Solera®Awning LED

Light Strip Kit

Installation and Owner’s Manual

(For Aftermarket Applications)

CCD-0002359

Table of Contents

Introduction ............................................ 2

Safety ................................................... 2

Parts List ................................................ 3

Resources Required ................................... 3

Preparation ............................................. 3

Custom Sizing of the LED Light Strip .................. 3

Removing the Old LED Light Strip ..................... 4

Installation .............................................. 4

LED Light Strip ........................................ 4

LED Light Switch Installation .......................... 5

Wiring Diagrams ....................................... 6

Front of Switch ......................................... 6

Back of Switch ......................................... 6

LED Light Switch Operation ........................... 6

Notes .................................................. 7-8

Solera®Awning

LED Light Strip Kit

Installation and

Owner’s Manual

(For Aftermarket Applications)

Solera® Awning Aftermarket LED Light Strip KitSolera® Awning Aftermarket LED Light Strip Kit

Part #Part # DescriptionDescription

674282 15’ Solera Awning LED Light Strip kit

674283 21’ Solera Awning LED Light Strip Kit

lci1.com 574-537-8900 Rev: 02.06.20

Solera®Awning LED

Light Strip Kit

Installation and Owner’s Manual

(For Aftermarket Applications)

CCD-0002359

Introduction

The exible light strip slides onto an integrated light cord

included on all Solera® Universal Awning Fabric, the Prep

Flex or Fabled Fabric Awning. The innovative design

allows you to enjoy dramatic lighting outside of the RV

when the awning is extended or retracted.

NOTE: Images used in this document are for reference

only when assembling, installing and/or operating this

product. Actual appearance of provided and/or purchased

parts and assemblies may differ.

Additional information about this product can be

obtained from lci1.com/support or by using the

myLCI app. Replacement kits can be ordered from

https://store.lci1.com/ or by using the myLCI app.

The myLCI app is available for free on iTunes® for iPhone®

and iPad® and also on Google Play™for Android™users.

iTunes ®, iPhone®, and iPad®are registered trademarks of

Apple Inc.

Google Play™and Android™are trademarks of Google Inc.

NOTE: This manual will refer to the “drive side” and “idler

side” throughout for various instructions. The “drive side”

is the right hand side of the awning when facing the awning

from the exterior of the unit. The “idler side” is the left

hand side of the awning when facing the awning from the

exterior of the unit.

MOVING PARTS CAN PINCH, CRUSH, OR CUT. KEEP

CLEAR AT ALL TIMES.

Safety

Read and fully understand all instructions before installing

or operating this product. Adhere to all safety labels.

This manual provides general instructions. Many variables

can change the circumstances of the instructions, i.e.,

the degree of di󰀩culty, operation and ability of the

individual performing the instructions. This manual

cannot begin to plot out instructions for every possibility,

but provides the general instructions, as necessary,

for e󰀨ectively interfacing with the device, product

or system. Failure to correctly follow the provided

instructions may result in death, serious personal injury,

severe product and/or property damage, including voiding

of the LCI limited warranty.

lci1.com 574-537-8900 Rev: 02.06.20

Solera®Awning LED

Light Strip Kit

Installation and Owner’s Manual

(For Aftermarket Applications)

CCD-0002359

Preparation

Custom Sizing of the LED Light Strip

There are two available sizes for the awning fabric LED light

strip kit. If the awning width, measuring the awning fabric

edge-to-edge, measures 10’ - 15’ the 15’ LED light strip

kit should be used. If the awning fabric measures 16’ - 21’

the 21’ awning LED light kit should be used. To achieve a

custom size, the LED light strip can be cut along the black

line at the nearest copper cut tab (Fig.1A).

NOTE: If cutting the LED light strip is required, it is very

important to cut only on the given cut line between the

copper cut tabs (Fig.1A). Cutting through or before the

copper cut tabs will result in no electrical conductivity to

the following section.

1. At the closest applicable length needed, usually the

width of the awning fabric, measure from the wired side out.

2. Cut the excess light strip from the opposite side of

the wiring on the LED light strip. Use a pair of sharp

scissors to cut the LED light strip directly down the

given cut line (Fig.1A).

3. Seal the LED light strip cut end with a dab of silicone

along the edge and let dry.

Fig.1

Resources Required

• Cordless or electric drill

or screw gun

• Appropriate drive bits

• Cordless or electric saw

• Appropriate cutting blades

• Sharp scissors,

if applicable

• Fuse appropriate for wiring

• Silicone sealant

• Marker

15’ Solera® Awning Aftermarket LED Light Strip15’ Solera® Awning Aftermarket LED Light Strip

Kit PN 674282Kit PN 674282

LetterLetter PNPN DescriptionDescription QtyQty

A 387593 15’ LED Light Strip 1

B 431032 Light Switch 1

C 431033 Light Switch Plate 1

D 227619 #8 x 1” Square Pan Head Screw 2

E 388271 #10 - 16 x 3/8” Pan Head Screw 1

Parts List

21’ Solera® Awning Aftermarket LED Light Strip21’ Solera® Awning Aftermarket LED Light Strip

Kit PN 674283Kit PN 674283

LetterLetter PNPN DescriptionDescription QtyQty

A 387594 21’ LED Light Strip 1

B 431032 Light Switch 1

C 431033 Light Switch Plate 1

D 227619 #8 x 1” Square Pan Head Screw 2

E 388271 #10 - 16 x 3/8” Pan Head Screw 1

NOTE: Part numbers are shown for identification purposes

only. Not all parts are available for individual sale. All parts

with a link to the Lippert Store can be purchased.

lci1.com 574-537-8900 Rev: 02.06.20

Solera®Awning LED

Light Strip Kit

Installation and Owner’s Manual

(For Aftermarket Applications)

CCD-0002359

Fig.4

Installation

LED Light Strip

NOTE: Awning MUST be extended to access the polycord

on the awning fabric and to run the LED power wire down

the drive mount arm.

1. Starting on the drive side of the awning, slide the LED

light strip (non-wired end) (Fig.3A) onto the polycord of

the awning fabric (Fig.3B), located close to the awning rail

(Fig.3C) down the width of the awning fabric to the end,

towards the idler side.

2. Flip the LED light strip drive side (wired end) up to see the

back side of the light strip.

3. Install a #10 - 16 x 3/8” pan head screw (Fig.4A) into the

black plastic track of the LED light strip. Make sure to install

the screw at a slight angle in between the LED light strip and

the polycord in the awning fabric, to prevent the LED light

strip from sliding o󰀨 the awning fabric polycord.

Fig.3

Removing the Old LED Light Strip

NOTE: Awning MUST be extended to access the polycord

on the awning fabric and the LED power wires down the

drive mount arm.

1. If replacing only the LED light strip, remove the old LED

light strip by locating and removing the #10 - 16 x 3/8” pan

head screw (Fig.2A) located on the drive side, in the back of

the LED light strip, holding the LED light strip in place.

Fig.2

2. Cut the wires to the old LED light strip just inside the

wall of the unit. The wires to the new LED light strip can be

spliced into the old wires rather than replacing all the wiring

to the switch and power source and replacing the switch.

3. Remove the old LED light strip by sliding the LED light

strip completely out from the awning fabric polycord.

NOTE: If the light switch needs to be replaced as well,

remove the two #8 x 1” pan head screws in the light switch

plate (Fig.5B). Remove the light switch, plate and disconnect

the wiring to the LED light strip and the power source.

lci1.com 574-537-8900 Rev: 02.06.20

Solera®Awning LED

Light Strip Kit

Installation and Owner’s Manual

(For Aftermarket Applications)

CCD-0002359

LED Light Switch Installation

1. Determine where to mount the LED light switch. The

LED light switch can be mounted anywhere inside the

trailer or trailer compartment. The mounting location must

be watertight. The typical location for the LED light switch

is near the entry door, close to where the wires from the

LED light strip enter inside the unit wall.

2. Cut a hole in the wall or wall of the compartment using

the inside opening of the switch plate as a guide (Fig.6D).

Use the switch plate to trace where the cutout should be

located. The top and bottom horizontal cuts should be

parallel.

3. Place the light switch (Fig.6C) into the switch plate (Fig.6A).

NOTE: Make sure the switch is oriented correctly with the on

position (vertical line) located at the top of the switch.

4. Located on the backside of the light switch, insert the

LED light strip wires onto the proper spade. Red wire is

positive, black wire is negative.

5. Connect the LED red power wire to the unit’s power

source. Make sure the black wire is connected to a ground

and the red wire is connected to 12V DC power source

6. Connect the 3A fuse to protect all wiring going to the

light, that meets or exceeds RVIA standards. See the

Wiring Diagram section.

7. Test the light switch to make sure the LED light strip is

wired properly.

8. Secure the switch plate onto the unit wall with the two

provided #8 x 1” pan head screws (Fig.6B).

Fig.6

NOTE: Make sure the screw does not completely go through

the polycord and into the awning fabric. Make sure that the

LED light strip is hanging straight, parallel to the ground.

4. Depending on top wire or bottom wire installation,

remove the wire covers in the drive side mount arm.

5. If bottom installation, take the LED light strip power wire

(Fig.5A) from the light track and run it down the drive arm.

Make sure to run the wires over the center pin of the drive

mount arm. If top installation, run the wires through the top

hole in the drive side mount arm (Fig.5B) inside the unit wall

and down to the switch.

NOTE: If completing an entirely new installation, proceed

to the LED Light Switch Installation

6. Splice the new LED light strip power wires onto the old

wires just inside the unit’s wall.

NOTE: Make sure the red wire is to power and the black

wire is to ground.

7. Test the light switch to make sure the LED light strip is

wired properly.

8. Reinstall wire covers in the drive mount arm.

Fig.5

lci1.com 574-537-8900 Rev: 02.06.20

Solera®Awning LED

Light Strip Kit

Installation and Owner’s Manual

(For Aftermarket Applications)

CCD-0002359

LED Light Switch Operation

NOTE: Leaving the LED light strip switch on for an

extended period of time can drain the trailer’s battery.

1. To turn the LED light strip on, press the toggle switch to

the vertical line symbol (Fig.7A).

2. To turn the LED light strip o󰀨, press the toggle switch to

the circle symbol (Fig.7B).

Fig.7

Wiring Diagrams

Front of Switch

Back of Switch

red wire

black wire

LED light strip

front of light switch

3A circuit protection

per RVIA code

ground power

ground

battery

light switch plate

light switch

light red wire

power red wire

light black wire

ground black wire

lci1.com 574-537-8900 Rev: 02.06.20

Solera®Awning LED

Light Strip Kit

Installation and Owner’s Manual

(For Aftermarket Applications)

CCD-0002359

Notes

lci1.com 574-537-8900 Rev: 02.06.20

Solera®Awning LED

Light Strip Kit

Installation and Owner’s Manual

(For Aftermarket Applications)

CCD-0002359

Manual information may be distributed as a complete

document only, unless Lippert Components provides

explicit consent to distribute individual parts.

All manual information is subject to change without

notice. Revised editions will be available for free

download at lci1.com. Manual information is considered

factual until made obsolete by a revised version.

Please recycle all obsolete materials and contact

Lippert Components with concerns or questions.

Notes

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Accesorios de Lippert Components

Lippert Components

Lippert Components Solera Manual de usuario

Lippert Components

Lippert Components Solera Manual de usuario

Lippert Components

Lippert Components Edge Awning Manual de usuario

Lippert Components

Lippert Components Solera Power Awning Manual de usuario

Lippert Components

Lippert Components Solera Hybrid Manual de usuario

Lippert Components

Lippert Components Solera Manual de usuario

Lippert Components

Lippert Components Solera Classic Awning Manual de usuario

Lippert Components

Lippert Components Solera Slide Topper Instrucciones de instalación

Lippert Components

Lippert Components Solera Instrucciones de instalación

Lippert Components

Lippert Components Solera Classic Instrucciones de instalación

Lippert Components

Lippert Components Solera TI-278 Instrucciones de funcionamiento y mantenimiento

Lippert Components

Lippert Components Awnbrella Instrucciones de instalación

Lippert Components

Lippert Components Solera Manual de usuario

Lippert Components

Lippert Components Solera Manual de usuario

Lippert Components

Lippert Components Solera Manual de usuario

Lippert Components

Lippert Components Solera Slide Topper with Access Plates Instrucciones de instalación

Lippert Components

Lippert Components Solera 795354 Instrucciones de instalación

Lippert Components

Lippert Components Solera Manual de usuario

Lippert Components

Lippert Components Solera Smart Arm Manual de usuario

Lippert Components

Lippert Components Solera 434718 Manual de usuario

Lippert Components

Lippert Components Solera Manual de usuario

Lippert Components

Lippert Components Solera Manual de usuario

Lippert Components

Lippert Components Solera Manual de usuario

Lippert Components

Lippert Components Solera Smart Arm Instrucciones de instalación

Manuales populares de Accesorios de otras marcas

Hillco

Hillco 2810 Manual de usuario

Siemens

Siemens QSA2700D Manual del operador

Contours

Contours ZY024 Manual de usuario

Saivod

Saivod VS621 Manual de usuario

Virtuox

Virtuox VirtuCLEAN 2.0 Manual de usuario

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manual de usuario

Z-Wave

Z-Wave HSD-200Z Manual de usuario

turck

turck FMX-IM-2UPLI63FX Manual de usuario

Decagon Devices

Decagon Devices 10HS Manual de usuario

UPPAbaby

UPPAbaby Cup Holder Manual de usuario

Elko

Elko SmartSensor Leakage Wireless Manual de usuario

Grizzly

Grizzly H8371 Manual de usuario

Panasonic

Panasonic HG-T Series Manual de usuario

IFM Electronic

IFM Electronic Efector 250 Series Guía de referencia

DigiDesign

DigiDesign 888/24 I/O Manual de usuario

PROZIS

PROZIS QUAY Manual de usuario

patagonia

patagonia PSI Vest Manual de usuario

SFC Energy

SFC Energy EFOY GO! Manual de usuario
