Marantz RC-9500 Manual de usuario
Model RC9500 User Guide
Touch Screen Remote Control
For US and Canada
FCC Compliancy:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rule. These limits are designed to pro-
vide reasonable protection against harmful interference in residential installation.
This equipment generates, uses, and can radiate radio frequency energy and , if
not installed and used in accordance with the instructions, may cause harmful inter-
ference to radio communications. However, there is not guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful inter-
ference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
✜Reorient or relocate the RX-77 RF Extender.
✜Increase the separation between the equipment and receiver.
✜Connect the equipment into an outlet on a different circuit from the receiver.
✜Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
The user changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
For Europe
Declaration of Conformity N° V04ECRC9500:
We, Marantz Europe B.V., PO Box 8744, 5605 LS Eindhoven, The Netherlands
declare under our responsibility that the Marantz product described in this user
guide is in compliance with the corresponding technical standards such as
EN301 489-1 of 2002-08, EN301 489-3 of 2002-08, EN300 220-1 of 2002-09 and
IEC60950 of Edition 2002.
Eindhoven, The Netherlands
Bert Kiggen
Marketing manager of Marantz Europe B.V.
Dear customer,
Please be informed that this carton only contains a copy of the user manual in English. For
German, French, Dutch, Spanish and Italian please visit our website www.marantz.com and
check the download section (touch screen remotes).
Sehr geehrter Verbraucher,
bitte beachten Sie, dass diese Verpackung lediglich eine englischsprachige
Bedienungsanleitung enthält. Eine deutsche Bedienungsanleitung erhalten Sie als
Download File (Software - Fernbedienungen) über unsere Internetseite www.marantz.de
oder telefonisch unter 0541-4046630.
Cher client,
Vous trouverez dans cette boîte une copie du manuel d'utilisation en anglais. Les versions
allemande, française, hollandaise, espagnole ou italienne sont disponibles sur notre site:
www.marantz.com (choisir Download et Touch screen remotes ).
Geachte klant,
Wij informeren u dat deze doos enkel een engelse gebruiksaanwijzing bevat. Voor gebruik
van een duitse, franse, nederlandse, spaanse of italiaanse versie verwijzen we u naar onze
website www.marantz.com waar u talenversies kunt downloaden via touch screen remotes.
Estimado consumidor,
Le informamos que este paquete sólo contiene la versión inglesa del manual de usuario. Si
desea obtener la versión española, alemana, francesa u holandesa, podrá conseguirla en
nuestra página web www.marantz.com, sección "download, touch screen remotes" (mandos
con pantalla táctil).
Attenzione: le istruzioni per l'uso a corredo di questo telecomando sono soltanto in lingua
inglese. Le istruzioni in tedesco, francese, olandese, spagnolo ed italiano sono scaricabili
dal sito www.marantz.com sezione "DOWNLOAD" - Touch Screen Remotes.
Automating Your Home Theater
With The Marantz RC9500
RC9500 Remote Control User Guide
The information in this manual is copyright-protected. No part of this user guide
may be copied or reproduced in any form without prior written consent from
Marantz.
MARANTZ SHALL NOT BE LIABLE FOR OMISSIONS OR FOR TECHNICAL
OR EDITORIAL ERRORS CONTAINED IN THIS USER GUIDE. MARANTZ
SHALL NOT BE HELD LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAM-
AGES RESULTING FROM THE SUPPLYING OR USE OF THIS INFORMA-
TION. MARANTZ SHALL NOT BE HELD LIABLE FOR INCIDENTAL OR CON-
SEQUENTIAL DAMAGES RESULTING FROM THE PERFORMANCE OR USE
OF THE MATERIALS DESCRIBED IN THIS USER GUIDE.
The information in this user guide may be subject to change without prior notice.
All other brand or product names are trademarks or registered trademarks of
their respective companies or organizations.
© 2004 Marantz America, Inc.
All rights are reserved. Reproduction in whole or in part is prohibited without
prior consent of the copyright owner.
User Guide
1
Introduction 2
1. The Marantz RC9500 2
2. The Battery 3
Getting Started 6
1. Activating the RC9500 6
2. Navigating the RC9500 7
3. Operating a Device 11
4. Check Battery Life - The Information Page 12
5 The Setup Pages 12
6. Setting Time and Date 14
7. The Mode Menus 16
8. Adjusting the Touch Screen Brightness 17
Customizing Your RC9500 18
1. Introduction 18
2. Cloning All Your Existing Remotes 18
3 Complex Operation? Macros or Help... 20
4. Programming Help Lists 22
5. Macro/Page Jump Capabilities 23
6. Programming Macros & page Jumps 25
Reference 28
1. Learning IR Commands 28
2. Labeling Buttons, Pages and Devices 32
3. Adding Devices 35
4. Deleting Buttons and Devices 39
5. Moving Devices 41
6. Programming Macros 42
7. Creating and Editing Timers 46
8. Using the Remote Control with RF (Radio Frequency) 54
9. Wizz.it 9 Software 56
Maintaining the RC9500 58
Troubleshooting 59
Frequently Asked Questions 62
Overview of Symbols 64
Specifications 66
Index 67
Service and Support 72
Table of Contents
User Guide
2
The RC9500 is designed to control most devices that understand
infrared (IR) remote control signals. Its Easy-to-Use Touch Screen and
its Intuitive Interface makes it a perfect remote control for every user.
The RC9500 is completely customizable and programmable. You can
add devices and functions, re-label buttons, record macros and animate
your macros. Although the RC9500 is pre-programmed for Marantz
components, a vast collection of built-in tab guided panels with pre-
arranged button art enables you to easily choose the perfect interface
for any non-Marantz component. The RC9500 easily “learns” com-
mands from the vast majority of manufacturers’ remote controls.
Introduction
VOLUME Up/Down
buttons (page 11)
CHANNEL Up/Down
buttons (page 11)
MUTE button
(page 11)
Learning / Sending
Infrared (IR) Eyes (page 28)
Right Function
button (page 8)
4-Way Cursor
buttons (page 9)
Page +/ -
buttons (page 9)
Backlight
button (page 6)
USB Port
(page 57)
HOME
button (page 7)
1. The Marantz RC9500
Left Function
button (page 8)
MENU
button (page 11)
ENTER
button (page 11)
EXIT
button (page 11)
Touch Screen
The Touch Screen
When you use the RC9500 for the first time, you will have to:
• Install the battery pack.
• Place the RC9500 in the docking station (DS9500) and charge
the RC9500.
• Tap the INFO button on the UPPER TOOL BAR to check
battery life.
Warning Use the docking station only with supplied NiMH rechargeable
battery pack.
We strongly advise you NOT to plug other appliances (like mobile
phones, PDA’s) into the docking station. This will damage both the
docking station and the appliance.
User Guide
3
Introduction
MODE icon
(page 7)
INFO
button (page 3)
DEVICE SCROLL
button (page 9)
DEVICE OVERVIEW
button (page 8)
UPPER TOOL BAR
CURSOR NAVIGATION
button (page 9)
USER CONTROL
AREA
LOWER TOOL BAR
PAGE OVERVIEW
button (page 9)
2. The Battery
DEVICE SCROLL
button (page 9)
Installing the Battery Pack
1 Press the latch on the battery cover and remove the battery
cover from the RC9500.
2 Plug the cable of the battery pack in the connector as illustrated.
3 Place the battery pack in the battery compartment.
4 Place the battery cover back on.
Note Make sure the cable of the battery pack does not get stuck
between the molded interior and the battery cover.
After a few seconds, the RC9500 starts up automatically and an
introduction screen appears. The RC9500 beeps twice to
indicate that it has finished starting up.
Because the battery pack of the RC9500 is not fully pre-
charged, you will have to charge it as described in the next
page.
User Guide
4
Introduction
12
3 4
Charging the RC9500
For charging the RC9500, you use the docking station DS9500.
1 Connect the power adapter to the docking station and plug it
into a wall outlet.
Note Use only the supplied power adapter with the docking station.
2 Slide the RC9500 into the docking station until it clicks.
Charging starts immediately. The blue charging LEDs on the
front of the docking station indicate charging takes place.
When the RC9500 is fully charged,
the LEDs are turned off.
Make sure you lift
the RC9500 up at
an angle of 30° to 45°
when you take the RC9500 out from the docking station.
Note Normal charging time is 2 to 3 hours, depending on the
condition of the battery pack.
You can operate the RC9500 while it is being charged.
The battery pack does not have to be entirely empty before
recharging.
You can place the RC9500 in the docking station at any time.
When the battery is running low, the Low Battery
icon appears.
Recharge the RC9500 as soon as possible to
ensure the perfect performance.
Note The RC9500 retains all settings when the battery is completely
empty. You will only have to adjust the clock.
User Guide
5
Introduction
30° to 45°
Low Battery icon
DS9500
User Guide
6
Turning on the Touch Screen
Tap the Touch Screen gently with your finger or a blunt, soft
object like a pencil eraser, press the hard buttons or pick the
RC9500 up.
The display is activated and you will see the Home page.
Notes · If the display stays blank or becomes black, adjust the bright-
ness using the buttons on the left side.
(see page 17)
· If another panel is displayed, press the HOME button.
· The RC9500 shuts down automatically after being
left alone for a few seconds (you can adjust the time out period
in the Setup pages).
Using the Backlight
RC9500’s backlight can be activated in three different ways,
Pressing the BACKLIGHT button
By pressing the BACKLIGHT button on the left side of the
RC9500, the backlight for the screen and keys is turned on.
Picking up the RC9500
The RC9500 has the Pickup sensor in it. By picking your
RC9500 up from the docking station and tilting more than 50°,
the backlight is turned on.
Note To enable this function, the “Pickup sensor” setting in the Setup
has to be set to “On”. (see page 13)
Tapping the Touch Screen
By tapping the Touch Screen, the backlight is turned on.
Note If the “Auto button light” setting is set to “Off”, button backlight
will not be turned on automatically. (see page 13)
The backlight shuts off after the preset time to save power. (see page 13)
Note The backlight will not turn on at the certain low battery level but
the remote will still function.
Getting Started
1. Activating the RC9500
HOME
Otros manuales para RC-9500
4
Tabla de contenidos
Otros manuales de Mando a distancia de Marantz
Marantz
Marantz RC-5400 Manual de usuario
Marantz
Marantz RC2001 Manual de usuario
Marantz
Marantz RC2001 Manual de usuario
Marantz
Marantz RC-1400 Manual de usuario
Marantz
Marantz RC3200 Manual de usuario
Marantz
Marantz RC3200 Manual de usuario
Marantz
Marantz RC5200 Manual de usuario
Marantz
Marantz RC101 Manual de usuario
Marantz
Marantz RC-9500 Manual de usuario
Marantz
Marantz RC9200 Manual de usuario
Marantz
Marantz RC5000i Manual de usuario
Marantz
Marantz RC101 Manual de usuario
Marantz
Marantz RC3200 Manual de usuario
Marantz
Marantz RC-9500 Manual de usuario
Marantz
Marantz RC-1400 Manual de usuario
Marantz
Marantz RC1200 Manual de usuario
Marantz
Marantz RC-1400 Manual de usuario
Marantz
Marantz RC5000 Manual de usuario
Marantz
Marantz Professional RC600PMD Manual de usuario
Marantz
Marantz RC3001/E1B Manual de usuario
