Lorex N844 Series Manual de usuario

Network Video Recorder (NVR)

Quick Setup Guide

N844 Series

lorex.com

Contents

Package contents and dimensions...........................................1

Using the mouse.............................................................................10

Adding cameras from the LAN...................................................12

Back panel overview......................................................................2

Using the quick menu.................................................................. 11

Smart motion detection................................................................13

Setup

Step 1: connect cameras................................................ 3

Step 4: connect monitor/TV............................................7

Step 2: connect router......................................................5

Step 5: connect power......................................................8

Step 3: connect mouse....................................................6

Step 6: Lorex Setup Wizard.............................................9

Using deterrence features............................................................16

Changing the recorder’s output resolution..............................19

Playback and search.....................................................................20

Backup..............................................................................................21

Lorex Fusion....................................................................................22

Face detection

Remote viewing

Smart plan..........................................................................14

Before you start.................................................................23

Mask detection..................................................................15

Connect to the app...........................................................24

Lorex Home app live view................................................25

Package contents and dimensions

• 4K Ultra HD Security NVR

• Power adapter

• Ethernet cable

• USB mouse

• HDMI cable

12.6” / 320mm

10” / 250mm

2.2”

57mm

Back panel overview

1 2 3 4 5 6 7

1. Power port: Connect power

2. PoE ports: Connect cameras*

3. LAN port: Connect router*

4. VGA port: Connect monitor*

Note:

The 8 channel NVR recorder in this guide is for illustration only. Your recorder may

appear different, with all the same ports in different locations.

*Not included / sold separately.

5. Audio In/Out: Connect microphone / speaker*

6. HDMI port: Connect monitor*

7. USB port: Connect mouse or USB memory stick

Setup step 1 — Connect cameras

1. Connect cameras directly to the NVR (recommended)

Connect the Ethernet cable to the camera and then connect the other end of the Ethernet cable

to the NVR’s PoE ports. The camera may take a minute to power on after being connected.

NVR’s PoE ports

Camera’s Ethernet connector

IMPORTANT: Test your cameras prior to selecting a permanent mounting location by

temporarily connecting the cameras and cables to your NVR using one of the following two methods.

2. Connect cameras to a PoE switch or router on your network (not included)

Connect the Ethernet cable to the camera and then connect the other end of the Ethernet cable

to a router or switch on your network. The camera may take a minute to power on after being

connected.

Router LAN portPoE switch

Power adapter

Camera’s Ethernet connector

NVR’s PoE ports Notes:

• This guide covers connecting IP cameras to your security recorder only. For full instructions on installing

your cameras, please refer to your camera’s documentation at lorex.com.

• Connecting cameras to a router, or a network switch without PoE, requires a power adapter for each

camera. Refer to your camera’s documentation at lorex.com for the correct power adapter model number.

Setup step 2 — Connect router

Connect the recorder

to your router using the

included Ethernet cable.

Notes:

• If you are using a PoE switch, ensure the switch is connected to the same network as your recorder.

• To receive automatic rmware updates and enable remote viewing with mobile apps, a high speed

Internet connection is required (minimum upload speed of 5Mbps required for 4K viewing; 3.5Mbps for

lower resolutions). All other system features can be used without an Internet connection.

Setup step 3 — Connect mouse

Connect the included USB

mouse to the USB port on

the recorder.

To copy your video recordings

and to perform a rmware

upgrade, connect a USB stick

or ash drive to the USB port on

the front panel of the recorder.

Setup step 4 — Connect monitor/TV

Connect the recorder to

a monitor/TV using the

included HDMI cable or a

VGA cable (not included).

The HDMI port supports up

to 4K resolution, and VGA

supports up to 1080p.

Note: To optimize picture quality, set the recorder’s video output to match the resolution of your monitor.

See ‘Changing the Recorder’s Output Resolution’ pg.19 for details.
