Ltech LT-916 Manual de usuario
Product introduction
4. With the operations can be completed via the RDM
master console, such as parameters browsing & settings, DMX address settings,
equipment recognition, etc.
RDM remote management protocol,
2. Easy operation with digital display and the touch buttons.
1. Designed for Hi-power multiple channels application, 16 channels output, and up to
1152W output power.
9. 16bit (65536 levels) / 8bit (256 levels) grey level available.
8. High/low frequency PWM available.
1
Short circuit
protection
RDM Over current
protection
Overheat
protection
3. 3-pin XLR, RJ45 DMX and green terminal interface with photoelectric isolation,
improve signal transmission efficiency and anti-interference ability, the
green
terminal also has signal amplifier function.
6.
when a fault occurs.
With short circuit, over current and overheat protection, as well as warning function
7. With power-on state management and fast self-testing function.
www.ltech-led.com
RJ45
3-pin XLR Photoelectric
isolation
5. With firmware upgrade function.
2
122
110
39
LT-916
DMX512/RDM
3-pin XLR, RJ45, green terminal
12~24Vdc
3A × 16CH Max. 48A
(0~36W...72W) × 16CH Max. 1152W
8bit (256 levels) / 16bit (65536 levels)
Yes
Short circuit / Overheat / Over current protection,
recover automatically.
-30°C~65°C
180×122×39mm(L×W×H)
193×127×41mm(L×W×H)
730g
5-Year
Warranty
www.ltech-led.com
180
156
Technical specs
Model :
Input signal :
DMX interfaces :
Input voltage :
Current load :
Output power :
Grey level :
:
Protection :
Working temperature :
Dimensions :
Package size :
Weight (G.W.) :
Photoelectric isolation
E500585
Unit: mm
Product size
006
www.ltech-led.com
3
Powered by DC1
Max. 24A
Powered by DC2
Max. 24A
DC1 DC2
M
<
<
Main component description
12-24V
input voltage
dc Green terminals
LED lamp connection
DMX/RDM input & output
3-pin XLR RJ45 Green terminals
(with signal amplifier function)
DIP switch
Screen
High Smooth
Low Std
30S off
Enable
PWM Hz DIM
16
Bit
8
Digital display
Digital display will enter the locked
mode without operating after 15S.
Long press “M” key to unlock.
Short press “M” key to switch numbers.
Press “ ””v” key to adjust value.
^
Power
indicator
Signal
indicator
Digital
display DIP
switch
Press or keys simultaneously for 2-3 seconds, decoder will enter self-testing function.“ ” ”v”
^
006
www.ltech-led.com
4
1
3
2
PUSH
1
3
2
PUSH
12-24Vdc 12-24Vdc 12-24Vdc
LT-916 LT-916 LT-916
Wiring diagram
1. DMX console onnectionc :
DMX
console
DMX signal
DMX signal DMX signal
If the recoil effect occurs because of longer signal line or bad line quality, please try to
connect 0.25W 90-120Ω terminal resistor at the end of each line.
LT-916 is equipped with 3 kinds of DMX terminals for users’
selection. The following diagram takes 3-pin XLR as an
example, same connecting method for the rest two: RJ45
& green terminal (with amplifier function).
Resistor
terminal
5
LEDs
LEDs
RGBW LEDs
DMX/RDM signal
DMX/RDM signal
DMX/RDM signal
DMX/RDM signal
2 Connecting LED lights:
LED
driver
LED
driver
12-24Vdc
12-24Vdc
Power to
LEDS3, 4
Power to
LEDS3, 4
LT-916
LT-916
Output port
(Wiring method as follow)
1
1
2
2
3
3
4
4
LED driver
Power to
LEDS1, 2
Power to
LEDS1, 2
www.ltech-led.com
R
CH
1
2
3
4
G
B
W
3. The connection diagram of 3 kinds of DMX/RDM terminals:
3-pin XLR connected in parallel
Green terminal connected in parallel
RJ45 connected in parallel
These 3 terminals can be connected in a mixed way.
Resistor
terminal
Resistor
terminal
Resistor
terminal
Installation attentions: please reserve enough ventilation distance between decoders (>20mm),
be sure not to block the vent, or it will affect lifetime of decoder for .poor heat dissipation
LT-916
LT-916
LT-916
6
www.ltech-led.com
Installation distance > 20mm
Vent
*
LT-916
LT-916
LT-916
LT-916
LT-916 LT-916
7
Resistor
terminal
Resistor
terminal
Resistor
terminal
4. The connection diagram of :AMP signal amplifier terminal
AMP
AMP
Connecting with green terminal or an extra amplifier will be needed when more than 32
decoders are connected or use overlong signal wire(as shown below).
Signal amplifier should not be more than 5 times continuously.
LT-916
LT-916
LT-916
LT-916
LT-916
LT-916
www.ltech-led.com
*
LT-916
LT-916
LT-916
8
www.ltech-led.com
LT-916LT-916
WIFI-RDM01
LED
12-24Vdc 12-24Vdc
5-24Vdc power input
LED
driver LED
driver
LED
driver LED
driver
Work with RDM editor
LT-916 can work with LTECH RDM editor (Model: WiFi-RDM01) to realize changing the parameters
by long-range setting, wiring diagram as below:
Suppot portable
power supplies
LT-916
…
…
LED LED
12-24Vdc
LED
driver LED
driver
9
www.ltech-led.com
ac
b
d
RDM editor App interface instruction
a: Click”Add”, edit the address in corresponding box.
b: Click”ID”, get more product details.
c: Click” ”, enter edited interface.
d: Click”No.”, issue the recognizing command.
Supporting WiFi-RDM01 upgrade
and DMX driver upgrade.
WiFi-RDM01
upgrade
DMX device
upgrade
Well installation of products first, then working with WiFi -RDM01 to realize setting parameters
and firmware upgrade by App.
Download the App, setting LT-916 parameters (dimming range, brightness, boot fade time etc.)
after well connecting the RDM editor, more details, please check the manual of WiFi-RDM01.
