DEMO MANUAL DC2073B

DESCRIPTION

LTC1799, LTC6900, LTC6905,

LTC6905-XXX, LTC6906, LTC6907

LTC6908 SOT23 Silicon Oscillators

DC2073Bdemoboardfeatures Linear Technology'sSOT23

packaged silicon oscillators. The DC2073B demo board is

available in eleven different options; DC2073B-A through

DC2073B-K. These eleven options provide for the evalu-

ation of resistor-set oscillator ICs and fixed frequency

ICs (Table1).

L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Linear

Technology Corporation. All other trademarks are the property of their respective owners.

Design files for this circuit board are available at

http://www.linear.com/demo/DC2073B

Table 1. Resistor-Set Oscillator ICs and Maximum Frequency Error at TA= 25°C

PART NUMBER, BOARD ASSEMBLY FREQUENCY PROGRAM METHOD DESCRIPTION

LT C

6905, DC2073B-A Resistor Programmable 17.225MHz ≤ fOSC ≤ 170MHz, ±1.4% at V+ = 2.7V

and ±2.2% at V+= 5V

LTC1799, DC2073B-B Resistor Programmable 5kHz ≤ fOSC ≤ 10MHz, ±1.5% at V+ = 3V and

±1.5% at V+= 5V (Up to 20MHz)

LTC6900, DC2073B-C Resistor Programmable 5kHz ≤ fOSC ≤ 10MHz, ±1.5% at V+ = 3V and

±1.5% at V+= 5V (Up to 20MHz)

LTC6905-133, DC2073B-D Three Fixed Frequencies Set by Three-State Input fOSC = 133MHz, 66.7MHz and 33.5MHz,

±1.0% at V+= 3V and ±1.5% Typical at V+= 5V

LTC6905-100, DC2073B-E Three Fixed Frequencies Set by Three-State Input fOSC = 100MHz, 50MHz and 25MHz,

±1.0% at V+= 3V and ±1.5% Typical at V+= 5V

LTC6905-96, DC2073B-F Three Fixed Frequencies Set by Three-State Input fOSC = 96MHz, 48MHz and 24MHz,

±1.0% at V+= 3V and ±1.5% Typical at V+= 5V

LTC6905-80, DC2073B-G Three Fixed Frequencies Set by Three-State Input fOSC = 80MHz, 40MHz and 20MHz,

±1.0% at V+= 3V and ±1.5% typical at V+= 5V

LTC6906, DC2073B-H Resistor Programmable 10kHz ≤ fOSC ≤ 1MHz, ±0.5% at V+= 2.7V to 3.6V

and ±0.7% at V+= 2.25V

LTC6907, DC2073B-I Resistor Programmable 400kHz ≤ fOSC ≤ 4MHz, ±0.65% at V+= 3V to 3.6V

LTC6908-1, DC2073B-J Spread Spectrum Modulation, Complementary

Outputs (0°/180°) Resistor Programmable

250kHz ≤ fOSC ≤ 5MHz, ±1.5% at V+= 2.7V and

±2.0% at V+= 5V

LTC6908-2, DC2073B-K Spread Spectrum Modulation, Quadrature

Outputs (0°/90°) Resistor Programmable

250kHz ≤ fOSC ≤ 5MHz, ±1.5% at V+= 2.7V and

±2.0% at V+= 5V

dc2073bfa

DEMO MANUAL DC2073B

QUICK START PROCEDURE

Test Equipment:

1. A single 3V power supply.

2. An oscilloscope with a bandwidth of at least 5x fOSC.

(For example, if fOSC = 100MHz then use a 500MHz

oscilloscope).

3. A screwdriver to adjust the potentiometer.

Note:The DC2073B potentiometer is shorted with a

zero ohm resistor for factory testing. The zero ohm

(RJ10) resistor must be removed to allow setting the

frequency with a screwdriver. If the potentiometer is

set to a high value (>100k), then touching the DC2073B

can produce output jitter.

Basic Test Procedure:

1. Connectpower supply to V+and GND, turrets E4 andE5.

2. Connect oscilloscope probe to OUT1 and GND.

Note: The ground lead of an oscilloscope probe has a

series inductance that can generate a resonant circuit

with the probe's capacitance. Probe resonance adds

transient peaks and ringing on a high speed wave-

form. Reliable probing of the high frequency LTC6905

and LTC6905-XXX (with corresponding demo boards

DC2073B-A, -D, -E, -F or -G), must use a very short

connectionofthe

oscilloscopeprobegroundtotheboard

GND (see probe tip picture in Figure1 Test Setup).

3. Set the JP1 jumper to the N divider position for the

desired frequency shown on Table2.

4. Turn on supply.

5. The oscilloscope display shows a 3V squarewave

(0V to 3V).

6. For the resistor-set ICs (DC2073B-A, -B, -C, -H, -I, -J

or -K) turn the RPOT potentiometer for the desired fre-

quency.(The frequency adjustment is very coarse when

the potentiometer is turned near the fully clockwise or

counter-clockwise position).

Verify Oscillator Accuracy

The fOSC accuracy of the resistor-set ICs (DC2073B-A, -B,

-C, -H, -I, -J or -K), can be verified by setting RSET to the

exact value from the fOSC equation shown in Table 2. For

the DC2073B-A, -B, -C, -J, -K, RSET = RPOT + RSET2.

RSET1 and RSET2 are never installed on the same board.

Connecting an ohmmeter across RPOT and RSET1 or

RSET2 forces current into the IC set pin (Pin 3 or 4) and

causes an error in the ohmmeter reading. The RS resistor

is in series with RPOT and equal to RSET1 or RSET2 and

the equivalent RSET = RPOT + RS.

Procedure to Verify Oscillator Accuracy

a. Calculate RSET for the desired frequency (RSET in Table 2).

b. Removethepower supply leadsfrom DC2073B and con-

nect an ohmmeter from POT (E6) to V+(DC2073B-A,

-B, -C, -J or -K) or GND (DC2073B-H or-I).

C. Adjust RPOT for the exact value of RSET needed.

Note: If the potentiometer is turned near the fully clock-

wiseorcounter-clockwisepositiontheRPOTadjustment

may be too coarse for setting an exact RSET value. In

addition, for a frequency adjustment near the upper or

lower fOSC range, RSET may be greater or less than the

default DC2073B RPOT + RSET1 or RSET2 value, in this

case the RSET1 or RSET2 resistor must be removed

and replaced with a lower or higher value.

dc2073bfa

DEMO MANUAL DC2073B

QUICK START PROCEDURE

Figure 1. Test Setup

dc2073bfa

DEMO MANUAL DC2073B

QUICK START PROCEDURE

Table 2. fOSC Frequency and N Divider Setting

LTC6905, DC2073B-A

fOSC =168.5MHz •10kΩ

RSET

+1.5MHZ











•1

N, RSET =168.5MHz •10kΩ

N• fOSC –1.5MHz

N = 1 (JP1 to V+), 68.9MHz ≤ fOSC ≤ 170MHz

N = 2 (JP1 to OPEN), 34.45MHz ≤ fOSC ≤ 85MHz

N = 4 (JP1 to GND), 7.225MHz ≤ fOSC ≤ 42.5MHz

LTC1799, DC2073B-B

fOSC =

10MHz

N•

10kΩ

RSET

, RSET =

10MHz

fOSC

•

10kΩ

N = 1 (JP1 to GND), 500kHz ≤ fOSC ≤ 20MHz

N = 10 (JP1 to OPEN), 50kHz ≤ fOSC ≤ 2MHz

N = 100 (JP1 to V+), 5kHz ≤ fOSC ≤ 200kHz

LTC6900, DC1073A-C

fOSC =

10MHz

N•

20kΩ

SET

, RSET =

10MHz

OSC

•

20kΩ

N = 1 (JP1 to GND), 500kHz ≤ fOSC ≤ 20MHz

N = 10 (JP1 to OPEN), 50kHz ≤ fOSC ≤ 2MHz

N = 100 (JP1 to V+), 5kHz ≤ fOSC ≤ 200kHz

LTC6905-133, DC2073B-D

fOSC =

133MHz

N = 1 (JP1 to V+), fOSC = 133MHz

N = 2 (JP1 to OPEN), fOSC = 66.7MHz

N = 4 (JP1 to GND), fOSC = 33.5MHz

LTC6905-10, DC2073B-E

fOSC =

100MHz

N = 1 (JP1 to V+), fOSC = 100MHz

N = 2 (JP1 to OPEN), fOSC = 50MHz

N = 4 (JP1 to GND), fOSC = 25MHz

LTC6905-96, DC2073B-F

fOSC =

96MHz

N = 1 (JP1 to V+), fOSC = 96MHz

N = 2 (JP1 to OPEN), fOSC = 48MHz

N = 4 (JP1 to GND), fOSC = 24MHz

LTC6905-80, DC2073B-G

fOSC =

80MHz

N = 1 (JP1 to V+), fOSC = 80MHz

N = 2 (JP1 to OPEN), fOSC = 40MHz

N = 4 (JP1 to GND), fOSC = 20MHz

LTC6906, DC2073B-H

fOSC =

1MHz

N•

100kΩ

RSET

, RSET =

1MHz

fOSC

•

100kΩ

N = 1 (JP1 to GND), 0.1MHz ≤ fOSC ≤ 1MHz

N = 3 (JP1 to OPEN), 33kHz ≤ fOSC ≤ 333kHz

N = 10 (JP1 to V+), 10kHz ≤ fOSC ≤ 100kHz

LTC6907, DC2073B-I

fOSC =

4MHz

N•

50kΩ

SET

, RSET =

4MHz

OSC

•

50kΩ

N = 1 (JP1 to GND), 0.4MHz ≤ fOSC ≤ 4MHz

N = 3 (JP1 to OPEN), 133kHz ≤ fOSC ≤ 1.33MHz

N = 10 (JP1 to V+), 40kHz ≤ fOSC ≤ 400kHz

LTC6908-1, DC2073B-J

Complementary Outputs (0°/180°) without Modulation:

250kHz ≤ fOSC ≤ 5MHz, (JP1 to DIV/MOD)

fOSC =

10MHz

N•

10kΩ

RSET

, RSET =

10MHz

fOSC

•

10kΩ

Spread Spectrum Modulation Rate:

(JP1 to GND), fOSC/16

(JP1 to OPEN), fOSC/32

(JP1 to V+), fOSC/64

LTC6908-1, DC2073B-K

Quadrature Outputs (0˚/90˚) without Modulation:

250kHz ≤ fOSC ≤ 5MHz, (JP1 to DIV/MOD)

fOSC =

10MHz

N•

10kΩ

SET

, RSET =

10MHz

OSC

•

10kΩ

Spread Spectrum Modulation Rate:

(JP1 to GND), fOSC/16

(JP1 to OPEN), fOSC/32

(JP1 to V+), fOSC/64

dc2073bfa

DEMO MANUAL DC2073B

Information furnished by Linear Technology Corporation is believed to be accurate and reliable.

However, no responsibility is assumed for its use. Linear Technology Corporation makes no representa-

tion that the interconnection of its circuits as described herein will not infringe on existing patent rights.

dc2073bfa

DEMO MANUAL DC2073B

Linear Technology Corporation

1630 McCarthy Blvd., Milpitas, CA 95035-7417

(408) 432-1900 ●FAX: (408) 434-0507 ●www.linear.com

 LINEAR TECHNOLOGY CORPORATION 2013

LT 0616 Rev A • PRINTED IN USA
