Magic Chef MCSCD6W3 Manual de usuario

COUNTERTOP DISHWASHER

User Manual

MODEL MCSCD6W3

IMPORTANT SAFEGUARDS

READ THIS MANUAL AND ALL INSTRUCTIONS BEFORE USE.

1. Do not use this appliance for other than its intended use.

2. Do not unplug your appliance by pulling on the power cord. Always grasp the plug !rmly and

pull it straight out from the outlet.

3. Do not operate your appliance in the presence of explosive fumes.

4. Do not add or mix any "ammable or explosive substances to wash.

5. Do not operate your appliance when parts are missing or broken.

6. Do not abuse, sit on or stand on the door or the dishwasher rack.

7. Do not use this appliance for commerical dishwashing purposes.

8. Do not wash plas#c items unless they are marked dishwasher safe or the equivalent. For

plas#c items without such markings, check the manufacturers recommenda#ons.

9. Do not operate this appliance unless all enclosure panels are properly in place.

10. Do not tamper with controls.

11. Do not touch the HEATING ELEMENT during or a$er immediate use.

12. Do not allow children to play in or on the appliance. To reduce risk of injury, close

supervision and observa#on of children is needed around the dishwasher.

13. Do not repair or replace any part of the appliance or a%empt any servicing unless speci!cally

recommended in the user repair instruc#ons that you understand and the necessary skills to

carry out such dishwasher servicing.

14. Do not use this dishwasher outdoors.

15. Do not use extension cords or adapters to connect the unit to any electrical power source.

-PAGE 2-

16. Use only detergents or we!ng agents recommended for use in a dishwasher and keep them

out of the reach of children.

17. When loading items to be washed:

A) Locate sharp items to prevent any damage to the door seal.

B) Load sharp knives with the handles up to reduce the risk of any personal injuries.

18. This appliance must be properly installed in accordance with the installa"on instruc"ons

before its use.

19. This appliance must be connected to a proper electrical outlet with the correct electrical

supply.

20. Proper grounding must be ensured to reduce the risk of shock and #re. DO NOT CUT OR

REMOVE THE GROUNDING PLUG. If you do not have a three-prong electric receptacle outlet

in the wall, have a cer"#ed electrician install the proper receptacle. The wall receptacle

MUST be properly grounded.

21. To reduce the risk of injury, immediately replace worn power cords, loose plugs and/or

power outlets.

22. Disconnect electrical power and water intake hose to dishwasher before cleaning and/or

servicing.

23. If your old appliance is not being used, we recommend that you store the unit out of the

reach of children or remove its door. This will reduce the risk of injury to children.

24. Hydrogen gas may be produced if the water heater has not been used in more than two

weeks. This could be explosive and can explode under certain circumstances. If this is the

case, before using this appliance, turn on all the hot faucets and let the hot water run for a

few minutes. This will let the trapped hydrogen escape. During this process do not turn on

an electric appliance, smoke, light a match or lighter, or use a $ame to avoid serious injury,

due to the highly $ammable nature of hydrogen gas.

-PAGE 3-

ELECTRICAL REQUIREMENTS

GROUNDING INSTRUCTIONS

This appliance must be plugged into at least a 15 AMP 120 Volt 60 Hz grounded outlet. This

appliance must be grounded. It is equipped with a 3-prong power cord with a grounding

plug. The plug must be plugged into an outlet that is properly installed and grounded.

Improper use of the grounded wire can result in the risk of electric shock.

Consult a quali!ed electrician if necessary. Do not a"empt to tamper or modify the plug in

any form.

Avoid the use of an extension cord because it may overheat and cause a risk of !re.

However, if it is necessary to use an extension cord:

A) Use only a 3-prong extension cord with a 3-prong grounding plug.

B) The marked ra"ng of the extension cord must be equal to or

greater than the ra"ng of this appliance.

C) The extension cord should be posi"oned such that it does not

drape over the counter or tabletop where it can be pulled by

children or tripped over.

ATTEMPTING ANY MAINTENANCE OR CLEANING

To minimize the possibility of electric shock, unplug this appliance from the power supply or

disconnect at the household electrical panel by removing the fuse or switching o# the circuit

breaker before a$emp"ng any maintenance or cleaning.

NOTE: Pressing the Power ON/OFF bu"on to an OFF posi#on does NOT disconnect the

appliance from the power supply.

Do not, under any

circumstances, cut,

remove, or bypass the

grounding prong.

Wall outlet with a

3-prong receptacle.

Power supply cord with

3-prong grounding plug.

WARNING

!WARNING

-PAGE 4-

SPECIFICATIONS

PARTS AND FEATURES

CONTROL PANEL

FRONT VIEW

1) Power Light (ON/OFF) 5) Start/Reset Bu!on

2) Power Bu!on (ON/OFF) 6) Delay Feature

3) Wash Cycle Selector 7) Intake Warning Light

4) Delayed Start Bu!on 8) Rinse Aid Warning Light

23 4 5

-PAGE 5-

PARTS AND FEATURES

INSIDE VIEW BACK VIEW

฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀-PAGE 6-

INSTALLATION INSTRUCTIONS

UNPACKING AND PROPER PLACEMENT

UNPACKING

1. Inspect and remove all packing materials. This includes the foam

and any adhesive tape both inside and outside of the unit.

2. Inspect and remove any remains of packaging, tape, or printed

materials before powering on your appliance.

3. Check to see if you have all of the following parts:

Quick Faucet Adapter (1)

Instruc!on Manual (1)

Measuring Cup for Powdered Detergent (1)

Measuring Spoon for Liquid Rinse Aid (1)

Clip on Basket for 3-in-1 Tablets (1)

Rack (1)

Cutlery/Silverware Basket (1)

4. Clean the interior surface with lukewarm water using a so" cloth.

PROPER PLACEMENT

1. First determine the best countertop surface loca!on for your new

dishwasher. It must be close to a 120 Volt (15 Amp) outlet and a

sink with water supply and drainage system.

2. The minimum height clearance required to install your dishwasher

on a countertop surface with overhead cupboards or kitchen

cabinets is 17.8. This countertop dishwasher is 17.2 in height.

(Reference the diagram on the next page for more informa!on)

-PAGE 7-

THE QUICK FAUCET ADAPTER EASILY CONNECTS TO THE SINK FAUCET.

A) First remove aerator from your faucet nozzle and a!ach the quick connect threaded

adapter to the faucet. The quick connect faucet adapter allows easy snap-on/snap-

o" connec#on to standard (7/8 diameter) faucets.

B) Connect the dishwasher Quick Connect Faucet Adapter to the faucet $rst to ensure

the hose length $ts the dishwashers selected loca#on. Both hose and $%ngs must

be connected to the back of the dishwasher. The plas#c water intake and drain

$%ngs are unique to each design and are made to easily $t the dishwasher.

A hose that a!aches to a sink spray can burst if it is installed on the same

water line as the dishwasher. If your sink has a sink spray, it is recommended that the hose

be disconnected and the hole plugged.

C) Water Intake Hose: Connect to the rear of the dishwasher using the large, 4-corner

shaped wing nut.

D) Drain Hose: Connect to the rear of the dishwasher. It is suggested you use pliers to

#ghten but DO NOT over #ghten.

1) Drain Port Connec#on 5) Faucet Adapter 9) Locking Collar

2) Quick Connect Connec#on 6) Faucet Washer 10) Inlet Hose Connec#on

3) Inlet Port Connec#on 7) Pressure Relief Value 11) Drain Hose Connec#on

4) Quick Connect Connec#on 8) Faucet Adapter Connec#on

QUICK FAUCET ADAPTER CONNECTION

WARNING

!WARNING

ghten but DO NOT over #ghten.

)

-PAGE 9-
