Digital synthesis, high reliability, Xenon tube
STROBOSCOPE
Model : DT-2249
A
Your
p
urchase of this
Digital synthesis
Stroboscope marks a
step forward for you
into the field of
precision measurement.
Althou
g
h this
Stroboscope is a
complex and delicate
instrument, its durable
structure will allow
many years of use if
proper operatin
g
techniques are
developed. Please read
the followin
g
instructions carefully
and always keep this
manual within easy
reach.
OPERATION MANUAL
Warning !
Do not look directly at strobe/reflector.
Light pulses at the frequency greater than
5 Hz may cause photosensitive epilepsy in
some individuals if directly viewed.
A feature of the instrument is to make
moving objects appear to be stationary.
Precaution should therefore be taken to
ensure that there is no physical contact
made with objects being viewed.
Caution Symbol
Caution :
* Risk of electric shock !
Caution :
* Do not use fingers or any tool
to touch the FLASH TUBE.
* The instrument contains no user
serviceable parts and should not
be opened by the user.
* Repair or after service should be
done by a qualified technician
only.
* Power plug should apply the correct
ACV power voltage
* Operating duty cycle should be
adhered to.
* Cleaning - Only use the dry cloth to
clean the plastic case !
Environmental Condition
* Comply with EN61010
Transient overvoltage at Mains Supply 2500V
* Pollution Degree 2.
* Altitude up to 2000 meters.
* Indoor use.
* Relative humidity 80% max.
TABLE OF CONTENTS
1 FEATURES................................................................ 1
2 SPECIFICATIONS......................................................
.
2
3 FRONT PANEL DESCRIPTION.....................................4
3-1 Display...............................................................
.
4
3-2 Di
g
ital ad
j
ustin
g
knob..........................................4
3-3 - button..............................................................4
3-4 + button.............................................................4
3-5 ÷ 2 button..........................................................4
3-6 x 2 button...........................................................4
3-7 Xenon tube.........................................................4
3-8 Power switch......................................................
.
4
3-9 Power input socket..............................................4
3-10 Handle fix knot..................................................4
3-11 Handle fix screw................................................4
3-12 Handle fix knob.................................................4
3-13 Handle..............................................................4
4. STROBOSCOPE MEASURING PROCEDURES................
.
6
4-1 Preparation and operating consideration............. 6
4-2 Checkin
g
Speed.................................................
.
7
4-3 Checkin
g
Motion................................................
.
9
5. FLASH TUBE REPLACEMENT......................................9
6.
T
HE ADDRESS OF AFTER SERVICE CENTER................10
1. FEATURES
* The Digital Stroboscope is used the microprocessor
circuit design, high accuracy, digital readout, light duty,
that is ideal for inspecting and measuring the speed of
moving gears, fans, centrifuges, pumps, motors and
other equipment used in general industrial
maintenance, production, quality control, laboratories
and as well as for schools and colleges for
demonstrating strobe action.
* Digital synthesis circuit, high stability and high adjusting
resolution, easy operation.
* Crystal time base to offer high accuracy measurement &
fast measuring time.
* Xenon flash tube, high intensity.
* Wide range : 60 to 30,000 RPM.
* Red LED display, easy to read.
* Adjustment resolution : 0.1 RPM ( < 1,000 RPM ),
1 RPM ( 1,000 RPM ).≧
* High intensity light.
* Setting buttons : Digital adjust button, x 2 button,
÷ 2 button, + button, - button, easy operating.
* Xenon flash tube with plug and socket, easy to make
the tube replacement.
* Compact and heavy duty housing case.
1
2. SPECIFICATIONS
2-1 General Specification
Display 14 mm(0.56") LED, 5 digits.
Flash adjust 60 to 30,000 RPM/FPM.
range
* RPM : round per minute.
* FPM : flash per minute.
Resolution 0.1 RPM :
< 1,000 RPM.
1 RPM :
1,000 RPM≧
Function Digital rotate knob,
buttons x 2 button, ÷ 2 button,
+ button, - button,
Accuracy ± (0.05 % + 1d)
* Spec. tested under the environment
RF Field Strength less than 3 V/M &
frequency less than the 30 MHz only.
Power Supply 110 Vac ± 10%, 50/60 Hz.
or
220 Vac ± 10%, 50/60 Hz.
or
230 Vac ± 10%, 50/60 Hz.
* A " Voltage rating label "
is affixed under the bottom
case to show the voltage
rating of power supply.
When use the stroboscope,
make sure to identify the
power supply voltage
exactly.
Circuit *Microcomputer LSI circuit & crystal
control time base.
*Digital synthesis circuit for the
signal adjusting.
2
Signal The signal adjusting circuit is used the
Stability digital synthesis circuit, the output
signal will existing high stability and
not change.
Power Less than 30 Watt.
Consumption
Operating Temp. 0 to 50 (32 to 122 ).℃℉
Operating Less than 80% R.H.
Humidity
Dimension 21 x 12 x 12 cm (8.3 x 4.8 x 4.8 inch).
Weight 1Kg/2.2 LB.
Housing Compact and impact plastic injection
case with plastic mirror type reflector.
Calibration Crystal time base and microprocessor
circuit, don't necessary take any
external calibration process.
Accessories Operation manual............
.
1 PC.
Included Power cable.....................1 PC.
2-2 Flash Tube Specification
Flash tube Xenon lamp.
Flash Duration Approximately 60 to 1,000
microseconds.
Flash color Temp. Xenon white 6,500 K degree.
Flash energy 4 Watts-seconds (joules).
Beam Angle 80 degrees.
Flash tube It is required to change the flash tube
replacement when the instrument start to flash
irregularly at speeds > 3600 RPM/FPM.
Operating duty For prolong life and safety, please
Cycle adhere to the following operation duty
cycle: < 2000 RPM - 2 hours
2001 to 3600 RPM - one hour
3601 to 8000 RPM - 30 minutes
> 8000 RPM - 10 minutes.
* 10 min. cooling off period between cycles.
3
3. FRONT PANEL & LAYOUT
DESCRIPTION
Fig. 1
4
Fig. 2
3-1 Display
3-2 Digital adjusting knob
3-3 - button
3-4 + button
3-5 ÷ 2 button
3-6 x 2 button
3-7 Xenon tube
3-8 Power switch
3-9 Power input socket
3-10 Handle fix knot
3-11 Handle fix screw
3-12 Handle fix knob
3-13 Handle
3-14 Front top cover
5
4. STROBOSCOPE MEASURING
PROCEDURES
4-1 Preparation and operating consideration
1)Install the handle " Handle " ( 3-13, Fig. 1 ) to
main instrument body, refer to
" Handle fix knot " ( 3-10, Fig. 2 ),
" Handle fix screw " ( 3-11, Fig. 2 )
" Handle fix knob " ( 3-12, Fig. 2 )
2)Connect the Power cable into the Power input socket
" 3-9, Fig. 1 ".
Caution :
* The power plug should be
connected to the correct AC
power supply.
3)A " Voltage rating label " is affixed under the
bottom case to show the voltage rating of
power supply.
When use the stroboscope, make sure to identify
the power supply voltage exactly.
Plug power cable's plug into a properly grounded
AC outlet.
4)For prolong life and safety, please adhere to the
following operation duty cycle:
< 2000 RPM - 2 hours
2001 to 3600 RPM - one hour
3601 to 8000 RPM - 30 minutes
> 8000 RPM - 10 minutes.
* 10 min. cooling off period between cycles.
6
