This document provides detailed information on the AIR-R Pro reader
device structure and steps for installing and connecting it.
It also includes instructions for preventing or troubleshooting many
common problems.
This guide is for informational purposes only, and in the event of any
discrepancies, the actual product takes precedence.
All instructions, software, and functionality are subject to change
without prior notice.
The latest version of the manual and additional documentation can
be found on our website or by contacting customer support.
The user or installer is responsible for complying with local laws and
privacy regulations when collecting personal data during the use of
the product.
•Wi-Fi device name when searching
• Access Point (AP) Wi-Fi IP address of the device
•Wi-Fi password
•Login
•Password
•RFID 125 kHz
•RFID 13.56 MHz
•Copy protection
•Bluetooth
•AP Wi-Fi timer
•Wiegand or Open Supervised Device Protocol
•(OSDP) sending method
•Wiegand format 125 kHz
•Wiegand format 13.56 MHZ
AIR-R Pro_(serial number)
192.168.4.1
None
admin
admin
Enabled
Enabled
Disabled
Disabled
30 minutes
Wiegand
34 bit
26 bit
Introduction
Default Device Settings
3AIR-R Pro
Communications
•Wi-Fi
• Bluetooth
• Wired interfaces
802.11 b/g/n 2.4 GHz
Bluetooth® 5 (LE)
Wiegand / OSDP via RS-485
12-24 VDC +/- 10 %
0.5 A (6 W)
0.13 A (1.56 W)
0.5 A (6 W)
Yes
Yes
Electrical characteristics
• Input voltage
• Operation current (MAX) 12 VDC
• Operation current (AVG) 12 VDC
•Switchable output current (MAX) 12 VDC
•Output short-circuit protection
•Power supply reverse polarity protection
Device info
• Model
• Processor
•Over-the-air (OTA) update
•Built-in web server
•Support for 125 kHz identifiers
•Support for 13.56 MHz identifiers
•Support for copy protection for MIFARE
Classic mini/1K/4K identifiers
AIR-R Pro
ESP32-S3
Yes
Yes
EM-Marin
MIFARE DESFire; MIFARE Plus; MIFARE Ultra
Light; MIFARE Classic mini/1K/4K;
MIFARE Classic EV1 1K/4K; NFC Tag
Yes
2
1
Physical connections
• Inputs *
• Outputs (open collector) 0.5 A *
3280 ft (1000 m)
328 ft (100 m)
33 ft (10 m)
33 ft (10 m)
Work distance
• RS-485 **
• Wiegand
• Wi-Fi 2.4 GHz (open space)
• Bluetooth (open space)
Device Specifications
Physical characteristics
•Housing material
•Mounting method
•Dimensions (diameter, height)
•Weight
ABS plastic UL94 V-0
Wall mount
2.36" x 0.67" (60 x 17 mm)
(mounting ring) 2.36" x 0.86" (60 x 22 mm)
1.59 oz (45 g)
Environmental requirements
•Operating temperature
•Ingress Protection rating
-22°F ~ 158°F (-30°C ~ 70°C)
IP65
* When using OSDP.
** See general specifications for RS485 interface.
Device version before revision
4AIR-R Pro
Device Dimensions
0.67"
3.375"
125, 65535
5AIR-R Pro
2.125"
2.36"
RFID CARD
Red
Black
Green
Orange
White
Yellow
Brown
Gray
Black
+VDC
GND
Green Led
Red Led
RS-485 A+
RS-485 B-
Data 0
Data 1
GND
Blue Lock
Pink DPS
Green
White
Orange
Yellow
Pink
TX- # 6
TX+ # 3
RX- # 2
RX+ # 1
Data Led
1
3
4
5
7
8
9
10
11
2
6
12
13
14
15
16
Wire Designation
6AIR-R Pro
The current hardware version of the AIR-R Pro reader has more wires than is needed for installation
and use. This is necessary for future improvements and extensions of the device.
The wires required to connect the AIR-R Pro reader are highlighted in color.
The type of device determines the order and purpose of the wires.
The numbering starts with the red wire number 1 and reads from left to right.
Wires that are not used should be ignored.
Installation
It is best to avoid installing the device on metal surfaces, as this may
reduce the card reading distance, WI-Fi connection quality, and
Bluetooth connectivity.
If installing on a metal surface is necessary, use the reinforced plastic
mounting base that is supplied with the device.
Wiegand connection
The length of the communication line through the Wiegand interface
must not exceed 328 ft (100 m).
This interface is susceptible to external sources of interference. We do
not recommend running it directly parallel to power cables or near
electric lights.
It is recommended that the Wiegand communication line be routed
at least than 1.64 ft (0.5 m) away from any power cables.
If the communication line is longer than 16.4 ft (5 m), UTP 5E cable is
recommended.
Connecting OSDP
The OSDP uses an RS-485 interface that is designed for long-distance
communications. It operates at ranges up to 3,280 ft (1,000 m) with
good resistance to noise interference.
The OSDP communication line should be laid as far away as possible
from power cables and electric lights. A UTP 5E or FTP 5 twisted pair
cable should be used as the OSDP communication line (if possible,
ground the shield at one end). To ensure reliable system operations, it
is best to use one power source for the controllers and a separate one
for the actuators.
The power supply line wires for the reader should be kept as short as
possible to avoid a significant voltage drop across them.
After cabling, ensure that the power supply voltage to the reader is at
least 12 VDC with the locks switched on.
Installation Recommendations
7AIR-R Pro
Red
Black
Orange
Green
Gray
Brown
W /Bn Bn
W /WGO
WB
B
G
O
+VDC
GND
Red Led
Green Led
Data 1
Data 0
Cable length up to 165 feet
Warning
Make sure that the power supply voltage
meets the recommended requirements.
8AIR-R ProAIR-R ProAIR-R Pro
Wiegand Interface
Connection Diagram
Warning
The voltage level at the power supply and at the reader may differ depending on the cable length and the resistance of the conductor.
The recommended voltage should be at least +10 VDC.
Use a multimeter in the VDC measurement mode to verify that the power supply voltage meets the recommended requirements.
9AIR-R ProAIR-R Pro
Red
Black
Orange
Green
Gray
Brown
W /WGO
WB
B
G
O
GND
Red Led
Green Led
Data 1
Data 0
Red
Black
+VDC
GND
Cable lengths from 165 to 325 feet
Warning
Warning
The voltage level at the power supply and at the reader may differ depending on the cable length and the resistance of the conductor.
Use a separate power supply to connect the reader if the cable is longer than 165 feet or the voltage at the end of the line is less than 10
volts.
BE SURE TO CONNECT THE GND OF THE CABLE FROM THE CONTROLLER TO THE GND OF THE AUXILIARY POWER SUPPLY!
DO NOT USE POWER SUPPLIES WITH DIFFERENT VOLTAGE LEVELS!
Use a multimeter in the VDC measurement mode to verify that the power supply voltage meets the recommended requirements.
Make sure that the power supply voltage
meets the recommended requirements.
Wiegand Interface with Additional Power Supply
Connection Diagram
Power Supply
10AIR-R Pro 10AIR-R Pro
Power Supply
White
Black
Yellow
RS-485 A+
GND
RS-485 B-
Red
Black
+VDC
GND
Open Supervised Device Protocol Reader via RS-485
Connection Diagram
Cable lengths up to 165 feet
Warning
Make sure that the power supply voltage
meets the recommended requirements.
* Both GND wires have a physical connection inside the device.
RS-485 A+
GND
RS-485 B-
Warning
The voltage level at the power supply and at the reader may differ depending on the cable length and the resistance of the conductor.
Use a separate power supply to connect the reader if the cable is longer than 165 feet or the voltage at the end of the line is less than 10
volts.
BE SURE TO CONNECT THE GND OF THE CABLE FROM THE CONTROLLER TO THE GND OF THE AUXILIARY POWER SUPPLY!
DO NOT USE POWER SUPPLIES WITH DIFFERENT VOLTAGE LEVELS!
Use a multimeter in the VDC measurement mode to verify that the power supply voltage meets the recommended requirements.
