Logitech HD Pro Webcam C920 Manual de usuario

Setup Guide

Logitech®HD Pro Webcam C920

Logitech®HD Pro Webcam c920

Contents

English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

繁體中文. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

한국어. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

English 3

Logitech®HD Pro Webcam c920

Features

1. Carl Zeiss® autofocus HD 1080p lens

2. Microphone

3. Activity light

4. Flexible clip/base

5. Tripod attachment

6. Product documentation

Setup Guide

Logitech®HD Pro Webcam C920

4English

Getting started with

Thank you for buying your c920!

Use this guide to set up and begin using your

Logitech webcam.

If you have questions before you start, or if you

just want to learn more about your Logitech

webcam, please visit logitech.com/support.

Setting up your webcam

1 Place your webcam

Designed for the way you like to make a video call,

place the Webcam c920 where you want it—on

a computer monitor, desktop, or tripod.

For placement on a monitor

Grasp the webcam as shown and open the ﬂexible/

clip base with your other hand. Mount the webcam,

making sure the foot on the ﬂexible/clip base is

ﬂush with the back of your monitor.

1 2 3

English 5

Logitech®HD Pro Webcam c920

2 Connect your webcam

3 Install the software

If you’re using your webcam with Windows® 8, the

software required is downloaded automatically

when you connect your webcam for the ﬁrst time,

and installed silently in the background.

Important: Make sure you’re connected to the

Internet, so the software can be downloaded.

If you’re using your webcam with Windows® 7 or

Windows Vista®, you must install the Logitech®

Webcam Software, available from:

logitech.com/downloads

Getting started with videocalling

Your Logitech HD Pro Webcam c920

provides full HD 1080p video calling.

To take advantage of video calling

both you and the person you call must install

Skype™, or use a dierent video-calling

application such as Yahoo!® Messenger,

Windows Live® Messenger or Gmail.

Learn more: skype.com

As well as a webcam and video calling

application, both callers need:

• A computer with speakers (or a headset)

and a microphone; your Logitech HD

Pro Webcam c920 has two built-in

microphones.

• A broadband Internet connection

(e.g., DSL, T1, or cable)

USB

6English

Getting started with

Using your webcam with Windows 8

Use the Camera app, available from the Windows 8 Start screen, to operate and control your webcam.

Understanding the Camera app

1. Preview window. Click or tap to capture photos

or videos (depending on whether Video Mode

is selected).

2. Change webcams (when you have more

than one). The face of your Logitech webcam

illuminates when selected.

3. Adjust your camera settings.

4. Activate or deactivate the Timer feature. When

activated, there is a three second countdown to

capturing a photo or video.

5. Turn Video Mode on (to record videos) or o (to

take photos).

6. Click or tap on the arrows to scroll through the

photos and videos you have captured.

Videos are denoted by a timer and play button

in the bottom right-hand corner:

Tip: The Camera app lets you use your webcam’s most popular features quickly and easily. If you want to

take advantage of the enhanced features your webcam oers, such as motion detection, use the Logitech

Webcam Software available from logitech.com/downloads.

English 7

Logitech®HD Pro Webcam c920

Adjusting your Camera settings

The Logitech software optimizes the settings for your environment automatically. To adjust any of your

settings choose Camera options. This is available from the Camera app (see the previous page) and from

within Metro apps that support webcams.

1. Choose your required resolution for photo capture, or video capture when

in Video Mode.

2. Choose the microphone you want to use to record sound in your videos, if

you have more than one available.

3. Access More Options, to beneﬁt from enhanced features such as digital

Zoom and Move.

If the More Options pane doesn’t show the Logitech logo and oer

enhanced options, it is likely that the Logitech software didn’t install

correctly when you ﬁrst connected your camera. To reinstall it, go to the

Windows Store and look for Logitech Camera Controller.

4. Zoom in or out to include/exclude your surroundings.

5. Having zoomed in, drag the white box to pan (adjust the focus area of

your webcam).

6. Use Follow my face so you’re always in the picture.

7. Enjoy clear conversations without annoying background noise.

Depending on the features available with your camera, you can access further

advanced settings by scrolling.

Sharing your photos and videos

You can share your photos and videos via e-mail, Twitter, Facebook®, YouTube®, or Microsoft SkyDrive®.

Follow these steps:

1. In the Camera app, scroll to the photo or video you want to share.

2. Select Share in the Charms bar (or press - H):

3. Choose the media through which you want to share the photo or video.

8English

Getting started with

1. Capture pictures and videos.

2. View captured images and share via e-mail,

Facebook, or YouTube.

3. Capture videos triggered by detected motion.

4. Control your webcam while on a video call.

5. Change webcams (when you have more

than one).

6. Open Logitech Webcam Software settings.

7. Open help dashboard.

Using your webcam with Windows 7 and Windows Vista

The Logitech Webcam Software provides everything you need to use and control your webcam.Launch the

software from the Windows Start® menu, or by right-clicking on the camera icon in the Windows taskbar.

Understanding the Logitech Webcam Software

English 9

Logitech®HD Pro Webcam c920

Capturing video

andsnappingpictures

Quick Capture allows you to take photos and record

videos easily.

You have easy access to webcam controls

and settings:

1. Preview window

2. Capture mode: photo/video

3. Capture button

4. Webcam controls

5. Photo thumbnails

6. Video thumbnails

7. Click a thumbnail to enter the gallery

Viewing and sharing using

theGallery

Clicking on an image thumbnail in the gallery (1)

opens the video or photo in the review window (2).

You can then:

• Attach the video or picture ﬁle to an e-mail (3)

• Edit the photo or splice together video (4)

• Upload the picture or video to Facebook (5)

• Upload a video to Twitter or YouTube (6)

You may also drag and drop a gallery image onto

one of the function tiles (items 3–6) to launch an

editing application or to attach or upload.

10 English

Getting started with

Using motion detection

• Set up your webcam to record video when

it detects movement.

• Adjust captured video duration and

detection sensitivity.

• Captured video is automatically saved

to your computer.

• View content in the Gallery or upload it using

the One-touch Upload window.

Fine tuning your webcam during

a video call

1. Launch the webcam controller when on a

video call.

2. Use pan and tilt to ﬁnd the best angle.

3. Zoom in or out to include/exclude

your surroundings.

4. Use Follow my face so you’re always

in the picture.

5. Enjoy clear conversations without annoying

background noise.

6. Correct for poor lighting environments

using RightLight.

7. Choose between auto- or manual focus.

8. Adjust advanced webcam settings.
