may cause serious off-set loading and make truck turn over.
13. When maintaining and repairing truck, stand bar should be used to support fork arm in order to
prevent table from falling (there should be no goods on table), and guarantee the safety in
maintenance and repairing.
14. Please operate strictly according to “notes (warning)”, otherwise it will bring damage to truck
and human body.
Ⅴ. Operation methods：
1. Please step on the foot lever for several times to raise the working table.
2. Please lift the handle knob upward slowly, and open the one-way valve to make the working
table descend slowly.
3. Please make the brake open before moving the truck.
Ⅵ. Maintenance and upkeep:
It is very important to conduct necessary maintenance and upkeep so as to prolong the service life
and safety of the lift table. Please check the lift table before operation according to the following
items:
1. Whether there is any distortion and bending of various positions of the lift table.
2. Please check the brake of the truck and the wearing condition of the wheels.
3. Check oil leakage in the hydraulic system.
4. Please add or fill lubricant to each friction surface before daily operation.
5. If there is any failure, the lift table should be repaired at once, then it can be put into use again.
6. Chang the hydraulic oil every twelve months, choose the following or close brand hydraulic oil
according to the climate conditions of different areas:
a) YBN32 is adaptive under the environment temperature of -10~+40°C;
b) YCN32 is adaptive under the environment temperature of -20~+40°C.
Ⅶ. Assembly method：
The handle and foot lever are dismantled when ex-factory, they might be fixed together by the
users when using. The assembly methods are as follows:
Handle installation method: as shown following drawing, fix the handle (B1) to mounting hole
of the truck body (A) with bolt (B7), spring washer (B6), flat
washer (B5), then screw down the bolt (B7) with wrench.
Foot lever mounting: insert the foot lever (B31) into the hole, put in the screw (B29) and the
plain washer (B27) , the spring washer (B28) ,then screw down the
screw (B29) with wrench.
