LTC 19 Manual de usuario
22”/24” HD LED TV with DVB-T2/-S2
2209 g.1 / 2409 g.1
Contents
Caution
Safety Information
Accessories
OSD Menu
1. Picture menu
2. Sound menu
3. Channel menu
4. Feature menu
Simple Troubleshooting
Product Introduction
Connections
Remote Control
Basic Operation
Multimedia Operation
Recording Operation
5. Setup menu
Caution
Correct disposal of this Product
(Waste Electrical & Electronic Equipment (WEEE)
Your product is designed and manufactured with high quality materials and
components which can be recycled and reused.
This symbol means that electrical and electronic equipment, at their end-
of-life should be disposed of separately from your household waste.
Please dispose of this equipment at your local community waste collection/
recycling center.
In the USA there are separate collection systems for used electrical and
electronic products. Please help us to conserve the environment we live in!
1
The exclamation point within an equilateral triangle is intend to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
The lightning flash with arrowhead symbol, within an equilateral triangle
is intended to alert the user to the presence of un-insulated “dangerous
voltage” within the products enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to the persons.
directives.
This unit complies with The Restriction of the use of certain Hazardous
substances in Electnical and Electronic Equipment
Safety Information
To ensure reliable and safe operation of this equipment, please read carefully all the
instructions in this user guide, especially the safety information below.
Electrical safety
• To prevent overload, don't share the same mains supply socket with too many other
items of equipment.
- Do not place any connecting wires where they may be stepped on or tripped over.
- Do not place heavy items on the leads, which may damage them.
- Hold the Mains plug, not the wires, when removing from a socket.
- During a thunderstorm or while leaving the TV for long periods, disconnect the aerial
(if outdoor) and mains power from the supply.
- Do not allow water or moisture to enter the TV . Do NOT use in wet
or moist areas such as Bathrooms, steamy kitchens or near swimming pools.
• Pull the plug out immediately, and seek professional help if:
- the mains plug or cable is damaged.
- liquid is spilt onto the set, or if it is accidentally exposed to water or moisture.
- anything accidentally penetrates the ventilation slots.
- the set does not work normally.
- Do NOT remove the safety covers. There are no user serviceable parts inside.
You may invalidate the warranty. Qualified personnel only are permitted to service
this apparatus.
-T
oavoid battery leakage, remove exhausted batteries from the remote control
handset, or when not using for along period.
- Do NOT break open or throw exhausted batteries on a fire.
Physical safety
• Do NOT block ventilation slots in the back cover. You may place the TV in a cabinet,
but ensure at least 5cm (2") clearance all around the unit.
• Do NOT tap or shake the TV screen, you may damage the internal circuitry. Take good
care of the remote control, do not drop it or allow it to come into contact with liquids.
• To clean the TV use a soft dry cloth. Do NOT use solvents or petrol based fluids. For
stubborn stains, you may use a damp soft cloth with diluted detergent.
2
DC-cable
Adapter
3
Technical Specification
* Note: The configuration of the components may look different from the following illustration
- TV System
- Screen Size
- Resolution
- Aerial input
PAL BG/DK/I SECAM BG/DK L/L’
19”/22”/24 ”inch(diagonal)
1920x1080
- Audio output power
- Power Consumption
2x3W
12V 2.5A 30W /
Accessories
User’s Guide
Remote Control Mini AV cable
E-35D
RF cable
12V 3A 36W
NFX EShare You
Front View
Product Introduction
:Turn on/standby the TV set.
(IR) Infrared Receiver: Receives IR signals from the remote control.
(Power on/Standby) LED indicator: Press to turn on and standby.
The effective receiving range for the signal is 5-8 metres from the front of the remote
control window, and 30
0
to the left or right side and 20
0
above or below the control
window.
:Display the input source menu.
MENU: Display/exit the OSD menu.
CH+/-: Scan through channels.
VOL+/-: Adjust the volume.
Indicator on(Red) Standby mode
Indicator on(Green) Power on mode
4
Remote Control window
Connections
5
RF: Connect antenna or cable 75 Ohm coaxial to receive TV signal.
POWER: Connect to the mains adaptor.
HDMI: Connect it to the HDMI of DVD or other equipment.
VGA: For PC display.Connect it to the D-Sub 15 pins analog output connector of the PC.
PC in: Connect it to the audio output terminal of PC.
SCART: Connect them to the SCART video output terminal of DVD.
Coax: Digital output to AV receiver.
USB: Connect to USB device for multimedia and PVR.
DVB-S2: Connect a Satellite signal.
Common Interface: CI slot.
Headphone: Connect it to your headphone or other audio equipment.
POWER
COAX
Common Interface
DVB-S2
USBHDMI
Headphone out
VGA
PC IN RF
Remote Control
The remote control is using Infra-Red(IR). Point it towards the front of the LED TV. The remote
control may not work correctly if it is operated out of range or out of angle.
6
EPG : Electronic program guide.
TV/RADIO : TV/Radio Select .
REC:Press to start recording in DTV mode (In DTV mode only).
: Set your TV to power on or standby mode.
:Press to mute the sound.Press again or press VOL+ to unmute.
0--9:Press 0-9 to select a TV channel directly while watching TV.
DISPLAY:Press to display the source and channel‘s Information.
: Return to the previously viewed program.
P.MODE : Adjust the picture mode.
S.MODE : Adjust the sound mode.
SLEEP : Select amount of time before TV turn itself off
automatically.
VOL+/- : Press to increase /dscrease the sound level.
AUDIO : Select audio mode.
CH+/- : Press to scan through or to select a channel.
SOURCE : Press the button to display the sources list.
MENU : Brings up the main menu to the screen. Press MENU
key to exit when searching.
EXIT : Press to close the OSD.
: Allows you to navigate the on-screen menus.
ENTER: Press to confirm the selection (MEDIA as input source).
TEXT : Switch to Teletex* mode.
FAV : Favourite channel list.
SUBTITLE : DTV subtitle.
NFX: press the key "NFX" go into NETFLIX app directly .
: press the key "You " go into YouTube app directly.
SUBPAGE : Sub coded page access.
EShare : press the key "EShare" go into E-Share app directly.
REVEAL : Reveal/hidden the hidden words .
[]
[]
[]
[]
[]
[]
/ / /
Shortcut buttons in TV and Media mode.
Press to PLAY/PAUSE.
Press to play a program in fast rewind mode.
Press to play a program in fast forward mode.
Press to STOP playing.
Press to go to previous chapter.
Press to go to next chapter.
: Home button, back to main page.
NFX EShare You
You
Remote Control
7
MUTE: Press to mute the sound, press again or press
VOL+ to unmute.
P-MODE: Select the picture mode.
S-MODE: Select the sound mode.
SLEEP: Standby timer.
Press 0-9 to select a TV channel directly when you
are watching TV.
SOURCE: Press to display the input source menu.
EXIT: Exit the OSD menu.
DISPLAY: Press to display the current mode’s information.
CH + /- : Scan through channels.
VOL+/- : Adjust the volume.
-/-- : Press this button to enter a program number for different digit.
TITLE:Return to the title in DVD mode.
Return to the previous channel viewed.
Allows you to navigate the on-screen menus and adjust the
system settings to your preference.
CURSOR KEYS / OK
/ / /
NFX EShare You
