Marantz CD6007 Manual de usuario

CD Player

CD6007

Owner’s Manual

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Accessories 4

Inserting the batteries 5

Operating range of the remote control unit 5

Part names and functions 6

Front panel 6

Display 9

Rear panel 10

Remote control unit 11

Connections

Connecting an amplifier 18

Connecting to a device with digital audio input connectors 19

Connecting a USB memory device to the USB port 20

Connecting devices with remote control connectors 21

Connection 21

Setting 21

Connecting the timer device 22

Connecting the power cord 23

Playback

Basic operation 25

Turning the power on 25

Switching the power to standby 25

Selecting the playback media mode 26

Switching the display’s brightness 26

Playing CDs 27

Playing tracks in a specific order (Program playback) 29

Playing DATA CDs 30

Playing files 31

Playing a USB memory device 33

Playing files stored on USB memory devices 34

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Settings

Menu map 36

Menu operation 37

H/P AMP GAIN 38

Filter 38

Digital Out 39

Timer Play 39

Auto-Standby 40

Tips

Tips 42

Troubleshooting 43

Power does not turn on / Power is turned off 44

Operations cannot be performed through the remote control unit 45

Display on this unit shows nothing 45

No sound comes out 46

Sound is interrupted or noise occurs 46

Desired sound does not come out 46

USB memory devices cannot be played back 47

Cannot playback Discs 48

Appendix

Playing back Discs 49

Files 49

Playing back a USB memory devices 51

Playback order of music files 52

About discs and files 53

Cautions on using media 54

Loading discs 54

How to handle media 55

Cleaning discs 55

Explanation of terms 56

Trademark information 58

Specifications 59

Index 62

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Thank you for purchasing this Marantz product. To ensure proper operation, please read this owner’s manual carefully before using the product.

After reading this manual, be sure to keep it for future reference.

Accessories

Check that the following parts are supplied with the product.

Quick Start Guide CD-ROM

(Owner’s Manual)

Safety Instructions

Power cord Remote control unit

(RC004PMCD)

R03/AAA batteries Audio cable

Remote connector cable

Warranty

(for USA/for CANADA)

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Inserting the batteries

1Remove the rear lid in the direction of the arrow and

remove it.

2Insert two batteries correctly into the battery

compartment as indicated.

Batteries

3Put the rear lid back on.

NOTE

0To prevent damage or leakage of battery fluid:

0Do not use a new battery together with an old one.

0Do not use two different types of batteries.

0Remove the batteries from the remote control unit if it will not be in use for long

periods.

0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery

compartment and insert new batteries.

Operating range of the remote control

unit

Point the remote control unit at the remote sensor when operating it.

Approx. 23 ft/7 m

30°

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Part names and functions

Front panel

wq e i

ouyQ0 Q1 Q2rt

For details, see the next page.

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

or Q0ty uu iewq Q1 Q2

APower operation button (X)

This turns the power on/off (standby). (v p. 25)

BPower indicator

This is lit as follows according to the power status:

0Power on : Off

0Standby : Red

CDisc tray open/close button (5)

Opens and closes the disc tray. (v p. 27)

DForward-skip button (9)

Plays the next track. Press and hold to fast-forward the track.

EReverse-skip button (8)

Returns to the start of the currently playing track. Press and hold to fast-

reverse the track.

FDISPLAY OFF indicator

Lights when the display is off. (v p. 26)

GDisplay

Various information is displayed here. (v p. 9)

HDisc tray

Used to insert a disc.

IRemote control sensor

This receives signals from the remote control unit. (v p. 5)

JPlay button (1)

Playback starts.

KStop button (2)

Stops playback.

LPause button (3)

Pauses playback.

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Q4 Q5 Q6

MUSB port

This is used to connect USB storages (such as USB memory devices).

(v p. 20)

NDISC/INPUT button

Used to select the playback source. (v p. 26)

OHeadphones jack (PHONES)

Used to connect headphones.

PHeadphone volume control knob (LEVEL)

Adjusts the headphone volume.

NOTE

0To prevent hearing loss, do not raise the volume level excessively when using

headphones.

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Display

wq ter y

AInformation display

Displays various information or playback elapsed time and so on of the

disc.

BPlayback mode indicators

1 : Lights up during playback.

3 : Lights up during pause.

CTOTAL indicator

Lights when the total number of tracks and total time of the CD are

displayed.

DRANDOM indicator

Lights during random playback.

ERepeat mode indicators

Lights to match the repeat mode settings.

FFolder mode indicator

Lights up when the folder mode is set in the CD-R/CD-RW playback

range. (v p. 32)

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Rear panel

ywrt

AAUDIO OUT connectors

Used to connect devices equipped with analog audio inputs connectors

or an external power amplifier. (v p. 18)

BDIGITAL AUDIO OUT connectors (COAXIAL/OPTICAL)

Used to connect an Amplifier or D/A converter that has a digital input

connectors. (v p. 19)

CFLASHER IN jack

Used when using a control BOX or other such control devices to control

this unit.

DREMOTE CONTROL connectors

Used to connect to a Marantz amplifier that is compatible with the

remote control function. (v p. 21)

EEXTERNAL/INTERNAL switch

Turn this switch to “EXTERNAL” to operate the unit by pointing the

remote control at the amplifier connected to this unit using the remote

control connection. (v p. 21)

FAC inlet (AC IN)

Used to connect the power cord. (v p. 23)

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index
