Manhattan 365925 Manual de usuario

HI-SPEED

USB 2.0 FILE

TRANSFER

CABLE

USER

MANUAL

MODEL 365925

MAN-365925-UM-0308-01

Thank you for purchasing the MANHATTAN

Hi-Speed

USB 2.0 File Transfer Cable, Model 365925.

Designed so you can transfer ﬁles between computers at

speeds up to 480 Mbps, this handy cable comes with user-

friendly ﬁle transfer software and automatically detects and

installs peripherals.

The easy-to-follow instructions in this manual help make

installation of the cable quick and simple, so you’ll also

soon be enjoying the beneﬁts of these features:

• Quickly and easily transfer ﬁles via USB ports — ideal for

transferring data between Windows XP and Vista-equipped

computers

• Hot pluggable — connect while the computer is running

• No external power necessary

• Activity LED

• Plug and Play

• No additional drivers or software needed for Vista

• Lifetime Warranty

System Requirements

• Intel Pentium 1 GHz or faster PC

• 128 MB RAM or higher

• USB port (Hi-Speed USB 2.0 for Hi-Speed transfer)

• Windows XP SP2 or Vista

NOTE: Screen images have been modiﬁed to ﬁt on page.

INSTALLATION

Windows Vista

Simply plug the Hi-Speed USB 2.0 File Transfer Cable in to

the USB port on your computer and it’s ready to use. No

further installation is required.

Windows XP

The Windows Easy Transfer utility must be installed before

plugging in the File Transfer Cable (Step 4 below).

1. Insert the

provided CD

into your CD-

ROM drive.

An auto-run

screen will

automatically

pop up and

guide you to

install the

utility. Click

“Next.”

2. After reading the license agreement on the subsequent

screen, select “I Agree” and click “Next.”

3. An Updating Your System screen presents a status bar

to show installation progress. When it updates to the

Completing...Installation screen, click “Finish.”

4. At this point, you can plug the File Transfer Cable into the

USB port

on your PC.

When the

Easy Transfer

Cable screen

appears, you

can select

“Transfer ﬁles

and settings”

to launch the

utility or “Take

no action.”

Click “OK.”

OPERATION

Launch the Easy Transfer Utility on Both Computers

Easy Transfer is a Windows-based utility that allows two

computers to transfer ﬁles and settings from a computer

running Windows XP or Vista to another computer running

Windows Vista. To use the utility, plug the File Transfer

Cable into the USB ports on both computers and then start

the utility on both computers.

• On Windows Vista: Select Start ‡ Programs ‡

Accessories ‡ System Tools ‡ Windows Easy Transfer.

• On Windows XP: Select Start ‡ Programs ‡ Windows

Easy Transfer. After launching the utility, just follow the

on-screen instructions.

NOTE: Keep the following in mind when using the utility.

• You must launch Easy Transfer on both computers

involved in the transfer of ﬁles/settings so that they can

detect each other.

• Transfers can only be made from Windows XP/Vista to

Windows Vista: You cannot transfer ﬁles/settings from

Vista to XP.

• When prompted to choose a transferring media, select

USB cable.

• You can only transfer ﬁles/settings between operating

systems using the same language; for example, you

can’t transfer ﬁles/settings from a traditional Chinese

system to an English system.

Transfer Example

The following steps exemplify the screens and associated

procedures involved with a transfer of ﬁles from Windows

XP to Vista. NOTE: The partial screen samples shown may

not actually show during some transfer procedures, or may

appear different due to varying OS versions or computer

settings.

1 XP & Vista: A Windows Easy Transfer welcome screen

displays. Click “Next.”

2 XP: The prompt “Choose how to transfer ﬁles and

settings to your computer” displays. Select “Use an

Easy Transfer Cable (recommended)” as shown

above.

2 Vista: The prompt “Do you have an Easy Transfer Cable?”

displays. Select “Yes, I have an Easy Transfer

Cable” shown above.

3 XP & Vista: When the prompt (above) “Install the Easy

Transfer Cable and connect your computers”

displays, wait for the message “A connection to the

other computer has been detected” to display —

it only appears brieﬂy at the bottom of the screen.

4 XP: When the prompt “What do you want to transfer

to your new computer?” displays (below), make a

selection from among the three options that appear.

Subsequent screens in this example are based on

an “Advanced options” selection.

4 Vista: When the message “Your computers are now

connected” displays, stop while the XP system

proceeds through Steps 5 and 6.

5 XP: When the prompt

“Select user

accounts, ﬁles,

and settings to

transfer” displays,

select the folders

you want to be

transferred and

click “Next.”

6 XP: If either account-related option is selected in Step

4 XP, the prompt “Type a new user name or click

a name in the list”

displays. Select

either option for the

target (ﬁle-receiving)

computer, then click

“Next.”

7 XP & Vista: A “Please wait until the transfer is complete”

message displays with a procedure status bar.

Wait for the next screen to appear.

8 XP: When the message “You’re ready to transfer ﬁles

and settings to your new computer” displays, click

“Close” to exit the utility.

8 Vista: When the message “The transfer is complete”

displays (with a summary of transferred items),

click “Close” to exit the utility.

SPECIFICATIONS

General

• Plug and Play — automatic detection and installation of

peripherals

• Windows XP/Vista compatible

Certiﬁcations/Approvals

• FCC

• CE

• Hi-Speed USB 2.0

• Windows

Connections

• Interface: USB 2.0

• Transfer speeds: up to 480 Mbps

• Connection type: type-A male connections

Power

• Bus powered

• Power consumption: < 500 mA (Suspend and Active

modes)

System Requirements

• Intel Pentium 1 GHz or faster PC

• 128 MB RAM or higher

• USB port (Hi-Speed USB 2.0 for Hi-Speed transfer)

• Windows XP SP2 or Vista
