Marantz 0747192136499 Manual de usuario

Brandenbrg Concerto No.

1:10 9:20

CD Player

Owner’s Manual

Accessories 4

Inserting the batteries 5

Operating range of the remote control unit 5

Part names and functions 6

Front panel 6

Display 8

Rear panel 9

Remote control unit 10

Connections

Connecting an amplifier 15

Connecting to a device with digital audio input connectors 16

Connecting a USB flash drive to the USB port 17

Connecting devices with remote control connectors 18

Connection 18

Setting 18

Connecting the timer device 19

Connecting the power cord 20

Playback

Basic operation 22

Turning the power on 22

Switching the power to standby 22

Selecting the playback media mode 23

Switching the display’s brightness 23

Playing CDs 24

Playing tracks in a specific order (Program playback) 26

Playing DATA CDs 27

Playing files 28

Playing a USB flash drive 30

Playing files stored on USB flash drives 31

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Settings

Menu map 33

Menu operation 34

H/P Amp Gain 35

Filter 35

Digital Out 36

Power On Link 36

Timer Play 37

Auto-Standby 37

Tips

Tips 39

Troubleshooting 40

Power does not turn on / Power is turned off 41

Operations cannot be performed through the remote control unit 42

Display on this unit shows nothing 42

No sound comes out 43

Sound is interrupted or noise occurs 43

Desired sound does not come out 43

USB flash drives cannot be played back 44

Cannot playback Discs 45

Appendix

Playing back Discs 46

Files 46

Playing back a USB flash drives 48

Playback order of music files 49

About discs and files 50

Cautions on using media 51

Loading discs 51

How to handle media 52

Cleaning discs 52

Explanation of terms 53

Specifications 55

Index 58

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Thank you for purchasing this Marantz product. To ensure proper operation, please read this owner’s manual carefully before using the product.

After reading this manual, be sure to keep it for future reference.

Accessories

Check that the following parts are supplied with the product.

Remote connector cableAudio cable

Remote control unit

(RC005PMCD)

Quick Start Guide Safety Instructions Cautions on Using Batteries Power cord

2×R03/AAA batteries

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Inserting the batteries

1Remove the rear lid in the direction of the arrow and

remove it.

2Insert two batteries correctly into the battery

compartment as indicated.

Batteries

3Put the rear lid back on.

NOTE

0To prevent damage or leakage of battery fluid:

0Do not use a new battery together with an old one.

0Do not use two different types of batteries.

0Remove the batteries from the remote control unit if it will not be in use for long

periods.

0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery

compartment and insert new batteries.

Operating range of the remote control

unit

Point the remote control unit at the remote sensor when operating it.

Approx. 7 m

30°

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Part names and functions

Front panel

qw uiytoQ0 Q1er

For details, see the next page.

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

qw uiytoQ0Q1er

APower operation button (X)

This turns the power on/off (standby). (v p. 22)

BPlay/Pause button (p)

Press this button to pause during playback. If pressed while paused or

stopped, resumes playback from the last track played.

CStop button (i)

Stops playback.

DINPUT button

Used to select the playback source. (v p. 23)

EProtection circuit indicator

This blinks when the protection circuit has operated. (v p. 41)

FDisplay

Various information is displayed here. (v p. 8)

GDisc tray

Used to insert a disc.

HRemote control sensor

This receives signals from the remote control unit. (v p. 5)

IDisc tray open/close button (q)

Opens and closes the disc tray. (v p. 24)

JReverse-skip button (k)

Returns to the start of the currently playing track. Press and hold to fast-

reverse the track.

KForward-skip button (j)

Plays the next track. Press and hold to fast-forward the track.

LUSB port

This is used to connect USB storages (such as USB flash drives).

(v p. 17)

MHeadphone volume control knob (PHONES LEVEL)

Adjusts the headphone volume.

NHeadphones jack

Used to connect headphones.

NOTE

0To prevent hearing loss, do not raise the volume level excessively when using

headphones.

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Display

wq ter y

AInformation display

Displays various information or playback elapsed time and so on of the

disc.

BPlayback mode indicators

1 : Lights up during playback.

3 : Lights up during pause.

CTOTAL indicator

Lights when the total number of tracks and total time of the CD are

displayed.

DRANDOM indicator

Lights during random playback.

ERepeat mode indicators

Lights to match the repeat mode settings.

FFolder mode indicator

Lights up when the folder mode is set in the CD-R/CD-RW playback

range. (v p. 29)

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Rear panel

twer

AAUDIO OUT connectors

Used to connect devices equipped with analog audio inputs connectors

or an external amplifier. (v p. 15)

BDIGITAL AUDIO OUT connectors (COAXIAL/OPTICAL)

Used to connect an amplifier or D/A converter that has a digital input

connectors. (v p. 16)

CREMOTE CONTROL connectors

Used to connect to a Marantz amplifier that is compatible with the

remote control function. (v p. 18)

DEXTERNAL/INTERNAL switch

Turn this switch to “EXTERNAL” to operate the unit by pointing the

remote control at the amplifier connected to this unit using the remote

control connection. (v p. 18)

EAC inlet (AC IN)

Used to connect the power cord. (v p. 20)

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Remote control unit

The remote control provided with this unit can control a Marantz amplifier.

0“Amplifier operations” (v p. 13)

oOperating this unit

ARemote control signal transmitter

This transmits signals from the remote control unit. (v p. 5)

BPower operation button (CD X)

This turns the power on/off (standby). (v p. 22)

CDisc tray open/close button (q)

Opens and closes the disc tray. (v p. 24)

DSystem buttons

These perform playback related operations.

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index
