Logitech Harmony One+ Manual de usuario

User Manual

Version 1.0

Logitech®

Harmony®

One+

Remote

trademarks or trademarks of Logitech in the US and other countries. All other trademarks

arethe property of their respective owners.

III

LOGITECH HARMONY ONE+ USER MANUAL

Contents

Introduction ............................................................1

Getting to know your Harmony One+.......................................1

How your Harmony One+ works .........................................1

Devices,inputs, andactivities ...........................................1

The buttons on your Harmony One+......................................2

What’s on the Harmony One+ touchscreen ................................3

Using your Harmony One+ ................................................4

Selecting an activity ...................................................4

Using the Remote Assistant .............................................4

Controllingyour devices individually .....................................4

Using your favorite channels ............................................5

Turning off your devices................................................5

Setting the date and time ..............................................5

Recharging your remote ...............................................5

Using the Help button .................................................6

Setting up your Harmony One+ for the rst time.............................7

Overview ............................................................7

1. Creating your user account ..........................................8

2. Connecting your Harmony One+ to your computer ......................8

3. Setting up the devices you want to control .............................8

4. Setting up activities ................................................9

5. Updating the remote ...............................................9

Determining your inputs ..............................................10

Device Worksheet ......................................................11

Testing your remote ..................................................12

Changing your setup ....................................................13

Adding and changing activities ..........................................13

LOGITECH HARMONY ONE+ USER MANUAL

Adding and changing devices ............................................13

Adding a passthrough device to an activity ...............................14

Changing buttons for a device or activity.................................15

Teaching commands using your old remote ..............................15

Setting up favorite channels ...........................................16

Troubleshooting problems with your Harmony One+ ........................17

Getting help with your Harmony One+ ....................................18

Using the on-remote help .............................................18

Glossary ...............................................................19

Product Specication ...................................................21

LOGITECH HARMONY ONE+ USER MANUAL

Introduction

The Logitech Harmony One+ universal touchscreen remote is your answer to effortless

home entertainment. With one-button activities, you can go from watching TV

towatching a DVD or listening to music with a single touch. The guided online setup

steps you through the conguration of your Harmony One+, so you’ll soon be ready

tosit back and relax!

Whether you’re new to Harmony products or you consider yourself an expert,

thisUserManual provides you with the information you need.

Getting to know your Harmony One+

How your Harmony One+ works

The Harmony One+ is an activity-based infrared (IR) universal remote control.

UsingHarmony software, you can set up the Harmony One+ to control up to

15devices.

The Harmony One+ delivers powerful activity-based control using Smart

StateTechnology®. This technology allows the Harmony One+ to keep track

ofthedevices itcontrols, so it always knows which of your devices are on.

Devices,inputs, andactivities

To make the most of your Harmony One+, you need to understand the following

terms: devices, inputs, and activities.

Devices

Devices are the components of your entertainment system. They’re things like your TV,

cable box, DVD player, or game console.

Inputs

Inputs are connections on the back of your devices. Inputs are used to connect

yourdevices to each other. When you want to go from watching TV to watching

aDVD orlistening to music, you typically need to switch your TV and/or audio receiver

to the correct input. For example, if your DVD player is connected to your TV using

theHDMI 1 input, then the TV needs to be set to HDMI 1 to watch a DVD.

Activities

An activity is something you do with your entertainment system, like watching TV,

listening to music, or playing a game. Your Harmony remote automates activities

sothat a single button turns on all the necessary devices for each activity, and switches

them to the required inputs. For example, pressing the Watch TV button might

turn on your TV, your cable or satellite receiver, and your audio receiver, andswitch

tothecorrect video and audio inputs.

The activity also determines which devices handles important functions such as

changing channels or controlling the volume.

LOGITECH HARMONY ONE+ USER MANUAL

The buttons on your Harmony One+

My Activities

1/2 pages Tue 4:51

Options Devices

Activities

Menu Info

GuideExit

Vol

Replay Skip

+ +

Help

abc def

ghi jkl mno

pqrs tuv wxyz

clear enter

Off

The buttons on the

Harmony One+ may

have different functions

or control different

devices depending on

the activity or device.

For more information,

see Changing buttons

for a device or activity

on page 15.

Off

The Off button turns off all the devices in the current activity.

The arrow keys help you page through items on the touch

screen.

Options Devices The function buttons are dynamic and select the functions

displayed above on the button on the touchscreen.

Activities The Activities button displays your activities.

Help The Help button starts the on-remote help.

Menu The Menu button opens the on-screen menu for the device

selected.

The page up and page down arrows help you navigate

through your on-screen guide or menu.

Info The Info button opens the information section of

youron-screen guide.

Exit

The Exit button closes your on-screen menu or guide.

Guide

The Guide button opens your on-screen guide.

Vol

The volume button changes the volume.

The navigation pad arrows allow you to move through menus

or on-screen guides.

The channel button changes the channels.

The mute button mutes the sound.

The previous channel buttons returns you to the last channel

you were on.

Replay Skip

The play area puts your play, pause, skip and other buttons

inone area for quick access.

abc def

ghi jkl mno

pqrs tuv wxyz

The number pad has the digits 0-9.

enter

The enter button enters a selection from the number pad.

clear

The clear button clears an entry from the number pad.

LOGITECH HARMONY ONE+ USER MANUAL

What’s on the Harmony One+ touchscreen

Activities

When you press the Activities button, the touchscreen

displays the activities you have set up. When you tap

anactivity on the touchscreen, the activity starts, and the

commands for that activity appear on the touchscreen.

The commands may apply to any of the devices that

youuse for that activity. For example, if you’re watching TV,

thetouchscreen displays functions and commands for your TV

and the cable or satellite box you use in the Watch TV activity.

Devices

When you are viewing activities on your remote’s touchscreen,

you can switch to device mode by pressing the Devices button

on your remote. A list of devices appears on the touchscreen.

You can select a device, then view the commands that are

available for that device.

Favorite channels

If you have favorite channels set up on your Harmony One+,

a Favorites option will appear at the bottom of the

touchscreen when you start the Watch TV activity.

TapFavorites then tap the name or icon for the favorite

channel you want to watch.

Status icons

A: The status indicator ashes whenever a command is being

sent from your Harmony One+. B: The status of the battery.

C: The current date and time. Navigating screen options

The buttons surrounding the remote’s screen allow you to

navigate the screen options. The arrow buttons help you

move through each page ofoptions, while the bottom buttons

allow you to choose theoption displayed on the touchscreen

above. The upper left corner of the screen shows the current

page number and how many pages there are in total.

Watch a DVD

1/2 pages Tue 4:51

Devices

Chptr+

Aspect

Chptr- Frame

Advance

Angle Zoom

Off

Devices

1/2 pages Tue 4:51

Activities

DVD

Off

My Activities

1/2 pages

Options Devices

Activities

Menu Info

GuideExit

Vol

Replay Skip

+ +

Help

abc def

ghi jkl mno

pqrs tuv wxyz

clear enter

Off

Tue 4:51

My Activities

1/2 pages Tue 4:51

Options Devices

Watch TV

Watch a DVD

Listen to Music

Off

LOGITECH HARMONY ONE+ USER MANUAL

Using your Harmony One+

Selecting an activity

You can start an activity by pressing the Activities button

onyour remote then tapping the appropriate activity on

thetouchscreen.

Harmony One+ will take care of powering on the required

devices, powering off the ones not needed, and changing

inputs if necessary.

Using the Remote Assistant

The Harmony One+’s Remote Assistant appears on the

touchscreen when you disconnect the remote after syncing,

and when you start an activity. It guides you through the activity. For example,

whenyou select the Watch TV activity, the Remote Assistant asks you if the TV is on

and if the other devices in the activity are congured properly.

You can temporarily turn off the Remote Assistant by pressing the function

button below Options then tapping the Turn Remote Assistant Off option on

thetouchscreen. The Remote Assistant will reappear after the next sync.

Controllingyour devices individually

In some cases, you may want to control a device individually. You may, for example,

want to access a function not included in the current activity (such as picture-in-

picture). When you are in an activity, pressing the Devices button shows you a list

ofyour devices. Choose the device you want to control. If necessary, use the arrow

buttons to nd the page with the desired device. Once you select the device,

theHarmony One+ screen shows the commands for that device. Choose the desired

command. Once you’ve nished, press the center button to return to activities mode.

My Activities

1/2 pages Tue 4:51

Options Devices

Off

Watch TV

Watch a DVD

Listen to Music

If you nd yourself regularly switching to device mode to perform

aparticular function, you should consider adding that function

toanactivity. For more information, see Setting up activities

onpage9.

LOGITECH HARMONY ONE+ USER MANUAL

Using your favorite channels

You can set up favorite channels for your TV, or your cable or satellite receiver.

Foreach channel, you can choose the icon you want to appear on the touchscreen.

For more information, see Setting up favorite channels on page 16.

To select a favorite channel:

1. Press the Watch TV button. On your remote’s touchscreen, select the Favorites

option. Your favorite channels will appear on the screen.

2. If you have set up more than four favorite channels, they will appear

onmultiplepages. Use the arrow buttons to move between pages.

3. To jump to a favorite channel, simply tap the channel number or icon.

Turning off your devices

Press the Off button to power off all the devices used in the current activity.

Setting the date and time

You can change the date and time that appears on the Harmony One’s touchscreen.

To set or change the date and time, follow these steps:

1. On your Harmony One’s screen, press the function button below Options.

2. Tap the Date and Time option.

Recharging your remote

Your Harmony One+ comes with a charging

station. The charging station plugs into a wall

outlet and charges the battery every time

youput the remote on it. To ensure your remote

stays charged, be sure to place it back on

thecharging station when you’re done using it.

You don’t need to turn off devices when switching between

activities. The Harmony One+ ensures the proper devices for

theactivity are on or off.

Off

LOGITECH HARMONY ONE+ USER MANUAL

Using the Help button

Because obstacles or distance can interfere with the signals the Harmony One+ sends

when it starts an activity (for example, someone walks between your Harmony One+

and the TV when you press Watch TV, or you’re very far away from the system

whenyou start an activity), your Harmony One+ can become “out of sync” with

yourdevices.

Before pressing the Help button, be sure you’ve addressed the cause

of the problem (for example, remove any obstacles from the line

ofsight).

To x the problem, use the Help feature on your remote.

1. On the remote, press the Help button.

2. Answer the questions and follow the instructions on

the Harmony One+ touchscreen. The Harmony One+

re-sends commands to make your remote “in sync”

with your devices.

3. To access advanced help features, press and hold

theHelp button for 5 seconds.

If you have used the Help feature to x the problem several

times in the past, you may be asked some questions

tohelp x the problem permanently. When you’re done

withthisprocess, the Harmony One+ will be “in sync”

withyour devices.

ExitHelp

Didthat fix

theproblem?

No Yes

Tabla de contenidos

Otros manuales de Mando a distancia de Logitech

Logitech

Logitech HARMONY REMOTE 600 Series Manual de usuario

Logitech

Logitech Harmony 880 Guide Manual de usuario

Logitech

Logitech Harmony 525 Manual de usuario

Logitech

Logitech Harmony 550 - Harmony 550 Universal Remote Manual de usuario

Logitech

Logitech Harmony One Manual de usuario

Logitech

Logitech Harmony Ultimate Hub Manual de usuario

Logitech

Logitech Harmony 650 Manual de usuario

Logitech

Logitech Harmony 300 Manual de usuario

Logitech

Logitech Harmony 650 Manual de usuario

Logitech

Logitech Harmony 600 Manual de usuario

Logitech

Logitech SPOTLIGHT Guía del usuario

Logitech

Logitech HARMONY 950 Manual de usuario

Logitech

Logitech Harmony 650 Manual de usuario

Logitech

Logitech Harmony Ultimate Hub Manual de usuario

Logitech

Logitech Harmony 650 Manual de usuario

Logitech

Logitech R700 Manual de usuario

Logitech

Logitech Squeezebox 596SQCNTL Manual de usuario

Logitech

Logitech Harmony Ultimate Hub Manual de usuario

Logitech

Logitech HARMONY 520 Manual de usuario

Logitech

Logitech Harmony 200 Manual de usuario

Logitech

Logitech Harmony 550 - Harmony 550 Universal Remote Manual de usuario

Logitech

Logitech R400 - Wireless Presenter Presentation Remote... Manual de usuario

Logitech

Logitech Harmony Smart Control Add-on Manual de usuario

Logitech

Logitech COVER FPO Manual de usuario

Manuales populares de Mando a distancia de otras marcas

Panasonic

Panasonic EUR7622KB0 Manual de usuario

Bang & Olufsen

Bang & Olufsen Beo4 Manual de usuario

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manual de usuario

Multiplex

Multiplex PROFI TX 9 Manual de usuario

One Remote

One Remote RMB4 Manual de usuario

FUTABA

FUTABA 9ZAP - PART2 Manual de usuario

HR Matic

HR Matic HR MULTI 3 Manual de usuario

Yamaha

Yamaha ACC-GNRST-30-20 Manual de usuario

EisSound

EisSound KBSOUND Manual de usuario

Marantz

Marantz RC101 Manual de usuario

Conrad

Conrad FS20 TC6 Manual de usuario

Anritsu

Anritsu MP1777A Manual de usuario

Niles

Niles WVC100 Guía de solución de problemas

RCA

RCA RCU1300 Manual de usuario

Bang & Olufsen

Bang & Olufsen BEO6 Manual de usuario

GE 94901 Manual de usuario

Onbon

Onbon YQ1-75 Manual de usuario

FUTABA

FUTABA R7108SB Instrucciones de instalación
