DEMO MANUAL DC1795A

Description

LTC6950

1.4GHz Low Phase Noise, Low Jitter PLL

with Clock Distribution

Demonstration circuit 1795A features the LT C

6950, a

1.4GHz low phase noise, low jitter PLL with clock dis-

tribution.

For ease of use, the DC1795A comes installed with a

100MHz reference and a 1GHz VCSO, voltage controlled

SAW oscillator with sine wave output. All differential

inputs and outputs have 0.5" spaced SMA connectors.

The DC1795A has four AC coupled LVPECL outputs with

50Ω transmission lines making them suitable to drive

50Ω impedance instruments. The LVDS/CMOS output is

DC coupled. The LTC6950’s EZSync™ function is made

available via a turret and an SMA connector.

L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks and EZSync

and ClockWizard are trademarks of Linear Technology Corporation. All other trademarks are the

property of their respective owners.

For the evaluation of the LTC6950 with other VCOs and

references,theDC1795Acanbe modified to accommodate

different on-board or external components. It also allows

the user the option of a passive or active loop filter.

A DC590 USB serial controller board is used for SPI com-

munication with the LTC6950, controlled by the supplied

ClockWizard™ software.

Design files for this circuit board are available at

http://www.linear.com/demo/DC1795A

Figure 1. DC1795A Connections

Ribbon

cable

connecon

to DC590

LVDS/CMOS

DC-coupled

Outputs, SMA PECL0

AC Coupled

Outputs, SMA

Frequency Reference

SMA

PECL1

AC Coupled

Outputs, SMA

PECL2

AC Coupled

Outputs, SMA

PECL3

AC Coupled

Outputs, SMA

5V DC Supply,

BNC & turret

3.3V DC Supply,

BNC & turret

5V U4 (VCXO) DC

Supply, turret

U3 (VCO) DC

Supply, turret

External VCO

Input, SMA

External VCO Charge

Pump Output, SMA

and turret

Acve Loop Filter

Op-amp (U2) DC

, turret

EZSyncTM

SYNC Input,

SMA & turret

Stat Outputs,

turrets

Downloaded from Arrow.com.

dc1795af

DEMO MANUAL DC1795A

Quick start proceDure

The DC1795A is easy to set up to evaluate the performance

of the LTC6950. Follow the procedure below.

The DC590 and ClockWizard application are required to

control the DC1795A through a personal computer (PC).

DC590 CONFIGURATION

Place the DC590 jumpers in the following positions (refer

to Figure 2):

JP4: EE - Must be in the EN position.

JP5: ISO - ON must be selected.

JP5: SW - ON must be selected.

JP6: VCCIO - 3.3V or 5V must be selected. This sets

the SPI port to 3.3V or 5V operation. 3.3V operation is

recommended.

Connect the DC590 to one of your computer’s USB ports

with the included USB cable.

CLOCKWIZARD INSTALLATION

The ClockWizard software is used to communicate with

the LTC6950. It uses the DC590 to translate between USB

andSPI-compatibleserialcommunications formats. It also

includes advanced PLL design and simulation capabilities.

The following are the ClockWizard system requirements:

• Windows Operating System: Windows XP, Windows

2003 Server, Windows Vista, Windows 7

• Microsoft .NET 3.5 SP1 or later

• Windows Installer 3.1 or later

• Linear Technology’s DC590 hardware

Figure 2. DC590 Jumper and Connector Locations



JP6

jumpers

J4,ribbon

cable

connection

tothe

DC1795

JP5jumpers

JP4

jumper

J3,USB

connection

toPC

Downloaded from Arrow.com.Downloaded from Arrow.com.

dc1795af

DEMO MANUAL DC1795A

Quick start proceDure

Download the ClockWizard setup file at www.linear.com/

ClockWizard.

Run the ClockWizard setup file and follow the instructions

given on the screen. The setup file will verify and/or install

Microsoft .NET and install the ClockWizard. Refer to the

Help menu for software operation.

DC1795A CONFIGURATION

1. Connect the GND, V+= 3.15V to 3.45V, V+to 5.25V and

V+ VCXO turrets to a power supply and apply power

(see Figure 1 and the Typical DC1795A Requirements

and Characteristics table).

2. Connect the DC590 to the DC1795A with the provided

ribbon cable.

3. Run the ClockWizard application.

4. In ClockWizard, click File > Load Settings and point to

the “LTC6950_PECL0_250MHz.clkset” file.

The green “STAT1” LED on the DC1795A should turn on

and the “STAT2” LED should turn off indicating that the

loop is locked at 1000MHz. A 250MHz signal should be

present on the PECL0 outputs.

Be sure to power down or terminate any unused RF output

with 50Ω, or poor spurious performance may result.

Figure 3. ClockWizard Screenshot

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

dc1795af

DEMO MANUAL DC1795A

Quick start proceDure

TROUBLESHOOTING

If the green LED does not illuminate, follow the instruc-

tions below:

1. Verify that you are able to communicate with the

DC1795A.Thebottom status line in ClockWizard should

read “LTC6950” and “Comm Enabled.”

2. Verify that V+ = 3.15V to 3.45V, V+to 5.25V and V+

VCXO turrets have the correct voltages on them (see

the Typical DC1795A Requirements and Characteristics

table).

3. Select “Status” Output = 2 in ClockWizard’s System

Tab. Click “Read All.” See if the NO_VCO or NO_REF

boxes in the second column are checked.

a. If NO_REF is checked, verify the “V+XO” test point

voltage is set to 3.3V. Verify R73 is installed (0 ohm)

b. IF NO_VCO is checked, verify the components between

U4 and U1 match the default BOM.

Contact the factory for further troubleshooting.

Dc1795a reconfiguration

The DC1795A allows the use of a variety of references,

VCOs and active or passive loop filters. The following

covers the hardware reconfiguration of the DC1795A.

Refer to ClockWizard and the LTC6950 data sheet to bet-

ter understand how to change programmed parameters

on the DC1795A.

LTC6950 CLKSET FILES

The ClockWizard provides three different clkset files for

evaluation purposes. These files were made for the default

bill of materials. If board modifications are made, these

files or the loop filter may need to be modified for the

LTC6950 to lock correctly.

1. LTC6950_PECL0_250MHz.clkset: Produces a 250MHz

output on PECL0. All other outputs are powered down.

2. LTC6950_Figure16_250MHZ.clkset: Matches Figure

16 of the LTC6950 data sheet. To sync outputs, refer

to the EZSync Function section.

3. LTC6950_ALL_CHAN_250MHz.clkset: Produces a

250MHz output on all five outputs. To sync outputs,

refer to the EZSync Function section.

EZSync FUNCTION

Apply a 1ms or longer high pulse to the SYNC SMA con-

nector to take advantage of the EZSync function. Refer

to the LTC6950 data sheet for SYNC timing and level

requirements.

LVPECL OUTPUT OPTIONS

The DC1795A has four AC coupled LVPECL outputs.

Internal biasing (IBIASx = H) is required with this default

termination network. The DC1795A has options for pull

downorseriesresistors to accommodate the other LVPECL

termination networks described in the data sheet.

LVDS/CMOS OUTPUT OPTIONS

The LVDS/CMOS output is DC coupled without on-board

termination by default. The DC1795A provides pull down,

series and a differential termination resistor options to

accommodate other termination networks described in

the data sheet.

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

dc1795af

DEMO MANUAL DC1795A

Dc1795a reconfiguration

REFERENCE OPTIONS

Table 1 details the available reference options and board

modifications for each available option. The CLKSET files

described above assume the noise profile of the default

reference. If a different reference is used, change the

reference noise profile in ClockWizard before simulating

the LTC6950 under the Loop Design tab.

VCO INPUT OPTIONS

Table 2 describes the available VCO input options. Board

modifications and power requirements for each option are

also provided in Table 2. There are two different oscillator

footprints on the board: U3, which accommodates the

popular 0.5"×0.5" package, and U4, which accommodates

another common 14mm × 9mm package with four or six

pins. U4 also accommodates the smaller 5mm × 7.5mm

package. An external connectorized VCO can also drive the

LTC6950 through SMA connector J15. The CLKSET files

described above assume the noise profile for the default

VCO. If a different VCO is used, change the VCO noise

profile in ClockWizard before simulating the LTC6950

under the Loop Design tab.

CLOCK FOLLOWER

Whenusingthe LTC6950 as a clock follower the LTC6950’s

PLL circuitry can be powered down by setting the PDPLL

bit in ClockWizard. This will reduce the LTC6950’s overall

power consumption. Table 2 describes how to reconfigure

the board for a differential external input when using the

LTC6950 as a clock follower. Refer to the EZSync Function

section and to the data sheet for more details on using

the LTC6950 as a clock follower.

LOOP FILTER DESIGN AND INSTALLATION

Tables 3, 4 and 5 cross reference the loop filter options

showninClockWizard’sLoopDesigntabwiththeDC1795A

component reference designators. Table 3 is dedicated to

thedefaultoscillator,componentU4.Table4isdedicatedto

anothercommonoscillatorfootprint,componentU3.Table5

can be used with external oscillators. Use ClockWizard to

select, design and simulate different loop filters.

Some VCO tuning voltage ranges are greater than the

LTC6950charge pump voltage range (refertothe LTC6950

data sheet). In such cases, an active loop filter using an

op amp can deliver the required tuning voltage. When

satisfied with the loop filter design, use Tables 3, 4 and 5

to help identify which components should be modified.

The loop filter components are located on the bottom side

of the DC1795A.

Table 1. Reference Options and Board Modifications

DEFAULT

OPTION

REFERENCE

OPTION INSTALL DEPOPULATE LTC6950 PERFORMANCE COMMENTS

lOn-Board NA NA Limited by on board reference at

frequency offsets <10kHz

U9 can accommodate any 5mm × 7.5mm or

9mm × 14mm oscillator package

External C67

0402 0.1µF R73, C71 Best performance when using an

ultralow noise external reference

For improved performance connect J4 to a very low

noise reference, such as the Wenzel 501-04517D

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

dc1795af

DEMO MANUAL DC1795A

Dc1795a reconfiguration

Table 2. VCO Input Options: Power Settings and Board Modifications

DEFAULT

OPTION

BOARD MODIFICATIONS OSCILLATOR POWER SETTINGS

COMMENTSOSCILLATOR INSTALL DEPOPULATE

V+OA

TURRET

V+VXCO

TURRET

V+VCO

TURRET

lU4 NA

(Default)

[For Active Filters

Only] Determined by

U4 VTUNE specification.

5V for Default U4.

Must be less than 24V

Determined

by U4 VCC

specification.

5V for Default

U4. Must be

less than 24V

- Connects to

pin 2 of U4.

Not used with

Default U4

Refer to Table 3: loop

filter component

selections for U4

U3 U3, *C38

0402 0Ω

*R43 [For Active Filters

Only] Determined by

U3 VTUNE specification.

Must be less than 24V

- Determined

by U3 VCC

specification.

Must be less

than 24V

- Refer to Table 4: loop

filter component

selections for U3

Single-Ended

External

*C25

0402 0Ω

*R25, R40,

R41

[For Active Filters

Only] Determined by

External Oscillator

VTUNE specification,

must be less than 24V

- - - Connect signal to

J15. Refer to Table 5:

loop filter component

selections.

Differential

External

*C25, C26

0402 0Ω

C69 0402

~100pF

*R25, R40,

R41

[For Active Filters

Only] Determined by

External Oscillator

VTUNE specification,

must be less than 24V

- - - Connect signals to J14

and J15. [For External

Oscillator Only] Refer

to Table 5: loop filter

component selections.

* General Recommendations: There are several termination and common mode options on the DC1795A for different input signal types. Refer to the

DC1795A schematic, the LTC6950 data sheet and the data sheet for the VCO or clock distribution component used for an optimum termination network.

Table 3. Loop Filter Selection for U4 Oscillator (Refer to ClockWizard’s Loop Design Tab)

DEFAULT

OPTION

CLOCKWIZARD AND BOM CROSS REFERENCE OTHER MODIFICATIONS

COMMENTS

LOOP FILTER

TYPE RZ CI CP R1 C2 L1 INSTALL DEPOPULATE

lFilter 1 (Passive) RZ_P CI1_P + CI2_P CP_P - - - - - RZ_P, CI1_P, CI2_P, CP_P

populated with default values

Filter 2 (Passive) RZ_P CI1_P + CI2_P CP_P R12 C22 - - -

Filter 3 (Passive) RZ_P CI1_P + CI2_P CP_P R72 C22 R12 - -

Filter 4 (Active) RZ_A CI1_A + CI2_A CP_A R12 C22 - R69, R71

(0402 0Ω)

R70, R72 Select CPINV under the

ClockWizard System tab

Table 4. Loop Filter Selection for U3 Oscillator (Refer to ClockWizard’s Loop Design Tab)

DEFAULT

OPTION

CLOCKWIZARD AND BOM CROSS REFERENCE OTHER MODIFICATIONS

COMMENTSLOOP FILTER TYPE RZ CI CP R1 C2 L1 INSTALL DEPOPULATE

Filter 1 (Passive) RZ_P CI1_P + CI2_P CP_P - - - R18

(0402 0Ω)

R12

Filter 2 (Passive) RZ_P CI1_P + CI2_P CP_P R18 C29 - R12

Filter 3 (Passive) RZ_P CI1_P + CI2_P CP_P R72 C29 R18 - R12

Filter 4 (Active) RZ_A CI1_A + CI2_A CP_A R18 C29 - R69, R71

(0402 0Ω)

R12, R70,

R72

Select CPINV under the

ClockWizard System tab

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

dc1795af

DEMO MANUAL DC1795A

Dc1795a reconfiguration

Table 5. Loop Filter Selection for External Oscillator (Refer to ClockWizard’s Loop Design Tab)

DEFAULT

OPTION

CLOCKWIZARD AND BOM CROSS REFERENCE OTHER MODIFICATIONS

COMMENTSLOOP FILTER TYPE RZ CI CP INSTALL DEPOPULATE

Filter 1 (Passive) RZ_P CI1_P + CI2_P CP_P R68

(0402 0Ω)

R72 Connect CPOUT turret to VTUNE of

external oscillator

Filter 4 (Active) RZ_A CI1_A + CI2_A CP_A R67, R69

(0402 0Ω)

R70, R72 Select CPINV under the ClockWizard

System tab. Connect CPOUT turret to

VTUNE of external oscillator

typical Dc1795a reQuirements anD characteristics

PARAMETER INPUT OR OUTPUT PHYSICAL LOCATION DETAILS

3.3V Power Supply Input J2 BNC connector, or

V+= 3.15V to 3.45V turret

Low-noise and spur-free 3.3V,

500mA default (200mA configured*).

Powers LTC6950, U6, U7, U8 and U9

Charge Pump Power Supply Input J1 BNC connector, or

V+to 5.25V turret

Low-noise and spur-free 5V, 35mA*.

Powers LTC6950 and provides common mode to U2

VCXO/VCSO Power Supply Input V+VCXO turret Low-noise and spur-free 5V, 20mA*. Powers U4

LVDS/CMOS+, LVDS/CMOS–Two Outputs J19 and J18 SMA connectors** DC coupled, 250MHz, (if enabled)*.

Refer to LTC6950 data sheet for output levels for LVDS and

CMOS option.

PECL0+, PECL0–Two Outputs J17 and J16 SMA connectors** AC coupled, 250MHz, 800mVPdifferential*.

Must have LTC6950’s IBIAS0 = H with default BOM. DC1795A

has options for an external pull down resistor if IBIAS0 = L.

PECL1+, PECL1–Two Outputs J13 and J12 SMA connectors** AC coupled, 250MHz, 800mVPdifferential (if enabled)*. Must

have LTC6950’s IBIASX = H with default BOM. DC1795A has

options for an external pull down resistor if IBIASX = L.

PECL2+, PECL2–Two Outputs J8 and J7 SMA connectors**

PECL3+, PECL3–Two Outputs J11 and J10 SMA connectors**

SYNC Input SYNC turret or J9 SMA connector EZSync, 0V to 3.3V control signal, refer to the data sheet

STAT1, STAT2 Output STAT1 and STAT2 turret STAT1 GREEN LED, if ON LTC6950 is locked*.

STAT2 RED LED, if ON indicates issue*.

Refer to the troubleshooting section and data sheet

Loop Bandwidth - Set by loop filter component values 4.2kHz*

VCO Power Supply Input V+VCO turret Board Modifications required for use, see Table 2

Active Loop Filter Supply Input V+OA turret Board Modifications required for use, see Table 2

REF, External Reference Input J4 SMA connector Board Modifications required for use, see Table 1

VCO+, VCO–, External VCO or

Input for clock distribution

Input J14 and J15 SMA connectors Board Modifications required to use External VCO.

See Tables 2 and 5. Clock Distribution, see Table 2 only

CPOUT Output CPOUT Turret Used with External VCO, connect to external VCO’s VTUNE

voltage

* These values are for the “LTC6950_PECL0_250MHz” file and the default on board VCO and Reference.

** Any unused RF output must be powered down or terminated with 50Ω, or poor spurious performance may result.

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

dc1795af

DEMO MANUAL DC1795A

layout top layer

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

dc1795af

DEMO MANUAL DC1795A

parts list

ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER

1 0 CI1_A, C22, C29, CP_A CAP., 0603 OPT

2 1 CI1_P CAP., X7R, 0.1µF, 25V, 10%, 0603 AVX, 06033C104KAT2A

3 0 CI2_A CAP., 1206 OPT

4 1 CI2_P CAP., X7R, 0.56µF, 25V, 10%, 1206 AVX, 12063C564KAT2A

5 1 CP_P CAP., X7R, 0.056µF, 16V, 10%, 0603 AVX, 0603YC563KAT2A

6 3 C1, C3, C7 CAP., TANT, 47µF, 20V, 20%, 7343 AVX, TAJD476M020HNJ

7 2 C2, C8 CAP., X7R, 1µF, 10V, 10%, 0603 AVX, 0603ZC105KAT2A

8 20 C4, C9-C19, C42-C48, C60 CAP., X7R, 0.01µF, 6.3V, 10%, 0201 AVX, 02016C103KAT2A

9 3 C5, C24, C32 CAP., X7R, 0.1µF, 50V, 10%, 0805 AVX, 08055C104KAT2A

10 29 C6, C28, C31, C33-C36, C39-C41, C49-C58,

C61-C66, C71, C73, C74

CAP., X7R, 0.1µF, 10V, 10%, 0402 AVX, 0402ZC104KAT2A

11 3 C23, C30, C59 CAP., TANT, 47µF, 35V, 10%, 7361 AVX, TAJV476K035RNJ

12 0 C25-C27, C38, C67, C69, C70 CAP., 0402 OPT

13 2 C68, C72 CAP., NPO, 100pF, 25V, 10%, 0402 AVX, 04023A101KAT2A

14 1 D1 LED, GREEN, LED-ROHM-SML-010FT ROHM, SML-010FTT86L

15 1 D2 LED, RED, LED-ROHM-SML-010VT ROHM, SML-010VTT86L

16 15 E1-E11, E16, E17, E20, E21 TURRET, TESTPOINT 0.064" MILL-MAX, 2308-2-00-80-00-00-07-0

17 2 J1, J2 CONN, BNC, 5 PINS CONNEX, 112404

18 2 J3, J9 CONN., SMA 50Ω STRAIGHT MOUNT CONNEX, 132134

19 13 J4, J7, J8, J10-J19 CONN., SMA 50Ω EDGE-LAUNCH EMERSON, 142-0701-851

20 1 J5 CONN., HEADER, 14 PIN, 2mm MOLEX, 87831-1420

21 1 RZ_P RES., CHIP, 196Ω, 1/16W, 1%, 0603 VISHAY, CRCW0603196RFKEA

22 5 R1, R2, R4, R5, R10 RES., CHIP, 4.99k, 1/16W, 1% 0402 VISHAY, CRCW04024K99FKED

23 0 R6, R9, R17, R19, R21-R24, R26, R30-R33,

R36, R38, R42, R46, R52, R57, R60, R61

RES., 0402 OPT

24 4 R7, R16, R28, R29 RES., CHIP, 49.9, 1/16W, 1% 0402 VISHAY, CRCW040249R9FKED

25 15 R8, R43, R44, R55, R56, R62-R66, R74-R78 RES., CHIP, 0Ω, 0402 VISHAY, CRCW04020000Z0ED

26 5 R11, R12, R70, R72, R73 RES., CHIP, 0Ω, 0603 YAGEO, RC0603JR-070RL

27 5 R13-R15, R35, R58 RES., CHIP, 200K, 1/16W, 1% 0402 VISHAY, CRCW0402200KFKED 2rls

28 0 R18, R67-R69, R71, RZ_A, R53 RES., 0603 OPT

29 5 R20, R51, R54, R59, R79 RES., CHIP, 100, 1/16W, 1% 0402 NIC, NRC04F1000TRF

30 2 R25, R40 RES., CHIP, 150, 1/16W, 1% 0402 VISHAY, CRCW0402150RFKED

31 2 R37, R39 RES., CHIP, 330, 1/16W, 1% 0402 VISHAY, CRCW0402330RFKED

32 1 R41 RES., CHIP, 37.4, 1/16W, 1% 0402 VISHAY, CRCW040237R4FKED

33 1 U1 I.C. LTC6950IUHH, QFN48UHH-5X9 LINEAR TECH., LTC6950IUHH#PBF

34 1 U2 I.C. LT1678IS8, SO8 LINEAR TECH., LT1678IS8#PBF

35 0 U3 VCO, 0.5" × 0.5" OPT

36 1 U4 VCSO, 1GHz 5V CRYSTEK, CVCSO-914-1000.000

37 1 U5 I.C., SERIAL EEPROM, TSSOP8 MICROCHIP, 24LC025-I /ST

38 2 U6, U7 I.C., DUAL BUFFER, SC70-6 FAIRCHILD SEMI., NC7WZ17P6X

39 1 U8 I.C., DUAL TRANSCEIVER, SOT363 NXP, 74LVC 1T45GW

40 1 U9 CLOCK OSCILLATOR, 100MHz, 3.3V CRYSTEK, CCHD-575-25-100.000

dc1795af

DEMO MANUAL DC1795A

schematic Diagram

4 4

3 3

2 2

1 1

NOTE: UNLESS OTHERWISE SPECIFIED

1. ALL RESISTORS ARE IN OHMS, 0402

2. ALL CAPACITORS ARE IN MICROFARADS, 0402

(LOK)

(ERR)

THE LAYOUT FOOTPRINT FOR U4 AND U9 ACCEPTS

MOST OSCILLATORS IN 9mm X 14mm OR 5mm X

7.5mm PACKAGES WITH EITHER FOUR OR SIX PINS.

V+OA

V+VCO

V+

V+OA

V+CP

V+VCXO

V+VCO

V+VCXO

V+CP

V+

SDI

SCLK

SDO

SIZE

DATE:

IC NO. REV.

SHEET OF

TITLE:

APPROVALS

PCB DES.

APP ENG.

TECHNOLOGY Fax: (408)434-0507

Milpitas, CA 95035

Phone: (408)432-1900

1630 McCarthy Blvd.

LTC Confidential-For Customer Use Only

CUSTOMER NOTICE

LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A

CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS;

HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO

VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL

APPLICATION. COMPONENT SUBSTITUTION AND PRINTED

CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT

PERFORMANCE OR RELIABILITY. CONTACT LINEAR

TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE.

THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND

SCHEMATIC

SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.

SCALE = NONE

www.linear.com

03/24/2014, 05:07 PM

1.4 GHZ LOW PHASE NOISE, LOW JITTER PLL WITH CLOCK DISTRIBUTION

KIM T.

MICHEL A.

N/A

LTC6950IUHH

DEMO CIRCUIT 1795A

SIZE

DATE:

IC NO. REV.

SHEET OF

TITLE:

APPROVALS

PCB DES.

APP ENG.

TECHNOLOGY Fax: (408)434-0507

Milpitas, CA 95035

Phone: (408)432-1900

1630 McCarthy Blvd.

LTC Confidential-For Customer Use Only

CUSTOMER NOTICE

LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A

CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS;

HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO

VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL

APPLICATION. COMPONENT SUBSTITUTION AND PRINTED

CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT

PERFORMANCE OR RELIABILITY. CONTACT LINEAR

TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE.

THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND

SCHEMATIC

SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.

SCALE = NONE

www.linear.com

03/24/2014, 05:07 PM

1.4 GHZ LOW PHASE NOISE, LOW JITTER PLL WITH CLOCK DISTRIBUTION

KIM T.

MICHEL A.

N/A

LTC6950IUHH

DEMO CIRCUIT 1795A

SIZE

DATE:

IC NO. REV.

SHEET OF

TITLE:

APPROVALS

PCB DES.

APP ENG.

TECHNOLOGY Fax: (408)434-0507

Milpitas, CA 95035

Phone: (408)432-1900

1630 McCarthy Blvd.

LTC Confidential-For Customer Use Only

CUSTOMER NOTICE

LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A

CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS;

HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO

VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL

APPLICATION. COMPONENT SUBSTITUTION AND PRINTED

CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT

PERFORMANCE OR RELIABILITY. CONTACT LINEAR

TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE.

THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND

SCHEMATIC

SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.

SCALE = NONE

www.linear.com

03/24/2014, 05:07 PM

1.4 GHZ LOW PHASE NOISE, LOW JITTER PLL WITH CLOCK DISTRIBUTION

KIM T.

MICHEL A.

N/A

LTC6950IUHH

DEMO CIRCUIT 1795A

REVISION HISTORY

DESCRIPTION DATEAPPROVEDECO REV

MICHEL A.PRODUCTION2 03-24-14

REVISION HISTORY

DESCRIPTION DATEAPPROVEDECO REV

MICHEL A.PRODUCTION2 03-24-14

REVISION HISTORY

DESCRIPTION DATEAPPROVEDECO REV

MICHEL A.PRODUCTION2 03-24-14

R36

OPT

R36

OPT

C58

0.1uF

C58

0.1uF

R28

49.9

R28

49.9

CI1_A OPT

0603

CI1_A OPT

0603

C27 OPTC27 OPT

OPT

RZ_P

196

0603

RZ_P

196

0603

R42

OPT

R42

OPT

R71

OPT

0603

R71

OPT

0603

U2 LT1678IS8

OUTA 1

-INA 2

+INA 3

V- 4

+INB

-INB

OUTB

V+

J8 PECL2+

C32 0.1uF

0805

C32 0.1uF

0805

R70

0603

R70

0603

C50

0.1uF

C50

0.1uF

J14

VCO+ J14

VCO+

CP_A OPT

0603

CP_A OPT

0603

R73 0

0603

R73 0

0603

C52

0.1uF

C52

0.1uF

R22

OPT

R22

OPT

C25 OPTC25 OPT

J13 PECL1+

C40

0.1uF

C40

0.1uF

C70

OPT

C70

OPT

C66

0.1uF

C66

0.1uF

R32

OPT

R32

OPT

C23

35V

47uF

7361

C23

35V

47uF

7361

C29

OPT

0603

C29

OPT

0603

E10

STAT1 E10

STAT1

SYNC J9

SYNC

OPT

GND 1

VTUNE 2

GND 3

GND 4

GND 5

GND 6

GND 7

GND 8

GND

RFOUT

GND

VCC

GND

C54

0.1uF

C54

0.1uF

J7 PECL2-

R68 OPT

0603

R68 OPT

0603

CI2_P 0.56uF

1206

CI2_P 0.56uF

1206

R29

49.9

R29

49.9

R1 4.99KR1 4.99K

J18 LVDS/CMOS-

R67 OPT

0603

R67 OPT

0603

C30

35V

47uF

7361

C30

35V

47uF

7361

R53

OPT

R53

OPT

J19 LVDS/CMOS+

R52

OPT

R52

OPT

RZ_A OPT

0603

RZ_A OPT

0603

J12 PECL1-

C57

0.1uF

C57

0.1uF

C56

0.1uF

C56

0.1uF

J11 PECL3+

R39

330

R39

330

CI1_P 0.1uF

0603

CI1_P 0.1uF

0603

E11

STAT2 E11

STAT2

R61

OPT

R61

OPT

R55

V+OA E2

V+OA

J15

VCO- J15

VCO-

C49

0.1uF

C49

0.1uF

CVCSO-914-1000

VTUNE

GND

3OUT+ 4

OUT- 5

VCC 6

J17 PECL0+

20V

47uF

7343

20V

47uF

7343

R35

200K

R35

200K

4.99K

R65

C24 0.1uF

0805

C24 0.1uF

0805

CPOUT J3

CPOUT

C22

OPT 0603

C22

OPT 0603

R18

OPT

0603

R18

OPT

0603

R72

0603

R72

0603

J4 REF

C71

0.1uF

C71

0.1uF

J16 PECL0-

R31

OPT

R31

OPT R66

R66

R17

OPT

R17

OPT

R69

OPT

0603

R69

OPT

0603

R12 0

0603

R12 0

0603

R30

OPT

R30

OPT

GND E7

GND

J10 PECL3-

R74

R46

OPT

R46

OPT

C51

0.1uF

C51

0.1uF

C69

OPT

C69

OPT

CPOUT E4

CPOUT

R21

OPT

R21

OPT

SYNC E9

SYNC

C67

OPT

C67

OPT

R9 OPTR9 OPT

C72

100pF

C72

100pF

R75

CPCP

R16

49.9

R16

49.9

V+XOV+XO

E17

GND E17

GND

R40

150

R40

150

R43 0R43 0

SML-010MT

GRN

SML-010MT

GRN

E16

V+VCO E16

V+VCO

C53

0.1uF

C53

0.1uF

CCHD-575-25-100

VTUNE 1

EN 2

GND 3

OUT+

OUT-

VCC

R76

R26

OPT

R26

OPT

C28

0.1uF

C28

0.1uF

GND E6

GND

R77

V+VCXO E5

V+VCXO

C55

0.1uF

C55

0.1uF

R60

OPT

R60

OPT

R33 OPTR33 OPT

R20 100R20 100

CI2_A OPT

1206

CI2_A OPT

1206 R23 OPTR23 OPT

C6 0.1uFC6 0.1uF

C38 OPTC38 OPT

LTC6950IUHH

V+CP

GND

V+

V+VCO

VCO-

VCO+

V+VCO

V+

GND

V+ 18

V+P3 1

PECL3- 2

PECL3+ 3

V+P3 4

V+P2 5

PECL2- 6

PECL2+ 7

V+P2 8

V+P1 9

PECL1- 10

PECL1+ 11

V+P1 12

V+P0 13

PECL0- 14

PECL0+ 15

V+P0 16

V+

V+REF

GND 17

SDO 24

LV/CM- 21

CS 23

V+ 20

V+

SCLK

SDI

STAT1

SYNC

STAT2

LV/CM+ 22

REF+

REF-

V+

V+REF

V+ 19

GND

R37

330

R37

330

R78

R56

EN E8

R57

OPT

R57

OPT

C26 OPTC26 OPT

CP_P

0.056uF

0603

CP_P

0.056uF

0603

R62

R25

150

R25

150 C68

100pF

C68

100pF

R44 0R44 0

C59

35V

47uF

7361

C59

35V

47uF

7361

R63

R41 37.4R41 37.4

EN-XOEN-XO

C5 0.1uF

0805

C5 0.1uF

0805

R19

OPT

R19

OPT

SML-010VT

RED

SML-010VT

RED

R64

R38

OPT

R38

OPT

R24

OPT

R24

OPT

49.9

Tabla de contenidos

Otros manuales de Placa madre de Linear Technology

Linear Technology

Linear Technology DC823B-A Guía de configuración rápida

Linear Technology

Linear Technology DC299 Manual de usuario

Linear Technology

Linear Technology DC1562B Guía de configuración rápida

Linear Technology

Linear Technology DC1765A Guía de configuración rápida

Linear Technology

Linear Technology DC1444A Manual de usuario

Linear Technology

Linear Technology DC426B Manual del operador

Linear Technology

Linear Technology DC1338B Guía de configuración rápida

Linear Technology

Linear Technology DC2522A Manual de usuario

Linear Technology

Linear Technology DC1705C Guía de configuración rápida

Linear Technology

Linear Technology DC1842B Manual de usuario

Linear Technology

Linear Technology DC1084A-A Guía de configuración rápida

Linear Technology

Linear Technology DC1546A Guía de configuración rápida

Linear Technology

Linear Technology DC1504A Guía de configuración rápida

Linear Technology

Linear Technology DC1555A Guía de configuración rápida

Linear Technology

Linear Technology DC1513B Guía de configuración rápida

Linear Technology

Linear Technology DC1789A Guía de configuración rápida

Linear Technology

Linear Technology DC2581A Guía de configuración rápida

Linear Technology

Linear Technology DC2043B Guía de configuración rápida

Linear Technology

Linear Technology DC1959A Guía de configuración rápida

Linear Technology

Linear Technology DC1816B Manual de usuario

Linear Technology

Linear Technology DC2016A Guía de configuración rápida

Linear Technology

Linear Technology DC2024A Guía de configuración rápida

Linear Technology

Linear Technology DC2347A Guía de configuración rápida

Linear Technology

Linear Technology Demo Circuit 1402A Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario
