MAJORITY Orwell Manual de usuario

HOME AUDIO • CAMBRIDGE

Orwell

Digital Radio

User Manual

What’s In the Box?..............................................................................................................

Controls And Functions…………………………..………………………………………….....................

Instructions Guide…………………………………………………………………………….......................

Basic Operation……………………………………………………………………………………

DAB/DAB+ Radio………………………………………………………………………………….

DAB/DAB+ Radio Presets…………………………………………………………………….

FM Radio………………………………………………………………………..........................

FM Radio Presets…………………………………………………………………………………

Bluetooth Mode……………………………………………………………………………………

Settings : Clock and Date………………………………………………….......................

Settings : Dual Alarm Clock…..………………………………………………………………

Settings : Alarm Functions and Snooze………………………………………………...

Radio Settings………………………………………………………………………………………

Additional Features………………………………………………………………………………

Troubleshooting………………………………………………………………………………........................

Specification…………………………………………………………………………………………………………

Warranty……………………………………………………………………………………………………………...

Safety Information…………………………………………………………………………….......................

Contents

What’s in the Box?

Box Contents

A. Majority Orwell Radio

B. Type-C cable

C. Supply User Guide

Top View

Controls & Functions

1. Preset 1

2. Preset 2

3. Preset 3

4. Preset 4

5. Preset 5+

6. +Vol-

7. Power

8. Previous

9. Mode

10. OK

11. Menu/Info

12. Next

13. DC IN

14. Reset

15. Headphone

16. Antenna

23 4 5 6

810 12

Basic Operation

Please note all (Ref.) refer to Page 3-4Controls and Functions mapping guide.

Starting up your radio

Before using for the first time, charge the radio for fully portable play, by plugging the

USB-C cable into the DC-IN 5V 1A port and connect to USB-plug placed in mains-

power supply, or charge from power-bank or other USB-C power device.

Press and hold the ‘Power’ (Ref.7) button to turn on radio to Standby, and screen will

display battery charging.

Once display shows fully charged, you can remove the radio from the USB-C power

and fully turn on radio. Alternatively, you can continue to keep connected to USB-C

power.

Ensure the radio is positioned where you have a good radio signal, making sure the

antenna (Ref.16) is extended in full, so you can get the best possible signal.

Press the ‘Power’ (Ref.7) button to fully turn-on radio.

From the ‘Welcome to Digital Radio’ screen, you will be required to select your chosen

radio language.

Select ‘Mode’ (Ref.9) to switch in between DAB, FM and Bluetooth.

Note: When DAB Mode is activated for thefirst time, a scan will automatically

commence, orwill play the last station before theunit isturned off.

Standby

To change your radio back to standby, press the ‘Power’ (Ref.7) button.

To turn your radio off completely, press and hold the ‘Power’ (Ref.7) button.

Instructions Guide

DAB/DAB+ Radio

Fully extend the antenna (Ref.16) to ensure that the best signal can be received

before scanning.

From the ‘Welcome to Digital Radio’ screen, your radio will automatically scan for

DAB+ stations.

On first use, it will automatically scan all stations and save them. Additionally, the

Majority Orwell will synchronize the time and date of the station.

If the unit hasn’t automatically scanned or you would like to rescan the available

stations, press and hold the ‘Menu/Info’ (Ref.11) button and select ‘Full Scan’ by

pressing ‘◀ ◀’ or ‘▶ ▶’ button (Ref.8/12).

It would be advisable to repeat on DAB Mode if you are having trouble listening to a

specific radio station.

By selecting the ‘Full Scan’, the radio will scan for available stations on the frequency

band and store all stations that have a good signal. After searching has finished, it will

automatically play the first station stored.

To select a different station, use the ‘◀ ◀’ or ‘▶ ▶’ button (Ref.8/12) to find your

desired station. Select the station by clicking the ‘OK’ (Ref.10) button.

Note: DAB Mode is not indicated bydisplaying ‘DAB’ on the screen. The first

available radio player will display rolling text.

Rescanning DAB Stations

When on DAB Mode, press and hold ‘Menu/Info (Ref.11) button and select ‘Full Scan’

to rescan for available DAB+ stations in your area. The radio will now begin scanning

for DAB+ stations with the screen displaying ‘Full Scan’.

Instructions Guide

DAB/DAB+ Presets

Storing DAB Stations

You can store up to 20 DAB+ radio stations for easy navigation.

To store a station that you are currently playing:

Press and hold the ‘Preset 1-5+’ (Ref.1/5) button for 2-3 seconds until the Preset

Store settings open and the display shows ‘Preset Store <x:(Empty)>’. Release the

‘Preset’ button.

Press the ‘◀ ◀’ or ‘▶ ▶’ button (Ref.8/12) to change the ‘<1’ to the number you want

to store the station as. Press ‘OK’ (Ref.10) button to save the station to that preset

number . The display will then show: ‘Preset x stored’.

Note: If there is an existing DAB+ station stored under a preset, it will be

overwritten when you store the new station.

Recalling a DAB+ stored station

Press the ‘‘Preset 1-5+’ (Ref.1/5) button to open Preset Recall settings. Do not hold

down the button as this will open Preset Store settings.

Press the ‘◀ ◀’ or ‘▶ ▶’ button (Ref.8/12) to scroll through your preset stations.

Follow by pressing the ‘OK’ (Ref.10) button to select your choice and the station will

begin playing.

Instructions Guide

Station Information for DAB/DAB+ Radio

When you are listening to a DAB/DAB+ radio station with good signal, you can press

the ‘Info/Menu’ button (Ref.11) repeatedly to show different program information such

as:

Signal Strength: Displays a signal bar with the strength of the current station.

Bit Error Rate: Provides details of the signal error rate.

Channel and Frequency: Displays the station’s transmission channel number and

frequency.

PTY (Program Type): Shows the type and description of the program provided by the

DAB+ station.

Time and Date: Displays the time and date information provided by the broadcaster.

Bit Rate: The data rate at which the signal is being transmitted.

Dynamic Label Segment (DLS): Displays scrolling text information supplied by the

broadcaster.

Instructions Guide

FM Radio

Press the ‘Mode’ button (Ref.9) multiple times to switch between DAB, FM and

Bluetooth. The first time you switch to FM Mode, the FM frequency ‘87.5MHZ’ will be

displayed in the screen.

Fully extend the antenna (Ref.16).

To scan for the available stations with good signal up the bandwidth, press the

button ‘▶ ▶’ (Ref.12) for the radio to begin scanning up the frequency band. The next

available station with good signal will then begin to play.

To scan down the frequency band, press and hold the ‘◀ ◀’ button (Ref.8) for a few

seconds for the station down the frequency band with good signal.

How to tune a specific frequency manually

To listen to a specific frequency, press and hold the ‘▶ ▶’ button (Ref.12) to search

up the bandwidth quickly and hold the ‘◀ ◀’ button (Ref.8) to search down quickly. It

will stop searching when the button is released.

To search slowly, press ‘◀ ◀’ or ‘▶ ▶’ (Ref.8/12) multiple times to scroll through.

Stereo and Mono

When on FM Mode, press and the ‘Info/Menu’ button (Ref.11) and select ‘Yes’ or ‘No’

by pressing ‘◀ ◀’ or ‘▶ ▶’ (Ref.8/12) to switch between Stereo and Mono Mode.

Instructions Guide

FM Radio Presets

Storing FM Stations

You can store up to 20 FM radio stations for easy navigation. To store a station that

you are currently playing:

Press and hold the ‘Preset 1-5+’ (Ref.1/5) button for 2-3 seconds until the Preset

Store settings open and the display shows ‘Preset Store <x:(Empty)>’. Release the

‘Preset’ button.

Press the ‘◀ ◀’ or ‘▶ ▶’ button (Ref.8/12) to change the ‘<1’ to the number you want

to store the station as. Then press ‘OK’ (Ref.10) button to save the station to that

preset number. The display will then show ‘Preset x stored’.

Note: If there is an existing FM station stored under a preset, it will be overwritten

when you store the new station.

Recalling a FM stored station

Press the ‘Preset 1-5+’ (Ref.1/5) button to open Preset Recall settings. Do not hold

down the button as this will open Preset Store settings.

Press the ‘◀ ◀’ or ‘▶ ▶’ button (Ref.8/12) to scroll through your preset stations.

Follow by pressing the ‘OK’ (Ref.10) button to select your choice and the station will

start playing.

Instructions Guide
