Magicfx FLAMEBLAZER Manual de funcionamiento

FLAME FX PART01875

rev 01-01

USER AND INSTALLATION MANUAL

ENGLISH

FLAMEBLAZER.

2 MAGICFX FLAMEBLAZER®—User and Installation Manual

DISCLAIMER

WARNING Read this manual carefully before installing and/or using this

product. Failure to read the manual and to follow the printed

instructions may lead to personal injury and/or damage to the

product.

Nothing from this publication may be copied, reproduced and/or published by

means of printing, photocopying or by any other means, without the prior written

approval of MAGIC FX.

MAGIC FX reserves the right to modify specications stated in this manual.

TRADEMARKS

Any brand names mentioned in this manual are registered trademarks of their

respective owners.

LIABILITY

MAGIC FX accepts no liability for claims from third parties arising from unauthorised

use, use other than that stated in this manual, and use other than in accordance with

the General Conditions registered at the Chamber of Commerce.

We further refer to the General Conditions. These are available on request, free of

charge.

Although considerable care has been taken to ensure a correct and comprehensive

description of all relevant components, the manual may nonetheless contain errors

and inaccuracies.

Should you detect any errors or inaccuracies in the manual, we would be grateful if

you would inform us. This helps us to further improve our documentation.

MAGICFX FLAMEBLAZER®—User and Installation Manual 3

TABLE OF CONTENTS

Disclaimer 2

Trademarks 2

Liability 2

Introduction 4

Target group 4

Language 5

Abbreviations 5

Revision table 5

1 Description 6

1.1 Main parts 7

1.2 FLAMEBLAZER fuel 7

1.3 Technical data 8

  

  

1.6 ARM control 10

1.7 DMX control 10

1.8 Display panel 11

  

2 Safety 15

2.1 General safety rules 15

2.2 Rigging 15

2.3 Noise Levels 15

  

2.5 Safety warnings 16

  

  

  

  

3.4 Mount on a truss 26

3.5 Connect the machine 28

3.6 Fire with DMX 31

3.7 Fire with pyro 31

3.8 Use the emergency stop 32

  

5 Maintenance 32

6 Correct disposal 34

7 EC Declaration of Conformity 35

4 MAGICFX FLAMEBLAZER®—User and Installation Manual

INTRODUCTION

Congratulations! You have bought a great new product from MAGIC FX.

This manual contains all information required for the intended use of the equipment.

Deviation from the described intended use can result in a hazardous situation and/or

property damage.

This manual includes notes and warnings on safe operation of the equipment. These

notes and warnings are accompanied by the following icons. Read them attentively!

DANGER Indicates a hazardous situation that, if not avoided, will result in

death or serious injury. This signal word is to be limited to the most

extreme situations.

WARNING Indicates a hazardous situation that, if not avoided, could result

in death or serious injury.

CAUTION Indicates a hazardous situation that, if not avoided, could result

in minor or moderate injury.

NOTICE Indicates information considered important, but not hazard-

related (e.g. messages relating to property damage).

TARGET GROUP

This manual is targeted at authorised personnel in the event industry that install and

operate the FLAMEBLAZER and the required ARM SYSTEM.

Authorised personnel are those who:

• Are appointed by their supervisor to install and/or operate FLAMEBLAZER and

the related ARM SYSTEM at the event.

• Are trained in recognizing and avoiding hazards related to SFX applications

at events.

• Are familiar with the safety instructions of each involved ARM SYSTEM

component.

• Are familiar with and abide by the applicable local, national and

international laws and regulations.

MAGICFX FLAMEBLAZER®—User and Installation Manual 5

LANGUAGE

This document contains the original instructions in English. In case you require other

languages please contact MAGIC FX.

ABBREVIATIONS

 Description

SFX Special eects

DMX Digital Multiplex

RDM Remote Device Management

ARM SYSTEM MAGICFX®SFX SAFETY ARM SYSTEM

ARM CONTROLLER MAGICFX®SFX SAFETY ARM CONTROLLER

E-STOP MAGICFX®SFX SAFETY E-STOP

TERMINATOR MAGICFX®SFX SAFETY TERMINATOR

FLAMEBLAZER MAGICFX®FLAMEBLAZER

Abbreviations

REVISION TABLE

Doc nr Revision Date Description Author Approved

PART01875 01-00 03-6-2020 Initial release MB, ES RD

PART01875 01-01 27-10-2020 Updated graphics PW LL

PART01875 01-02 10-11-2022 Updated ARM SYSTEM TF PvdW

6 MAGICFX FLAMEBLAZER®—User and Installation Manual

1 DESCRIPTION

The FLAMEBLAZER is a special eects machine for controlled emission of ame jets

into the air in a xed direction.

The machine uses specic ammable fuels that are projected from a single outlet

across spark ignition probes to produce the ame jet. An integrated electric pump

draws the fuel from the 5 L can and generates the ring pressure.

There are three nozzles available with the FLAMEBLAZER which are interchangeable,

allowing the user to choose a small, medium or large ame. Based on zero wind the

sizes are as follows:

• L nozzle, up to 10 m (included);

• S nozzle, up to 6 m (accessory);

• M nozzle, up to 8 m (accessory).

A specic nozzle exchange tool is available to change between the S, M and L

nozzles (SFX 1404)

The FLAMEBLAZER is operated with DMX and RDM, or with an external low voltage

pyro controller (9-40 Vdc). The FLAMEBLAZER can be operated in sequence with

multiple machines. Furthermore, the FLAMEBLAZER is congured for safety control with

an ARM SYSTEM.

MAGICFX FLAMEBLAZER®—User and Installation Manual 7

1.1 MAIN PARTS

BURN CHAMBER

FLUID ENCLOSURE

PYRO INPUT

ARM CONTROLLER

INPUT & OUTPUT

SAFETY EYE

DMX INPUT & OUTPUT

(5-POLE)

SCREEN & BUTTONS FX LED INDICATION

POWER INPUT & OUTPUT

Main parts

1.2 FLAMEBLAZER FUEL

The FLAMEBLAZER uses two types of fuel to create the eect. The fuel is loaded into an

ADR Can 5 L located in the machine.

NOTICE Only use these types of fuel: Isopropanol, ISOPAR G, H & L. The use

of other fuels or water may degrade the performance of the

machine or cause internal damage.

CAUTION Fuels are highly ammable and must be handled with caution

and in accordance with local health and safety regulations.

Always follow the safety instructions from the fuel packaging

when handling and working with the fuel.

8 MAGICFX FLAMEBLAZER®—User and Installation Manual

1.3 TECHNICAL DATA

Product Product Name FLAMEBLAZER

Product Code MFX1401

Product Type FLAME FX

Main

Dimensions

Length 410 mm 16.4 in

Width 300 mm 11.8 in

Height 281 mm 11 in

Weight Empty Weight 18.7 kg 41 lbs

Package Length 540 mm 21.3 in

Width 400 mm 15.7 in

Height 420 mm 16.5 in

Packaged Weight 20.7 kg 45.6 lbs

Environment Minimum Temperature -10 ºC 14 ºF

Maximum Temperature) 50 ºC 122 ºF

Humidity (Relative) 20 % to 90 % (non condensing)

Electrical Voltage Input 220-250 Vac

Voltage Frequency 50-60 Hz

Power Consumption 370 W

Power Connector Neutrik®powerCON TRUE1 (in&out)

Controlling Control Options DMX / Pyro

Control Protocols DMX512-A (ANSI E1.11)

RDM (ANSI E1.20)

≈ 9-40 Vdc

Control Connectors Neutrik®5-pole male/ female XLR

4 mm banana socket

Safety

controlling

ARM Connector Neutrik®etherCON, RJ45 (in&out)

 Congure Options On Device & RDM

Usage Consumable(s) Isopropanol, ISOPAR G, H & L

Consumable Consumption S nozzle: ≈ 12 ml/s

M nozzle: ≈ 30 ml/s

L nozzle: ≈ 50 ml/s

Technical data

MAGICFX FLAMEBLAZER®—User and Installation Manual

1.4 PRODUCT IDENTIFICATION

Type plate

1.5 ACCESSORIES

Code Product Included

SFX1401 MAGICFX®FLAMEBLAZER Nozzle S

SFX1402 MAGICFX®FLAMEBLAZER Nozzle M

SFX1403 MAGICFX®FLAMEBLAZER Nozzle L 1x

SFX1404 FLAMEBLAZER Nozzle exchange tool

MFX0313 Schuko to Neutrik®powerCON TRUE1 cable - 1.5 m

MFX0305 MAGICFX®BASEPLATE II

MFX3106 Doughty Half Coupler (100 kg) M10

SPR00119 Safety Steel

SPR01885 Empty ADR Can 5 L (w/out Cap) 1x

SPR90106 FLAMEBLAZER CUSTOM CAN CAP 5L 1x

MFX3080 MAGICFX®Flame Fluid IPA 5L

MFX3086 MAGICFX®Flame Fluid Isopar L 5L

Accessories

Please contact MAGIC FX for additional possibilities.

For information about the accessories of the ARM CONTROLLER (MFX3220), refer to the

ARM CONTROLLER User and Installation Manual (PART01882).

10 MAGICFX FLAMEBLAZER®—User and Installation Manual

1.6 ARM CONTROL

NOTICE The FLAMEBLAZER cannot be operated without connection to an

ARM CONTROLLER in an ARM SYSTEM.

The FLAMEBLAZER is congured for safety control with an ARM SYSTEM. The

FLAMEBLAZER cannot be operated without the safety signal from the control unit of

the ARM SYSTEM: The ARM CONTROLLER. When there’s no signal, the internal relief

valve opens. The system depressurises immediately and prevents the FLAMEBLAZER to

produce any high-risk SFX output. As a result, any related hazard/or property

damage is stopped and prevented.

The ARM CONTROLLER is equipped with a key switch to arm/disarm the connected

SFX machine(s), an emergency stop button, and a reset button. The ARM SYSTEM is

wired with EtherCON cables that carry the safety signal from the ARM CONTROLLER.

For more information about the ARM SYSTEM and to learn how to congure a

complete safety system, refer to the ARM SYSTEM Conguration Manual (PART02323).

For more information about the ARM CONTROLLER and to learn how to correctly set

up and use the ARM SYSTEM, refer to the ARM CONTROLLER User and Installation

Manual (PART01882).

1.7 DMX CONTROL

The FLAMEBLAZER is controlled with 1 enable address and 1 operational address:

DMX address Address range Control

Enable address 1 - 512 Device enable/disable

Start address 1 - 512 Eect trigger

DMX addresses

The enable address cannot be the same as the operational address. Operating of

these addresses results in the following:

DMX address DMX Value (decimal) Result

Enable address 0 99 Device disabled

100 154 Device enabled

155 255 Device disabled

Start address

(Eect trigger)

0 199 No output

200 255 Output eect

Operation of the DMX addresses

Otros manuales para FLAMEBLAZER

Tabla de contenidos

Otros manuales de Equipo de DJ de Magicfx

Magicfx

Magicfx MFX1201 Manual de usuario

Magicfx

Magicfx Super Blaster XL Manual de usuario

Magicfx

Magicfx SNOWCASE Series Manual de funcionamiento

Magicfx

Magicfx SUPERBLASTER Manual de funcionamiento

Magicfx

Magicfx SHOT BASE DMX Manual de usuario

Magicfx

Magicfx SMOKEBUBBLE BLASTER MFX1603 Manual de funcionamiento

Magicfx

Magicfx CO2LAUNCHER Manual de funcionamiento

Magicfx

Magicfx STADIUMSHOT III Manual de funcionamiento

Magicfx

Magicfx DEEJAY SHOTGUN MFX0371 Manual de usuario

Magicfx

Magicfx STADIUMSHOT III Manual de funcionamiento

Magicfx

Magicfx MFX0803 Manual de funcionamiento

Magicfx

Magicfx SPARXTAR SPARK FX Manual de funcionamiento

Magicfx

Magicfx STAGE SHOT II Manual de funcionamiento

Magicfx

Magicfx Snowbox SNOW FX Manual de funcionamiento

Magicfx

Magicfx Power Drop Manual de usuario

Magicfx

Magicfx MFX3203 Manual de funcionamiento

Magicfx

Magicfx STAGE SHOT II Manual de funcionamiento

Magicfx

Magicfx CONFETTI FX SUPERBLASTER II Manual de funcionamiento

Magicfx

Magicfx CO2JET II Manual de usuario

Magicfx

Magicfx CO2 Jet Manual de funcionamiento

Magicfx

Magicfx SHOR BASE MFX0360 Manual de usuario

Magicfx

Magicfx PSYCO2JET Manual de funcionamiento

Magicfx

Magicfx COMBINER RACK MFX3224 Manual de funcionamiento

Magicfx

Magicfx CO2 GUN II Manual de funcionamiento

Manuales populares de Equipo de DJ de otras marcas

ALPHA LITE

ALPHA LITE ALPHA 1500 Manual del propietario

Chauvet

Chauvet OVATION E-930VW Manual de usuario

Zumtobel

Zumtobel APHRODITE Home Manual de usuario

Snow Masters

Snow Masters Zig Oscillator Manual de usuario

EuroLite

EuroLite 50530554 Manual de usuario

Beamz

Beamz BUV243 Manual de usuario

thomann

thomann Stairville DJ Lase 40-G MK-III Manual de usuario

Eagletone

Eagletone 6 Eyes Flower Manual de usuario

EuroLite

EuroLite FLD-1508 Manual de usuario

Technical Pro

Technical Pro LG8xSEA Manual de usuario

JB Systems

JB Systems Lounge Laser DMX Manual de usuario

Lightmaxx

Lightmaxx Vega Halo 90 Manual de usuario

Elation

Elation FUZE WASH Z350 Manual de usuario

Maverick

Maverick MK3 WASH Manual de usuario

Infinity

Infinity TF-260C7 Fresnel Manual de usuario

Chauvet

Chauvet EVE E-50Z Manual de usuario

Eliminator Lighting

Eliminator Lighting E 138 Manual de usuario

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Manual de usuario
