FEATURES

The 40M3FS is a full sized 40 meter Yagi designed for the various interests and band segments. We provide

you the dimensions to optimize the antenna just for your needs. The result is a powerful package of clean mechani-

cal design, quality materials, and outstanding performance that will deliver years of enjoyment on the 40 meter band.

Note the pattern and gain of 10 dBd when the antenna is only 50 feet above ground! Gain increases with height

above ground and can approach 6 dB more than the free space gain of 6 dBd.

The rugged aluminum boom is 3-1/2 O.D. .23” wall in the middle with 3” x .125 wall tips. Elements diameters

start at 2-1/2” x .125 wall 6061-T6 are and are mounted to the boom using machined saddles and stainless hard-

ware. All three elements are supported by a phillystran overhead guy system. The element sections have been

computer optimized for at least 100 MPH winds. An overhead guy system is supplied for the boom as well. All

hardware except for the U-Bolts is stainless steel. A hairpin type match couples the 5 kW 1:1 balun to the feedline.

The antenna is completely DC grounded. Compare performance, construction and durability....you’ll agree that this

40 meter Yagi is tops in its class!

M2 Antenna Systems, Inc. 4402 N. Selland Ave. Fresno, CA 93722

Tel: (559) 432-8873 Fax: (559) 432-3059 Web: www.m2inc.com

Rev.01

Model ....................................40M3FS

Frequency..............................7.0-7.3(200 kHz BW)

Gain.......................................8.1 dBi

Front to back..........................20 dBd Typical

Front to side...........................30 TO 45 dB x height

Beamwidth, AZ ....................60°

Feed type...............................SO-239 (‘N’ Opt.)

Feed Impedance....................50 Ohms Unbalanced

VSWR....................................1.3:1 typ. 2:1 Max

Power Handling .....................3 kW Others avl.

Boom Length / Dia.................47’ 6” / 3-1/2”

Element Dia...........................2-1/2” to 1/2”

Turning Radius: .....................44” Ft

Stacking Distance..................98’ opt.

Mast Size...............................2” to 3 ” Nom.

Wind area / Survival ..............17.5 Sq. Ft./100 MPH

Weight / Ship Wt....................180Lbs. / 190Lbs.

M2 Antenna Systems, Inc.

Model No: 40M3FS

SPECIFICATIONS:

*Subtract 2.14 from dBi for dBd / FS = Free Space

Tool required: 7/16”, 1/2 and 9/16” end wrenches or sockets, #2 Phillip screwdriver and

11/32 nut driver or equivalent.

THE FOLLOWING ARE SIMPLIFIED INSTRUCTIONS. YOU WILL NEED THIS WRITTEN

SECTION TO HELP SET THE ORDER OF ASSEMBLY AND TO COVER THE MOST IM-

PORTANT POINTS.

We have provided Penetrox (zinc paste / anti seize compound) that you should put on the

tubes at every joint prior to assembly. It also serves as an antiseize lubricant for all the

hardware. Also put just a tiny dab on every thread just before assembly and you should

have no trouble with sections binding or bolts seizing during assembly.

1. IF SPACE IS A PROBLEM, we suggest you build just the tips of the elements first. Start

with the 1-1/2” sections. If the 1-3/8 sleeves are separate, insert them into the butt of each 1-

1/2 inch section, align the holes and insert an eyebolt and nut loosely just to keep things

aligned. Now add the 1-1/4” section and its sleeve. Bolt and screw sizes are noted on the

element assembly sheet. Continue adding sections until you get the 1/2 inch sections. The

REFLECTOR element requires slightly more length so 3/8” diameter tips are required.

2. It may be convenient at this time to determine just what part of the band you want to opti-

mize. NOTE the DIMENSION SHEET has 4 choices of tip dimensions. These match up

with 3 choices of spacing which will come later in the assembly. Adjust EXPOSED TIP

LENGTH (SEE COMPRESSION CLAMP DETAIL SHEET) for your band segment choice.

This will allow for band change later, should you find it desirable.

3. Build the center sections of the REFLECTOR AND DIRECTOR next. Mark the center of

the 2-1/2” x 158 inch sections and attach the elements to the 8 x 1/4” plate using 2-1/2 sad-

dles and 3/8-16 x 4” bolts and locknuts. Align the element holes perpendicular to the plate

and tighten. Add the 3” saddle clamps that connect the plates to the antenna boom. Leave

the nuts finger tight as this will allow the element to just slide on over the end of the boom.

You can also install the welded vertical riser element supports at this time using 1/4-20 x 1”

bolts and locknuts, put the bolts in from the bottom of the assembly and tighten securely.

4. Now assemble the DRIVEN ELEMENT center section. Mount the 2” X 36” FIBERGLASS

center insulator on the remaining 8 x 8 x 1/4” element mounting plate using two sets of 2”

saddles. Use 3/8-16 bolts and locknuts. Center the insulator, rotate the insulator so the ele-

ment mounting holes are perpendicular to the plate and tighten the hardware. Install the

welded vertical riser element support at this time using 1/4-20 x 1” bolts and locknuts. Put

the bolts in from the bottom of the assembly and tighten securely. Slide each MARKED ele-

ment half over the insulator, align the holes and add the bolts as shown on the element as-

sembly sheet.

5. Next add the 5/16” TURNBUCKLES to the top plates of the risers. Add the black Philis-

tran HTPG 1200 x 19 ft. cords at this time. Use a 3/6” thimble and two wire clips (small u-

bolts to secure cable).

40M3FS ASSEMBLY MANUAL

6. Assemble the boom using 3/8-16 x 4” bolts, lock washers and nuts. Install the eyebolts

with the 1/8” wire rope attached. Using the correct spacing mark the driven element posi-

tion. Mount the 12 x 12 x 3/8” boom to mast plate on the DIRECTOR end loosely using 3-

1/2” saddles.

7. If a temporary 2” mast can be installed at this time, you can set up the overhead turn-

buckle plate with two (2) 2” u-bolts and , two (2) 3/8” forged turnbuckles. Install 4 heavy du-

ty 2” u-bolts on the plate and add the mast. Place the turnbuckle plate 6 to 7 feet above the

boom and loosely install the overhead cable.

8. Mount the inner sections of each element on the boom and align elements perpendicular

with the plane of the 3/8” forged eyebolts. You can determine the CENTER OF BALANCE

at this point since the element tips are very close to the same weight. Mount the BOOM TO

MAST (BMP) at this point using 3-1/2” saddles and 3/8-16 x 5” bolts and locknuts. Align the

plate and tighten. Then the cables can be final tensioned and the temporary mast re-

moved, readying the antenna for final installation

9. Attach the 1-1/2” and smaller element tips. Note the rear hole is enlarged so a 1/4”

u-bolt can be installed at this joint. Also install the 8-32 x 1-3/4” screw and locknut and

tighten securely. Align the eyebolt in the plane of the element and tighten securely.

10. With the antenna laying on flat ground, connect the outer end of each of the element

support cables using a 3/16” thimble or cable eye and two clips (small cable u-bolts). re-

move all the slack and tighten the clips. Final tensioning can be done from the center with

the other eyebolts and locknuts.

Before installing the antenna on a tower, go over all the hardware connections and be sure

each has been tightened. No movement should be detected in the element joints. Be care-

ful during installation and be sure you are clear of all power lines and other high obstruc-

tions. C U on 40! 73, Mike, K6MYC

CAREFULLY DESIGNED AND MANUFACTURED BY:

M2 ANTENNA SYSTEMS INC.

4402 N. Selland Ave.

Fresno, CA 93722

www.m2inc.com [email protected]

40M3FS ASSEMBLY MANUAL

40M3FS DIMENSION SHEET

40M3FS ELEMENT ASSEMBLIES

ELEMENT MOUNTING PLATE ASSEMBLY

GENERIC COMPRESSION CLAMP DETAIL

DESCRIPTION ................................................................................. QTY

BOOM, 3” X SCHD. 40 X 240” .......................................................... 1

BOOM 3.0 X .125 X 180” ................................................................. 2

ELEMENT SEC. 2-1/2 X .125 X 158” SBE........................................ 2

ELEMENT SEC. 2-1/2 X .125 X 79” SOE ......................................... 2

ELEMENT SEC. 2.0 X .125 X 78” SOE............................................. 6

ELEMENT SEC. 1 1/2 X .058 X 60” SOE W/ SLEEVE ..................... 6

SLEEVE 1 3/8 X .058 X 56.00 INSTALLED IN 1-1/2” ....................... 6

ELEMENT SEC. 1 1/4 X .058 X 60.00 SOE W/SLEEVE................... 6

SLEEVE 1 1/8 X .058 X 48.00 INSTALLED in 1-1/4” ........................ 6

ELEMENT SEC. 1.0 X .058 X 43.00” .............................................. 6

ELEMENT SEC, 7/8 X .058 X 60” (EXTENDED SLEEVE) ............... 6

ELEMENT SEC. 3/4 X .049 X 42” SOE............................................. 6

ELEMENT SEC. 1/2 X .049 X 60” ..................................................... 2

ELEMENT TIPS 1/2 X .049 X 61” ..................................................... 2

ELEMENT TIP, 1/2 X .049 X 49.25” .................................................. 2

ELEMENT TIP, 3/8” X 30-1/2”........................................................... 2

BETA TUBE 3/8 X .049 X 76.00........................................................ 2

CENTER INSULATOR 2” X 36” FG, W/ COUPLING RINGS, 4 ........ 1

ELEMENT SUPPORT RISER 1-1/2 X .125 X 36” (WELDED) .......... 3

SMALL PARTS BOX

BRACKET, RISER, 3 X 4 “ WELDED (M2AVR0067) ........................ 3

EYEBOLT, 1/4 X 3, FORGED .......................................................... 6

TURNBUCKLE, 5/16, SS, HOOK AND EYE ..................................... 6

ELEMENT MTG. PLT. 8 X 8 X .250 ................................................. 3

SADDLES, 3-1/2", HD (M2AMC0149).............................................. 8

SADDLES, 3”, HD (M2AMC0140)..................................................... 8

SADDLE CLAMP, 2-1/2”, HD (M2AMC0150).................................... 8

SADDLE CLAMP, 2,", HD (M2AMC0131) ......................................... 4

U-BOLT 3"......................................................................................... 6

U-BOLT 2" HEAVY DUTY ................................................................. 4

U-BOLT 2" ........................................................................................ 2

U-BOLT, 1-1/2”.................................................................................. 6

PHILLYSTRAN HTPG 1200 X 18'..................................................... 6

BOOM TO MAST PLATE 12 X 12 X 3/8” ALUM. .............................. 1

TURN BUCKLE PLT., HD 4 X 6 X .250............................................ 1

TURNBUCKLE 3/8 FORGED EYE AND JAW .................................. 2

WIRE ROPE, 1/8” X 22' W/ 3/8X 5” EYE BOLT .............................. 2

WIRE CLIP, 1/8 GALV. ..................................................................... 30

THIMBLE EYE 3/16, ZINC. ............................................................... 16

CABLE TIES, LARGE ....................................................................... 6

40M3FS PARTS & HARDWARE

SHORTING BAR 1/2 X 1/2 X 5” ALUM. (M2ASB0262) .................... 1

CLAMP BLOCKS 3/8” (M2AMC0261) ............................................... 4

1:1 BALUN 5KW (FGBL0300)........................................................... 1

BAND CLAMP W/ HOLE 21/2 –3-3/4” #52 WITH HOLE.................. 1

PLATE, BALUN MTG. 4 X 4 X 1/8” (M2APT0011)............................ 1

U-BOLT, 2” HINDLEY, SS................................................................ 2

U-BOLT, 2-1/2 .................................................................................. 1

COMPRESSION CLAMP, 5/8”.......................................................... 6

COMPRESSION CLAMP, 1/2”.......................................................... 2

ANTI SEIZE COMPOUND ................................................................ 2

ASSEMBLY INSTRUCTIONS ........................................................... 1

HARDWARE

BOLT, 3/8-16 X 5” SS ....................................................................... 8

BOLT, 3/8-16 X 4-1/2” SS ................................................................. 8

BOLT, 3/8-16 X 4” SS ....................................................................... 12

BOLT, 3/8-16 X 3-1/2, SS ................................................................ 4

NUT, LOCKING, 3/8-16 SS............................................................... 40

NUT, 5/16-18 SS............................................................................... 24

LOCKWASHER, SPLIT RING, 5/16 SS ............................................ 18

BOLT, 1/4-20 X 3-1/2” SS ................................................................. 2

BOLT, 1/4-20 X 3”, SS ...................................................................... 3

BOLT, 1/4-20 X 2 3/4 SS................................................................... 12

BOLT, 1/4-20 X 2-1/4” SS ................................................................. 12

BOLT, 1/4-20 X 1.0 SS...................................................................... 9

SET SCREW, 1/4-20 X 1/4”, SS ....................................................... 2

NUT, NYLOC 1/4-20 SS.................................................................... 40

NUT, PLAIN, 1/4-20, SS................................................................... 3

FLAT WASHER, 1/4”, ss ................................................................... 2

SCREW, 8-32 X 1 3/4 SS.................................................................. 6

SCREW, 8-32 X 1.5 SS..................................................................... 12

SCREW, 8-32 X 1.25 SS................................................................... 12

SCREW, 8-32 X 0.50 SS................................................................... 16

NUT, 8-32 SS.................................................................................... 16

NUT, NYLOC 8-32 SS....................................................................... 30

ALLEN WRENCH 1/8”....................................................................... 1

M2 ANTENNA SYSTEMS INC.

4402 N. Selland Ave.

Fresno, CA 93722

www.m2inc.com [email protected]

40M3FS PARTS & HARDWARE

Tabla de contenidos

Otros manuales de Antena de M2 Antenna Systems

M2 Antenna Systems

M2 Antenna Systems 75-5AS Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 403CP20 Manual de usuario

M2 Antenna Systems

M2 Antenna Systems FGSD-2.4DH Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 222 HO LOOP Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 248CP22A Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 393CP18 Manual de usuario

M2 Antenna Systems

M2 Antenna Systems EB-432/RK70CM Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 10M7DX Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 6M3 Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 7-10-30LP8 Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 35.7-4 Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 420-450-11HP Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 235-11 Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 1700-26-2 Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 6M5XHG Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 678-14 Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 140CP14M Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 303CP26 Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 300XP12 Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 2M-440XPSS Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 2MCP22 Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 20M5-125 Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 500-1000-10 Manual de usuario

M2 Antenna Systems

M2 Antenna Systems 6M6LN Manual de usuario

Manuales populares de Antena de otras marcas

Alfa Network

Alfa Network APA-L01 Manual de usuario

Naval

Naval PR-422CA Manual de usuario

Feig Electronic

Feig Electronic ID ISC.ANTH200/200 Series Manual de usuario

TERK Technologies

TERK Technologies TV44 Manual de usuario

Directive Systems & Engineering

Directive Systems & Engineering DSE2324LYRMK Manual de usuario

HP J8999A Manual de usuario

MobilSat

MobilSat MSP-S Manual de usuario

Steren

Steren ANT-UHF 13 Manual de usuario

Novatel

Novatel 600-G Manual de operación

Radio Shack

Radio Shack Amplified VHF/UHF/FM Indoor Antenna Manual de usuario

TRENDnet

TRENDnet TEW-AO12O Manual de usuario

Radio Shack

Radio Shack 15-1837 Manual de usuario

CommScope

CommScope CMAX-OMFX-43M-I53 Manual de usuario

Ramsey Electronics

Ramsey Electronics DAP25 Manual de usuario

COBHAM

COBHAM SAILOR 800 VSAT Manual de uso y cuidado

Trango Systems

Trango Systems AD900-9 Manual de usuario

Steren

Steren ANT-100 Manual de usuario

Proxim

Proxim 5054-PA-23 Manual de usuario
