VP-10S1 3 Chip DLPTM High Definition Projector

The soon-to-be legendary VP-10S1 uses 3-chip DLP®technology which uses a separate DMD™ device to process each primary color. This is

the same technology used in the big DLP Cinema®projectors found in many of the state-of-the-art movie palaces worldwide. By combining

this proven methodology with Marantz’s expertise in video projector design, the VP-10S1 will display an image that truly must be experienced

to be believed. Colors so saturated that you will want to pinch yourself to see if you are dreaming, and a black level that can be approximated

by outer space — barely. If you were waiting for digital projection to become better than CRT, your wait has ended.

• Texas Instruments 3-chip DLP®

Technology

• High Definition DMD™ HD-2 “Mustang”

Chipset

• 3 Chip, 10-Bit Faroudja DCDi™

Processing

• 14-Bit Gamma Correction

• 12-Bit Color Path

• 1200 ANSI Lumens Brightness

• >3600:1 Contrast Ratio

• Custom Optics by Marantz

• 3 Lens Options

• Motorized Lens (Shift H/V,

Zoom, Focus)

• Exclusive O.R.C.A.™ Color Corrected

Light Source

• Coated and Painted Combining Prism

• 250 Watt VIP Lamp

• DVI Input with HDCP

• Auto Color Temperature Calibration

System

• 2 Multi-scan Component Inputs (RCA

and BNC)

• RS232C Terminal for System Control

• 2 DC Triggers

• D-BUS Remote Connection (3.5mm

Mini-jack)

• Illuminated I/O Terminal Panel

Compatible

SPECS.qxp 1/28/05 11:18 AM Page 25

FEATURES

Display Device

Panel Size

Aspect Ratio

Resolution

Brightness

Brightness Uniformity

Contrast Ratio

Projection Size

Throw Distance 100"

TV System

Computer Signal Capability

DTV / HDTV Capability

Video Processor

3:2 Pull Down

Optics

O.R.C.A Filter

Life Lamp

Picture Memories

Keystone Correction

Fine Picture Menu

Picture Modes

Color Temperatures

Black Level Selection

Optical Zoom

Lens Shift

Dust-Free Sealed Optics

Noise Cancel Structure

Chassis

Illuminated I/O Terminal Panel

Auto Color Temp. Calibration

FCC

DMD (TI DLP™ Technology)

HD2 x3-chip

0.81"

16:9

1280x720

1000 / 1200 ANSI Lumen

(Lamp Mode Low / High)

90%

3600 :1

60" - 300"

125

1/2

" - 156

7/8

" (LN10VP32)

156

7/8

" - 209

3/18

" (LN10VP40)

209

3/18

" - 313

3/4

" (LN10VP53)

NTSC, PAL, SECAM

VGA, SVGA, XGA, SXGA

480i, 480p, 720p, 1080i

Faroudja DCDi™ Processing

•

Marantz Custom

•

1500 Hours (Average)

•(12)

•(H/V)

•

(Theater, Standard, Dynamic and User)

•( 5 Steps)

•

•(x1.25: LN10VP32)

•(x1.33: LN10VP40)

•(x1.5: LN10VP53)

•(V: +115% / -20%, H: +/- 25%)

•

Extruded Aluminum Frame

•

Class B

IN/OUTPUTS

VIDEO

Composite Video In

S-Video In

Component In

RGB/HD In

Digital Video In

OTHERS

D-Bus Remote (RC-5) In/Out

External Control (RS232C)

DC Trigger Out

GENERAL

Color

Remote Control

Power Requirement

Power Consumption

Dimensions W x H x D (Inches)

Weight (lbs.)

2 (RCA / BNC)

1 (D-Sub 15-Pin)

1 (DVI-D with HDCP)

1 / 1 (3.5 mm mini jacks)

•

2 (3.5 mm mini jacks)

Gun Metallic

RC-12VP3

AC 100-120 V/ 220-240 V, 50/60Hz

< 380W

1/16

" X 26

7/16

" X 12

7/8

90.3

VP-10S1

Digital Light Processing, DLP, the DLP logo, and the DLP medallion are trademarks

of Texas Instruments.

DCDi®and DCDi by Faroudja®are registered trademarks of Faroudja, a division of

Genesis Microchip Inc.

*All specifications, dimensions and weights are subject to change without notice. D&M Holdings, Marantz, Marantz America, Inc. or any of its subsidiaries will not assume any liability for errors within this document.
