Logic Instrument Fieldbook E1 Manual de usuario
Fieldbook E1
User’s Guide
Fieldbook)E1)User’s)Guide)
1
Safety Information
1. Please read these safety instructions carefully.
2. Please keep this User’s Guide for later reference.
3. Please disconnect this device from the power source before cleaning.
Do not use liquid or detergent for cleaning. Use a moist sheet or cloth
for cleaning.
4. Make sure the device is connected to a power source with the correct
voltage, frequency, and ampere.
5. All cautions and warnings on the equipment should be noted.
6. Never pour any liquid into opening to prevent fire or electrical shock.
7. Never open the device. Only qualified service personnel should open
the device to prevent damage or personal injury.
8. Get the equipment checked by a service personnel in any of these
cases:
a. Liquid has penetrated the device.
b. The device has been exposed to moisture.
c. The equipment has not worked well or you cannot get it to work
according to User’s Guide.
d. The device was dropped and damaged, and there are obvious
signs of breakage.
Fieldbook)E1)User’s)Guide)
2
9. Caution on the use of the battery: Use only the battery recommended
by the manufacturer or the same type of battery installed by the
manufacturer. Incorrect battery may cause explosion or fire hazard.
Recycle or discard used batteries according to the manufacturer’s
instruction or your local authorities.
10. The device uses nonvolatile memory that requires a battery to retain
system information when power is removed. The 3V lithium battery is
onboard the system. Battery life depends on the amount of time the
computer is powered on. If the computer does not display the correct
time and date, replace the battery.
IMPORTANT:Loss of BIOS settings occurs when the battery is removed.
BIOS settings must be reconfigured whenever the battery is replaced.
WARNING:A risk of fire and chemical burn exists if the battery is not
handled properly. Do not disassemble, crush, puncture, or short external
contacts, or expose the battery to temperatures higher than 60 °C (140 °F).
Do not dispose of a used battery in water or fire.
CAUTION:There is a danger of explosion if the battery is incorrectly
replaced. Replace only with same or equivalent type recommended by the
manufacturer. Discard used batteries according to the manufacturer’s
instructions.
Fieldbook)E1)User’s)Guide)
3
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a
class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
!Reorient or relocate the receiving antenna.
!Increase the separation between the equipment and receiver.
!Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
!Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
Fieldbook)E1)User’s)Guide)
4
FCC RF Radiation Exposure Statement:
1. This transmitter has demonstrated co-location compliance
requirements with Wi-Fi, Bluetooth and RFID Modules. This transmitter
must not be co-located or operating in conjunction with any other
antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure limits set
forth for an uncontrolled environment. This device was tested for
typical hand held operations with the device contacted directly to the
human body to the back side of the tablet. To maintain compliance with
FCC RF exposure compliance requirements, avoid direct contact to the
transmitting antenna during transmitting.
Fieldbook)E1)User’s)Guide)
5
Europe – EU Declaration of Conformity
This device complies with the essential requirements of the R&TTE
Directive 1999/5/EC and EMC directive 2004/108/EC. The following test
methods have been applied in order to prove presumption of conformity
with the essential requirements of the R&TTE Directive 1999/5/EC and
EMC directive 2004/108/EC:
!EN 55022: 2006 +A1: 2007
!EN 61000-3-2: 2006
!EN 61000-3-3: 1995 + A1 : 2001 + A2 : 2005
!EN 55024: 1998 + A1: 2001 + A2: 2003
•IEC 61000-4-2: 2008;
•IEC 61000-4-3: 2006 + A1:2007;
•IEC 61000-4-4: 2004;
•IEC 61000-4-5: 2005;
•IEC 61000-4-6: 2003 + A1: 2004 +A2: 2006;
•IEC 61000-4-8: 1993 +A1: 2000;
•IEC 61000-4-11: 2004
!EN 60950-1: 2001
Safety of information technology equipment
!EN 300 328 V1.7.1: 2006
!EN 301 489-17 V2.1.1: 2009 and EN 301 489-1 V1.8.1: 2008
!EN 62311: 2008
Fieldbook)E1)User’s)Guide)
6
This device is a 2.4GHz wideband transmission system (transceiver),
intended for use in all EU member states and EFTA countries under the
following conditions and/or with the following restrictions:
!In Italy, the end-user should apply for a license at the national
spectrum authorities in order to obtain authorization to use the device
for setting up outdoor radio links and/or for supplying public access to
telecommunications and/or network services.
!This device may not be used for setting up outdoor radio links in
France and in some areas the RF output power may be limited to
10mW EIRP in the frequency range of 2454 – 2483.5MHz. For detailed
information the end-user should contact the national spectrum
authority in France.
Fieldbook)E1)User’s)Guide)
7
Table of Contents
CHAPTER 1. GENERAL INFORMATION................................... 11
1.1. INTRODUCTION.................................................................... 11
1.2. SPECIFICATIONS.................................................................. 12
1.2.1. Main System ............................................................... 13
1.2.2. Interfaces .................................................................... 14
1.2.3. Control buttons............................................................ 14
1.2.4. Power supply............................................................... 15
1.2.5. Environment ................................................................ 15
1.2.6. Material ....................................................................... 16
1.2.7. Certifications ............................................................... 16
1.2.8. Optional: Internal Module ............................................ 17
1.3. PACKAGE CONTENTS .......................................................... 19
CHAPTER 2. SYSTEM SETUP................................................... 20
2.1. EXPLORING YOUR FIELDBOOK E1 ........................................ 20
2.1.1. Front View ................................................................... 21
2.1.2. Rear View.................................................................... 23
2.1.3. Left View ..................................................................... 25
2.1.4. Right View ................................................................... 27
2.1.5. Bottom View ................................................................ 29
2.2. PREPARING FOR INSTALLATION ............................................ 30
2.2.1. Switch ON the Main Battery ........................................ 30
2.2.2. Connecting a power supply......................................... 31
Fieldbook)E1)User’s)Guide)
8
Fieldbook AC Adapter .................................................................................32
2.2.3. Insert a SIM Card ........................................................ 34
2.2.4. Insert a Micro SD Card................................................ 36
2.2.5. Restore Factory Settings............................................. 38
2.2.6. Turn On the Device ..................................................... 39
2.3. ANDROID SETTINGS............................................................. 40
2.3.1. Setting Up for the First Time ....................................... 40
2.3.2. Finger Gestures .......................................................... 40
2.3.3. Home Screens ............................................................ 41
2.4. CONNECT THE FIELDBOOK E1 TO OTHER DEVICES ............... 42
2.4.1. Connecting a USB Device........................................... 42
2.4.2. Connecting an HD Display .......................................... 44
2.4.3. Connecting a Headphone ........................................... 46
CHAPTER 3. FIELDCONTROL .................................................. 48
3.1. INTRODUCTION.................................................................... 48
3.2. FIELDCONTROL OVERVIEW.................................................. 49
3.2.1. Launching FieldControl ............................................... 49
3.2.2. Field Control Main Page.............................................. 50
3.3. MAIN PAGE FUNCTION CONTROLS ....................................... 53
3.3.1. Brightness ................................................................... 53
3.3.2. Volume ........................................................................ 54
3.3.3. Auto-Rotation .............................................................. 54
3.3.4. Profile Selection .......................................................... 55
3.3.5. Radio control settings.................................................. 56
Airplane Mode .............................................................................................56
