strobe so that
the lock (1) aligns to the threaded hole
(2) of the strobe.
（1）
（2）
Installation
Align the white bar (1) on the SOFT Pro
to the white dot (2) on the dock then
attach the SOFT Pro to the dock in the
direction shown in the figure
Rotate the SOFT Pro clockwise
until the white dot of the SOFT
Pro aligns to the white dot of
the dock.
（1）
（2）
Uninstallation
Press the lock button (1)
and rotate the SOFT Pro
counterclockwise
Until the white bar (2) aligns to
the white dot（3）
Separate the SOFT Pro main body from
the dock in the direction shown in the
figure
（1）
（2）
（3）
•Align the handle of the power button (1)
to the groove (2)
•Long press the power button (1) for 2
seconds to turn on the beam light
•Press the power button to switch
between white light and red light
•Long press the power button for 3
seconds till the led turns red to turn off
the beam light
Usage
（1）
（2）
（3）
•Beam light luminance adjustment: turn the
power button (1) clockwise to increase
the luminance and counterclockwise to
decrease it
•Beam light delay shutoff time setting: long
press the power button (1) for 6 seconds
till the led stays red to enter the setting
state. Press the button again to change
the delay shutoff time then exit the
setting state (switchable between 0.2
seconds and 1.2 seconds)
•Beam spot adjustment: turn the knob (3)
to change the beam spot size
Maintenance And Storage
⚫After each underwater use, always remove this product from the strobe and soak it in fresh water for
several hours to dissolve any salt buildup. Wipe off water with soft cloth and let it dry in shaded and
well-ventilated area.
⚫Periodically apply grease on the O-Ring of the battery end cap to prevent problems caused by salt
buildup or electrical corrosion.
⚫A diffuser is not usable in combination with this product.
⚫Do not tighten screws too much to avoid damage on the screw holes.
