INSTRUCTION MANUAL

MANUEL D'INSTRUCTION

MANUAL DE INSTRUCCIONES

Cordless Angle Nut Runner

Clé à angle sans fil

Atornillador Angular Inalámbrico

BFL080F

BFL081F

BFL120F

BFL121F

BFL200F

003614

IMPORTANT: Read Before Using.

IMPORTANT: Lire avant usage.

IMPORTANTE: Leer antes de usar.

ENGLISH (Original instructions)

SPECIFICATIONS

Model BFL080F BFL120F BFL081F BFL121F BFL200F

Hard joint

2 - 8 N • m

(17.7 - 70.9 in • lbs)

5 - 12 N • m

(44.3 - 106 in • lbs)

2 - 8 N • m

(17.7 - 70.9 in • lbs)

5 - 12 N • m

(44.3 - 106 in • lbs)

8 - 20 N • m

(70.9 - 177 in • lbs)

Fastening

torque Soft joint

2 - 7.5 N • m

(17.7 - 66 in • lbs)

5 - 12 N • m

(44.3 - 106 in • lbs)

2 - 7.5 N • m

(17.7 - 66 in • lbs)

5 - 11.5 N • m

(44.3 - 102 in • lbs)

8 - 18 N • m

(70.9 - 160 in • lbs)

Square drive 9.5 mm (3/8") 9.5 mm (3/8") 9.5 mm (3/8") 9.5 mm (3/8") 9.5 mm (3/8")

No load speed (RPM) 450/min. 250/min. 700/min. 410/min. 220/min.

430 x 65 x 74 mm

(17" x 2-9/16" x 2-15/16")

(With Battery Cartridge BH9020A)

430 x 71 x 92 mm (17" x 2-13/16" x 3-5/8")

(With Battery Cartridge BH1220)

413 x 74 x 92 mm (16-1/4" x 2-15/16" x 3-5/8")

(With Battery Cartridge BH1220C)

Dimensions

454 x 65 x 74 mm

(17-7/8" x 2-9/16" x 2-15/16")

(With Battery Cartridge BH9033A)

454 x 71 x 92 mm (17-7/8" x 2-13/16" x 3-5/8")

(With Battery Cartridge BH1233)

421 x 74 x 107 mm (16-5/8" x 2-15/16" x 4-1/4")

(With Battery Cartridge BH1233C)

Net weight 1.5 kg (3.3 lbs) 1.6 kg (3.6 lbs)

Rated voltage D.C. 9.6 V D.C. 12 V

• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.

• Specifications and battery cartridge may differ from country to country.

• Weight, with battery cartridge, according to EPTA-Procedure 01/2003

GEA006-2

General Power Tool Safety

Warnings

WARNING Read all safety warnings and all

instructions. Failure to follow the warnings and

instructions may result in electric shock, fire and/or

serious injury.

Save all warnings and

instructions for future reference.

The term "power tool" in the warnings refers to your

mains-operated (corded) power tool or battery-operated

(cordless) power tool.

Work area safety

1. Keep work area clean and well lit. Cluttered or

dark areas invite accidents.

2. Do not operate power tools in explosive

atmospheres, such as in the presence of

flammable liquids, gases or dust. Power tools

create sparks which may ignite the dust or fumes.

3. Keep children and bystanders away while

operating a power tool. Distractions can cause

you to lose control.

Electrical Safety

4. Power tool plugs must match the outlet. Never

modify the plug in any way. Do not use any

adapter plugs with earthed (grounded) power

tools. Unmodified plugs and matching outlets will

reduce risk of electric shock.

5. Avoid body contact with earthed or grounded

surfaces such as pipes, radiators, ranges and

refrigerators. There is an increased risk of

electric shock if your body is earthed or grounded.

6. Do not expose power tools to rain or wet

conditions. Water entering a power tool will

increase the risk of electric shock.

7. Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.

Keep cord away from heat, oil, sharp edges or

moving parts. Damaged or entangled cords

increase the risk of electric shock.

8. When operating a power tool outdoors, use an

extension cord suitable for outdoor use. Use of

a cord suitable for outdoor use reduces the risk of

electric shock.

9. If operating a power tool in a damp location is

unavoidable, use a ground fault circuit

interrupter (GFCI) protected supply. Use of an

GFCI reduces the risk of electric shock.

Personal Safety

10. Stay alert, watch what you are doing and use

common sense when operating a power tool.

Do not use a power tool while you are tired or

under the influence of drugs, alcohol or

medication. A moment of inattention while

operating power tools may result in serious

personal injury.

11. Use personal protective equipment. Always

wear eye protection. Protective equipment such

as dust mask, non-skid safety shoes, hard hat, or

hearing protection used for appropriate conditions

will reduce personal injuries.

12. Prevent unintentional starting. Ensure the

switch is in the off-position before connecting

to power source and/or battery pack, picking

up or carrying the tool. Carrying power tools

with your finger on the switch or energising power

tools that have the switch on invites accidents.

13. Remove any adjusting key or wrench before

turning the power tool on. A wrench or a key left

attached to a rotating part of the power tool may

result in personal injury.

14. Do not overreach. Keep proper footing and

balance at all times. This enables better control

of the power tool in unexpected situations.

15. Dress properly. Do not wear loose clothing or

jewellery. Keep your hair, clothing, and gloves

away from moving parts. Loose clothes,

jewellery or long hair can be caught in moving

parts.

16. If devices are provided for the connection of

dust extraction and collection facilities,

ensure these are connected and properly used.

Use of dust collection can reduce dust-related

hazards.

Power tool use and care

17. Do not force the power tool. Use the correct

power tool for your application. The correct

power tool will do the job better and safer at the

rate for which it was designed.

18. Do not use the power tool if the switch does

not turn it on and off. Any power tool that cannot

be controlled with the switch is dangerous and

must be repaired.

19. Disconnect the plug from the power source

and/or the battery pack from the power tool

before making any adjustments, changing

accessories, or storing power tools. Such

preventive safety measures reduce the risk of

starting the power tool accidentally.

20. Store idle power tools out of the reach of

children and do not allow persons unfamiliar

with the power tool or these instructions to

operate the power tool. Power tools are

dangerous in the hands of untrained users.

21. Maintain power tools. Check for misalignment

or binding of moving parts, breakage of parts

and any other condition that may affect the

power tool’s operation. If damaged, have the

power tool repaired before use. Many accidents

are caused by poorly maintained power tools.

22. Keep cutting tools sharp and clean. Properly

maintained cutting tools with sharp cutting edges

are less likely to bind and are easier to control.

23. Use the power tool, accessories and tool bits

etc. in accordance with these instructions,

taking into account the working conditions

and the work to be performed. Use of the power

tool for operations different from those intended

could result in a hazardous situation.

Battery tool use and care

24. Recharge only with the charger specified by

the manufacturer. A charger that is suitable for

one type of battery pack may create a risk of fire

when used with another battery pack.

25. Use power tools only with specifically

designated battery packs. Use of any other

battery packs may create a risk of injury and fire.

26. When battery pack is not in use, keep it away

from other metal objects, like paper clips,

coins, keys, nails, screws or other small metal

objects, that can make a connection from one

terminal to another. Shorting the battery

terminals together may cause burns or a fire.

27. Under abusive conditions, liquid may be

ejected from the battery; avoid contact. If

contact accidentally occurs, flush with water. If

liquid contacts eyes, additionally seek medical

help. Liquid ejected from the battery may cause

irritation or burns.

Service

28. Have your power tool serviced by a qualified

repair person using only identical replacement

parts. This will ensure that the safety of the power

tool is maintained.

29. Follow instruction for lubricating and

changing accessories.

30. Keep handles dry, clean and free from oil and

grease.

GEB050-2

CORDLESS SCREWDRIVER

SAFETY WARNINGS

1. Hold power tool by insulated gripping

surfaces, when performing an operation where

the fastener may contact hidden wiring.

Fasteners contacting a "live" wire may make

exposed metal parts of the power tool "live" and

could give the operator an electric shock.

2. Always be sure you have a firm footing.

Be sure no one is below when using the tool in

high locations.

3. Hold the tool firmly.

4. Keep hands away from rotating parts.

5. Do not touch the bit or the workpiece

immediately after operation; they may be

extremely hot and could burn your skin.

SAVE THESE INSTRUCTIONS.

WARNING:

DO NOT let comfort or familiarity with product

(gained from repeated use) replace strict adherence

to safety rules for the subject product. MISUSE or

failure to follow the safety rules stated in this

instruction manual may cause serious personal

injury.

USD301-1

Symbols

The followings show the symbols used for tool.

･volts

･direct current

･no load speed

･revolutions or reciprocation per minute

ENC005-2

IMPORTANT SAFETY

INSTRUCTIONS

FOR BATTERY CARTRIDGE

1. Before using battery cartridge, read all

instructions and cautionary markings on (1)

battery charger, (2) battery, and (3) product

using battery.

2. Do not disassemble battery cartridge.

3. If operating time has become excessively

shorter, stop operating immediately. It may

result in a risk of overheating, possible burns

and even an explosion.

4. If electrolyte gets into your eyes, rinse them

out with clear water and seek medical

attention right away. It may result in loss of

your eyesight.

5. Do not short the battery cartridge:

(1) Do not touch the terminals with any

conductive material.

(2) Avoid storing battery cartridge in a

container with other metal objects such as

nails, coins, etc.

(3) Do not expose battery cartridge to water

or rain.

A battery short can cause a large current

flow, overheating, possible burns and

even a breakdown.

6. Do not store the tool and battery cartridge in

locations where the temperature may reach or

exceed 50 ﾟC (122 ﾟF).

7. Do not incinerate the battery cartridge even if

it is severely damaged or is completely worn

out. The battery cartridge can explode in a fire.

8. Be careful not to drop or strike battery.

9. Do not use dropped or struck battery.

SAVE THESE INSTRUCTIONS.

Tips for maintaining maximum battery life

1. Charge the battery cartridge before completely

discharged.

Always stop tool operation and charge the

battery cartridge when you notice less tool

power.

2. Never recharge a fully charged battery

cartridge.

Overcharging shortens the battery service life.

3. Charge the battery cartridge with room

temperature at 10 ﾟC - 40 ﾟC (50 ﾟF - 104 ﾟF).

Let a hot battery cartridge cool down before

charging it.

4. Charge the Nickel Metal Hydride battery

cartridge when you do not use it for more than

six months.

FUNCTIONAL DESCRIPTION

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before adjusting or

checking function on the tool.

Installing or removing battery cartridge

• Always switch off the tool before insertion or

removal of the battery cartridge.

For Models BFL080F, BFL120F

003615

• To remove the battery cartridge, withdraw it from

the tool while pressing the buttons on both sides of

the cartridge.

• To insert the battery cartridge, align the tongue on

the battery cartridge with the groove in the housing

1. Battery cartridge

and slip it into place. Always insert it all the way

until it locks in place with a little click. If not, it may

accidentally fall out of the tool, causing injury to

you or someone around you.

For Models BFL081F, BFL121F, BFL200F

003616

• To remove the battery cartridge, withdraw it from

the tool while sliding the button on the front of the

cartridge.

• To insert the battery cartridge, align the tongue on

the battery cartridge with the groove in the housing

and slip it into place. Always insert it all the way

until it locks in place with a little click. If you can

see the red part on the upper side of the button, it

is not locked completely. Insert it fully until the red

part cannot be seen. If not, it may accidentally fall

out of the tool, causing injury to you or someone

around you.

• Do not use force when inserting the battery

cartridge. If the cartridge does not slide in easily, it

is not being inserted correctly.

Refresh charging

Refreshing battery adapter (optional accessory) can

refresh an inactive battery cartridge.

• Refresh charging should be done once a week.

• When you charge a new battery cartridge or a

battery cartridge that has not been used for a long

time, it may not accept a full charge. In this case,

refresh charging must be done. The battery

cartridge may decrease the tool performance,

because the chemical substance of the battery

cartridge is inactive.

Checking the remaining battery capacity

Indicating lamp

80% - 100%

60% - 80%

40% - 60%

10% - 40%

0% - 10%

Indicating lamp

Capacity

80% - 100%

60% - 80%

40% - 60%

10% - 40%

0% - 10%

orange

001254

When charging

When the charging begins, the first (far left) indicating

lamp begins to flicker. Then, as charging proceeds, the

other lamps light, one after the other, to indicate the

battery capacity.

When using

When the tool is switched on, the lamps will light to

indicate the remaining battery capacity. When the tool is

switched off, the light goes out. If the battery has not

been used for a long time, or is needed refresh charging,

the orange lamp begins to flicker. Use Makita refreshing

adapter to refresh the battery.

CAUTION:

• A battery cartridge extracted from the charger that

has been unplugged with the battery cartridge

inserted does not indicate the battery capacity due

to its protective function even if the tool is switched

on after the battery insertion into the tool. At this

time, recharge it for about five seconds before use.

NOTE:

• Please contact Makita Authorized or Factory

Service Center if the warning lamp of the battery

cartridge does not light up when using or charging.

Switch action

003617

1. Switch trigger

1. Battery cartridge

CAUTION:

• Before inserting the battery cartridge into the tool,

always check to see that the switch trigger

actuates properly and returns to the "OFF" position

when released.

To start the tool, simply pull the switch trigger. Release

the switch trigger to stop.

Reversing switch action

003618

CAUTION:

• Always check the direction of rotation before

operation.

• Use the reversing switch only after the tool comes

to a complete stop. Changing the direction of

rotation before the tool stops may damage the tool.

• When not operating the tool, always set the

reversing switch lever to the neutral position.

This tool has a reversing switch to change the direction

of rotation. Depress the reversing switch lever from the A

side for clockwise rotation or from the B side for

counterclockwise rotation.

When the reversing switch lever is in the neutral position,

the switch trigger cannot be pulled.

Lighting up the lamps

003619

CAUTION:

• Do not look in the light or see the source of light

directly.

Pull the switch trigger to light up the lamp. The lamp

keeps on lighting while the switch trigger is being pulled.

The light automatically goes out 10 seconds after the

switch trigger is released.

NOTE:

• Use a dry cloth to wipe the dirt off the lens of lamp.

Be careful not to scratch the lens of lamp, or it may

lower the illumination.

LED indicator

The lamp on the tool shows the following functions.

1. Light

2. LED indicator

1. Reversing

switch lever

Lamp Beeper

Warning against

insufficient fastening Lights upinred.Retighten thescrew

Warning for battery

cartridge capacity

Flickers inred

slowly.

Replace thebattery

with fullycharged one

Checking the

remaining battery

capacity, autostop

Lights upinred.

A long beep

A series of long

beeps

A series of short

beeps

A series of long

beeps

A series of short

beeps

A series of long

beeps

A series of long

beeps

A long beep Replace thebattery

with fullycharged one

Check thelamp, light

and beeper operation

Lights upfirstin

green, nextred.

(And then the

lightcomes on.)

Anti-reset of controller

Flickers inred

and green

alternatively.

Replace thebattery

with fullycharged one

Overheat Flickers inred

quickly.

Removethebattery

cartridge immediately

and cool thetool

down.

Improper clutch work

Flickers inred

and green

alternatively.

Ask Makita Authorized

or Factory Service

Center for repairs or

adjustment.

Operation error of the

switch trigger

Delayed re-start

Auto-stop fastening

This function works when the

tool has reached thepreset

fastening torqueand normal

tightening has been completed.

This helps overtightening to be

avoided.

For approximatelyone second

after auto-stop fastening, the

tool does not start even if the

switch trigger is pulled.

Insufficient fastening has been

performed when theswitch

trigger has released before

reaching thepreset fastening

torque.

This indicates theappropriate

time to replace thebattery

cartridge when thebattery

power becomes low.

This function works when

thebattery power is almost

used up. Atthis time, tool

stops immediately.

This function works to check the

proper operation of thelamp,

lightand beeper when abattery

cartridge has been inserted into

thetool.

This function works when an

abnormal drop of thebattery

voltage occurs for some reason,

and thetool stops.

This function works when the

temperature of thecontroller

goes upvery highly, and the

tool stops.

Thetool stops when there are

some problems with theclutch.

This function works to avoidthe

tool's immediate start upon

insertion of battery cartridge into

thetool with theswitch trigger

being pulled.

Flickers inred

and green

alternatively.

Releasetheswitch

trigger.

Function Status Action to betaken

Lights upin

green for

approximately

one second.

Status of thelamp/beeper

006387

Adjusting the fastening torque

003621

When you wish to drive machine screws, wood screws,

hex bolts, etc. with the predetermined torque, adjusting

the fastening torque as follows.

1. First remove the battery cartridge from the tool.

2. Loosen the screws securing the light cover.

3. Rotate the ring in the front of the tool by hand so

that a hole can be seen below the ring.

4. Place the battery cartridge in place and pull the

switch trigger. Release it so that the adjusting ring

rotates and becomes visible in the hole. And then

remove the battery cartridge.

003622

5. Use an optional adjusting grip to adjust the

fastening torque. Insert the pin of the adjusting

grip into the hole in the front of the tool. And then,

turn the adjusting grip clockwise to set a greater

fastening torque, and counterclockwise to set a

smaller fastening torque.

6. Align the yellow line with your desired number on

the fastening torque scale.

7. Insert the battery cartridge and be sure that a

fastening torque has been set up by using a

fastening torque tester.

8. Tighten the screws to secure the light cover and

then rotate the ring in front of the tool until the ring

is locked.

NOTE:

• Numbers on the fastening torque scale is a

guideline to set up your desired fastening torque.

ASSEMBLY

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before carrying out

any work on the tool.

Selecting correct socket or screw bit

There are different types of sockets or bits for some

models depending on applications. Choose and install a

correct socket or bit for your application.

Installing or removing socket

003623

To install the socket, push it onto the square drive of the

tool with one hand by depressing a pin on the square

drive with another hand until it locks into place. To

remove the socket, simply pull it off depressing the pin

on the square drive.

Installing or removing bit

004170

For tools with retracting sleeve

To install the bit, pull the sleeve in the direction of the

arrow and insert the bit into the sleeve as far as it will go.

Then release the sleeve to secure the bit.

To remove the bit, pull the sleeve in the direction of the

arrow and pull the bit out firmly.

For tools without retracting sleeve

To install the bit, just insert the bit into the spindle as far

as it will go.To remove the bit, pull the bit out firmly.

1. Screw bit

2. Sleeve

1. Socket

2. Hole

3. Pin

1. Angle head

2. Adjusting ring

3. Ring

4. Scale

5. Adjusting grip

Hole for Adjusting grip

Edge of Adjusting ring

Compression spring

OPERATION

Hold the tool firmly and place the socket over the bolt or

nut. Then switch the tool on. When the clutch cuts in, the

motor will stop automatically. Then release the switch

trigger.

NOTE:

• Hold the tool with its square drive pointed straight

at the bolt or nut, or the bolt or nut will be

damaged.

Limits of fastening capacity

Use the tool within the limits of fastening capacity. If you

use the tool beyond the limits, the clutch does not work.

And the tool cannot deliver enough fastening torque.

Range of fastening capacity

Torque

Revolution angle( )

N m

360

300

240

180

120

0234 5678

BFL080F

003624

BFL081F

Range of fastening capacity

Revolution angle()

TorqueN m

005026

Range of fastening capacity

Torque

Revolution angle( )

360

300

240

180

120

05678N m

91011 12

BFL120F

003625

Range of fastening capacity

Torque

Revolution angle( )

360

300

240

180

120

05678N m

91011 12

BFL121F

003626

Range of fastening capacity

Torque

Revolution angle( )

N m

360

300

240

180

120

081012 14 161820

BFL200F

003627

NOTE:

• The revolution angle means the angle which a

screw/bolt revolves when the tool attains to 100%

from 50% of desired torque.

• Use of a low temperature conditioned battery

cartridge may sometimes give warning for battery

cartridge capacity by warning lamp and beeper

which makes the tool stop immediately. In this case,

the range of fastening capacity may be inferior to

those shown in the above even if a charged battery

cartridge is used.

MAINTENANCE

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before attempting to

perform inspection or maintenance.

• Never use gasoline, benzine, thinner, alcohol or

the like. Discoloration, deformation or cracks may

result.

Replacing carbon brushes

001145

Remove and check the carbon brushes regularly.

Replace when they wear down to the limit mark. Keep

the carbon brushes clean and free to slip in the holders.

Both carbon brushes should be replaced at the same

time. Use only identical carbon brushes.

Use a screwdriver to remove the brush holder caps.

Take out the worn carbon brushes, insert the new ones

and secure the brush holder caps.

003628

To maintain product SAFETY and RELIABILITY, repairs,

any other maintenance or adjustment should be

performed by Makita Authorized or Factory Service

Centers, always using Makita replacement parts.

ACCESSORIES

CAUTION:

• These accessories or attachments are

recommended for use with your Makita tool

specified in this manual. The use of any other

accessories or attachments might present a risk of

injury to persons. Only use accessory or

attachment for its stated purpose.

If you need any assistance for more details regarding

these accessories, ask your local Makita Service Center.

• Various type of Makita genuine batteries and

chargers

• Automatic refreshing adapter

• Protector

• Angle head set

• Adjusting grip

MAKITA LIMITED ONE YEAR WARRANTY

Warranty Policy

Every Makita tool is thoroughly inspected and tested

before leaving the factory. It is warranted to be free of

defects from workmanship and materials for the period

of ONE YEAR from the date of original purchase.

Should any trouble develop during this one year period,

return the COMPLETE tool, freight prepaid, to one of

Makita’s Factory or Authorized Service Centers. If

inspection shows the trouble is caused by defective

workmanship or material, Makita will repair (or at our

option, replace) without charge.

This Warranty does not apply where:

IN NO EVENT SHALL MAKITA BE LIABLE FOR ANY

INDIRECT, INCIDENTAL OR CONSEQUENTIAL

DAMAGES FROM THE SALE OR USE OF THE

PRODUCT. THIS DISCLAIMER APPLIES BOTH

DURING AND AFTER THE TERM OF THIS

WARRANTY.

MAKITA DISCLAIMS LIABILITY FOR ANY IMPLIED

WARRANTIES, INCLUDING IMPLIED WARRANTIES

OF "MERCHANTABILITY" AND "FITNESS FOR A

SPECIFIC PURPOSE," AFTER THE ONE YEAR TERM

OF THIS WARRANTY.

This Warranty gives you specific legal rights, and you

may also have other rights which vary from state to

state. Some states do not allow the exclusion or

limitation of incidental or consequential damages, so

the above limitation or exclusion may not apply to you.

Some states do not allow limitation on how long an

implied warranty lasts, so the above limitation may not

apply to you.

repairs have been made or attempted by others:

repairs are required because of normal wear and

tear:

the tool has been abused, misused or improperly

maintained:

alterations have been made to the tool.

EN0006-1

1. Screwdriver

2. Brush holder

cap

1. Limit mark

Otros manuales para BFL080F

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Manuales populares de Aprietatuercas de otras marcas

KUKEN

KUKEN PTS-800 EX Manual de usuario
