MadBoy TOTAL Manual de usuario
OWNER’S MANUAL
BATTERY-POWERED KARAOKE SYSTEM
WITH TWO WIRELESS MICROPHONES
TOTAL
WWW.MADBOY-AUDIO.COM
ENGLISH
Table of Contents
Safety Instructions ........................................................................................................
Getting Started
Features ....................................................................................................................
Connectors ................................................................................................................
What’s in the box .......................................................................................................
Speaker .........................................................................................................................
Control Panel ................................................................................................................
Remote Control .............................................................................................................
Wireless Microphone .....................................................................................................
Functions
TWS (True Wireless Stereo) .....................................................................................
Recording ..................................................................................................................
Connecting the Speaker
Basic operation instructions ......................................................................................
Connecting the Bluetooth audio device .....................................................................
Connecting audio to the analog line input ..................................................................
Connecting a wired microphone ................................................................................
Media player (USB / microSD) ..................................................................................
FM radio ...................................................................................................................
Cables and Connectors .................................................................................................
Technical Specifications ................................................................................................
3
4
4
4
5
6-7
8-9
10
11
11
12
12
12
13
13
13
14
15
WWW.MADBOY-AUDIO.COM
2
WWW.MADBOY-AUDIO.COM
Safety Instructions
3
1. Read instructions: All safety and operating instructions should be read before installation.
2. Keep instructions: Safety and operating instruction should be retained for future reference.
3. Heed warnings: Warnings on the apparatus and in the operating instruction should be adhered to.
4. Follow instructions: All operating instructions should be followed.
5. Accessories: Only use accessories specified by the manufacturer.
6. Water and moisture: Do not use this apparatus near water.
7. Ventilation: Do not block any ventilation openings.
8. Heat: Do not install near heat sources such as radiators or other apparatus that produces heat.
9. Protect power cord: Power cord should be placed so that it is not likely to be walked on or pinched
by items placed upon it. Do not use the apparatus if power cord is damaged.
10. Cleaning: Unplug power cord before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
11. Nonuse periods: Unplug the power cord if apparatus is left unused for a long period of time.
12. Objects and liquids: Care should be taken so that object do not fall and liquids are not spilled into
the enclosure through the openings.
13. Recycling: Equipment should not be disposed of in the normal waste stream. Dispose of battery
packs properly. Please follow your regional recycling scheme for batteries, packaging, and electronic
waste.
14. Damage requiring service: The apparatus should be serviced by qualified service personnel when:
A. Objects has fallen inside enclosure.
B. The apparatus has exposed to rain or moisture.
C. The apparatus has been dropped or enclosure is damaged.
D. The apparatus do not operate normally.
15. Servicing: Refer all servicing to the qualified service personnel.
16. Warranty: Warranty service should be done by qualified service personnel authorized by Madboy
Audio International Oy. Warranty is invalidated if a warranty seal has been altered, removed or
defaced.
Warning!
To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
Getting Started
Features:
ŸBattery-powered karaoke system with two wireless microphones
ŸDisco light with seven different light styles and colors
ŸKaraoke speaker with two 8" woofer speakers and one tweeter speaker
ŸClass-D amplifier with 80 W RMS output power
ŸBluetooth audio input for streaming music from a mobile device
ŸBluetooth TWS feature for connecting two speakers with Bluetooth
ŸUSB/SD card reader for media playback
ŸTwo microphone inputs for wired microphones
ŸVolume control and echo volume for microphones
ŸVolume, bass and treble control for music
ŸEqualizer presets for music
ŸMega bass feature makes the sound more powerful
ŸFM radio
Connectors:
§Audio inputs:
ŸBluetooth audio input (A2DP/AVRCP)
ŸAnalog 1/8" stereo jack (Line in)
ŸUSB / microSD memory*
ŸFM radio
§Microphone channels:
ŸTwo unbalanced 1/4" TS jacks
WWW.MADBOY-AUDIO.COM
4
What’s in the Box:
Speaker (1)
Wireless
microphones (2)
BASS TREBLE
M.VOL VOL
EQ
MODE LIGHT REPEAT
REC
PLAY R-DEL
ECHO- M-PRI
REC
ECHO+
0
1 2 3
456
7 8 9
Remote control (1) Power cord (1)
Owner’s
manual (1)
OWNER’S M ANUAL
WIRELESS KARAOKE SYSTEM
WITH TWO MICROPHONES
TOTAL
WWW.MADBOY-AUDIO.COM
ENGLISH
*USB hard drives are not supported
USB
RECO
REPLAY
WWW.MADBOY-AUDIO.COM
5
Speaker
Display
IR receiver
Woofer
Tweeter
Wheels
Battery
Power input
Handle
Woofer
Disco light
Disco light
WWW.MADBOY-AUDIO.COM
Control Panel
6
3
2
4
5
6
7
8
9
10
12
11
13
14
15
16
18
1
17
19
MODE / SETTING
BATTERY LEVEL
USB MODE
IN USE
USB
RECO
REPLAY
RECORDER
RUNNING
PLAYING
RECORDED
FILE
1. MIC 1 / MIC 2: Unbalanced 1/4" TS jacks for wired microphones.
LINE IN: Analog 1/8" stereo input jack for external audio source (music).
USB: USB connector for playing audio files from external USB memory.
TF CARD: microSD card interface for playing audio files.
2. HANDLE: Telescopic pull-out trolley handle.
3. LED ON/OFF: Turn the disco light on or off.
4. M-PRI: Set the music ducking function on or off. The ducking function temporarily lowers the
volume level of the music when the microphone voice signal is present.
5. LIGHT: Modify the style and color of the disco light.
Short press: Change the style of the disco light. Off, L 1-7
Long press: Change the color of the disco light. Automatic, 1. red, 2. yellow, 3. green, 4. light blue,
5. dark blue, 6. purple, 7. white (C
6. REC: Record the microphone voice to external memory (USB/microSD). Music cannot be recorded.
7. TWS: Enable / disable True Wireless Stereo function.
8. EQ: Seven different equalizer presets for music. 1. Flat, 2. Pop, 3. Rock, 4. Jazz
5. Classical, 6. Country
9. MEGA BASS: Turn on the mega bass to make the sound more powerful.
10. MAIN POWER SWITCH: Turn the power on or off.
11. PLAY/PAUSE:
Note 1
Bluetooth mode: Play or pause the music on the connected bluetooth device.
USB/Card mode: Play/pause the current music track.
FM mode: Automatically scan radio stations and store in memory (P1, P2..).
12. REPEAT: ”ONE” to loop a single track or ”ALL” to play all tracks from external memory (USB/uSD).
13. PREVIOUS:
Note 1
Bluetooth mode: Play the previous music track on the connected bluetooth device.
USB/Card mode: Short press: Play the previous music track.
Long press: Fast backward.
FM mode: Select the previous radio station stored in the memory.
14. NEXT:
Note 1
Bluetooth mode: Play the next music track on the connected bluetooth device.
USB/Card mode:
Short press: Play the next music track.
Long press: Fast forward.
FM mode: Select the next radio station stored in the memory.
15. MODE: Select the input source for music. Bluetooth, FM radio, Line in, USB/microSD (if inserted).
16. MENU: Short press to browse between settings and adjust the setting by turning the main volume
wheel. Menu will close automatically after 5 seconds. Settings: music treble (t), music bass (b),
microphone volume (n), microphone echo volume (E). Keep ”MENU” button pressed over 5
seconds to reset all settings.
17. CHARGING INDICATOR: Red light: the battery is charging. Green light: the battery is full.
18. DISPLAY: The display shows the currently used mode and setting.
19. MAIN VOLUME WHEEL:
Main function: Rotate the wheel to adjust the music volume.
Secondary function: Change the value of menu setting when the menu is opened.
Note 1: Bluetooth device and application (YouTube, Spotify etc.) with AVRCP support needed.
Control Panel
WWW.MADBOY-AUDIO.COM
7
WWW.MADBOY-AUDIO.COM
8
Remote control
BASS TREBLE
M.VOL VOL
EQ
ECHO-
0
1
MODE LIGHT REPEAT
REC REC
PLAY R-DEL
ECHO+ M-PRI
23
56
8 9
4
7
1 21
3
4
13
5
17
6
18
7
8
9
10
12
11
14 15
16
19
WWW.MADBOY-AUDIO.COM
9
1. MUTE .......................... Mute the speaker. Press again to disable the mute.
2. POWER ....................... Turn the power on or off.
3. PLAY/PAUSE .............. Bluetooth mode: Play or pause the music on the connected
Note 1
bluetooth device.
USB/microSD mode: Play/pause the current music track.
FM mode: Automatically scan radio stations and store to internal
memory.
4. PREVIOUS ................. Bluetooth mode: Play the previous music track on the connected
Note 1
bluetooth device.
USB/microSD mode: Play the previous music track.
FM mode: Select the previous radio station stored in the memory.
5. NEXT ........................... Bluetooth mode: Play the next music track on the connected
Note 1
bluetooth device.
USB/microSD mode: Play the next music track.
FM radio mode: Select the next radio station stored in the memory.
6. MODE .......................... Select input source (Bluetooth, FM radio, Line in, USB, microSD card).
7. LIGHT .......................... Short press: change the style of the disco light (off, L 1-7).
Long press: change the color of the disco light (automatic, C 1-7).
8. REPEAT ....................... USB/card mode: Set as ”ONE” to loop a single track or ”ALL” to
play all tracks.
9. REC .............................. Record the microphone voice to external memory (USB/microSD card).
10. REC PLAY ................. Play a recorded file.
11. REC DEL .................... Delete a recorded file.
12. ECHO +/- ................... Adjust the microphone echo volume.
13. M-PRI ......................... Set the music ducking function on or off.
14. BASS .......................... Boost or cut the low frequencies of the music.
15. TREBLE ..................... Boost or cut the high frequencies of the music.
16. EQ .............................. Select the EQ preset for the music. 1. Flat, 2. Pop, 3. Rock, 4. Jazz
5. Classical, 6. Country
17. M.VOL ........................ Adjust the microphone volume.
18. VOL ............................ Adjust the music volume.
19. 0-9 .............................. Select the track from external memory (USB/microSD card).
Note 1: Bluetooth device and application (YouTube, Spotify etc.) with AVRCP support needed.
Remote control
WWW.MADBOY-AUDIO.COM
Wireless Microphone
10
Functions
1. GRILL: Removable metal grill protects a
cartridge from damage and an inner foam
filter reduces wind, breath and pop
noises.
2. DISPLAY: Display indicates the
frequency of the microphone. If the
display is blinking, it means the battery
level is low. Low battery level may cause
dropouts or completely signal loss. Please
replace batteries immediately.
3. POWER BUTTON: Keep the button
pressed awhile to turn the microphone on
or off.
4. BATTERY COVER: Battery compartment
for two ’AA’ batteries. Remove batteries if
the microphone is not used for long time.
Operation
ŸOpen the battery cover by turning the
cover counterclockwise. Install two
’AA’ batteries and close the cover. Pay
attention to the correct polarity.
ŸIf the display blinks, the battery level
is low. Please replace the batteries.
ŸTurn on/off the microphone by
keeping the power button pressed
awhile.
ŸRemove batteries if the microphone is
not used for long time to prevent
battery leakage.
Please handle the wireless microphone
with care. Warranty does not cover
damage caused by accidental misuse of
the product.
1
2
3
4
WIRELESS MIC
CH 1
863.1
Tabla de contenidos
Idiomas:
Otros manuales de Sistema de karaoke de MadBoy
MadBoy
MadBoy MFP-1500 Manual de usuario
MadBoy
MadBoy MFP-1000X Manual de usuario
MadBoy
MadBoy Boomer Manual de usuario
MadBoy
MadBoy Thunder Manual de usuario
MadBoy
MadBoy REMIX-31 Manual de usuario
MadBoy
MadBoy U-REMIX 3 Manual de usuario
MadBoy
MadBoy MFP-1500 Manual de usuario
MadBoy
MadBoy U-REMIX 2 Manual de usuario
MadBoy
MadBoy Boost-202 Manual de usuario
Manuales populares de Sistema de karaoke de otras marcas
Karaoke Warehouse
Karaoke Warehouse Player 2000 Manual de usuario
VocoPro
VocoPro DVG-888K II Manual de usuario
ION
ION DISCOVER KEYBOARD USB Manual de usuario
The Singing Machine
The Singing Machine SMVG-620 Manual de usuario
Singsation
Singsation CENTER STAGE FREESTYLE Manual de usuario
RSQ
RSQ NEO K-2 Manual de usuario
