Owner’s Manual
Mahindra Goa
ISSUED: JUNE 2007
MAHINDRA & MAHINDRA LTD.
GATEWAY BUILDING, APOLLO BUNDER,
MUMBAI 400039, INDIA
3
Introduction
MAHINDRA GOA
1
Congratulations! On purchasing
the MAHINDRA GOA.
Your MAHINDRA incorporates the best
blend of luxury and sophistication offering
you the comfort of a car with the thrill of
a SUV.
Before you start driving your MAHINDRA,
we strongly suggest you to spend some
time understanding it better. A good way to
do this would be to read this manual while
simultaneously exploring your MAHINDRA
physically.
Such familiarization, we reckon, will go a
long way in enhancing the pleasure and
experience of driving your MAHINDRA.
We’ll be delighted to know about your
experience with your MAHINDRA. We wish
you happy & safe motoring in your new
vehicle.
4
Introduction
MAHINDRA GOA
1
Note
In view of policy of continuously
improving our products, we reserve the
right to alter specifications or designs
without prior notice and without
liability / Obligation. Illustrations do
not show the vehicle in the standard
form. Please be aware that this manual
applies to all models and options. As a
result you may find some explanations
for equipment not installed on your
vehicle.Alltheinformation,illustration,
and specifications in this manual are
based on the latest product information
available at the time of publication.
Due to improvements and changes in
design & specifications there may be
differences between your vehicle and
the information on this manual.
An Authorised Mahindra Dealer
knows your vehicle best. So when
maintenance or service is necessary,
that’s the place to go.
Caution
Any unauthorised add-on electrical
/ electronic installation (or) installing a
mobile two-way communication system
in your Mahindra vehicle could affect
electronically controlled fuel injection
system (CRDe / MPFI), ABS and other
electronic units. Before installing such
system / equipment contact your Mahindra
Authorised dealer.
Warning
AWARNINGindicatesasituation
in which serious or fatal injury could
result if the warning is ignored.
Caution
A CAUTION indicates a hazardous
situation which, if not avoided may result
in minor (or) moderate injuries, damage to
your vehicle or other properties.
Note
A NOTE provides information
and sometimes suggests how to make
better use of your vehicle.
5
Introduction
MAHINDRA GOA
1
Modification of your Mahindra
This vehicle should not be modified with
non-genuine products. Modification with
non-genuine parts / products could affect
performance, durability & safety of the
vehicle, and may even violate governmental
regulations. In addition, performance
problems or damage resulting due to the
unauthorised modification may not be
covered under warranty.
Keep this manual in the vehicle as a
reference for safe & enjoyable driving of
your Mahindra. This should be given along
with the vehicle to the next owner when
the vehicle is sold to the next owner.
Environmental Caring
Your vehicle has been designed with
the aim of caring for the environment. A
number of features have been incorporated
in your vehicle to ensure environmental
compatibility throughout their life cycle.
As a user, you too can contribute to
protect the environment by operating your
vehicle in a proactive manner. It is mostly
depends on your driving style and the way
you maintain your vehicle. Do not dispose
of parts replaced in the course of regular
vehicle maintenance (like battery, oil filter,
air filter, etc.) and oil containers (empty
or with used oil, etc.) with house hold
waste. Dispose of them through specialist
organizations. In all cases, comply with
state, territory and/or local bye-laws.
6
Introduction
MAHINDRA GOA
1
Graphic Symbols on your vehicle
Some of the following symbols are used to identify controls & display on your vehicle.
LIGHTS WATER IN FUEL FILTER HEADLIGHT LOW BEAM PARKING LIGHTS HAZARD WARNING
FLASHER REAR WINDOW
DEFROSTER HORN
WINDSCREEN WIPER WINDSCREEN WIPER &
WASHER REAR WIPER REAR WIPER & WASHER VENTILATOR FAN AC HIGH COOL AC LOW COOL
AC FACE MODE AC FACE/FLOOR MODE AC FLOOR MODE AC FLOOR &
DEFROSTING MODE DEFROSTER MODE AIR RECIRCULATION
Some of indicators & warning lights in instrument cluster
Security System Status
Battery Discharge Warning Light
Low Engine Oil Pressure Warning Light
Anti-Lock Brake System Warning Light
Door Ajar Warning Light
Engine Mallfunction Light
Seat Belt Warning Light
Fuel
Low Brake Fluid
Turn signal warning light
Head light beam
Engine pre-heater/glow-plug light
4WD Low indicator light
4WD high indicator light
Check Engine Warning Light
Rear Fog Light
Temperature
Parking Brake
7
Before Driving
MAHINDRA GOA
2
Contents
Identification Numbers _____________ 8
Seating Adjustments ______________ 12
Ignition Switch cum Steering Lock ___ 21
Dash Board______________________ 23
Combination Levers_______________ 24
Headlight Leveling / Guiding Lights __ 31
Instrument Cluster CRDe __________ 33
Cruise Control ___________________ 41
Cruise Controls / Audio Controls_____ 42
Voice Messaging System ___________ 43
Follow Me Home Headlight _________ 47
Rear View Mirrors ________________ 48
Foot Pedals _____________________ 50
Steering ________________________ 53
Transmission / Gear Shift __________ 54
Bonnet Release Lever _____________ 55
8
Before Driving
MAHINDRA GOA
2
Identification Numbers
Vehicle Identification Number
(VIN)/Vehicle Serial Number
Vehicle Identification Number (VIN) /
vehicle serial number is the legal identity
of your vehicle. It is used in registering
the ownership. To locate the vehicle serial
number and the engine number, open the
bonnet. You will find both the numbers on
a label near the bonnet release lever.
J
Engine Number
9
Before Driving
MAHINDRA GOA
2
Chassis Number
The chassis number is punched on the
right side of the chassis close to the front
right wheel, as shown in diagram given
alongside.
Engine Number
The engine number is punched on left-hand
side top face of the engine front cover.
This engine number is also punched on a
number plate located near bonnet release
lever.
Keys
Your MAHINDRA comes with a set of two
identical keys. The keys operate all locks
in your MAHINDRA including those of the
doors, ignition cum steering and fuel lid (if
applicable). We advise you to keep one of
these keys at a safe place for emergency
use (but not in the vehicle).
Central Lock
Close
Central Lock
Open
10
Before Driving
MAHINDRA GOA
2
Note
A new pair of keys can be acquired
through Mahindra Authorised Dealer
by stating the key number provided on
the tag.
Warning
Do not leave the ignition key in
your vehicle especially when children
are in the vehicle.
Never leave children & pet animals
unattended inside the vehicle.
Opening the Doors from Outside
Unlock the door using the remote or key
as applicable.
Place your hand behind the handle.
Press the inner lever towards you & pull
the door.
Opening the door from inside
Pull the lever as shown in the picture &
push the door.
Door locks
Both the front doors can be locked from
both the inside and the outside, using
either the door-lock lever or the key when
the door is closed. The upper door-lock
levers needs to be depressed individually
to lock doors from the inside. The driver’s
door can be locked only from the outside
with the key. This ensures you will never be
stranded outside, even if the keys are left
inside the vehicle.
The rear doors can be unlocked from inside
only.
