Lunos eGO Manual de usuario
Installation Instructions
eGO Decentralized Ventilation System with Heat Recovery
Safety instructions
Beware: Any assembly work to the ventilation device may only be carried out after disconnecting all phases of supply voltage. The
ventilation device is fitted with protective insulation according to Protection Class II.
Attention: The electric connection may only be made by authorised qualified personnel and according to the applicable version of
VDE 0100.
Attention: This device may not be operated by children and persons (filter replacement/ cleaning) who are not able to operate the
device safely due to their psychical, sensory or mental abilities or their inexperience or lack of knowledge. Children should be supervised
to ensure that they do not play with the device.
Supply Voltage: 230VAC 50Hz
Device Voltage: 12VDC SELV
Protection Rating: IP22
Volume Flow: 5 -20 m³/h, 45m³/h exhaust air max
Sound Level: 23 dB - 43 dB
Wiring: KAT6, KAT5e or KNX cables (For SIPS panel house –KAT 6 ISZH, CAT5e ISZH or KNX ISZH)
2/65 Ellice Road, Wairau Valley, Auckland 0629
Ph. 09-443 6996
Installaon Instrucons
THE HEATING COMPANY
2
*** Please check units for damage before installation.
48 mm
24 mm
Flush Box
18 W Transformer
50 mm deep
77 mm
50 mm
60 W Transformer
90 mm
*Note: Flush box should be aligned with timber frame
and the screw points must be horizontal.
UNI-FT - Controller
5W/2U - Switch
NOTE:
Can also be wired to the Smart Comfort Controller
THE HEATING COMPANY
3
Installation Position:
LUNOS eGO unit has two motors operating simultaneously to provide fresh air in and extract moist stale air out.
Minimum distances to the wall and surrounding components must be observed to ensure unobstructed air flow
without inadmissible mixing of supply and exhaust air!
Shipping parts:
Exterior Aluminium grilles
160mm PVC tube
Heat exchanger unit
220 to 500
THE HEATING COMPANY
Assembly:
Step 1 - The penetration through external walls - use Ø162 mm hole saw, for 160Ø PVC tube. When installing in
timber frame, fix to timber and seal with Proclima grommet (which is supplied) to building wrap or like. Tube to
have not more than 3 mm fall to outside. If necessary, shorten the pipe to the required installation length (min. 225
mm). The PVC tubes sits flush with the inside of the GIB, and external aluminium grille. The EPP adaptor can be cut
to size and clipped on to the back of the unit if wall depth is more than 225mm.
Prepare the cable for the device connection in the designed section. Please make sure to use the drilling template!
4
Step 2 –Insert the fan unit and connect all the cables as below.
THE HEATING COMPANY
5
Electrical Installation, electrical Connection & safety instruction:
Make sure that the supply voltages of all circuits are disconnected.
Each electrical circuit of this ventilation system must be fitted with a residual current protection (RCD).
Electrical connections are to be completed only by a qualified electrician.
Transformer can be localized (18W transformer) near the flush box for controller (5/UNI-FT) or installed in the
switch board (60W transformer). Install 240V power cableto the transformer then run CAT6 cabling to
Controller +ve and -ve. Then run CAT6 cable to eGo unit S1 +ve -ve, S2 +ve - ve.
Note: Use KAT 6 ISZH, KAT 5e ISZH or KNX ISZH cables for SIPS panel houses.
Note: Set the coding switch to B and the DIP switches as below.
DIP switch 1: “0”
DIP switch 2: “0”
DIP switch 3: “-“
DIP switch 4: “0”
Pierce the back of the switch, to insert the humidity sensor/ LED
l
ight (ribbon) as below.
THE HEATING COMPANY
6
Step 3 –Cover the connection section, put the filter back in place and close interior cover safely.
THE HEATING COMPANY
7
Filter Replacement/Cleaning
A red LED illuminating permanently when the filter requires replacing/cleaning. Remove internal grille, remove
filter, insert new or cleaned filter (the filter can be cleaned with dishwashing detergent) re-attach internal grille.
To reset the filter replacement LED, rocker the W1 (left switch) one time within 3 seconds. If it is successful the
LEDlights up in RED 3 times to confirm the reset.
NOTES:
THE HEATING COMPANY
7
Filter Replacement/Cleaning
A red LED illuminating permanently when the filter requires replacing/cleaning. Remove internal grille, remove
filter, insert new or cleaned filter (the filter can be cleaned with dishwashing detergent) re-attach internal grille.
To reset the filter replacement LED, rocker the W1 (left switch) one time within 3 seconds. If it is successful the
LEDlights up in RED 3 times to confirm the reset.
NOTES:
Venlaon
Under Tile Heang
In-Concrete Heang
Infrared Ceiling Heang
Panel Heaters
Mirror Demisters
Controllers
Self Levelling Compound
Insulate Mat
www.theheangcompany.co.nz
0800HEATING (432 846)
2/65 Ellice Road, Wairau Valley, Auckland 0629
Ph. 09-443 6996
