Lorex L164 Series Manual de usuario

4 CHANNEL digitAL vidEo

rECordEr

BUSINESS AND HOME SECURITY

SEE WHAT YOU’VE BEEN MISSING

• Four Channel digital video recorder

• Supports 2 disk drives (1 internal/1 removable)

• Password Security Protected

• Remote Control or Main Panel operation

• 4 camera inputs (4 BNC)

• Viewing options: Quad, Full Screen

• Quick Multiple Search Capability

• On Screen Display and Real Time Clock Function

• 3 Adjustable Video Quality Settings: High, Normal,

Basic

• High quality recording with modified MJPEG

compression (5~20Kbyte/frame)

• Alarm terminal block - integrated

FEAtUrES

L164 SEriES www.lorexcctv.com

The L164 Series of advanced digital video recorders

(DVR) offer market-leading features, easy installation

and ‘professional grade’ performance. The DVR

provides high quality recording with modiﬁed

MJPEG video compression, four input channels

and is designed to operate as part of any CCTV or

Observation system.

Includes remote controller

4 CHANNEL digitAL vidEo

rECordEr

SPECiFiCAtioNS

As our product is subject to continuous improvement,

SVII & subsidiaries reserve the right to modify product

design, specifications & prices without notice and without

incurring any obligation. E&OE

3700 Koppers Street, Suite 100

Baltimore, Maryland 21227,

USA.

Strategic Vista International Inc.

300 Alden Road, Markham,

Ontario L3R 4C1

Canada.

BUSINESS AND HOME SECURITY

Hard Disk Storage: IDE Type, UTMA 66 above (supports 2 HDD - up to 250GB each)

Camera support: 4 analog CCTV

Video Compression: Modiﬁed MJPEG (5~20Kbyte/frame)

Video Resolution up to: 720 x 480

Recording Resolution up to: 640 x 224 (full screen)

Record Modes: Alarm External / Timer / Manual

Camera inputs: 4 BNC Video inputs

Video output: 2 RCA Video outputs

Alarm history log: 1000 events

Security Protection: Password protection

Display refresh rate: 30 FPS NTSC, 25 FPS PAL

Record refresh rate: 30 FPS NTSC, 25 FPS PAL

Recording Time: up to 3360 HRS with 80GB HDD

Video loss detection: Yes

On Screen display: Yes

HDD Key Lock: Yes

Playback Searching: Date & Time / Full list Searching

Alarm input: TTL input, High (5V), Low (GND)

Alarm output: COM / N.O / N.C

Power source: AC100-240V switching adaptor

Power consumption: 25W

Dimension: 385(W) X 73(H) X 290(D) mm

Weight: 5 kg

Operating temperature: 0°C - 50°C

Dimensions:

UPC Code:

Front Panel

Back Panel

Product Views:

Top Side

Front

Model#: L164000: Four Channel DVR

with No HDD

7-78597-16400-8

Model#: L164-81: Four Channel DVR

with 1-80 GB HDD

7-78597-16481-7

Model#: L164161: Four Channel DVR

with 1-160 GB HDD

7-78597-16416-9

14.75”

11.5”

3”

Weight: 10.0 lbs
