UNIT INSTALLATION INFORMATION
SAFETY:
•Risk of scalding. Beware of accidentally operating the water drawoff dial
or push buttons especially when cleaning. If the dial is left in the ON
position (shown later) then pressing boost will cause water to flow
immediately from the font.
•This appliance must be earthed. If the plug supplied is not used then
ensure that the green/yellow cable is connected to a suitable earth.
•Risk of flooding –inlet hose. The hose supplied with this unit is non-toxic
food quality tested to 190psi. However, a hose is not a permanent
connection. It is, therefore, advisable to switch off boiler and close the
stopcock valve when boiler is not in use, e.g. overnight, weekends etc.
•Risk of flooding –overflow hose. Water spilling in the scale platform area
will run down a waste tube which should be plumbed –this is not intended
to be used as a dedicated drain facility. If a waste bucket is used it risks
overfilling.
•The utmost care has been taken in the manufacture and testing of this
unit. Failure to install, maintain and / or operate this boiler according to the
manufacturer’s instructions may result in conditions that can cause injury
or damage to property. If in any doubt about the serviceability of the boiler
always contact the manufacturer or your own supplier for advice.
•Children should be supervised to ensure that they do not play with the
appliance
•In the event any wires are damaged, such wires can only be replaced by
experts or professional afterservice staff from the manufacturer,
afterservice department or similiar function departments.
INSTALLATION DETAILS:
Electrical installation:
•Electrical specification: 2.8kW-230V-50Hz
•A 13A plug is factory fitted. A suitable 13A outlet is all that is required.
Plumbing installation procedure:
•Mains water pressure required (limits): 5-50psi (35-345kPa)
•Fit a stop Valve on a cold water line and attach a 3/4" BSP male fitting,
•(e.g. 3/4" x 1/2" 311 or washing machine type stop valve).
•Connect straight tailpiece of the hose to the stop valve fitting. Make sure that
the pre-attached sealing washer is fitted.
•Turn on the water to flush any impurities, dust etc from the inlet hose and
water pipe. Allow several gallons through.
