Lutron Electronics HT-3015 Manual de usuario

Temp., Dew point, RS232

HUMIDITY METER

Model : HT-3015

Your purchase of this HUMIDITY METER marks a step forward

for you into the field of precision measurement. Although this

METER is a complex and delicate instrument, its durable structure

developed. Please read the following instructions carefully and

always keep this manual within easy reach.

OPERATION MANUAL

TABLE OF CONTENTS

1. FEATURES.............................................................

2. SPECIFICATIONS...................................................

3. FRONT PANEL DESCRIPTION..................................

3-1 Display...........................................................................5

3-2 Power Button.................................................................

3-3 Hold Button ( Esc Button )..............................................

3-4 REC Button ( Enter Button )............................................

3-5 Function Button ( Send Button )......................................

3-6 Set Button ( Logger Button )...........................................

3-7 Battery Compartment/Cover............................................5

3-8 RS-232 Output Terminal..................................................5

3-9 Probe Input Socket ........................................................5

3-10 Probe Plug .....................................................................5

3-11 Probe handle..................................................................

3-12 Probe head ( Humidity & Temperature )...........................5

4. GENERAL MEASURING PROCEDURE...........................6

4-1 Humidity and Temperature measurement...........................6

4-2 Dew point measurement...................................................

4-3 Data Hold.........................................................................7

4-4 Data Record (Max, Min reading)........................................

4-5 Data Logger.....................................................................

5. ADVANCED MEASURING PROCEDURE........................9

5-1 Change the Temp , unit.............................................℃℉ 11

5-2 Change the data logger sampling time...............................

5-3 To show the balance data numbers in the memory.............

5-4 Clear the existing saving data from the memory..................13

5-5 Auto power ON/OFF..........................................................13

6. HOW TO SEND THE DATA OUT FROM THE METER.....

7. RS232 PC SERIAL INTERFACE...................................

8. BATTERY REPLACEMENT..........................................

1. FEATURES

*Humidity + Temperature + Dew point are combined

into one meter, intelligent and professional.

*0.01 %RH resolution for the humidity reading,

0.01 degree resolution for the Temp. reading.

*Fast humidity measuring response time.

*High accuracy and high precision.

*Dew point measurement.

*Manual and auto manual data logger.

*Data logger function with flexible sampling time

selection, can save max. 1000 reading data with

recall.

*Just few panel buttons, easy operation.

*Microprocessor circuit assures maximum possible

accuracy, provides special functions and features.

*Large LCD with two display, easy readout.

*Heavy duty & compact housing case, designed

for easy carry out & operation.

*Records Maximum and Minimum readings with Recall.

*Auto shut off saves battery life.

*Data hold function for freezing the desired value

on display.

*RS 232 PC serial interface.

*Show the humidity & temperature values on the

LCD display at same time.

*Built-in low battery indicator.

Wide humidity & temp. measuring range.

*Separate humidity & temp. probe, easy operation. &

remote measurement.

2. SPECIFICATIONS

2-1 General Specifications

Circuit Custom one-chip of microprocessor LSI

circuit.

Display LCD size : 61 mm x 35 mm

dual function LCD display.

Measurement Humidity : %RH ( Relative Humidity )

Unit Temperature : or .℃℉

Dew point : or .℃℉

Response Time 5 to 30 seconds typically.

@ Reach the 85% reading value

Temperature Automatic temp. compensation for the

Compensation humidity function.

Sampling Time Manual Push the data logger button

of Data Logger once will save data one time.

Auto 1, 2, 10, 30, 60, 600, 1800,

3600 seconds.

Data Hold Freeze the display reading.

Memory Recall Maximum & Minimum value.

Sampling Time Approx. 0.8 second.

Power off Auto shut off saves battery life or manual

off by push button.

Data Output RS 232 PC serial interface.

Operating 0 to 50 .℃

Temperature

Operating Main instrument : Less than 85% R.H.

Humidity Probe : 0 to 95 %RH.

Power Supply 006P DC 9V battery

( Alkaline or Heavy duty type ).

Power Current Approx. DC 8 mA.

Weight 306 g/0.67 LB.

@ Battery is included.

Dimension Main instrument :

180 x 72 x 32 mm

(7.1 x 2.8 x1.3 inch)

Humidity Sensor Probe :

197 mm ( 7.8 inch ) in length.

Accessories Instruction manual.....................

1 PC

Included Humidity probe..........................

1 PC

Carrying case.............................1 PC

Optional RS232 cable, UPCB-01

Accessories Data Acquisition software, SW-U801-WIN

Data Logger software, SW-DL2005

2-2 Electrical Specifications (23±5 )℃

Humidity/ Temperature

Range 10 % to 95 % R.H.

Humidity Resolution 0.01 % R.H.

Accuracy 70% RH :≧± (3% reading + 1% RH).

< 70% RH :

±3%RH.

Range 0 to 50 ,32 to 122 .℃℃℉ ℉

Temperature Resolution 0.01 degree

Accuracy - ± 0.8 .℃℃

- ± 1.5 .℉℉

Dew Point

℃Range -25.3 to 48.9℃℃

Resolution 0.01 ℃

℉Range -13.5 to 120.1 .℉℉

Resolution 0.01 .℉

Remark :

*Dew Point display value is calculated from the

Humidity/Temp. measurement automatically.

*The Dew Point accuracy is sum accuracy value of

Humidity & Temperature measurement..

Above specification tests under the environment RF

Field Strength less than 3 V/M & frequency less than

30 MHz only.

3. FRONT PANEL DESCRIPTION

Fig. 1

3-1 Display

3-2 Power Button

3-3 Hold Button ( Esc Button )

3-4 REC Button ( Enter Button )

3-5 Function Button ( Send Button )

3-6 Set Button ( Logger Button )

3-7 Battery Compartment/Cover

3-8 RS-232 Output Terminal

3-9 Probe Input Socket

3-10 Probe Plug

3-11 Probe handle

3-12 Probe head ( Humidity & Temperature )

4. GENERAL MEASURING

PROCEDURE

The meter default value are :

*The temperature reading unit is .℃

*The sampling time of data logger function is

2 seconds.

4-1 Humidity and Temperature measurement

1)Plug the " Probe Plug " ( 3-10, Fig. 1 ) into the " Probe

Input Socket " ( 3-9, Fig. 1 ).

2)Power on the meter by pressing the " Power Button "

( 3-2, Fig. 1 ), the LCD shows the unit " %RH " & " "℃

at the same time and measured value will show on

the display ( upper display is Humidity value, the

lower display is the temperature value ) .

3)The meter Temp. display unit is defaulted to " ". If℃

intend to let the meter's temperature unit default to " "℉

, then please refer section 5-1 ( page 11 ).

4-2 Dew point measurement

The procedures of " Dew point measurement " are same

as the above " 4-1 Humidity and Temperature

measurement " except select the " Dew point " function

by pressing the " Function Button " ( 3-5, Fig. 1 ) once,

the LCD will show the unit " DEW " & " ( or ).℃℉

The upper display show the Dew point value, the lower

display show the temperature value.

4-3 Data Hold

During the measurement, press the " Hold Button " ( 3-3,

Fig. 1 ) once will hold the measured value & the LCD will

display a " HOLD " symbol.

* Press the " Hold Button " once again will release the data

hold function.

4-4 Data Record ( Max., Min. reading )

* The data record function records the maximum and

minimum readings. Press the " REC Button " ( 3-4, Fig.

1 ) once to start the Data Record function and there

will be a " REC. " symbol on the display.

* With the " REC. " symbol on the display :

a)Press the " REC Button " ( 3-4, Fig. 1 ) once, the "

REC. MAX. " symbol along with the maximum value

will appear on the display.

If intend to delete the maximum value, just press

the " Hold Button " ( 3-3, Fig. 1 ) once, then the

display will show the " REC. " symbol only & execute

the memory function continuously.

b)Press the " REC Button " ( 3-4, Fig. 1 ) again, the

" REC. MIN. " symbol along with the minimum value

will appear on the display.

If intend to delete the minimum value, just press

the " Hold Button " ( 3-3, Fig. 1 ) once, then

the display will show the " REC. " symbol only &

execute the memory function continuously.

c)To exit the memory record function, just press the

" REC " button for 2 seconds at least. The display will

revert to the current reading.

4-5 Data Logger

The data logger function can save 1000

measuring data ( Humidity/Temp. value or

Dew point/Temp. value )

The data logger procedures are as following :

a)Press the " REC Button " ( 3-4, Fig. 1 ) once to

start the Data Record function and there will be a

" REC. " symbol on the display.

b)Auto Data Logger ( Sampling time can select to

1, 2, 10, 30, 60, 600, 1800, 3600 seconds )

Press the " Logger Button " ( 3-6, Fig. 1 ) once to

start the Data Logger function. The upper display

will show the sampling time in seconds ( For

example, 1, 2, 10, 30, 60, 600, 1800, 3600 ) once a

while then revert to the normal display screen. In

the same the top display will show the marker " A ",

the marker " A " will be flashed per sampling time.

Now the Date Logger function is executed.

Manual Data Logger ( Sampling time set to 0

second )

Press the " Logger Button " ( 3-6, Fig. 1 ) once will

save the data one time into the memory, at the

same time the marker " A " will be flashed once

a while.
