EN
6
Only one hot plate can be selected at
the same time
Warning:
To operate a hot plate, it must
use a hot plate,check the brightness
of the power indicator.After
choosing hot plate, brightness of
power indicator should increase.
Quick switch-on at maximum
power: Once you have selected the
hot plate, press the touch key
once. The hot plate will be activated at
full power.
SWITCHING OFF THE HOT PLATE
1The hot plate must previously be
selected.
2Using the touch key
the power level to 0.
sensor for 2 seconds, the related zone
and
RESIDUAL HEAT INDICATOR
The power indicator of the hot plate will
display an H when the glass surface
reaches a temperature that could
cause burning.
When this risk disappears,
Warning:
In a first run, H indication may
appear in a short time on the power
display. This showing is related
with setup operation and it does
Warning:
H indication is used for the safety
purposes in any case. Even if the
power on, H indication appears.
SWITCHING OFF THE DEVICE
touch key
H will appear in the zones that are hot.
The rest of the displays will not light up.
Double burner hot plate
If your cooker has this option, the
double burner hot plate offers the
possibility of using the inside ring or
also, in addition, the outside one,
depending on the size of the pot or
pan.
SWITCHING ON THE DOUBLE
HOT PLATE
1The related hot plate must be
selected.
2Select the desired power (from 1
or
3 Press the double hot plate touch
key
burner. When the double zone will
be activated, double zone indicator
SWITCHING OFF THE DOUBLE
HOT PLATE
1The key, by which its double burner
hot plate was switced on previously
is selected.
2Press the double hot plate touch
key to deactivate the double
burner. The double burner indicator
be deactivated
Locking of the touch keys
of the cooking hob
To prevent undesired manipulation
you can lock the entire unit, except
for the on/off touch key, using the
locking touch key
is useful for child safety. When the lock
comes on.
However, remember when the touch
the lock is activated (the lock indicator
On the other hand, if the touch control
To deactivate the locking function,
press the locking touch key
and touch control will be ready for use.
CHILD LOCK
complicated than key lock. User can
activate key lock via one sensor. But
child lock need a sensor sequence.
The Child Lock is being used to
prevent children from turning on
the hob.
Activating Child Lock :
1. The hob is switched on via
2. Any zone should not be selected.
When any zone is not selected,
and minus sensors is hold for 3
seconds at same time. At the end
of this period, a short buzzer sound
is heard
3. After buzzer signal , the
locking touch key is touched (there
is no need to keep press for a long
heard and the Child Lock will be
activated and all power display
shows “L”.
During Child Lock, if user touch any
Warning : Child lock status is not
being stored. If the energy of the hob
is butted, child lock status could not
be preserved.
Deactivating Child Lock :
