Introduction
The LCI Above Floor Slide-out (Vertical Motor) system is a rack and pinion style slide system. Utilizing a bi-
directional electric motor to actuate the drive shaft, the slide-out room is extended and retracted from the
same source. The actuator has a built-in automatic braking feature.
For information on the assembly or individual components of this product, please visit:
https://support.lci1.com/lci-above-floor-slide-outs .
NOTE: Images used in this document are for reference only when assembling, installing and/or operating
this product. Actual appearance of provided and/or purchased parts and assemblies may differ.
Safety
Read and understand all instructions before installing or operating this product. Adhere to all safety labels.
This manual provides general instructions. Many variables can change the circumstances of the instructions,
i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This
manual cannot begin to plot out instructions for every possibility, but provides the general instructions,
as necessary, for effectively interfacing with the device, product or system. Failure to correctly follow the
provided instructions may result in death, serious personal injury, severe product and/or property damage,
including voiding of the LCI limited warranty.
The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may cause
death or serious personal injury and/or severe product and property damage if not performed
safely and within the parameters set forth in this manual.
