Lindy 70586 Manual de usuario

70586

PCI 32 bit P&P

2S (16C650 32FIFO)

1P (ECP/EPP 32FIFO)

www.lindy.com

ž PAGE − 2

Description

The 70586 32Bit PCI bus Plug & Play 2S/1P I/O card is equipped with two

High-Speed RS-232.V24 Standard Serial Interfaces and one

ECP/EPP/SPP/BPP IEEE 1284 CENTRONICS Parallel Interface. The serial

ports include 32 Byte FIFO with a speed up to 921Kb/Sec. 70586 has two 9 pin

male connectors for attaching peripherals´ units with Serial RS-232 Standard

Interface and one 25 pin female connector for peripherals' units with IEEE 1284

CENTRONICS Parallel Interface.

Hardware Specification

Serial Port:

UART Chipset: SUN1889, Hardware FIFO is 32Byte FIFO

Compatible chips: with 16C650, 16C550, and 16C450.

IEEE standard: RS-232 Interface

Driver Chipset: TI-75232, speed up to 100Kb/Sec, length 300-500M.

Max. Speed: Up to 921Kb/Sec (HYPER Terminal program)

Parallel Port:

Parallel Chipset: SUN1689, Hardware FIFO is 32Byte FIFO

Compatible chips: with ACC3203, ST-78C36, and HT6535.

IEEE standard: ECP/EPP/SPP/BPP (PS-II) Interface

Max. Speed: Up to 2MB/Sec

Hardware Installation

Turn off the power of your computer

( Plug the 70586 Serial adapter into the PCI bus of your computer

( Connect the peripheral Printer, Modem, Scanner…etc.) to this adapter

( Turn on the power of your computer

PCI device listing display (for example…)

Bus No Device No Func No Vendor ID Device ID Device Class IRQ

0 7 1 8086 7010 IDE Controller 14

0 13 0 1409 7168 Simple COMM.

Controller

žPAGE −3

When Vendor ID, Device ID, Device Class or IRQ aren’t displayed or an error occurs,

please change the PCI slot.

After correct hardware installation you can start installing the software from the driver

CD.

Pin Assignments

Parallel 25 Pin female connector pin assignments:

Parallel 25 Pin female connector :

Pin Signal Pin Signal Pin Signal

1 STROBE 10 ACKNOWLEDGE 19 GROUND

2 DATA 0 11 BUSY 20 GROUND

3 DATA 1 12 PAPER EMPTY 21 GROUND

4 DATA 2 13 SELECT 22 GROUND

5 DATA 3 14 AUTO FEED 23 GROUND

6 DATA 4 15 ERROR 24 GROUND

7 DATA 5 16 INIT 25 GROUND

8 DATA 6 17 SELECT INPUT 26 GROUND

9 DATA 7 18 GROUND

Serial 9 Pin male connector pin assignments:

Serial 9 Pin male connector :

Pin Signal Pin Signal Pin Signal Pin Signal

1 CD 4 DTR 6 DSR 8 CTS

2 RD 5 GROUND 7 RTS 9 RI

3 TD

Technical Specification

Compatibility: PCI 32Bit card for 486/586/Pentium/Pentium-II/

P-III/C5/K6

Operating system: WIN 9.x/ME/NT/2000/XP, LINUX, DOS

Chips: 1 x SUN1889, 1 x SUN1689

Connections: 2 x DB 9 m connector serial

1xDB25Bfconnectorparallel

PCB: 2 Layer / 120 x 76 mm

žPAGE −4

This device complies with Part 15 of the FCC

Rules. Operation is subject to the following two

conditions: (1) this device may not cause

harmful interference, and (2) this device must

accept any interference received, including

interference that may cause undesired

operations.
