EtherFast®100BaseFX

SC Fiber Module

xpand the benefits you enjoy with your EtherFast 3116 or

3214 Switch as you expand your network. The Linksys

EtherFast®100BaseFX SC Fiber Module complements

your network while increasing the value in your investment by

adding functionality to your Switch.

The EtherFast 100BaseFX SC Fiber Module connects multiple

switches separated by distances of up to 2000 meters or 6560

feet. Networking at such distances is achieved with the use of

fiber optic cables,which allows speeds at that distance of up to

200 mbps.

And it’s so easy to set up! Simply insert the Fiber Module into

an available expansion slot on your EtherFast 3116 or 3124

Switch, tighten the thumbscrews, connect with the appropriate

fiber optic cable and you’re done.

• 100BASE-FX IEEE 802.3u compliant

• Maximum throughput of up to 200Mbps

• Fully compact design for use with the EF3116, and EF3124

• Onboard mini-jumper allows for operation in either Half or

Full Duplex

EtherFast®100BaseFX SC Fiber Module

Model No.: EF31SC

Fiber Optic Expansion and Reliability

in a Single Module

Features

Benefits

• Connect multiple switches at high speed as

your network grows

• Extend your network over a mile using reliable

multimode-fiber optic cable

• Easy to set up – No software setup required

• Make the most of your investment in your

EtherFast 3116 or 3124 Switch

Instant EtherFast®Series

Package ContentsSpecifications

Model Number EF31SC

Standards IEEE 802.3u

Ports 1 SCType Connector

Cabling Type Multimode Fiber

LEDs Link/Act, FDX

Environmental

Dimensions 1.95" x 3.40" x 1.00"

(49.6 mm x 86.3 mm x 25.4 mm)

Unit Weight 0.09 lbs. (0.04 kg)

Operating Temp. 32ºF to 122ºF (0ºC to 50ºC)

Storage Temp. -40ºF to 158ºF (-40ºC to 70ºC)

Operating Humidity 20% to 95%, Non-Condensing

Storage Humidity 20% to 95%, Non-Condensing

• One 100BaseFX SC Fiber Module

• One Registration Card

• One Quick Installation

DS-ef31sc-123002NC KL

Linksys

World Headquarters:

17401 Armstrong Ave.

Irvine, CA 92614 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete

list of local Linksys Sales and Technical

Support contacts,visit ourWorldwideWeb Site

www.linksys.com

• One EtherFast 3116 16-Port 10/100

Ethernet Switch

• One EtherFast 3124 24-Port 10/100

Ethernet Switch

Minimum Requirements
